General view, serializer

1.DRF View

• Django REST framework Based on the Web Application development framework , Rapid development of REST API Interface application

• Provide serializers , Help realize serialization and deserialization

• Provide class view 、 The extension class 、 View set to simplify view writing

• Provide filtration 、 Paging and other functions

• Provide API Of Web Visual interface , Test interface

API agreement

• Use as much as possible https agreement , To compare safety
• Try to appear in the domain name api word
• Try to appear the version number in the path Such as ： /v1/users/users/
• Try to use nouns in the path
• Use the request method To represent the operation of resources
• Concatenate query strings in the path , Realize data filtering 、 Pagination 、 Sort, etc

2. establish Django

django-admin startproject  Project name

2.1 To configure settings

INSTALLED_APPS = [
    'django.contrib.admin',
    'django.contrib.auth',
    'django.contrib.contenttypes',
    'django.contrib.sessions',
    'django.contrib.messages',
    'django.contrib.staticfiles',
    'rest_framework', # drf frame
    'corsheaders',
    'user'
]

MIDDLEWARE = [
    'django.middleware.security.SecurityMiddleware',
    'django.contrib.sessions.middleware.SessionMiddleware',
    'django.middleware.common.CommonMiddleware',
    # 'django.middleware.csrf.CsrfViewMiddleware',
    'django.contrib.auth.middleware.AuthenticationMiddleware',
    'django.contrib.messages.middleware.MessageMiddleware',
    'django.middleware.clickjacking.XFrameOptionsMiddleware',
    'corsheaders.middleware.CorsMiddleware'
]

DATABASES = {

    'default': {

        'ENGINE': 'django.db.backends.mysql',
        'HOST':'localhost',
        'PORT':3306,
        'USER':'root',
        'PASSWORD':'123123',
        'NAME':'p6',
    }
}

CORS_ORIGIN_WHITELIST = [
    "http://localhost:8080",
]
CORS_ALLOW_CREDENTIALS = True
CORS_ALLOW_HEADERS = ("*")
CORS_ALLOW_METHODS = ("*")

2.2 Create model classes

The model needs to add time and update time , For simplicity
Create parent class ----> Create other models that inherit from this parent

from django.db import models


# Create your models here.

class BaseModel(models.Model):
    created_time = models.DateTimeField(auto_now_add=True)
    update_time = models.DateTimeField(auto_now=True)

#  Departmental table
class Department(BaseModel):
    name = models.CharField(" Department name ",max_length=30)

    def __str__(self):
        return self.name
    class Meta:
        db_table = "department"

#  Job list
class Duty(BaseModel):
    name = models.CharField(" Job title ",max_length=30)

    def __str__(self):
        return self.name
    class Meta:
        db_table = "duty"

#  The employee table
class Staff(models.Model):
    SEX_CHOICE = (
        (1,' male '),
        (2,' Woman ')
    )
    name = models.CharField(" full name ",max_length=30)
    sex = models.IntegerField(" Gender ",choices=SEX_CHOICE,default=1)
    phone = models.CharField(" cell-phone number ",max_length=11)
    email = models.EmailField(" mailbox ",max_length=60)
    department = models.ForeignKey(Department,on_delete=models.CASCADE,verbose_name=' department ')
    duty = models.ForeignKey(Duty,on_delete=models.CASCADE,verbose_name=' duty ')
    def __str__(self):
        return self.name
    class Meta:
        db_table = 'staff'

User This model class inherits django Packaged AbstractUser,
There is no mobile number on it , Last login time , So define yourself

# User Model class
from django.contrib.auth.models import AbstractUser
from django.utils import timezone
class User(AbstractUser):
    mobile = models.CharField(" cell-phone number ",max_length=11)
    last_login = models.DateTimeField(" Last login ",default=timezone.now)
    def __str__(self):
        return self.username
    class Meta:
        db_table = "user"

notes ： This model class must be migrated for the first time , Otherwise, an error will be reported

3. Serializer

3.1 Serialization definition ：

Turn the model class object into a dictionary , And then pass by Response To json character string ----- serialize

3.2 Deserialization

Put the front end of json String passing Request object , Turn to dictionary or similar dictionary , Then it is transformed into the object of the model class through the serializer ----- Deserialization

3.3 Serializer

from rest_framework import serializers
from .models import *

#  Department serializer
class DepartmentSerializer(serializers.Serializer):
    id = serializers.IntegerField(label="ID",read_only=True)
    # allow_null  Is it empty  allow_blank  Allow null  trim_whitespace  Truncate the space on both sides
    name = serializers.CharField(label=" Department name ",min_length=2,max_length=10,allow_null=True,
                                 allow_blank=True,trim_whitespace=True)

class DutySerializer(serializers.Serializer):
    id = serializers.IntegerField(label="ID", read_only=True)
    name = serializers.CharField(label=" Job title ", min_length=2, max_length=10, allow_null=True,
                                 allow_blank=True, trim_whitespace=True)

