Tencent cloud international ECS has no network after logging in. How to troubleshoot?

If there is no network access after logging in to ECS （ For example, the web page cannot be accessed ）, May be DNS Configuration problems . You can refer to the following operations , take DNS Set to auto get , We'll talk to you next 87cloud Let's learn that there is no network after Tencent cloud international ECS logs in , How to check ？

To Windows Server 2012 For example .

1. Sign in Windows Cloud server .
2. In the operating system interface , single click



   , choice 【 Control panel 】>【 The Internet and Internet】>【 View network status and tasks 】>【 Change adapter settings 】.
3. Right click 【 Ethernet 】, choice 【 attribute 】, open “ Ethernet attribute ” window .
4. stay “ Ethernet attribute ” window , Double-click to open 【Internet Protocol version 4 (TCP/IPv4)】 Properties window .
5. stay “Internet Protocol version 4 (TCP/IPv4) attribute ” Window , choice 【 Automatically get IP Address 】 and 【 Automatically get DNS Server address 】, single click 【 determine 】. As shown in the figure below ：



Whether the private network instance can interoperate with the basic network instance ？

Support , But there are the following limitations ：

The network segment range of the private network （CIDR） It has to be for 10.0.0.0/16 ~ 10.0.47.0/16（ Including subsets ）, Otherwise, there will be conflicts .

Setup steps ：

Sign in Private network console , Click... On the private network ID/ name , Go to the private network details page , stay Basic network interworking Configure at , Associate the basic network hosts that need to be interconnected .

How to view the basic network ECS interworking with the private network ？

Sign in Private network console , Click... On the private network ID/ name , Go to the private network details page , stay Basic network interworking You can view the basic network ECS interworking with the private network ECS at .

Whether the ECS can be replaced to an overseas network ？

The ECS cannot change the network after purchase , If you need an overseas network , It is recommended to return the ECS , Re purchase overseas servers .

Intranet DNS How to configure ？

Please refer to Intranet DNS.

Local in the same network segment VPN You can get the network segment IP But no internet access , How to solve ？

Please check whether the following configurations are correct ：

1. Manually added IP Whether or not it is the same as that automatically obtained IP In the same IP subnet , Whether the subnet mask is consistent , Whether to configure the default gateway , Is the default gateway address correct ？
2. Whether to configure DNS,DNS Is the address correct ？
3. If the above information is correct , Please confirm the static configuration IP Does the address exist IP Address conflict .

If the above methods cannot solve the problem , please Submit work order   Contact us .

How to integrate A Account number and B The ECS under the account is added to the same intranet ？

The network between accounts is not interconnected by default , To realize network interworking between accounts , Available for purchase Peer to peer connection   perhaps Cloud networking   service .
