15+ urban road element segmentation application, this segmentation model is enough!

Image semantic segmentation is a classical and challenging task in computer vision . It aims to provide detailed pixel level image classification , It is equivalent to assigning semantic labels to each pixel . This technology is now widely used in urban security 、 System fields such as road condition judgment , For example, the application of map navigation is to recognize buildings by segmentation 、 wall 、 Road elements such as pavement conditions , So as to capture the key information of pavement more accurately .

In order to let everyone get started more quickly , Baidu visual technology department is based on the flying paddle Image segmentation development kit PaddleSeg It provides a complete set of practical examples of Urban Street View Road element segmentation industry , Provides data preparation from 、 The whole process scheme of model training and optimization , Lower the threshold of industrial landing . In this project, we need to put 19 Split the key objectives , So what is our specific plan idea ？

chart 1 Segmentation example

Click to read the original text GET Project links

https://aistudio.baidu.com/aistudio/projectdetail/4038141?contributionType=1

All source code and tutorials have been open source , Welcome to use .

Project difficulties

The goal is complex

• The road is complicated ： Include straight line , Turn a corner , Traffic lights, intersections, etc ;


• The environment is complex ： Adapt to the day 、 Night 、 Foggy and rainy days, etc ;

• Scene is complicated ： Urban Rd 、 rural 、 Expressway and other scenes are quite different .

The sample is unbalanced

• There are many categories ： Including pavement 、 Sidewalk 、 building 、 wall 、 fence 、 Pole 、 traffic lights 、 traffic sign 、 Vegetation 、 ground 、 sky 、 people 、 Cyclists 、 vehicle 、 truck 、 The bus 、 train 、 The motorcycle 、 Bicycle ;

• unbalanced ： At most... Will appear in each image 15 Cars and 30 A pedestrian , Sometimes there will be 2 Cars and no pedestrians , And various degrees of occlusion and truncation .

Model selection

The mainstream semantic segmentation schemes include the following series ：

• FCN（Fully Convolution Network）： Total convolution network , As a precedent of using deep learning for image segmentation , Its symbolic significance is greater than its practical significance .

• U-Net series ： stay UNet Before , The main partition networks are straight - barrel , Only the top-level or later layers of information are used for up sampling reconstruction . and UNet Is a convolution layer directly connected to the input .

• DeepLab series ：DeepLab In the field of image segmentation is another series , There are already several versions , And before UNet Compared with the series , The main difference is in the processing of the input image and the structure of the network .DeepLab The image pyramid is mainly used 、 Cavity convolution 、SPP Space Pyramid pooling 、 Can separate convolution and other methods to improve the effect of segmentation .

• HRNet series ：HRNet yes 2019 A new neural network was proposed by Microsoft Research Asia in , Different from the previous convolutional neural network , The network can still maintain high resolution in the deep layer of the network , Therefore, the predicted semantic information is more accurate , It is also more accurate in space .

• Transformer series ： since Transformer Since it was introduced into computer vision , It gave birth to a large number of related research and applications . In the direction of image segmentation , Emerged like SETR、TransUNet、SegFormer、MaskFormer Based on Transformer Semantic segmentation network model . It breaks the restriction of convolution structure on the access of image global information .

Because the segmentation target is complex , We selected the one with better accuracy HRNet In the series MscaleOCRNet Follow up experiments on the model , it SOTA Of mIoU Reached 87%. Compared with HRNet Network structure , It calculates a relation weight between each pixel and other pixels of the image on the result of segmentation , A superposition with the original feature constitutes OCRNet The Internet , Then based on the OCRNet Carry out layered and multi-scale training to form the final MscaleOCRNet, The multi-scale training and reasoning method is shown in the figure below .

chart 2 MscaleOCRNet programme

Algorithm optimization

In order to further improve the accuracy , Solve the problem of sample imbalance , We provide the following optimization ideas ：

• Modify the pre training model ： take mapillary Pre training changed to Cityscapes Pre training model , Migrate to KITTI-STEP Data set training can effectively improve the segmentation effect ;

• Add multi-scale training ： from [0.5,1.0] The two scales are increased to [0.5,1.0,2.0] Three scales ;

• Modify the input size ： Modify the input dimension by 1024x512 Change to original drawing size 1248x384.

Using tools

This project uses PaddleSeg Development complete .PaddleSeg It's based on the oars PaddlePaddle Developed an end-to-end image segmentation development kit , It covers a large number of high-quality segmentation models in different directions such as high precision and lightweight . Through modular design , Provides configurable drivers and API Call two applications , Help developers more easily complete the whole process of image segmentation applications from training to deployment . Provide semantic segmentation 、 Interactive segmentation 、 Panoramic segmentation 、Matting Four image segmentation capabilities .

Model deployment

Use the propeller native inference Library Paddle Inference, Used for server-side model deployment , In general, it is divided into three steps ：

1. establish PaddlePredictor, Set the exported model path ;

2. Create a for input PaddleTensor, The incoming to PaddlePredictor in ;

3. Get output PaddleTensor, Take out the results .

If you want to know more details , Welcome to our live course , The whole process of teaching is waiting for you .

Wonderful course preview

In order to make the kids more convenient to use the example tutorial , Baidu senior R & D Engineer will On 6 month 23 Japan （ Thursday ）20:00 spot Prepare data for in-depth analysis 、 The whole development process from scheme design to model optimization deployment , Hand in hand to teach you code practice .

Scan the code to sign up for the live class

Join the technology exchange group

References ： chart 2 Quote from “Hierarchical Multi-Scale Attention for Semantic Segmentation”
