Kubernetes basic self-study series | introduction to ingress API

Video source ：B standing 《2021 At the end of the year, strive to build Kubernetes Introduction to mastery - 2022 Happy appetizer of the year 》

Organize the teacher's course content and test notes while studying , And share it with you , Infringement is deleted , Thank you for your support ！

---

Information

Ingress-Nginx github Address ：
​​ ​https://github.com/kubernetes/ingress-nginx​​

Ingress-Nginx Official website ：
​​ ​https://kubernetes.github.io/ingress-nginx/​​

Deploy Ingress-Nginx

Log in and copy





       $ kubectl  apply -f mandatory.yaml


$ kubectl  apply -f service-nodeport.yaml







1.


2.



Ingress HTTP Agent access

deployment、Service、Ingress Yaml file

Log in and copy





       apiVersion: extensions/v1beta1


kind: Deployment


metadata:


  name: nginx-dm


spec:


  replicas: 2


  template:


    metadata:


      labels:


        name: nginx


    spec:


      containers:


        - name: nginx


          image: wangyanglinux/myapp:v1


          imagePullPolicy: IfNotPresent


          ports:


            - containerPort: 80


---


apiVersion: v1


kind: Service


metadata:


  name: nginx-svc


spec:


  ports:


    - port: 80


      targetPort: 80


      protocol: TCP


  selector:


    name: nginx


---


apiVersion: extensions/v1beta1


kind: Ingress


metadata:


  name: nginx-test


spec:


  rules:


    - host: www1.hongfu.com


      http:


        paths:


        - path: /


          backend:


            serviceName: nginx-svc


            servicePort: 80







1.


2.


3.


4.


5.


6.


7.


8.


9.


10.


11.


12.


13.


14.


15.


16.


17.


18.


19.


20.


21.


22.


23.


24.


25.


26.


27.


28.


29.


30.


31.


32.


33.


34.


35.


36.


37.


38.


39.


40.


41.


42.


43.



Ingress HTTPS Agent access

Create certificate , as well as cert storage

Log in and copy





       openssl req -x509 -sha256 -nodes -days 365 -newkey rsa:2048 -keyout tls.key -out tls.crt -subj "/CN=nginxsvc/O=nginxsvc"


kubectl create secret tls tls-secret --key tls.key --cert tls.crt







1.


2.



deployment、Service、Ingress Yaml file

Log in and copy





       apiVersion: extensions/v1beta1


kind: Ingress


metadata:


  name: nginx-test


spec:


  tls:


    - hosts:


      - ssl.hongfu.com


      secretName: tls-secret


  rules:


    - host: ssl.hongfu.com


      http:


        paths:


        - path: /


          backend:


            serviceName: nginx-svc


            servicePort: 80







1.


2.


3.


4.


5.


6.


7.


8.


9.


10.


11.


12.


13.


14.


15.


16.


17.



Nginx Conduct BasicAuth

Log in and copy





       yum -y install httpd


htpasswd -c auth foo


kubectl create secret generic basic-auth --from-file=auth







1.


2.


3.



Log in and copy





       apiVersion: extensions/v1beta1


kind: Ingress


metadata:


  name: auth.hongfu.com


  annotations:


    nginx.ingress.kubernetes.io/auth-type: basic


    nginx.ingress.kubernetes.io/auth-secret: basic-auth


    nginx.ingress.kubernetes.io/auth-realm: 'Authentication Required - foo'


spec:


  rules:


  - host: auth.hongfu.com


    http:


      paths:


      - path: /


        backend:


          serviceName: nginx-svc


          servicePort: 80







1.


2.


3.


4.


5.


6.


7.


8.


9.


10.


11.


12.


13.


14.


15.


16.


17.



Nginx Rewrite

name	describe	value
nginx.ingress.kubernetes.io/rewrite-target	The destination of the traffic must be redirected URI	strand
nginx.ingress.kubernetes.io/ssl-redirect	Indicates whether the location section is accessible only SSL（ When Ingress When the certificate is included, it defaults to True）	Boolean
nginx.ingress.kubernetes.io/force-ssl-redirect	Even if Ingress not enabled TLS, Also force redirection to HTTPS	Boolean
nginx.ingress.kubernetes.io/app-root	Definition Controller Application root that must be redirected , If it's in '/' In the context of	strand
nginx.ingress.kubernetes.io/use-regex	instructions Ingress Whether the path defined on uses a regular expression	Boolean

Log in and copy





       apiVersion: extensions/v1beta1


kind: Ingress


metadata:


  name: rew.hongfu.com


  annotations:


    nginx.ingress.kubernetes.io/rewrite-target: https://www.baidu.com


spec:


  rules:


  - host: rew.hongfu.com


    http:


      paths:


      - path: /


        backend:


          serviceName: nginx-svc


          servicePort: 80







1.


2.


3.


4.


5.


6.


7.


8.


9.


10.


11.


12.


13.


14.


15.
