JPA learning 2 - core annotation, annotation addition, deletion, modification and query, list query result return type, one to many, many to one, many to many

SpringDataJPA

summary

Spring A set of pairs provided JPA Operate on more advanced frameworks , Is in JPA A solution specifically designed for persistence under the specification

 

Core notes

Easy to use

Configure the of printing SQL Portability parameter

pom.xml

    <dependencies>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-data-jpa</artifactId>
        </dependency>


        <!--hibernate Yes JPA Standard support package -->
        <dependency>
            <groupId>org.hibernate</groupId>
            <artifactId>hibernate-entitymanager</artifactId>
            <version>5.4.30.Final</version>
        </dependency>


        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>

        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-devtools</artifactId>
            <scope>runtime</scope>
            <optional>true</optional>
        </dependency>
        <dependency>
            <groupId>mysql</groupId>
            <artifactId>mysql-connector-java</artifactId>
            <scope>runtime</scope>
        </dependency>
        <dependency>
            <groupId>org.projectlombok</groupId>
            <artifactId>lombok</artifactId>
            <optional>true</optional>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-test</artifactId>
            <scope>test</scope>
        </dependency>

        <dependency>
            <groupId>cn.hutool</groupId>
            <artifactId>hutool-all</artifactId>
            <version>5.6.3</version>
        </dependency>

        <!-- https://mvnrepository.com/artifact/junit/junit -->
        <dependency>
            <groupId>junit</groupId>
            <artifactId>junit</artifactId>
            <version>4.13.2</version>
            <scope>test</scope>
        </dependency>

        <!-- monitor sql journal  == SQL You can carry parameters , If you use JPA Self contained SQL Printing does not carry parameters -->
        <dependency>
            <groupId>org.bgee.log4jdbc-log4j2</groupId>
            <artifactId>log4jdbc-log4j2-jdbc4.1</artifactId>
            <version>1.16</version>
        </dependency>

    </dependencies>

application.yml == Be careful mysql Driver name and database connection URL

server:
  port: 8080

spring:
  datasource:
    username: root
    password: root
# url: jdbc:mysql://localhost:3306/lrc_blog_test2?useSSL=false&characterEncoding=UTF-8&serverTimezone=Asia/Shanghai
    url: jdbc:log4jdbc:mysql://localhost:3306/lrc_blog_test2?useSSL=false&characterEncoding=UTF-8&serverTimezone=Asia/Shanghai
# driver-class-name: com.mysql.cj.jdbc.Driver
    driver-class-name: net.sf.log4jdbc.sql.jdbcapi.DriverSpy
  jpa:
    show-sql: true
    database-platform: org.hibernate.dialect.MySQL8Dialect
    database: mysql
    hibernate:
# ddl-auto: create

principle = JDK A dynamic proxy

1. @Repository Defined dao The interface will go through JDK The dynamic proxy is converted to SimpleJpaRepository Object to execute concrete CRUD operation

2. SimpleJpaRepository adopt EntityManager Object to execute concrete CRUD operation

3. and EntityManager The specific implementation is realized by Hibernate To perform JDBC operation

Simple code = Built in interface

 
application.yml

server:
  port: 8080

spring:
  datasource:
    username: root
    password: root
    url: jdbc:mysql://localhost:3306/lrc_blog_test?useSSL=false&characterEncoding=UTF-8&serverTimezone=Asia/Shanghai
    driver-class-name: com.mysql.cj.jdbc.Driver
  jpa:
    show-sql: true
    database-platform: org.hibernate.dialect.MySQLDialect
    database: mysql
    open-in-view: true

 
Book.java

@Getter
@Setter
@ToString
@Entity
@Table(name = "book")
public class Book implements Serializable {

    private static final long serialVersionUID = 2095940921263481761L;



    /**  Primary key  -  Record insertion auto fill primary key processing {@path application.yml} */
    @Id
    @Column(name = "id")
    private String id;

    @Column(name = "create_time")
    private String createTime;

    @Column(name = "update_time")
    private String updateTime;

    /**  Whether the record is deleted logically ：0 Not delete  1 Logical deletion  -  Logical processing value definition {@path application.yml}*/
    @Column(name = "is_del")
    private Integer isDel;

    /**  Book status ;-1 Violations,  0 Published and made public  1 Published and private  -  Default 0 */
    @Column(name = "status")
    private String status;

