Ad22 Gerber files Click to open the Gerber step interface. Official solutions to problems
2022-06-27 05:03:00 【<!-- Xiao Zhang -- & gt;】
ad The official tutorial ( Loading is a little slow. Wait patiently )
https://www.altium.com/cn/documentation/altium-designer/workspacemanager-dlg-gerberx2propertiesformgerber-x2-setup-ad
problem : It opens at gerber files I want this one
Above is figure 1
But this one
The above figure is figure 2
The official said :gerber files Click to open figure 1 ,gerber x2 files Click to open figure 2
Now I turn on gerber files Also figure 2 ( Maybe it was updated )
I saw this sentence in the official picture below When enabled , new Gerber X2 Setup dialog Used to define the... To be generated Gerber File settings .


resolvent :
1. Click on the pinion to enter the preferences -system-general-advance
2. Enter... In the search box gerber ( Auto search )- Point to the arrow One Arrow removal - Click on close- Click OK to restart the software ,ok
