Implementation of handwritten numeral code recognition (pytorch)

Data preview ：

import pandas
df=pandas.read_csv('C:\\Users\\HP\\Desktop\\mnist_train.csv',header=None)
df.head()



MNIST Each row of data contains 785 It's worth . The first value is the number represented by the image , The rest 784 The first value is the image （ Size is 28 Pixels × 28 Pixels ） Pixel value .¶

We can use info() The function view DataFrame Overview of

df.info()

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 60000 entries, 0 to 59999
Columns: 785 entries, 0 to 784
dtypes: int64(785)
memory usage: 359.3 MB



The above results tell us , The DataFrame Yes 60 000 That's ok . This corresponds to 60 000 A training image . meanwhile , We can also confirm that each line has 785 It's worth .¶

Let's convert a row of pixel values into an actual image to visually view .

We use the universal matplotlib Library to display images . In the following code , We import matplotlib Library pyplot package

Complete code ：

####  Import library
import torch
import torch.nn as nn
import pandas
import matplotlib.pyplot as plt
from torch.utils.data import Dataset # yes pytorch How to load and import data
'''------------ Construct neural network class ------------'''
class Classifier(nn.Module):#nn.Module Is the parent of all classes
    """ classifier """
    def __init__(self):
        # initialization pytorch Parent class
        super().__init__()
        # Define the neural network layer
        self.model=nn.Sequential(
        nn.Linear(784,200),
        nn.Sigmoid(),
        nn.Linear(200,10),
        nn.Sigmoid()
        )
        # Create a loss function ( Mean square error )
        self.loss_function=nn.MSELoss()
        # Create optimizer , Use simple gradient descent
        self.optimiser=torch.optim.SGD(self.parameters(),lr=0.01)
        ''' visualization '''
        # Counters and lists for recording training progress
        self.counter=0
        self.progress=[]
    def forward(self,inputs):
        # Run the model directly
        return self.model(inputs)

    """ Trainer """
    def train(self,inputs,targets):
        # Calculate the output value of the network
        outputs=self.forward(inputs)
        # Calculate the loss value
        loss=self.loss_function(outputs,targets)
        """ The next step is to use the loss to update the link weight of the network """
        # The gradient goes to zero , Back propagation , And update the weight
        self.optimiser.zero_grad()
        loss.backward()
        self.optimiser.step()
        """ visualization """
        # every other 10 Increase the value of the counter once for each training sample , And add the loss value to the end of the list
        self.counter+=1
        if(self.counter%10==0):
            self.progress.append(loss.item())# Use here item() The function of is just to facilitate the expansion of a single valued tensor , Get the numbers inside
            pass
        # Every time 10000 Print the counter value after training , In this way, you can know the speed of training progress
        if(self.counter%10000==0):
            print("counter=",self.counter)
            pass
    """ Plot the loss value """
    def plot_progress(self):
        df=pandas.DataFrame(self.progress,columns=['loss'])
        df.plot(ylim=(0,1.0),figsize=(16,8),alpha=0.1,marker='.',grid=True,yticks=(0,0.25,0.5))
        pass
'''------------- establish MnistDataset class --------------'''
class MnistDataset(Dataset):
    def __init__(self,csv_file):
        self.data_df=pandas.read_csv(csv_file,header=None)
        pass
    def __len__(self):
        return len(self.data_df)
    def __getitem__(self,index):
        # Target image （ label ）
        label=self.data_df.iloc[index,0]
        target=torch.zeros((10))
        target[label]=1.0
        # Image data , The value range is 0~255, Standardize to 0~1
        image_values=torch.FloatTensor(self.data_df.iloc[index,1:].values)/255.0
        # Return label , Image data tensor and target tensor
        return label, image_values, target
    pass
    """ visualization """
    def plot_image(self,index):
        arr=self.data_df.iloc[index,1:].values.reshape(28,28)
        plt.title("label = " + str(self.data_df.iloc[index,0]))
        plt.imshow(arr,interpolation='none',cmap='Blues')
        pass
# Check whether everything is normal so far
mnist_dataset=MnistDataset('C:\\Users\\HP\\Desktop\\mnist_train.csv')
#mnist_dataset.plot_image(9)
""" Training classifier """
# Creating neural networks

C=Classifier()
# stay MNIST Data sets train neural networks
for label, image_data_tensor, target_tensor in mnist_dataset:
    C.train(image_data_tensor,target_tensor)
    pass
#  Draw classifier loss value
C.plot_progress()
#  load MNIST Test data
mnist_test_dataset = MnistDataset('C:\\Users\\HP\\Desktop\\mnist_test.csv')

counter= 10000
counter= 20000
counter= 30000
counter= 40000
counter= 50000
counter= 60000

#  Draw classifier loss value
C.plot_progress()

Now we have a network after training , Image classification is available . We will switch to include 10 000 Of an image MNIST Test data set . These are images that our neural network has never seen . Let's use a new Dataset Object load dataset

#  load MNIST Test data
mnist_test_dataset = MnistDataset('C:\\Users\\HP\\Desktop\\mnist_test.csv')
#  Pick an image
record = 19
#  Draw images and labels
mnist_test_dataset.plot_image(record)

Let's see how the trained neural network judges this image . The following code continues to use section 20 Image and extract the pixel value as image_data. We use forward() Function transfers the image and passes it through neural network

image_data = mnist_test_dataset[record][1]
#  Call the trained neural network
output = C.forward(image_data)
#  Draw the output tensor
pandas.DataFrame(output.detach().numpy()).plot(kind='bar',
legend=False, ylim=(0,1))