    /**  Title  */
    @Column(name = "name")
    private String name;

    /**  author  */
    @Column(name = "author")
    private String author;

    /**  Nationality of the author  */
    @Column(name = "country")
    private String country;

    /**  Download address  */
    @Column(name = "download_url")
    private String downloadUrl;

    /**  file type  */
    @Column(name = "file_type")
    private String fileType;

    /**  Reading experience  */
    @Column(name = "reading_feeling")
    private String readingFeeling;

    /**  Book sharers  -  nickname  */
    @Column(name = "sharer")
    private String sharer;

    /**  Whether the books violate the rules ：0 No violation  1 Violations,  -  Violations cannot be displayed  */
    @Column(name = "is_violation")
    private Integer isViolation;




    // Book status
    public final  static String STATUS_VIOLATION = "-1";
    public final  static String STATUS_PUBLISH_PUBLIC = "0";
    public final  static String STATUS_PUBLISH_PRIVATE = "1";

}

 
BookDao.java

@Repository
public interface BookDao extends JpaRepository<Book, String> {

}

 
JPATest.java

@SpringBootTest
public class JPATest {


    @Autowired
    BookDao bookDao;

    @Test
    public void test1() {


        List<Book> books = bookDao.findAll();
        books.stream().forEach(System.out::println);

    }

}

Customize SQL sentence

Inquire about

The way 1：dao Method name query form - Method name must findBy start

By method name ,JPA Automatic identification JPQL sentence

SysUserDao.java

@Repository
public interface SysUserDao extends JpaRepository<SysUser, String> {


    public SysUser findByIdAndNickName(String id, String nickName);

}

Test.java

    @Test
    public void test8() {

        SysUser sysUser = sysUserDao.findByIdAndNickName("d32478155b6530951cf6b3da56848d5c", " Mm-hmm ");
        System.out.println(sysUser);
    }

 

The way 2：JPQL Query form

@Repository
public interface BookDao extends JpaRepository<Book, String>, JpaSpecificationExecutor<Book> {


    //JPA Generate according to method name SQL
    public List<Book> findByNameLike(String name);

    // Write manually JPQL sentence   The first parameter is zero ：?1  The second parameter is ：?2  And so on
    @Query("from Book where name like ?1")
    public List<Book> findByNamexxx(String name);

    // Write manually JPQL sentence   Use  : Parameter name   To fill in JPQL Parameters of
    @Query("from Book where name like :name")
    public List<Book> findByNamexxx2(String name);

}

 
 
test.java

    @Test
    public void test4() {



        List<Book> books = bookDao.findByNameLike("% The brain %");
        books.stream().forEach(System.out::println);

        System.out.println("\n=========\n");

        books = bookDao.findByNamexxx("% The brain %");
        books.stream().forEach(System.out::println);

        System.out.println("\n=========\n");

        books = bookDao.findByNamexxx2("% The brain %");
        books.stream().forEach(System.out::println);


    }

 

The way 3：SQL Query form

BookDao.java

@Repository
public interface BookDao extends JpaRepository<Book, String>, JpaSpecificationExecutor<Book> {


    @Query(value = "select * from book where name like :name ", nativeQuery = true)
    public List<Book> findByNamexxx2(String name);

    @Query(value = "select * from book where name like ?1 ", nativeQuery = true)
    public List<Book> findByNamexxx3(String name);

}

 
 

BookDao.java

    @Test
    public void test5() {

        List<Book> books = bookDao.findByNamexxx2("% The brain %");
        books.stream().forEach(System.out::println);
    }
    @Test
    public void test6() {

        List<Book> books = bookDao.findByNamexxx3("% The brain %");
        books.stream().forEach(System.out::println);
    }

 

The way 4： Code level query , similar MyBatisPlus

 
BookDao.java

@Repository
public interface BookDao extends JpaRepository<Book, String>, JpaSpecificationExecutor<Book> {


}

 
Test.java

    @Test
    public void test9() {


        List<SysUser> sysUsers = sysUserDao.findAll(new Specification<SysUser>() {

            @Override
            public Predicate toPredicate(Root<SysUser> root, CriteriaQuery<?> query, CriteriaBuilder criteriaBuilder) {

                Path<Object> nickName = root.get("nickName");
                Path<Object> id = root.get("id");

