Redis cluster setup (Windows)

Redis High availability

Generally speaking , Data modification and write delete operations will consume a lot of resources , And the operation of query consumes relatively small resources , But the query operation will be more frequent than the addition, deletion and modification , So we can use clustering to help us achieve Redis High availability , Here are two very common ways to implement , They are master-slave replication and sentinel mode .

Master slave copy

First of all, we are right redis Operate on the configuration file , We need to make the port number of our primary node different from that of other nodes . Otherwise, it will happen redis Start second retreat . We turn on redis Directory folder for , Will be one of the
This is redis To start the default configuration file, we need to configure the following file . We will 6379 Master node .
Copy this folder . Copy two copies as slave nodes . We use the master node to write and change If it is a query operation, it will hit the slave node .

Let's change the port numbers of the other two Change it to 6380 6381 As a slave node . then Link with the server Input
slaveof 127.0.0.1 6379 It means to recognize the Lord Think of this node as master The other one uses the same operation . This completes the construction of a simple master-slave mode .

We input at the client of the master node set a 6
In the slave node get To this a Value however We Try changing this value It is found that the slave node cannot modify the value .

Sentinel mode

First, let's think about why we need sentinel mode ？
When our master-slave replicates the slave node g When it's time , Our master node can still complete the function of the slave node ,, We can increase the number of slave nodes later to reduce the pressure of these nodes , however , If it's the master node g What about it ？ Then the whole cluster will hang up , therefore We need a solution when the primary node is gone ,redis Sentinel mode is used .
Sentinel mode uses several other redis Server to monitor the running redis colony , It will also monitor these sentinels . When our master node g After that , The Sentinels will vote , Elect a new master node , Then attach other slave nodes to the master node , The original master node becomes offline .

How to achieve ？

First, the previous redis Don't worry about the master-slave replication mode We just need to build three new sentinels to monitor them , We are redis Create a new config
Content

#  This is Redis6379 Configure the content , Add other files in the same way, and then change the port ,26380, and  26381.

# At present Sentinel The port on which the service runs
port 26380
#  The main server the sentry listens to
sentinel monitor mymaster 127.0.0.1 6381 2
# 3s Inside mymaster No response , Think mymaster It's down.
sentinel down-after-milliseconds mymaster 3000
# If 10 Seconds later ,mysater It still hasn't started , Start up failover
sentinel failover-timeout mymaster 10000
#  When performing a failover ,  At most 1 Two slave servers synchronize the new master server at the same time
sentinel config-epoch mymaster 1

Then start Because our master node contains information about other slave nodes , So our Sentry can also monitor those slave nodes , Here, you only need to configure the master node .

So sentinel mode is activated .
