SQL optimizer parsing | youth training camp notes

This is my participation 「 The Fourth Youth Training Camp 」 The third part of note creation activities 1 God

One 、 Big data system and SQL

1、SQL Process flow

1.1 Parser

●String -> AST (Abstruct Syntax Tree)：

• Lexical analysis : Split string , Get the key words 、 Numerical constants 、 String constant 、 Operation symbols, etc token
• Syntax analysis : take token form ASTnode, And finally get one AST

● Realization ： Recursive descent (ClickHouse),Flex and Bison (PostgreSQL),JavaCC (Flink),Antlr (Presto,Spark)

1.2 Analyzer and Logical Plan

● Analyzer：

• Check and bind Database, Table, Column Meta information
• SQL Check the legitimacy of , such as min/max/avg The input of is a value
• AST -> Logical Plan

● Logical Plan：

• Describe logically SQL Corresponding step-by-step calculation operation
• Calculation operation : operator ( operator )

1.3 Physical Plan and Executor

● Physical Plan: Execution plan subtree

• The goal is : Minimize network data transmission
• Use the physical distribution of the data on ( Data affinity )
• increase Shuffle operator

● Executor

• Stand alone in parallel : cache,pipeline, SIMD
• Multiprocessor parallel : One fragment Corresponding to multiple instances

1.4 summary

• One SQL rules big data all

• SQL You need to go through Parser,Analyzer,Optimizer and Executor To deal with

• Query optimizer is the brain of database , In the big data scenario, it is very important for query performance

• The query optimizer needs to be aware of data distribution , Make full use of data affinity

• The query optimizer splits the logical plan into multiple physical plan segments according to the goal of minimizing network data transmission

Two 、 Common query optimizers

2.1 Query optimizer classification

2.2 RBO（Rule-based optimizer）

2.2.1 Relational algebra

• Operator ：Select Project Join Rename Union
• Equivalent transformation ： Associative law 、 Commutative law 、 Transitivity

2.2.2 Optimization principle

2.2.3 RBO- Column cut

• Scan the required columns in the table , Not all of them

2.2.4 RBO- Predicate push-down

• where The expression of is a predicate . Predicates filter data as soon as possible , To reduce overhead 2（ Conditions ：join yes inter）

2.2.5 RBO- Pass closures

• According to the expression equivalence , Filter conditions , A new filtering condition is derived

2.2.6 RBO-Runtime Filter

To a join If you can filter unnecessary data in advance at the query end , Can reduce overhead

• min-max The shortcomings of ： The scope must be close
• in-list： Just scan in-list The data in . shortcoming ： When there are many sets ,in-list Also great
• bloom filter： characteristic ： The size does not change with the size of the set , Fixed size , Give a number to judge whether it is

2.2.7 summary

• Main stream RBO Generally, there are hundreds of optimization rules based on experience induction
• advantage : Implement a simple , Fast optimization speed
• shortcoming : There is no guarantee of an optimal execution plan

2.3 CBO（Cost-based optimizer）

2.3.1 CBO- Concept

△ Use a model to estimate the cost of implementing the plan , Choose the least expensive execution plan

• The cost of executing the plan is equal to the sum of the execution costs of all operators
• adopt RBO obtain ( all ) Possible equivalent execution plans

△ Operator cost :CPU, Memory , disk IO, The Internet I/O Equal price

Statistics + Derivation rules → Calculate the operator cost → Calculate the cost of executing the plan → Execution plan enumeration

2.3.2 CBO- Statistics

Raw table statistics

• Table or partition level : Row number 、 Average row size 、 How many bytes does the table occupy in the disk
• Column level : min、max、num nulls、num not nulls、num distinct value(NDV)、histogram etc.

Derive statistics

• Selection rate ( selecthwty)： For a certain filter condition, how much data will be returned from the table
• base ( careinality )： In query plan, it often refers to the number of rows that the operator needs to process

2.3.2.1 CBO- How to collect statistical information

• stay DDL Specify the statistical information to be collected , The database collects or updates statistics when data is written

  CREATE TABLE REGION( R_ REGIONKEY INT NOT NULL, R NAME CHAR(25) NOT NULL, R_ COMMENT VARCHAR(152) ) DUPLICATE KEY(R_ REGIONKEY) DISTRIBUTED BY HASH(R_ REGIONKEY) BUCKETS 1 PROPERTIES (" sotumnselelR w");

• Do it manually explain analyze statement, Start the database to collect or update statistical information

ANALYZE TABLE table_name COMPUTE STATISICS FOR COLUMNS column-name1,column-name2....

