当前位置:网站首页>Altium designer 09 screen printing displays a green warning near the pad. How to prevent it from alarming?
Altium designer 09 screen printing displays a green warning near the pad. How to prevent it from alarming?
2022-06-23 04:46:00 【Boundless also initial heart】
There are three ways :
1、 Turn off online DRC
2、 Reset the error section Shortcut key T + M
3、 Modify rules
take SilkscreenOverComponentPads Medium Silkscreen Over Exposed Component Pads Clearance Medium 10mil Change it to 0mil The alarm can be eliminated .
I finally solved , It's not a rule setting problem , It's a matter of rule enforcement . Check in the design rules Design Rule Check You can choose online check Online DRC And batch inspection Batch DRC Check items for , As long as the corresponding check item is not checked , Because the warning here has no adverse effect on the final product , Therefore, this item can not be checked .
