[stm32f130rct6] idea and code of ultrasonic ranging module

Catalog

【 Hardware description 】

【 Theoretical explanation 】

【 software design 】

Timer initialization

Ultrasonic ranging function

Timer interrupt function

The main function

---

【 Hardware description 】

        STM32F103 Kernel development board , Ultrasonic module HC-SR04

  chart 1 HC-SR04 Physical drawing of ultrasonic module

【 Theoretical explanation 】

The ultrasonic module used in the process is HC-SR04 modular . There are four pins , Namely Echo、Trig、VCC、GND.Trig Trigger end ： It is to trigger the pin of ultrasonic ranging ;Echo Receiving signal end ： The ultrasonic returns to a high level , And we calculate the distance through the duration of high level .

Ultrasonic principle ：(1) use IO Trigger ranging , At least give 10us High level signal ;(2) Automatic module sending 8 individual 40khz The square wave , Automatically detects if a signal is returned ;(3) Return with signal , adopt IO Output a high level , The duration of the high level is the time from the ultrasonic wave is emitted to the time it returns .

The test distance = ( High level time * The speed of sound (340 M/S ) ) / 2

   chart 2 HC-SR04 Ultrasonic sequence diagram

【 software design 】

Timer initialization

This use TIM3、TIM5 To be responsible for data acquisition of ultrasonic module . Before the program enters while Before the cycle , Need to be right TIM3、TIM5 To initialize , Because the configuration of the two timers are similar , So just show one .

/**************************************************************************
 The functionality ： Timer 5 Channel input capture initialization
 Entrance parameters ： Entrance parameters ：arr： Auto reload value   psc： Clock presplitting frequency
 return    value ： nothing
**************************************************************************/
void TIM5_Cap_Init(u16 arr, u16 psc)
{
	GPIO_InitTypeDef GPIO_InitStructure;
	TIM_TimeBaseInitTypeDef TIM_TimeBaseStructure;
	TIM_ICInitTypeDef TIM_ICInitStructure;
	NVIC_InitTypeDef NVIC_InitStructure;
	RCC_APB1PeriphClockCmd(RCC_APB1Periph_TIM5, ENABLE);
    // Can make TIM5 The clock
	RCC_APB2PeriphClockCmd(RCC_APB2Periph_GPIOA | RCC_APB2Periph_GPIOB |
    RCC_APB2Periph_GPIOC, ENABLE); // Can make GPIO The clock

	GPIO_InitStructure.GPIO_Pin = GPIO_Pin_0 | GPIO_Pin_1 | GPIO_Pin_2 | GPIO_Pin_3;
	GPIO_InitStructure.GPIO_Mode = GPIO_Mode_IPD; //PA   Input
	GPIO_Init(GPIOA, &GPIO_InitStructure);

	GPIO_InitStructure.GPIO_Pin = GPIO_Pin_4 | GPIO_Pin_11;
	GPIO_InitStructure.GPIO_Mode = GPIO_Mode_Out_PP; // Output
	GPIO_InitStructure.GPIO_Speed = GPIO_Speed_2MHz; //2M
	GPIO_Init(GPIOA, &GPIO_InitStructure);

	GPIO_InitStructure.GPIO_Pin = GPIO_Pin_12;
	GPIO_InitStructure.GPIO_Mode = GPIO_Mode_Out_PP; // Output
	GPIO_InitStructure.GPIO_Speed = GPIO_Speed_2MHz; //2M
	GPIO_Init(GPIOB, &GPIO_InitStructure);

	GPIO_InitStructure.GPIO_Pin = GPIO_Pin_5;
	GPIO_InitStructure.GPIO_Mode = GPIO_Mode_Out_PP; // Output
	GPIO_InitStructure.GPIO_Speed = GPIO_Speed_2MHz; //2M
	GPIO_Init(GPIOC, &GPIO_InitStructure);

	// Initialize the timer 5
	TIM_TimeBaseStructure.TIM_Period = arr;					// Set the counter to automatically reload
	TIM_TimeBaseStructure.TIM_Prescaler = psc;				// Preassigned frequency counter
	TIM_TimeBaseStructure.TIM_ClockDivision = TIM_CKD_DIV1;	// Set the clock split :TDTS = Tck_tim
	TIM_TimeBaseStructure.TIM_CounterMode = TIM_CounterMode_Up; //TIM Upcount mode
	TIM_TimeBaseInit(TIM5, &TIM_TimeBaseStructure);	// according to TIM_TimeBaseInitStruct The parameter specified in TIMx Unit of time base

