Unitywebrequest is used in unity to load network and local pictures

In the actual project , There are often some needs to load pictures from the network to show . For example, players' avatars , Announcement big picture and some display pictures that need to be loaded , At this time, you need to use code to load the necessary image resources from the network .

Update the iterative version Unity Has been gradually giving up on WWW Support for , Introduction UnityWebRequest, See Unity Resource storage and loading - Local resources Update resources .

UnityWebRequest It also supports AssetsBundle,xml Wait for the download of file resources .

This paper is based on UnityWebRequest On the basis of , Realize the loading of network pictures and local disk pictures , And implemented on the screen .

First look at the use of WWW How to complete the image loading ：

using (WWW www = new WWW(url))
{
    yield return www;
    if (string.IsNullOrEmpty(www.error))
    {
         // Get the picture in the link
         Texture2D texture = www.texture;
    }
}

This code is relatively simple , Back to www.texture Is the link image , This completes the simple image loading .

however , actually , Usually, you need to load pictures into memory and cache them locally , So that it can be loaded quickly next time , Instead of pulling from the network again .

technological process ：

Key code ：github Address

///LoadImageMgr.cs
using System.Collections;
using System.Collections.Generic;
using UnityEngine;
using System;
using System.IO;
using UnityEngine.Networking;


public class LoadImageMgr
{
    /// <summary>
    /// download from web or hard disk
    /// </summary>
    /// <param name="url"></param>
    /// <param name="loadEnd">callback</param>
    /// <returns></returns>
    public IEnumerator LoadImage(string url, Action<Texture2D> loadEnd)
    {
        Texture2D texture = null;
        // Load from memory first
        if (imageDic.TryGetValue(url,out texture))
        {
            loadEnd.Invoke(texture);
            yield break;
        }
        string savePath = GetLocalPath();
        string filePath = string.Format("file://{0}/{1}.png", savePath, UnityUtil.MD5Encrypt(url));
        //from hard disk
        bool hasLoad = false;
        if (Directory.Exists(filePath))
            yield return DownloadImage(filePath, (state, localTexture) =>
            {
                hasLoad = state;
                if (state)
                {
                    loadEnd.Invoke(localTexture);
                    if (!imageDic.ContainsKey(url))
                        imageDic.Add(url, localTexture);
                }
            });
        if (hasLoad) yield break; //loaded
        //from web
        yield return DownloadImage(url, (state, downloadTexture) =>
        {
            hasLoad = state;
            if (state)
            {
                loadEnd.Invoke(downloadTexture);
                if (!imageDic.ContainsKey(url))
                    imageDic.Add(url, downloadTexture);
                Save2LocalPath(url, downloadTexture);
            }
        });
    }
    public IEnumerator DownloadImage(string url, Action<bool, Texture2D> downloadEnd)
    {
        using (UnityWebRequest request = new UnityWebRequest(url))
        {
            DownloadHandlerTexture downloadHandlerTexture = new DownloadHandlerTexture(true);
            request.downloadHandler = downloadHandlerTexture;
            yield return request.Send();
            if (string.IsNullOrEmpty(request.error))
            {
                Texture2D localTexture = downloadHandlerTexture.texture;
                downloadEnd.Invoke(true, localTexture);
            }
            else
            {
                downloadEnd.Invoke(false, null);
                Debug.Log(request.error);
            }
        }
    }
    /// <summary>
    /// save the picture
    /// </summary>
    /// <param name="url"></param>
    /// <param name="texture"></param>
    private void Save2LocalPath(string url, Texture2D texture)
    {
        byte[] bytes = texture.EncodeToPNG();
        string savePath = GetLocalPath();
        try
        {
            File.WriteAllBytes( string.Format("{0}/{1}.png", savePath , UnityUtil.MD5Encrypt(url)), bytes);
        }
        catch(Exception ex)
        {
            Debug.LogError(ex.ToString());
        }
    }
    /// <summary>
    /// get which path will save
    /// </summary>
    /// <returns></returns>
    private string GetLocalPath()
    {
        string savePath = Application.persistentDataPath + "/pics";
#if UNITY_EDITOR
        savePath = Application.dataPath + "/pics";
#endif
        if (!Directory.Exists(savePath))
        {
            Directory.CreateDirectory(savePath);
        }
        return savePath;
    }
    private Dictionary<string, Texture2D> imageDic = new Dictionary<string, Texture2D>();
    public static LoadImageMgr instance { get; private set; } = new LoadImageMgr();
}



///LoadImageHelper.cs
using System;
using System.Collections;
using UnityEngine;
using UnityEngine.UI;
public class LoadImageHelper : MonoBehaviour
{
    string defaultUrl = "http://avatar.csdnimg.cn/1/E/6/2_u013012420.jpg";
    /// <summary>
    /// use this to load image
    /// </summary>
    /// <param name="texture"></param>
    /// <param name="url"></param>
    public void LoadImage(RawImage rawImage, string url)
    {
        if (string.IsNullOrEmpty(url))
        {
            url = defaultUrl;
        }
        StartCoroutine(LoadTeture(url, (tex) => {
            rawImage.texture = tex;
        }));
    }

    IEnumerator LoadTeture(string url, Action<Texture2D> cb)
    {
        yield return LoadImageMgr.instance.LoadImage(url, cb);
    }
}
