Metartc5.0 API programming guide (I)

summary

metaRTC5.0 edition API Refactored , This article will introduce webrtc Transfer call process and examples .

metaRTC5.0 Version provides C++ And pure C Two interfaces .

pure C Interface YangPeerConnection

The header file :include/yangrtc/YangPeerConnection.h

typedef struct{
	void* conn;
	YangAVInfo* avinfo;
	YangStreamConfig streamconfig;
}YangPeer;

typedef struct {
	YangPeer peer;
// initialization
	void (*init)(YangPeer* peer);
// from stun The server obtains the Internet ip And port
	int32_t (*requestStunServer)(YangPeer *peer);
// Generate local end sdp
	int32_t (*createOffer)(YangPeer* peer, char **psdp);
// In exchange for sdp when , Get peer sdp after , Generate local sdp Back to the opposite end
	int32_t (*createAnswer)(YangPeer* peer,char* answer);
//http Listening signaling after listening to the request , Generate http Of answer sdp
	int32_t (*createHttpAnswer)(YangPeer* peer,char* answer);
// start-up metaRTC Start webrtc
	int32_t (*setRemoteDescription)(YangPeer* peer,char* sdp);
// Encapsulates the srs/zlm Signaling exchange and start metaRTC
	int32_t (*connectSfuServer)(YangPeer* peer);
// close metartc
	int32_t (*close)(YangPeer* peer);
// Live connection
	int32_t (*isAlive)(YangPeer* peer);
// Whether it is connected
	int32_t (*isConnected)(YangPeer* peer);
// Push audio stream
	int32_t (*on_audio)(YangPeer* peer,YangFrame* audioFrame);
// Push video stream
	int32_t (*on_video)(YangPeer* peer,YangFrame* videoFrame);
// push datachannel news
	int32_t (*on_message)(YangPeer* peer,YangFrame* msgFrame);
// send out rtc System message
	int32_t (*sendRtcMessage)(YangPeer* peer, YangRtcMessageType mess);
}YangPeerConnection;

C++ Interface YangPeerConnection2

The header file :include/yangrtc/YangPeerConnection2.h

class YangPeerConnection2 {
public:
	YangPeerConnection2(YangAVInfo* avinfo,YangStreamConfig* streamConfig);
	virtual ~YangPeerConnection2();
	YangStreamConfig* streamConfig;
public:
// initialization
	void init();
// from stun The server obtains the Internet ip And port
	int32_t requestStunServer();
// Generate local end sdp
	int32_t createOffer( char **psdp);
// In exchange for sdp when , Get peer sdp after , Generate local sdp Back to the opposite end
	int32_t createAnswer(char* answer);
//http Listening signaling after listening to the request , Generate http Of answer sdp
	int32_t createHttpAnswer(char* answer);
// start-up metaRTC Start webrtc
	int32_t setRemoteDescription(char* sdp);
// Encapsulates the srs/zlm Signaling exchange and start metaRTC
	int32_t connectSfuServer();
// close metartc
	int32_t close();
// Live connection
	int32_t isAlive();
// Whether it is connected
	int32_t isConnected();
// Push audio stream
	int32_t on_audio(YangFrame* audioFrame);
// Push video stream
	int32_t on_video(YangFrame* videoFrame);
// push datachannel news
	int32_t on_message(YangFrame* msgFrame);
// send out rtc System message
	int32_t sendRtcMessage( YangRtcMessageType mess);

private:
	YangPeerConnection m_conn;
};

Interface call process and examples

Configuration parameters

Parameter in YangStreamConfig and YangAVInfo Two struct in
libmetartc5/src/yangp2p/YangP2pRtc.cpp Code sample in

void g_p2p_rtcrecv_sendData(void* context,YangFrame* frame){
	YangP2pRtc* rtcHandle=(YangP2pRtc*)context;
    rtcHandle->publishMsg(frame);
}
void g_p2p_rtcrecv_sslAlert(void* context,int32_t uid,char* type,char* desc){
	if(context==NULL||type==NULL||desc==NULL) return;
	YangP2pRtc* rtc=(YangP2pRtc*)context;

	if(strcmp(type,"warning")==0&&strcmp(desc,"CN")==0){
		rtc->removePeer(uid);
	}
}
void g_p2p_rtcrecv_receiveAudio(void* user,YangFrame *audioFrame){
	if(user==NULL || audioFrame==NULL) return;
	YangP2pRtc* rtcHandle=(YangP2pRtc*)user;
	rtcHandle->receiveAudio(audioFrame);
}
void g_p2p_rtcrecv_receiveVideo(void* user,YangFrame *videoFrame){
	if(user==NULL || videoFrame==NULL) return;
    YangP2pRtc* rtcHandle=(YangP2pRtc*)user;
	rtcHandle->receiveVideo(videoFrame);
}

void g_p2p_rtcrecv_receiveMsg(void* user,YangFrame *msgFrame){
	if(user==NULL) return;

