Ice 100g network card fragment message hash problem

Problem description

stay x710 hash Partition and non partition tcp Message exception problem In this article , I described it x710 Network card at the same time hash The problem of fragmented and non fragmented messages .

In the actual application scenario , Packets in the same stream will generally be hash To the same queue , Business programs process messages of the same stream in the same queue .

When a stream contains both fragmented and non fragmented messages , Because there is a difference between segmented message and non segmented message quintuple , When configured hash When the rules are incorrect , These messages belonging to the same stream may be sent by the network card hash To different queues , At this point, the business program will generate exceptions .

Actual test findings , Our business processes use E810 The above problems exist in the network card , This article will describe this problem .

dpdk Version is ：dpdk-20.11

Past successful experience

Have dealt with x710 Similar problems of network card , The problem is described as follows ：

When configuring the ETH_RSS_FRAG_IPV4 And ETH_RSS_NONFRAG_IPV4_TCPhash After the type , Some connected fragment messages Because there is no L4 port number Will be hash To other queues .

When not configured ETH_RSS_NONFRAG_IPV4_TCP when ,ETH_RSS_FRAG_IPV4 The hash process will not be applied to non fragmented messages , These messages will be delivered to the queue 0.

resolvent ： Modify NIC rss-hash Configure non sharding tcp Messages only use L3 Head on hash,x710 adopt fdir To configure .

Based on the above information , Need configuration E810 The network card is not partitioned tcp Messages only use L3 Head on hash, How to configure it ？

ice E810 100G network card hash Configuration information

Our business processes use ETH_RSS_IP | ETH_RSS_TCP | ETH_RSS_UDPhash To configure , Related macros are defined as follows ：

#define ETH_RSS_IP ( \\
	ETH_RSS_IPV4 | \\
	ETH_RSS_FRAG_IPV4 | \\
	ETH_RSS_NONFRAG_IPV4_OTHER | \\
	ETH_RSS_IPV6 | \\
	ETH_RSS_FRAG_IPV6 | \\
	ETH_RSS_NONFRAG_IPV6_OTHER | \\
	ETH_RSS_IPV6_EX)

#define ETH_RSS_UDP ( \\
	ETH_RSS_NONFRAG_IPV4_UDP | \\
	ETH_RSS_NONFRAG_IPV6_UDP | \\
	ETH_RSS_IPV6_UDP_EX)

#define ETH_RSS_TCP ( \\
	ETH_RSS_NONFRAG_IPV4_TCP | \\
	ETH_RSS_NONFRAG_IPV6_TCP | \\
	ETH_RSS_IPV6_TCP_EX)

The meaning of the above configuration is... Using messages ip Head and head tcp head 、udp The content of the header hash, Fragment message and non fragment message hash The rules are the same ,E810 There will be problems described above when handling the network card .

dpdk in ice E810 Network card configuration rss hash The process of configuration

Function call diagram ：

ice_init_rss Function USES dev->data->dev_conf.rx_adv_conf.rss_conf Configure as parameter call ice_rss_hash_set Function completion hash The configuration process . The relevant code is as follows ：

rss_conf = &dev->data->dev_conf.rx_adv_conf.rss_conf
...........

/* RSS hash configuration */
ice_rss_hash_set(pf, rss_conf->rss_hf);

ice_rss_hash_set Function is the real configuration rss hash Function of , The key code is as follows ：

....................................................................
/* Configure RSS for tcp4 with src/dst addr and port as input set */
	if (rss_hf & ETH_RSS_NONFRAG_IPV4_TCP) {

		cfg.addl_hdrs = ICE_FLOW_SEG_HDR_TCP | ICE_FLOW_SEG_HDR_IPV4 |
				ICE_FLOW_SEG_HDR_IPV_OTHER;
		cfg.hash_flds = ICE_HASH_TCP_IPV4;
		ret = ice_add_rss_cfg_wrap(pf, vsi->idx, &cfg);
		if (ret)
			PMD_DRV_LOG(ERR, "%s TCP_IPV4 rss flow fail %d",
				    __func__, ret);
	}

	/* Configure RSS for tcp6 with src/dst addr and port as input set */
	if (rss_hf & ETH_RSS_NONFRAG_IPV6_TCP) {

		cfg.addl_hdrs = ICE_FLOW_SEG_HDR_TCP | ICE_FLOW_SEG_HDR_IPV6 |
				ICE_FLOW_SEG_HDR_IPV_OTHER;
		cfg.hash_flds = ICE_HASH_TCP_IPV6;
		ret = ice_add_rss_cfg_wrap(pf, vsi->idx, &cfg);
		if (ret)
			PMD_DRV_LOG(ERR, "%s TCP_IPV6 rss flow fail %d",
				    __func__, ret);
	}

The above code will not be fragmented IPv4_TCP The message hash Field set to TCP header + ipv4 header + Other IP Package type field ; Non segmented IPV6_TCP The message hash Field set to TCP header + ipv6 header + Other IP Package type field .

Obviously, you can directly modify the above code to customize non sharding tcp The message hash To configure , But this kind of modification is a little too rough , A better way is to modify rss_hf The value of is ETH_RSS_IPV4 | ETH_RSS_IPV6, In this configuration E810 The network card only uses 3 Layer head hash, There is no such problem of fragmentation and non fragmentation .

Quickly modify dpdk Medium ice_rss_hash_set function , Let the message only pass L3 I want to know more about it hash To test , modify patch as follows ：

Index: drivers/net/ice/ice_ethdev.c
===================================================================
--- drivers/net/ice/ice_ethdev.c
+++ drivers/net/ice/ice_ethdev.c
@@ -2795,6 +2795,8 @@
        ETH_RSS_NONFRAG_IPV6_TCP | \\
        ETH_RSS_NONFRAG_IPV4_SCTP | \\
        ETH_RSS_NONFRAG_IPV6_SCTP)
+
+       rss_hf = ETH_RSS_IPV4 |  ETH_RSS_IPV6

Test verification passed , Final adoption of amendment rte_eth_dev_configure Passed in function dev_conf Medium rss_hf Configure to ETH_RSS_IPV4 | ETH_RSS_IPV6 To fix this problem .

from E810 Problems found in driver implementation

Writing here, I found that it's actually divided tcp Messages are ordinary ip message , Do it hash Is in accordance with the IP The information of the head , Not divided TCP The message only carries TCP Head , Use different fields for these two different types of packages hash,hash It is normal to go to different queues , The exceptions here may only exist in our usage scenarios .