                Predicate predicate = criteriaBuilder.equal(nickName, " Mm-hmm ");
                Predicate predicate2 = criteriaBuilder.equal(id, "d32478155b6530951cf6b3da56848d5c");

                Predicate and = criteriaBuilder.and(predicate2, predicate);

                return and;
            }
        });
        sysUsers.forEach(System.out::println);
    }

 
Test.java

    @Test
    public void test10() {


        // Query criteria
        Specification<SysUser> whereConditions = new Specification<SysUser>() {

            @Override
            public Predicate toPredicate(Root<SysUser> root, CriteriaQuery<?> query, CriteriaBuilder criteriaBuilder) {

                Path<Object> nickName = root.get("nickName");
                Path<Object> id = root.get("id");
                Predicate predicate = criteriaBuilder.like(nickName.as(String.class), "% Um. %");
                Predicate predicate2 = criteriaBuilder.equal(id, "d32478155b6530951cf6b3da56848d5c");
                return criteriaBuilder.or(predicate, predicate2);
            }
        };

        // The sorting of records after query
        Sort sort = Sort.by(Sort.Direction.DESC, "createTime", "id", "nickName");

        List<SysUser> sysUsers = sysUserDao.findAll(whereConditions, sort);
        sysUsers.forEach(System.out::println);
    }

 
Test.java

    @Test
    public void test11() {


        // Query criteria
        Specification<SysUser> whereConditions = new Specification<SysUser>() {

            @Override
            public Predicate toPredicate(Root<SysUser> root, CriteriaQuery<?> query, CriteriaBuilder criteriaBuilder) {

                Path<Object> nickName = root.get("nickName");
                Path<Object> id = root.get("id");
                Predicate predicate = criteriaBuilder.like(nickName.as(String.class), "% Um. %");
                Predicate predicate2 = criteriaBuilder.like(id.as(String.class), "%5%");
                return criteriaBuilder.or(predicate, predicate2);
            }
        };

        // The sorting of records after query
        Sort sort = Sort.by(Sort.Direction.DESC, "createTime");
        // Paging information + Sort information
        Pageable pageable = PageRequest.of(2, 2, sort);

        Page<SysUser> page = sysUserDao.findAll(whereConditions, pageable);
        List<SysUser> sysUsers = page.getContent();

        sysUsers.forEach(System.out::println);
    }

 

Three return types = Choose... According to your preference

 
BaseDB.java

@Getter
@Setter
@MappedSuperclass
public class BaseDB {


    private static final long serialVersionUID = 3253505422347170166L;
    /**  Primary key  -  Record insertion auto fill primary key processing {@path application.yml} */
    @Id
    private String id;

    @Column(name = "create_time")
    private String createTime;

    @Column(name = "update_time")
    private String updateTime;

    /**  Whether the record is deleted logically ：0 Not delete  1 Logical deletion  -  Logical processing value definition {@path application.yml}*/
    @Column(name = "is_del")
    private Integer isDel;

}

 
SysUser.java

@Getter
@Setter
@Entity
@Table(name = "sys_user")
public class SysUser extends BaseDB{


    @Column(name = "nick_name")
    String nickName;


    @Column(name = "login_name")
    String loginName;

    @Override
    public String toString() {

        return "SysUser{" +
                "id='" + getId() + '\'' +
                ", nickName='" + nickName + '\'' +
                ", loginName='" + loginName + '\'' +

                '}';
    }
}

 
SysUserDao.java

@Repository
public interface SysUserDao extends JpaRepository<SysUser, String> {



    @Query(value = "select * from sys_user limit 5", nativeQuery = true)
    public List<SysUser> getPage();

    /** * @return Object[]  It stores all column values of the data record  */
    @Query(value = "select * from sys_user limit 5", nativeQuery = true)
    public List<Object[]> getPage2();

    /** * @return org.springframework.data.jpa.repository.query.AbstractJpaQuery.TupleConverter.TupleBackedMap */
    @Query(value = "select * from sys_user limit 5", nativeQuery = true)
    public List<Map> getPage3();


}

 
Test.java

    @Test
    public void test3() {


        System.out.println("\n============JavaBean form - recommend =========\n");

        List<SysUser> sysUsers = sysUserDao.getPage();
        sysUsers.forEach(System.out::println);

        System.out.println("\n==========Object[] Pure column valued form - Not recommended ===========\n");