	// initialization TIM5 Input capture parameter
	TIM_ICInitStructure.TIM_Channel = TIM_Channel_1;			// Select input
	TIM_ICInitStructure.TIM_ICPolarity = TIM_ICPolarity_Rising; // Rising edge capture
	TIM_ICInitStructure.TIM_ICSelection = TIM_ICSelection_DirectTI;
	TIM_ICInitStructure.TIM_ICPrescaler = TIM_ICPSC_DIV1; // Configure the input divider , Regardless of the frequency
	TIM_ICInitStructure.TIM_ICFilter = 0x00;			  // Configure input filter   Don't filter
	TIM_ICInit(TIM5, &TIM_ICInitStructure);

	// initialization TIM5 Input capture parameter
	TIM_ICInitStructure.TIM_Channel = TIM_Channel_2;			// Select input
	TIM_ICInitStructure.TIM_ICPolarity = TIM_ICPolarity_Rising; // Rising edge capture
	TIM_ICInitStructure.TIM_ICSelection = TIM_ICSelection_DirectTI;
	TIM_ICInitStructure.TIM_ICPrescaler = TIM_ICPSC_DIV1; // Configure the input divider , Regardless of the frequency
	TIM_ICInitStructure.TIM_ICFilter = 0x00;			  // Configure input filter   Don't filter
	TIM_ICInit(TIM5, &TIM_ICInitStructure);

	// initialization TIM5 Input capture parameter
	TIM_ICInitStructure.TIM_Channel = TIM_Channel_3;			// Select input
	TIM_ICInitStructure.TIM_ICPolarity = TIM_ICPolarity_Rising; // Rising edge capture
	TIM_ICInitStructure.TIM_ICSelection = TIM_ICSelection_DirectTI;
	TIM_ICInitStructure.TIM_ICPrescaler = TIM_ICPSC_DIV1; // Configure the input divider , Regardless of the frequency
	TIM_ICInitStructure.TIM_ICFilter = 0x00;			  // Configure input filter   Don't filter
	TIM_ICInit(TIM5, &TIM_ICInitStructure);

	// initialization TIM5 Input capture parameter
	TIM_ICInitStructure.TIM_Channel = TIM_Channel_4;			// Select input
	TIM_ICInitStructure.TIM_ICPolarity = TIM_ICPolarity_Rising; // Rising edge capture
	TIM_ICInitStructure.TIM_ICSelection = TIM_ICSelection_DirectTI;
	TIM_ICInitStructure.TIM_ICPrescaler = TIM_ICPSC_DIV1; // Configure the input divider , Regardless of the frequency
	TIM_ICInitStructure.TIM_ICFilter = 0x00;			  // Configure input filter   Don't filter
	TIM_ICInit(TIM5, &TIM_ICInitStructure);

	// Interrupt group initialization
	NVIC_InitStructure.NVIC_IRQChannel = TIM5_IRQn;
     //TIM interrupt
	NVIC_InitStructure.NVIC_IRQChannelPreemptionPriority = 0;
    // Take precedence 0 level
	NVIC_InitStructure.NVIC_IRQChannelSubPriority = 2;
    // From the priority 2 level
	NVIC_InitStructure.NVIC_IRQChannelCmd = ENABLE;
    //IRQ The channel is energized
	NVIC_Init(&NVIC_InitStructure);
    // according to NVIC_InitStruct The parameter specified in NVIC register
	TIM_ITConfig(TIM5, TIM_IT_Update | TIM_IT_CC1 | TIM_IT_CC2 | TIM_IT_CC3 | TIM_IT_CC4, ENABLE); // Allow update interrupt  , Allow capture interrupt
	TIM_Cmd(TIM5, ENABLE);		// Enable timer
}

Ultrasonic ranging function

The program here only shows timers 5 Channel 1

u16 TIM5CH1_CAPTURE_STA, TIM5CH1_CAPTURE_VAL, TIM5CH2_CAPTURE_STA, TIM5CH2_CAPTURE_VAL;
u16 TIM5CH3_CAPTURE_STA, TIM5CH3_CAPTURE_VAL, TIM5CH4_CAPTURE_STA, TIM5CH4_CAPTURE_VAL;
u16 TIM3CH1_CAPTURE_STA, TIM3CH1_CAPTURE_VAL, TIM3CH2_CAPTURE_STA, TIM3CH2_CAPTURE_VAL;
u16 TIM3CH3_CAPTURE_STA, TIM3CH3_CAPTURE_VAL, TIM3CH4_CAPTURE_STA, TIM3CH4_CAPTURE_VAL;
/**************************************************************************
 The functionality ： Ultrasonic receiving echo function
 Entrance parameters ： nothing
 return    value ： nothing
**************************************************************************/
void Read_Distane(void)
{
	TRIPA = 1;						// High level trigger
	delay_us(15);					// Time delay
	TRIPA = 0;						// Low level
	if (TIM5CH1_CAPTURE_STA & 0X80) // Successfully captured a high level
	{
		Distance_A = TIM5CH1_CAPTURE_STA & 0X3F;
		Distance_A *= 65536;				  // Total overflow time
		Distance_A += TIM5CH1_CAPTURE_VAL;	  // Get the total high level time
		Distance_A = Distance_A * 170 / 1000; // Turn it into mm In units of , According to the speed of sound propagation in the air 340m/s
		TIM5CH1_CAPTURE_STA = 0;			  // Enable the next capture
	}

