CVPR2022- Stereo matching of asymmetric resolution images

0. Abstract

• Research questions ： Stereo matching of a pair of images with different resolutions ;
• Method ： Unsupervised learning 、 Feature metric consistency 、 Self reinforcing optimization strategy ;
• verification ： In a variety of degraded Simulation data set And self collected Real data sets Experimental results on show that the proposed method is superior to the existing solutions .

1. Introduce

• Research background and significance ： at present , By two （ Or more ） Long distance camera systems composed of lenses with different focal lengths are widely used in smart phones . Such systems usually generate a pair of... In one shot （ Or a group ） Images with different resolutions , This makes many ideal applications possible , for example Continuous optical zoom and Image quality enhancement . For these applications , The corresponding point estimation of stereo images with asymmetric resolution is a key step , Usually by Traditional symmetric stereo matching algorithm （ Such as SGM) and Sampling on image To carry out . However, this method is easily affected by the artifacts introduced by sampling on the image , This effect is more obvious when the upsampling range is large .

• Contribution summary ：

  • First use Unsupervised learning methods The corresponding points are estimated from the resolution asymmetric stereo pairs ;
  • Realization Feature metric consistency , To avoid photometric inconsistencies due to unknown degradation ;
  • A method to enhance the consistency of feature metrics by progressive loss updating Self reinforcing strategy ;
  • stay Analog datasets and real datasets On , Compared with the comparison method, it has obvious performance improvement .

• Introduction to research methods ：

  • Unsupervised learning ： For the case of asymmetric resolution , Supervised methods require not only the true value of parallax but also high-quality degraded views as labels , It is also necessary to define the degenerate form to learn the network parameters , This makes it difficult to apply to various complex real-world systems . therefore , We turn to unsupervised learning .

  • Feature metric consistency ： For unsupervised stereo matching , The most widely used assumption is photometric consistency .

    • Pictured 1(a) Shown , The corresponding pixels in the symmetric stereo pair have $I_L[p_L]=I_R[p_R]$;

    • Pictured 1(b) Shown , The corresponding pixels in the asymmetric stereo pair may not have the same intensity or color , This photometric inconsistency will bring new difficulties to the corresponding point learning ;

    • The existing solution is through super-resolution (SR) Technology will LR View reverts to HR View , However , The existing SR Methods are mostly degenerate specific , The actual degradation is different from the assumed degradation , Performance will decline ;

    • This paper puts forward the idea of The feature space Instead of imposing consistency between two views in image space , be called Feature metric consistency , Specific consistent features can be generated through the feature extractor , namely , chart 1(b) Medium $F_L[p_L]=F_R[p_R]$. These features can then be used to formulate a feature to measure the loss , To avoid photometric inconsistencies .

      Feature metric consistency It was discovered through experiments . Although it is not the best to train the network with luminosity loss , But trained The feature extractor can extract consistent features .

• Self reinforcing optimization strategy ： When the stereo matching network is optimized through the loss of feature measurement , The feature extractor is also optimized , It can further enhance the consistency of feature metrics . So , A self enhancement strategy is introduced to Iterative optimization Feature extractor . To be specific , We use the feature extractor learned from the previous stage to form a new feature metric loss in the current stage , The new feature metric loss is used in the next stage of network training to learn a new feature extractor , Iterative optimization in turn . such , This method is still effective even for large degradation .

2. Resolution asymmetric stereo matching method is introduced

The method flow chart of this paper ：

2.1 Photometric consistency learning

• Align the stereo pair $I_L$ and $I_{r\uparrow }$ As input , Unsupervised stereo matching network $\Phi (\cdot ;\theta )$ The forecast is relative to the left view $I_L$ Parallax map $d_L=\Phi (I_L,I_{r\uparrow };\theta )$, Training based on the photometric consistency of the corresponding points , namely ：

  $$I_L[p_L]=I_{r\uparrow }[p_{r\uparrow }]\text{\hspace{1em}(1)}$$

• If parallax $d_L[p_L]$ Get an accurate estimate , So the left picture $I_L[p_L]$ It can be seen from the $I_{r\uparrow }[p_L]$ Combined with parallax transform, we get , namely ：

  $$I_{r\uparrow \to L}[p_L]=I_{r\uparrow }[p_L-d_L[p_L]]\text{\hspace{1em}(2)}$$

• therefore , The photometric loss can be determined by $I_L$ And its reconstruction results $I_{r\uparrow \to L}$ The error between , It is generally weighted $\alpha$ Of $L_1$ and $SSIM$ A combination of distances , namely ：

  $${\mathcal{L}}_{pm}=\Vert I_L-I_{r\uparrow \to L}{\Vert }_1+\alpha (1-SSIM(I_L,I_{r\uparrow \to L}))\text{\hspace{1em}(3)}$$

SSIM： Structural similarity index （Structural Similarity Index Measure）

First use photometric consistency loss ${\mathcal{L}}_{pm}$ Train an initial network ${\Phi }^0$ Including feature extraction network ${\Phi }_F^0$ And matching network ${\Phi }_M^0$

2.2 Feature measure consistency learning

• Given a stereo pair $I_L$ and $I_{r\uparrow }$,$\Phi (\cdot ;{\theta }_F)$ Extracted features $F_L={\Phi }_F(I_L;{\theta }_F)$ and $F_{r\uparrow }={\Phi }_F(I_L;{\theta }_F)$, These two features are consistent on the corresponding points of asymmetric pixels , namely ：

$$F_L[p_L]=F_{r\uparrow }[p_{r\uparrow }]\text{\hspace{1em}(4)}$$

• Will feature $F_L$ and $F_{r\uparrow }$ Concatenated into a cost body , And use ${\Phi }_M(\cdot ;{\theta }_M)$ Regularize , Return to the parallax map $d_L$. In obtaining the basis $d_L$ Transformed left view $I_{r\uparrow \to L}$ , Using a feature extractor ${\Phi }_F(\cdot ;{\theta }_F)$ take $I_L$ and $I_{r\uparrow \to L}$ Project to feature space , obtain $F_L$ and $F_{r\uparrow \to L}={\Phi }_F(I_{r\uparrow \to L};{\theta }_F)$.