        List<Object[]> sysUsers2 = sysUserDao.getPage2();
        sysUsers2.stream()
                .map(Arrays::toString)
                .forEach(System.out::println);


        System.out.println("\n==========Map form - recommend ===========\n");

        List<Map> sysUsers3 = sysUserDao.getPage3();
        sysUsers3.stream()
                .map(HashMap::new)
                .forEach(System.out::println);

    }

modify 、 Delete

@Repository
@Transactional  // Adding, deleting, or modifying requires adding transaction support
public interface BookDao extends JpaRepository<Book, String>, JpaSpecificationExecutor<Book> {


    @Query("update Book set name = ?2 where id = ?1")
    @Modifying  //update Need to add this annotation
    @Rollback(false)  // Do not rollback after execution  ==  If you add the first two annotations and cannot modify the data successfully , Then add this annotation
    public void udpateBookName(String id, String name);


    @Query("delete from Book where id = :id and name = :name")
    @Modifying
    @Rollback(false)  // Do not rollback after execution  ==  If you add the first two annotations and cannot modify the data successfully , Then add this annotation
    public void deleteByIdName(String id, String name);


}


}

 
 

    @Test
    public void test5() {


        bookDao.udpateBookName("0015ac644213f7db45d63e09c6403395", " test 2");

        bookDao.deleteByIdName("0015ac644213f7db45d63e09c6403395", " test ");



    }

 

Multi meter operation

One to many 、 For one more

SysUser.java

@Getter
@Setter
@Entity
@Table(name = "sys_user")
public class SysUser extends BaseDB implements Serializable {


    @Column(name = "nick_name")
    String nickName;


    @Column(name = "login_name")
    String loginName;

    @OneToMany(targetEntity = ArticleComment.class,fetch = FetchType.EAGER)
    @JoinColumn(name = "user_id", referencedColumnName = "id")
    @NotFound(action= NotFoundAction.IGNORE)
    List<ArticleComment> articleComments;


    @Override
    public String toString() {

        return "SysUser{" +
                "id='" + getId() + '\'' +
                ", nickName='" + nickName + '\'' +
                ", loginName='" + loginName + '\'' +
                ", createTime='" + getCreateTime() + '\'' +
                '}';
    }
}

 
ArticleComment.java

@Getter
@Setter
@Entity
@Table(name = "article_comment")
public class ArticleComment extends BaseDB implements Serializable {

    /**  Version number  */
    private static final long serialVersionUID = -6282048873013965389L;

    @ManyToOne(targetEntity = SysUser.class, fetch = FetchType.EAGER, cascade = CascadeType.ALL)
    @JoinColumn(name ="user_id", referencedColumnName = "id")
    @NotFound(action= NotFoundAction.IGNORE)
    private SysUser sysUser;

    /**  Comment on the article  - article Tabular id -  Logical foreign key associations  */
    @Column(name = "article_id")
    private String articleId;

    /**  Parent comment id - article_comment Tabular id -  Whether it is a sub comment , If it is empty, it is not a sub comment  -  Logical foreign key associations  */
    @Column(name = "parent_comment_id")
    private String parentCommentId;

    /**  Commentator  -  user id - user Tabular id -  Logical foreign key associations  */
    //@Column(name = "user_id")
    //private String userId;


    /**  To whom is this comment addressed  -  user ID */
    @Column(name = "replier_id")
    private String replierId;


    /**  Comment content  */
    @Column(name = "comment_content")
    private String commentContent;

    /**  The number of likes of the current comment  */
    @Column(name = "like_num")
    private Integer likeNum;
    /**  Current reviews don't like counting  */
    @Column(name = "not_like_num")
    private Integer notLikeNum;

    @Override
    public String toString() {

        return "ArticleComment{" +
                "id='" + getId() + '\'' +
                ", articleId='" + articleId + '\'' +
                ", parentCommentId='" + parentCommentId + '\'' +
                ", replierId='" + replierId + '\'' +
                ", commentContent='" + commentContent + '\'' +
                ", likeNum=" + likeNum +
                ", notLikeNum=" + notLikeNum +
                '}';
    }
}

 
SysUserDao.java

@Repository
public interface SysUserDao extends JpaRepository<SysUser, String>, JpaSpecificationExecutor<SysUser> {