	TRIPB = 1;						// High level trigger
	delay_us(15);					// Time delay
	TRIPB = 0;						// Low level
	if (TIM5CH2_CAPTURE_STA & 0X80) // Successfully captured a high level
	{
		Distance_B = TIM5CH2_CAPTURE_STA & 0X3F;
		Distance_B *= 65536;				  // Total overflow time
		Distance_B += TIM5CH2_CAPTURE_VAL;	  // Get the total high level time
		Distance_B = Distance_B * 170 / 1000; // Turn it into mm In units of , According to the speed of sound propagation in the air 340m/s
		TIM5CH2_CAPTURE_STA = 0;			  // Enable the next capture
	}

	TRIPC = 1;						// High level trigger
	delay_us(15);					// Time delay
	TRIPC = 0;						// Low level
	if (TIM5CH3_CAPTURE_STA & 0X80) // Successfully captured a high level
	{
		Distance_C = TIM5CH3_CAPTURE_STA & 0X3F;
		Distance_C *= 65536;				  // Total overflow time
		Distance_C += TIM5CH3_CAPTURE_VAL;	  // Get the total high level time
		Distance_C = Distance_C * 170 / 1000; // Turn it into mm In units of , According to the speed of sound propagation in the air 340m/s
		TIM5CH3_CAPTURE_STA = 0;			  // Enable the next capture
	}

	TRIPD = 1;						// High level trigger
	delay_us(15);					// Time delay
	TRIPD = 0;						// Low level
	if (TIM5CH4_CAPTURE_STA & 0X80) // Successfully captured a high level
	{
		Distance_D = TIM5CH4_CAPTURE_STA & 0X3F;
		Distance_D *= 65536;				  // Total overflow time
		Distance_D += TIM5CH4_CAPTURE_VAL;	  // Get the total high level time
		Distance_D = Distance_D * 170 / 1000; // Turn it into mm In units of , According to the speed of sound propagation in the air 340m/s
		TIM5CH4_CAPTURE_STA = 0;			  // Enable the next capture
	}
}

