Et5.0 configuring Excel

Usage mode ：

Write a watch

open Excel In the catalog UnitConfig.xlsx

A1： According to whether there is AppType.ClientH Distinguish whether the client or server loads the configuration
C3： Start reading data here
Reading and writing rules ：
The first 3 That's ok ： This line does not read the contents of the comment line , # The first column is not read , s This field is server specific at the beginning
The first 4 That's ok ： The content of this line is used as the name of the field , Do not empty
The first 5 That's ok ： The content of this line is the type of field , Do not empty
The first 6 Line and below ： Configuration data

nesting

When you need to nest in a list , I think you should reexamine your logic
If you really don't want to think about it , Be sure to nest ！ Then you can open another watch , This table is nested data , Then fill in the data of the nested table ID！
Need nested tables ：

Nested tables ：

About this way to visit , You can get the complete data , It's also extension friendly ：

var testConfig = Game.Scene.GetComponent<ConfigComponent>().Get(typeof(TestConfig),1001) as TestConfig;
var test2 = Game.Scene.GetComponent<ConfigComponent>().Get(typeof(Test2Config), testConfig.a);

Access configuration data

//  Read  TestConfig  Type all data
var array =  Game.Scene.GetComponent<ConfigComponent>().GetAll(typeof(TestConfig));
foreach (TestConfig config in array)
{

	Log.Debug($"{
      config.a}");
}

matters needing attention ：

id Fields are indispensable , Can't remove id Field

Click export client configuration or server configuration to report an error , This is because you are opening in exclusive mode Excel As a result of , Close the Excel Just fine

There is blank data in the readable field , Field data cannot be blank , Something must be written
Of course, you think it's troublesome and not in line with your habits , You can also modify the source code to read blank data and directly give a default value
But I don't approve of it . You can directly query the value by writing it directly on the table , Better for reading .
And when others read it, they won't wonder why it's blank

Deleted , Not completely deleted , Press down delete Deleted yellow column , But in fact, when reading, you will still read , You need to delete cells to read normally

Generate results ：

Click export client configuration or export server configuration

If there is no error, the system will ET\Unity\Assets\Res\Config The folder generates the corresponding configuration data
And in
Assets/Model/Module/Demo/Config
Assets/Hotfix/Module/Demo/Config
Server/Model/Module/Demo/Config
Generate configuration classes under the directory

Module source code ：

Editor Extension

Catalog ：ET\Unity\Assets\Editor\ExcelExporterEditor\ExcelExporterEditor.cs
Modify the class generation directory , The following path can be modified according to its own location ：

	private void OnGUI()
	{

		try
		{

			const string clientPath = "./Assets/Res/Config";

			if (GUILayout.Button(" Export client configuration "))
			{

				this.isClient = true;

				ExportAll(clientPath);

				ExportAllClass(@"./Assets/Model/Module/Demo/Config", "namespace ETModel\n{\n");
				ExportAllClass(@"./Assets/Hotfix/Module/Demo/Config", "using ETModel;\n\nnamespace ETHotfix\n{\n");

				Log.Info($" Export client configuration complete !");
			}

			if (GUILayout.Button(" Export server configuration "))
			{

				this.isClient = false;

				ExportAll(ServerConfigPath);

				ExportAllClass(@"../Server/Model/Module/Demo/Config", "namespace ETModel\n{\n");

				Log.Info($" The export server configuration is completed !");
			}
        }
		catch (Exception e)
		{

			Log.Error(e);
		}
	}

The field types supported by the extension configuration table , You need to support more types. Just add them here ：

	private static string Convert(string type, string value)
	{

		switch (type)
		{

			case "int[]":
			case "int32[]":
			case "long[]":
				return $"[{
      value}]";
			case "string[]":
				return $"[{
      value}]";
			case "int":
			case "int32":
			case "int64":
			case "long":
			case "float":
			case "double":
				return value;
			case "string":
				return $"\"{
      value}\"";
			default:
				throw new Exception($" This type is not supported : {
      type}");
		}
	}

Configuration is loaded

Configuration components ： ConfigComponent.cs
Traverse all configuration types ,BeginInit Add to cache after initialization

		public void Load()
		{

			this.allConfig.Clear();
			List<Type> types = Game.EventSystem.GetTypes();

			foreach (Type type in types)
			{

				object[] attrs = type.GetCustomAttributes(typeof (ConfigAttribute), false);
				if (attrs.Length == 0)
				{

					continue;
				}

				ConfigAttribute configAttribute = attrs[0] as ConfigAttribute;
				//  Only the specified configuration is loaded
				if (!configAttribute.Type.Is(AppType.ClientH))
				{

					continue;
				}

				object obj = Activator.CreateInstance(type);

				ACategory iCategory = obj as ACategory;
				if (iCategory == null)
				{

					throw new Exception($"class: {
      type.Name} not inherit from ACategory");
				}
				iCategory.BeginInit();
				iCategory.EndInit();

				this.allConfig[iCategory.ConfigType] = iCategory;
			}
		}

Configuration initialization

Configure each row as a class data , Deserialization json Save to dictionary

		public override void BeginInit()
		{

			this.dict = new Dictionary<long, IConfig>();

			string configStr = ConfigHelper.GetText(typeof (T).Name);

			foreach (string str in configStr.Split(new[] {
     "\n" }, StringSplitOptions.None))
			{

				try
				{

					string str2 = str.Trim();
					if (str2 == "")
					{

						continue;
					}
					T t = ConfigHelper.ToObject<T>(str2);
					this.dict.Add(t.Id, t);
				}
				catch (Exception e)
				{

					throw new Exception($"parser json fail: {
      str}", e);
				}
			}
		}