    @Query(value = "select * from sys_user limit 5", nativeQuery = true)
    public List<SysUser> getPage();

    /** * @return Object[]  It stores all column values of the data record  */
    @Query(value = "select * from sys_user limit 5", nativeQuery = true)
    public List<Object[]> getPage2();

    /** * @return org.springframework.data.jpa.repository.query.AbstractJpaQuery.TupleConverter.TupleBackedMap */
    @Query(value = "select * from sys_user limit 5", nativeQuery = true)
    public List<Map> getPage3();

    public SysUser findByIdAndNickName(String id, String nickName);

}

 
ArticleCommentDao.java

@Repository
public interface ArticleCommentDao extends JpaRepository<ArticleComment, String>, JpaSpecificationExecutor<ArticleComment> {


}

Inquire about

@Test
@Transactional  // Lazy loading , Could not find exception for agent , If you load it immediately, you can not add
public void test13() {

    List<SysUser> sysUsers = sysUserDao.getPage();
    sysUsers.forEach(sysUser -> {

        List<ArticleComment> articleComments = sysUser.getArticleComments();
        System.out.println(articleComments.size() + "：" + articleComments);
    });
}

 

@Test
@Rollback(value = false)
@Transactional
public void test16() {

    ArticleComment articleComment = articleCommentDao.getOne("1346e1060e95de36d8d8a7bbc8925dfb");
    SysUser sysUser = articleComment.getSysUser();
    System.out.println(sysUser);
}

Insert

 

The main table already contains foreign key records

Test.java

    @Test
    public void test12() {


        SysUser sysUser = sysUserDao.findById("c08d391e02bc11eb9416b42e99ea3e69").get();

        ArticleComment articleComment = new ArticleComment();
        articleComment.setId(UUID.fastUUID().toString(true));
        articleComment.setCommentContent("test==articleComment");
        articleComment.setSysUser(sysUser);

        articleCommentDao.save(articleComment);
    }

 

The main table does not contain foreign key records

    @Test
    @Rollback(value = false)
    @Transactional
    public void test15() {

        SysUser sysUser = new SysUser();
        sysUser.setId(UUID.fastUUID().toString(true));
        sysUser.setNickName(String.valueOf(" love you test"));

        ArticleComment articleComment = new ArticleComment();
        articleComment.setId(UUID.fastUUID().toString(true));


        articleComment.setSysUser(sysUser);
        articleComment.setCommentContent(String.valueOf("test==articleComment"));

        sysUserDao.save(sysUser);
        articleCommentDao.save(articleComment);

    }

 

Many to many

Inquire about

Role.java

@Getter
@Setter
@Entity
@Table(name = "role")
public class Role {


    @Id
    @GeneratedValue(strategy = GenerationType.IDENTITY)
    Long id2;

    @Column(name = "role_name")
    String roleName;

    @ManyToMany(targetEntity = User.class, fetch = FetchType.EAGER)
    @JoinTable(name = "user_role_rel",
            // The relationship between the current table and the intermediate table
            joinColumns = {
    @JoinColumn(name = "role_id", referencedColumnName = "id2")},
            // The relationship between another table and the intermediate table
            inverseJoinColumns = {
    @JoinColumn(name = "user_id", referencedColumnName = "id1")})
    List<User> roles;

}

 
User.java

@Getter
@Setter
@Entity
@Table(name = "user")
public class User {



    @Id
    @GeneratedValue(strategy = GenerationType.IDENTITY)
    Long id1;

    @Column(name = "user_name")
    String userName;

    @ManyToMany(targetEntity = Role.class, fetch = FetchType.EAGER)
    @JoinTable(name = "user_role_rel",
            // The relationship between the current table and the intermediate table
            joinColumns = {
    @JoinColumn(name = "user_id", referencedColumnName = "id1")},
            // The relationship between another table and the intermediate table
            inverseJoinColumns = {
    @JoinColumn(name = "role_id", referencedColumnName = "id2")})
    List<Role> roles;
}

 
Test.java

@Test
@Rollback(value = false)
@Transactional
public void test17() {

    User user = new User();
    user.setUserName("lrc2");

    Role role = new Role();
    role.setRoleName(" tourists 2");

    // Intermediate table relationship maintenance  ==  If the data without an intermediate table is empty
    role.setRoles(Arrays.asList(user));

    userDao.save(user);
    roleDao.save(role);

}