#  staff
class StaffSerializer(serializers.Serializer):
    id = serializers.IntegerField(label="ID",read_only=True)
    name = serializers.CharField(label=" Employee name ",min_length=2,max_length=10,allow_null=True,
                                 allow_blank=True,trim_whitespace=True)
    sex = serializers.IntegerField(label=" Gender ",default=1)
    phone = serializers.CharField(label=' cell-phone number ',min_length=11,max_length=11,allow_null=True,allow_blank=True,
                                  trim_whitespace=True)
    #  Foreign keys
    # queryset  Reverse query set   Deserialization
    department = serializers.PrimaryKeyRelatedField(queryset=Department.objects.all())
    duty = serializers.PrimaryKeyRelatedField(queryset=Duty.objects.all())

    #  Serialized method fields
    department_name = serializers.SerializerMethodField(read_only=True)
    # obj Employee model class object
    def get_department_name(self,obj):
        # obj.department  Department object
        return obj.department.name
    duty_name = serializers.SerializerMethodField(read_only=True)
    def get_duty_name(self,obj):
        return obj.duty.name

    #  data verification  attrs The dictionary from the front
    def validate(self, attrs):
        #  get data
        name = attrs.get("name")
        return attrs

    def create(self, validated_data):
        staff = Staff.objects.create(**validated_data)
        return staff
    #  rewrite update Method
    def update(self, instance, validated_data):
        instance.name = validated_data.get("name")
        instance.save()

        return instance

Common field types

Field	Field construction method
CharField	CharField(label=,min_length=2,max_length=10,allow_null=True,allow_blank=True,trim_whitespace=True)
IntegerField	IntegerField(label=“ID”,read_only=True)
PrimaryKeyRelatedField	PrimaryKeyRelatedField(queryset=Department.objects.all())
SlugField	SlugField(max_length=50, min_length=None, allow_blank=False) Regular fields , Verify the regular pattern [a-zA-Z0-9-]+
DecimalField	DecimalField(max_digits, decimal_places, coerce_to_string=None, max_value=None, min_value=None) max_digits: The maximum number of digits decimal_palces: Decimal place
TimeField	TimeField(format=api_settings.TIME_FORMAT, input_formats=None)
ImageField	ImageField(max_length=None, allow_empty_file=False, use_url=UPLOADED_FILES_USE_URL)

Option parameters

Parameter name	effect
max_length	Maximum length ： Output the maximum length check when deserializing
min_lenght	Minimum length ： Input minimum length check during deserialization
allow_blank/allow_null	Is it allowed to be empty ： Blank strings are allowed during deserialization , Not allowed by default
trim_whitespace	Truncate left and right white space characters , The default is True
max_value	minimum value ： Check the input maximum value in the inverse sequence
min_value	Maximum ： Input minimum value check during deserialization

---

General parameters

Parameter name	effect
read_only	This field is only used for serializing output , Default False
write_only	Indicates that this field is only used for deserializing input , Default false
required	Indicates that the field must be entered in deserialization , Default True
default	Use the default value when deserializing , If not specified , The default value when passing is 0
allow_null	Indicates whether the field is allowed to pass in None, Default False
validators	Validator , Define your own functions , Realize complex data verification
label	be used for HTML Exhibition API When the page is , The name of the field displayed
help_text	be used for HTML Exhibition API When the page is , Field help prompt information displayed
error_messages	A dictionary containing error numbers and information

a key :

• read-only: Display when serializing output , However, no verification is performed during deserialization verification
• write_only: Check during deserialization , However, this field is not output during serialization

3.4 ModelSerializer

class DepartmentModelSerializers(serializers.ModelSerializer):
    class Meta:
        model = Department
        fields = '__all__'
        read_only_fields = ["id",]


class DutyModelSerializers(serializers.ModelSerializer):
    class Meta:
        model = Duty
        fields = '__all__'
        read_only_fields = ["id",]

class StaffModelSerializers(serializers.ModelSerializer):
    department_name = serializers.SerializerMethodField(read_only=True)
    def get_department_name(self,obj):
        return obj.department.name
    duty_name = serializers.SerializerMethodField(read_only=True)
    def get_duty_name(self,obj):
        return obj.duty.name
    class Meta:
        model = Staff
        fields = "__all__"
        read_only_fields = ["id",]

and Serializer Difference

• Automatically generate a series of fields based on the model class
• Automatic generation based on model classes validators
• Default implementation update() and create() Method , You don't have to rewrite it
