Analyze the implementation principle of the onion model, and connect the onion model in your own project

Analyze the implementation principle of onion model , Connect the onion model in your own project

Last article First acquaintance with onion model , Analyze the middleware execution process , elementary analysis koa Middleware source A brief introduction to be based on koa The running process of the onion model middleware , I learned how to write middleware

But based on koa The onion model of can only be triggered when a request is made . In our usual projects , How to use the onion model ？

Simple analysis koa Code

koajs/koa The code analysis ：

Look for the koa Entrance file

adopt package.json In the document “main” Field found , The entry file is in lib/application.js

see application The execution process in

open application.js see
There are several familiar methods

• listen Method

koa The source code section ：

listen (...args) {

  debug('listen')
  const server = http.createServer(this.callback())
  return server.listen(...args)
}

In the actual project , We call listen Usually

app.listen('3000', function() {

  console.log(' Listening created successfully ')
})

Plug in koa Source code , You can see that at the beginning http.createServer Created a service
Then we introduced 3000 and Monitor successful The callback functions of are actually passed to server Of

http.createServer The callback function received here deals with the contents when the request is triggered

node-api file :http_createserver_options_requestlistener

Extra knowledge
stay http.createServer The callback function passed in and server.on(‘request’) It's the same effect

So when a request comes in , Execution is this.callback() Method

• callback Method

// compose  From the introduction of  koa-compose
// const compose = require('koa-compose')

callback () {

  const fn = compose(this.middleware)

  if (!this.listenerCount('error')) this.on('error', this.onerror)

  const handleRequest = (req, res) => {

    const ctx = this.createContext(req, res)
    return this.handleRequest(ctx, fn)
  }

  return handleRequest
}

1. fn It's from compose(this.middleware) Got , Among them this.middleware Is an array of functions , I'll talk about it later

2. listenerCount The method should be Application Inherit Emitter The method in , For the time being, I will not go into further study

3. What is called according to the above code is this.callback(), Back to you handleRequest Function

handleRequest in , Created ctx , This is for koa Customize the context of a response

because http.createServer In the callback function of 2 Return values , Namely req,res. therefore express Just take this 2 Parameters are returned directly to use , and koa It is an extra layer

4. Get ctx after , It's in handleRequest part

• handleRequest Method

handleRequest (ctx, fnMiddleware) {

  const res = ctx.res
  res.statusCode = 404
  const onerror = err => ctx.onerror(err)
  const handleResponse = () => respond(ctx)
  onFinished(res, onerror)
  return fnMiddleware(ctx).then(handleResponse).catch(onerror)
}

1. In this part, let's start with statusCode Defined as 404（ By default, there is no method to handle ）, If there is a response, it will be converted to the corresponding status code
2. handleResponse It was introduced from above fn Respond once after execution , In the end, it will trigger req.end() Method , Respond to the content
3. onFinished It's from on-finished A library introduced . Used to listen for the end of a response , If the response is wrong , Just execute the corresponding onerror, This should be introduced to listen for errors in requests

• analysis fnMiddleware source

from this.callback We can know fnMiddleware = compose(this.middleware)

among compose yes koa-compose

and this.middleware It is an empty array when initializing , stay use In the method push Go in content , be familiar with koa Of all know , use The method is to mount the middleware

also use The function is very simple , Simple judgment fn Whether a function , And then push go in , Waiting to be passed to compose

use (fn) {

  if (typeof fn !== 'function') throw new TypeError('middleware must be a function!')
  debug('use %s', fn._name || fn.name || '-')
  this.middleware.push(fn)
  return this
}

application Summary of rough analysis

1. listen Method to create a listener
   1.1 Use http.createServer(this.callback()) To create a response to a request
2. stay callback Function , Called compose(this.middleware) To get an executable function fnMiddleware
3. stay handleRequest Function , Added error listening , Mainly call fnMiddleware function , After success, the corresponding value is returned to complete the response
4. this.middleware From use function , Added middleware , therefore this.middleware It is a list of middleware , So the execution of middleware is in order

koa-compose analysis

original koa The middleware logic of is koajs/compose In this library , and koa Just called this library

According to the old rules , see package.json file , Found that there was no main Entry field of , Back to the root directory, I found that there is only one library index.js Core documents

Onion model all code ~

I have to sigh that the code written by the great God is always so simple but one by one

'use strict'

/** * Expose compositor. */

module.exports = compose

/** * Compose `middleware` returning * a fully valid middleware comprised * of all those which are passed. * * @param {Array} middleware * @return {Function} * @api public */

function compose(middleware) {

  if (!Array.isArray(middleware)) throw new TypeError('Middleware stack must be an array!')
  for (const fn of middleware) {

    if (typeof fn !== 'function') throw new TypeError('Middleware must be composed of functions!')
  }

  /** * @param {Object} context * @return {Promise} * @api public */

  return function(context, next) {

    // last called middleware #
    let index = -1
    return dispatch(0)
    function dispatch(i) {

      if (i <= index) return Promise.reject(new Error('next() called multiple times'))
      index = i
      let fn = middleware[i]
      if (i === middleware.length) fn = next
      if (!fn) return Promise.resolve()
      try {

        return Promise.resolve(fn(context, dispatch.bind(null, i + 1)))
      } catch (err) {

        return Promise.reject(err)
      }
    }
  }
}

To put it simply, the results of my analysis ：

1. establish compose, Pass in array , then compose It returns a function （ That's where we are koa See in the source code fnMiddleware）, At this time, the execution sequence of this batch of middleware has been determined