Timer interrupt function

/**************************************************************************
 The functionality ： Ultrasonic echo pulse width reading interrupt
 Entrance parameters ： nothing
 return    value ： nothing
**************************************************************************/
void TIM5_IRQHandler(void)
{
	u16 tsr;
	tsr = TIM5->SR;
	/ Channel 1 ///
	if ((TIM5CH1_CAPTURE_STA & 0X80) == 0) // It has not been successfully captured
	{
		if (tsr & 0X01) // overflow
		{
			if (TIM5CH1_CAPTURE_STA & 0X40) // The high level has been captured
			{
				if ((TIM5CH1_CAPTURE_STA & 0X3F) == 0X3F) // The high level is too long
				{
					TIM5CH1_CAPTURE_STA |= 0X80; // The tag was successfully captured once
					TIM5CH1_CAPTURE_VAL = 0XFFFF;
				}
				else
					TIM5CH1_CAPTURE_STA++;
			}
		}
		if (tsr & 0x02) // Capture 1 Capture event
		{
			if (TIM5CH1_CAPTURE_STA & 0X40) // Capture a drop edge
			{
				TIM5CH1_CAPTURE_STA |= 0X80;	  // Mark successfully captures a high level pulse width
				TIM5CH1_CAPTURE_VAL = TIM5->CCR1; // Get the current capture value .
				TIM5->CCER &= ~(1 << 1);		  //CC1P=0  Set to rising edge capture
			}
			else // Has not yet started , The first time to capture the rising edge
			{
				TIM5CH1_CAPTURE_STA = 0; // Empty
				TIM5CH1_CAPTURE_VAL = 0;
				TIM5CH1_CAPTURE_STA |= 0X40; // The tag captures the rising edge
				TIM5->CNT = 0;				 // The counter is cleared
				TIM5->CCER |= 1 << 1;		 //CC1P=1  Set to drop edge capture
			}
		}
	}
	/ Channel 2 ///
	if ((TIM5CH2_CAPTURE_STA & 0X80) == 0) // It has not been successfully captured
	{
		if (tsr & 0X01) // overflow
		{
			if (TIM5CH2_CAPTURE_STA & 0X40) // The high level has been captured
			{
				if ((TIM5CH2_CAPTURE_STA & 0X3F) == 0X3F) // The high level is too long
				{
					TIM5CH2_CAPTURE_STA |= 0X80; // The tag was successfully captured once
					TIM5CH2_CAPTURE_VAL = 0XFFFF;
				}
				else
					TIM5CH2_CAPTURE_STA++;
			}
		}
		if (tsr & 0x04) // Capture 2 Capture event
		{
			if (TIM5CH2_CAPTURE_STA & 0X40) // Capture a drop edge
			{
				TIM5CH2_CAPTURE_STA |= 0X80;	  // Mark successfully captures a high level pulse width
				TIM5CH2_CAPTURE_VAL = TIM5->CCR2; // Get the current capture value .
				TIM5->CCER &= ~(1 << 5);		  //CC1P=0  Set to rising edge capture
			}
			else // Has not yet started , The first time to capture the rising edge
			{
				TIM5CH2_CAPTURE_STA = 0; // Empty
				TIM5CH2_CAPTURE_VAL = 0;
				TIM5CH2_CAPTURE_STA |= 0X40; // The tag captures the rising edge
				TIM5->CNT = 0;				 // The counter is cleared
				TIM5->CCER |= 1 << 5;		 //CC1P=1  Set to drop edge capture
			}
		}
	}
	/ Channel III ///
	if ((TIM5CH3_CAPTURE_STA & 0X80) == 0) // It has not been successfully captured
	{
		if (tsr & 0X01) // overflow
		{
			if (TIM5CH3_CAPTURE_STA & 0X40) // The high level has been captured
			{
				if ((TIM5CH3_CAPTURE_STA & 0X3F) == 0X3F) // The high level is too long
				{
					TIM5CH3_CAPTURE_STA |= 0X80; // The tag was successfully captured once
					TIM5CH3_CAPTURE_VAL = 0XFFFF;
				}
				else
					TIM5CH3_CAPTURE_STA++;
			}
		}
		if (tsr & 0x08) // Capture 3 Capture event
		{
			if (TIM5CH3_CAPTURE_STA & 0X40) // Capture a drop edge
			{
				TIM5CH3_CAPTURE_STA |= 0X80;	  // Mark successfully captures a high level pulse width
				TIM5CH3_CAPTURE_VAL = TIM5->CCR3; // Get the current capture value .
				TIM5->CCER &= ~(1 << 9);		  //CC1P=0  Set to rising edge capture
			}
			else // Has not yet started , The first time to capture the rising edge
			{
				TIM5CH3_CAPTURE_STA = 0; // Empty
				TIM5CH3_CAPTURE_VAL = 0;
				TIM5CH3_CAPTURE_STA |= 0X40; // The tag captures the rising edge
				TIM5->CNT = 0;				 // The counter is cleared
				TIM5->CCER |= 1 << 9;		 //CC1P=1  Set to drop edge capture
			}
		}
	}
	/ Channel 4 ///
	if ((TIM5CH4_CAPTURE_STA & 0X80) == 0) // It has not been successfully captured
	{
		if (tsr & 0X01) // overflow
		{
			if (TIM5CH4_CAPTURE_STA & 0X40) // The high level has been captured
			{
				if ((TIM5CH4_CAPTURE_STA & 0X3F) == 0X3F) // The high level is too long
				{
					TIM5CH4_CAPTURE_STA |= 0X80; // The tag was successfully captured once
					TIM5CH4_CAPTURE_VAL = 0XFFFF;
				}
				else
					TIM5CH4_CAPTURE_STA++;
			}
		}
		if (tsr & 0x10) // Capture 4 Capture event
		{
			if (TIM5CH4_CAPTURE_STA & 0X40) // Capture a drop edge
			{
				TIM5CH4_CAPTURE_STA |= 0X80;	  // Mark successfully captures a high level pulse width
				TIM5CH4_CAPTURE_VAL = TIM5->CCR4; // Get the current capture value .
				TIM5->CCER &= ~(1 << 13);		  //CC1P=0  Set to rising edge capture
			}
			else // Has not yet started , The first time to capture the rising edge
			{
				TIM5CH4_CAPTURE_STA = 0; // Empty
				TIM5CH4_CAPTURE_VAL = 0;
				TIM5CH4_CAPTURE_STA |= 0X40; // The tag captures the rising edge
				TIM5->CNT = 0;				 // The counter is cleared
				TIM5->CCER |= 1 << 13;		 //CC1P=1  Set to drop edge capture
			}
		}
	}
	TIM5->SR = 0; // Clears the interrupt flag bit
}