• The characteristic measurement loss can be modeled after the photometric consistency loss ${\mathcal{L}}_{fm}$：

$${\mathcal{L}}_{fm}=\Vert F_L-F_{r\uparrow \to L}{\Vert }_1+\alpha (1-SSIM(F_L,F_{r\uparrow \to L}))\text{\hspace{1em}(5)}$$

Then we use the feature to measure the consistency loss ${\mathcal{L}}_{fm}$ Retraining the network gets ${\Phi }^1$ Including feature extraction network ${\Phi }_F^1$ And matching network ${\Phi }_M^1$

2.3 Self reinforcing strategy

Pictured 3(b) Shown , Given a stereo dataset with asymmetric resolution .

• use first ${\mathcal{L}}_{pm}$ Train a stereo matching network $\Phi (\cdot ;{\theta }_F^0;{\theta }_M^0)$（ abbreviation ${\Phi }^0$), Its feature extractor ${\Phi }_F^0$ Form characteristics to measure loss ${\mathcal{L}}_{fm}^0$.
• And then use it ${\mathcal{L}}_{fm}^0$ A new stereo matching network is optimized ${\Phi }^1$. stay ${\Phi }^1$ In the process of adjustment , Used to calculate ${\mathcal{L}}_{fm}^0$ The feature extractor is fixed .
• After adjustment , Enhanced ${\Phi }_F^1$ It can also form better characteristics to measure the loss ${\mathcal{L}}_{fm}^1$（ Will be used in the next step to enhance ）. Keep using ${\mathcal{L}}_{fm}^{k-1}$ To adjust ${\Phi }^k$, among $k\in 1,...,K$.

Be careful , We are only on the Internet ${\Phi }^k$ Converge to ${\mathcal{L}}_{fm}^{k-1}$ Time to build new losses ${\mathcal{L}}_{fm}^k$, Because frequently changing the lost space may make the training process unstable .

Through this self reinforcing strategy , A continuous optimization network with gradually enhanced feature metric consistency can be obtained

3. experiment

3.1 Experiments on simulated datasets

• Data sets ：

  • Middlebury and KITTI2015;Inria_SLFD and HCI
  • Degradation mode ：
    • Double triple down sampling （BIC）
    • Isotropic Gaussian kernel down sampling （IG）
    • Anisotropic Gaussian kernel down sampling （AG）
    • Isotropic Gaussian kernel JPEG Compress down sampling （IG JPEG）
    • Anisotropic Gaussian kernel JPEG Compress down sampling （AG JPEG）

• Evaluation indicators ：

  • 3 Pixel error （3PE）, The error of all areas exceeds 3 Pixel and exceeds the true value 5% Percentage of outliers of size ;
  • End point error （EPE）, The average absolute difference between the estimated parallax and the real parallax .

• The method of comparison ：

  • SGM
  • SR Preprocessing +BaseNet
    • RCAN+BaseNet
    • DAN+BaseNet
  • BsaeNet+ Other feature extractors
    • BaseNet+CL
    • BaseNet+AE

SR： Super resolution recovery , Unblinded SR Method RCAN, blind SR Method DAN

Other feature extractors ： To compare losses （Contrastive Loss,CL） Characteristic network of training , With an automatic encoder （Auto-Encoder,AE） As a feature network .

BaseNet They are all popular PSMNet. Use ADAM Solver optimizes the network （$\beta 1=0.9,\beta 2=0.999$） We set the learning rate to 0.001. The smoothing constraint of parallax is realized by weighted smoothness loss , namely ：

KaTeX parse error: \tag works only in display equations

therefore , The total loss function for all learning based solutions can be written as ：

KaTeX parse error: \tag works only in display equations

In style ,$\lambda$ It's the weighting factor ,${\mathcal{L}}_{pm/fm}$ Is the photometric loss of the first method , Or the corresponding characteristics of the second method and our method measure the loss . Phase in self enhancement strategy K The number is set to 3.

• result

  • Quantitative results



  • Qualitative results



3.2 Experiments on real datasets

• Data sets ： Asymmetric stereo pairs are manufactured by Huawei P30 Smartphone capture . The asymmetry factor is approximately equal to 3. After camera calibration and stereo correction , We captured... For indoor and outdoor scenes 30 For asymmetric stereo pairs . We divided them randomly 5 Yes as a test set , Others as training sets .

• result ：



4. Limitations and conclusions

• Limit ：
  • In addition to resolution , There may also be other types of asymmetry （ Such as color and brightness ）. Whether other types of asymmetric problems can be solved directly by extending the proposed method is still an open question .
• Conclusion ：
  • This paper reveals that the main challenge of unsupervised correspondence estimation from resolution asymmetric stereo images is photometric inconsistency . To overcome this challenge , We have achieved... In an efficient way Feature metric consistency , And introduced a Self reinforcing strategy To enhance this consistency . It is verified by comprehensive experiments , Our method shows excellent performance in dealing with various degradation between two views in practice .