2. When executed fn When , It's like a Recursive function , However, it is implemented through callback function
   The code is very clean , Is to define a dispatch Method , then return dispatch(0)
   When executed dispatch When ,0 Actually, as an index , Get the corresponding methods in the array in order fn = middleware[i]

3. Let's start with the recursive function
   fn(context, dispatch.bind(null, i + 1))
   Which translates as fn_0(context,fn_1) When the current function of the middleware is executed , The next function is also mentioned , call next It's called fn_1, If you don't call next That's right fn_0 After execution , The program will continue to go up , That's why you don't call next The next middleware will not execute
   As for the beginning koa Support asymc/await The cleverness of grammar lies in the use of return Promise.resolve() Wrap ordinary functions as Promise grammar , So called next You can use .then perhaps await 了

4. One of the most subtle is if (i === middleware.length) fn = next
   Why? next To assign as fn ?
   Because when i === middleware.length When , The array of middleware has been completely executed ,next Function is actually middleware[middleware.length] == null
   This will trigger if (!fn) return Promise.resolve() It can be understood as the... Of the whole function " Recursive header "

in general , The implementation of the whole onion model is to advance the next method to the current method next Parameters in , It allows you to decide when the next method will be called , And very flexible , For example, the following situations ：

Pipelined Mode

A pipeline is a process in which the execution of a method is passed to the next method , For example, the following pseudo code ：

app.use(function(ctx, next) {

  console.log('1')
  next()
})
app.use(function(ctx, next) {

  console.log('2')
  next()
})
app.use(function(ctx, next) {

  console.log('3')
  next()
})

next Functions are uniformly called at the end , Then it will print once 1 2 3

Classic onion pattern

app.use(function(ctx, next) {

  console.log('1')
  next()
  console.log('1 - end')
})
app.use(function(ctx, next) {

  console.log('2')
  next()
  console.log('2 - end')
})
app.use(function(ctx, next) {

  console.log('3')
  next()
  console.log('3 - end')
})

stay next There is function processing before and after the function , Layer by layer , It's like an onion
The result is ：

1
2
3
3 - end
2 - end
1 - end

Reverse order mode

app.use(function(ctx, next) {

  next()
  console.log('1')
})
app.use(function(ctx, next) {

  next()
  console.log('2')
})
app.use(function(ctx, next) {

  next()
  console.log('3')
})

This is printed in turn 3 2 1 了 .

Connect the onion model in your own project

Through the previous article First acquaintance with onion model , Analyze the middleware execution process , elementary analysis koa Middleware source Add the above koa Source code analysis , Onion model must be more familiar . How to access your own projects ？

To achieve this goal , We have to at least have a set of functions to Collect and store middleware methods （ similar koa Of use）, There is one Methods to trigger middleware execution （ similar koa Of handleRequest）, Finally, there is a set Middleware mechanism （ Use it directly koa-compose）

• Use koa-compose What are the limitations ？

1. That is, when the parameters are fixed, only 2 individual ： Namely context Parameters And a next Callback Arguments （ Of course, you can also change koa-compose Finish what you want to be ）
2. context Need to be an object Object type , Because one of the characteristics of reference data types is that they all point to the same memory address , Modify the data in a middleware , Other middleware can also respond immediately , In this way, the data can be transmitted normally

Like the following Onion Is to implement a simple version of the middleware trigger

adopt start Method , Put data in , Then a series of processing , Including log printing of data modification , All capital letters are capitalized , The first word of the sentence is capitalized

The results are as follows ：

const compose = require('koa-compose')
class Onion {

  constructor() {

    this.middleware = []
  }
  use(fn) {

    if (typeof fn !== 'function') throw new TypeError('middleware must be a function!')
    this.middleware.push(fn)
    return this
  }
  start(context) {

    const fnMiddleware = compose(this.middleware)
    const handleRes = () => context
    return fnMiddleware(context).then(handleRes)
  }
}

let onion = new Onion()

function loggerMiddleware() {

  return function(ctx, next) {

    console.log(` Before conversion ：${
      ctx.content}`)
    next()
    console.log(` After the transformation ：${
      ctx.content}`)
  }
}
function titleCase(text) {

  return text.trim().replace(text[0], text[0].toUpperCase())
}

function titleCaseMiddleware() {

  return function(ctx, next) {

    ctx.content = titleCase(ctx.content)
    next()
  }
}
function lowercaseMiddleware() {

  return function(ctx, next) {

    ctx.content = ctx.content.replace(/[A-Z]+/g, function(str) {

      return titleCase(str.toLowerCase())
    })
    next()
  }
}

onion.use(loggerMiddleware())
onion.use(lowercaseMiddleware())
onion.use(titleCaseMiddleware())

var obj = {
     content: 'my name is JIOHO' }
onion.start(obj).then(res => {

  console.log('================')
  console.log('start  Processing results :', res)
})

Research on middleware and onion model , This is just the entry level , There are more subtle processing depends on the actual scene ~