	YangP2pRtc* rtcHandle=(YangP2pRtc*)user;
	rtcHandle->receiveMsg(msgFrame);
}

int32_t YangP2pRtc::connectPeer(int32_t nettype, string server,int32_t localPort,int32_t pport,string app,string stream) {
	int32_t ret = 0;
	YangPeerConnection* sh=(YangPeerConnection*)calloc(sizeof(YangPeerConnection),1);

	strcpy(sh->peer.streamconfig.app,app.c_str());
	sh->peer.streamconfig.streamOptType=Yang_Stream_Both;

	strcpy(sh->peer.streamconfig.remoteIp,server.c_str());
	sh->peer.streamconfig.remotePort=pport;

	m_clientUid=m_uidSeq++;
	strcpy(sh->peer.streamconfig.stream,stream.c_str());
	sh->peer.streamconfig.uid=m_clientUid;

	sh->peer.streamconfig.isServer=0;
	sh->peer.streamconfig.localPort=localPort;

	sh->peer.streamconfig.recvCallback.context=this;
	sh->peer.streamconfig.recvCallback.receiveAudio=g_p2p_rtcrecv_receiveAudio;
	sh->peer.streamconfig.recvCallback.receiveVideo=g_p2p_rtcrecv_receiveVideo;
	sh->peer.streamconfig.recvCallback.receiveMsg=g_p2p_rtcrecv_receiveMsg;

}

pure C Interface call example

YangPeerConnection* sh=(YangPeerConnection*)calloc(sizeof(YangPeerConnection),1);
.... Configuration parameters ..
// Pass in parameters to YangPeerConnection	memcpy(&sh->peer.streamconfig.rtcCallback,&m_context->rtcCallback,sizeof(YangRtcCallback));
	sh->peer.avinfo=&m_context->avinfo;

//1. initialization
	yang_create_peerConnection(sh);
    sh->init(&sh->peer);
//2. Generate local end sdp,srs and zlm This step is not required for the call ,p2p need
	char* localSdp;
	char* remoteSdp=(char*)calloc(12*1000,1);
     //stun request , Connect srs and zlm Unwanted
	if(m_context->avinfo.rtc.hasIceServer){
	if(sh->requestStunServer(&sh->peer)!=Yang_Ok) yang_error("request stun server fail!");
	}
	sh->createOffer(&sh->peer, &localSdp);

//3. Get the opposite end or sfu Server's sdp after , start-up metartc
   // Point to point call
    ret=sh->setRemoteDescription(&sh->peer,remoteSdp);
   //srs/zlm call , It's sealed inside sdp Exchange and metartc start-up
    ret=sh->connectSfuServer(&sh->peer)

//4. After executing the program , Destroy object
		sh->close(&sh->peer);
		yang_destroy_peerConnection(sh);
		yang_free(sh);

C++ Interface call example

.... Parameter configuration ..
//1. initialization
YangPeerConnection2* sh=new YangPeerConnection2(&m_context->avinfo,&streamconfig);
sh->init();

//2. Generate local end sdp, Be careful ：srs and zlm This step is not required for the call
	char* localSdp;
	char* remoteSdp=(char*)calloc(12*1000,1);
     //stun request , Connect srs and zlm Unwanted
	if(m_context->avinfo.rtc.hasIceServer){
	if(sh->requestStunServer()!=Yang_Ok) yang_error("request stun server fail!");
	}
	sh->createOffer(&localSdp);


//3. Get the opposite end or sfu Server's sdp after , start-up metartc
//srs/zlm call
    ret = sh->connectSfuServer();
//p2p call
    ret=sh->setRemoteDescription(remoteSdp);

//4. After executing the program , Destroy object
        sh->close();
		yang_delete(sh);