The main function

int main(void)
{
	delay_init();					// Delay function initialization
	MY_NVIC_PriorityGroupConfig(2); // Set interrupt grouping
	JTAG_Set(SWD_ENABLE);			// open SWD Interface   You can use the of the motherboard SWD Interface debugging

	QuDong_Init();					  // Initialize the drive port
	uart_init(115200);				  // A serial port 1 initialization
	CAN_Config();					  // initialization can, In interrupt reception CAN Data packets */
	MiniBalance_PWM_Init(3599, 0);	  //PWM The highest frequency  20K
	TIM2_Cap_Init(0XFFFF, 72 - 1);	  // Timer 2  Input capture   Open the channel  TIM2_CH3 TIM2_CH4
	TIM6_Int_Init(100 - 1, 7200 - 1); // Timer 6 initialization  10ms interrupt
	TIM5_Cap_Init(0XFFFF, 72 - 1);	  // Ultrasonic wave begins to melt   Default comment   Ultrasonic wiring   Reference resources timer.h file
	TIM3_Cap_Init(0XFFFF, 72 - 1);	  // Ultrasonic wave begins to melt   Default comment   Ultrasonic wiring   Reference resources timer.h file

	printf(" Start ！\r\n");

	v_mc = (int)get_mc(0.2); // Enter the speed value   Pulse frequency corresponding to conversion bit
	L = 6.0;

	/***  Hardware adaptation  ***/
	TIM_SetCompare1(TIM4, 0);
	TIM_SetCompare2(TIM4, 0);
	delay_ms(250);

	while (1)
	{
		TIM_SetCompare1(TIM4, sv_L);
		TIM_SetCompare2(TIM4, sv_R * 1.013);

		if (TIM2_CH3Structure.Capture_FinishFlag == 1)
		{
			printf("Frequency_L = %d Hz    ", TIM2_CH3Structure.value);
			printf("V_L = %f M/s\r\n", get_v(TIM2_CH3Structure.value));
			TIM2_CH3Structure.Capture_FinishFlag = 0;
		}
		if (TIM2_CH4Structure.Capture_FinishFlag == 1)
		{
			printf("Frequency_R = %d Hz    ", TIM2_CH4Structure.value);
			printf("V_R = %f M/s\r\n", get_v(TIM2_CH4Structure.value));
			TIM2_CH4Structure.Capture_FinishFlag = 0;
		}
		else
		{
			printf("Wave is not exist or Cature is incomplete.\n");
		}

		A = Distance_A; //y
		C = Distance_C; //*y
		D = Distance_D; //y
		c = Distance_c; //*y
		B = Distance_B; //*y
		a = Distance_a; //*n
		b = Distance_b; //y
		d = Distance_d; //y
		printf(" Away from the front ：%d    ", b);
		printf(" Distance to the rear ：%d    ", C);
		printf(" Distance left ：%d    ", B);
		printf(" To the right ：%d\r\n", c);
		delay_ms(1000);
	}
}

void TIM6_IRQHandler(void) // TIM6 10ms interrupt
{

	if (TIM_GetITStatus(TIM6, TIM_IT_Update) != RESET) //  Check the specified TIM6 Whether the interruption occurs or not
	{
		// Ultrasonic ranging & Avoiding obstacles
		Read_Distane();
		Read_Distane2();
		if (b < 600)
		{
			GPIO_ResetBits(GPIOC, GPIO_Pin_1 | GPIO_Pin_0); // Lower the brake
		}
		else
		{
			GPIO_SetBits(GPIOC, GPIO_Pin_1 | GPIO_Pin_0);
			if (TIM2_CH3Structure.value <= v_mc)
			{
				sv_L = (int)(float)(Velocity_PI(TIM2_CH3Structure.value, v_mc) / -20000.0 * 3600.0);
			}
			if (TIM2_CH4Structure.value <= v_mc)
			{
				sv_R = (int)(float)(Velocity_PI(TIM2_CH4Structure.value, v_mc) / -20000.0 * 3600.0);
			}
		}
	}

	TIM_ClearITPendingBit(TIM6, TIM_IT_Update); // eliminate TIM6 Interrupt pending bit of
}

Here we are , The basic ideas and procedures of the ultrasonic module have been listed .

I'm a rookie , Everyone's encouragement is the driving force for me to continue to create , If you think it's good , Welcome to your attention , give the thumbs-up , Collection , forward , thank you ！