• Dynamic sampling

SELECT count(*) FROM table_name

2.3.2.2 CBO- Statistical information derivation rules

• Filter Selectivity
  • AND Conditions :fs(a AND b)=fs(a)* fs(b)
  • OR Conditions : fs(a OR b) = fs(a) + fs(b) - (fs(a) * fs(b))
  • NOT Conditions : fs(NOT a)= 1.0 - fs(a)
  • It's equal to the condition (x = literal )
    • literal < min && literal > max : 0
    • 1/NDV
• Less than condition (x < literal )
  • literal<min:0
  • literal>max:1
  • (literal-min)/(max-min)

2.3.3 CBO- Execution plan enumeration

• Single table scan : An index scan ( Random I/O) vs Full table scan ( The order IO)
  • If the data queried is very unevenly distributed , Index scanning may not be as good as full table scanning
• Join The implementation of the : Hash Join Vs. SortMerge Join
• The two tables Hash Join : How to identify small tables by building hash tables with small tables ?
• Multiple tables Join :
  • Which connection sequence is the best ?
  • Whether to explore each combination ?
• N A table joins , just left-deep tree It's almost N! A connection sequence
  • e.g. N= 10-> in total 3, 628, 800 Connection order

2.3.4 CBO Summary

• CBO Use cost models and statistics to estimate the cost of implementing the plan
• CBO Use greedy or dynamic programming algorithm to find the optimal execution plan
• In the big data scenario CBO It is very important for query performance

2.4 Summary

• Main stream RBO Realization - Generally, there are hundreds of optimization rules based on experience induction
• RBO Implement a simple , Fast optimization speed
• RBO There is no guarantee of an optimal execution plan
• CBO Use cost models and statistics to estimate the cost of implementing the plan
• CBO Use greedy or dynamic programming algorithm to find the optimal execution plan
• In the big data scenario CBO It is very important for query performance

3、 ... and 、 Community open source practice

3.1 Apache Calcite overview

• One size fitsall： A unified SQL Query engine
• modularization , pluggable , Stable and reliable
• Support heterogeneous data models
  • Relational type
  • Semi structured
  • streaming
  • Geospatial data
• built-in RBO and CBO

3.1.1 Calcite RBO

HepPlanner

• Optimize the rules (Rule)
  • Pattern : Match expression subtree
  • Equivalent transformation : Get a new expression
• Built in 100+ Optimize the rules
• Four matching rules
  • ARBITRARY/DEPTH FIRST : Depth first
  • TOP DOWN : Topological order
  • BOTTOM_ UP : And TOP_ DOWN contrary
• Traverse all rule , Until there is no rule Can be triggered
• Fast optimization speed , Implement a simple , But there is no guarantee of optimality

3.1.2 Calcite CBO

VolcanoPlanner

• be based on Wolcano/Cascade frame
• The cost optimal Hypothesis
• Memo : Store candidate execution plans
  • Group : Equivalent plan set
• Top-down Dynamic planning search
• application Rule Search for candidate plans
• Memo
  • The essence : AND/OR graph
  • Sharing subtrees reduces memory overhead
• Group winner: The best plan at present
• prune ： Reduce search space
• Top-down Traverse ： choice winner Build the best execution plan

3.1.3 Summary

• Mainstream query optimizers include RBO and CBO
• Apache Calcite It is a very popular query optimizer in the field of big data
• Apache Calcite RBO Many optimization rules are defined , Use pattern Matching subtree , Perform equivalent transformation
• Apache Calcite CBO be based on Volcano/Cascade frame
• Volcano/Cascade The essence of : Memo、 Dynamic programming 、 prune

Four 、 Cutting edge trends

4.1 AI4DB

• Self configuration
  • Intelligent tuning ( OtterTune , QTune )
  • Load forecasting / Dispatch
• Self diagnosis and self healing : Error recovery and migration
• Self optimization :
  • Statistical information estimation ( Learned cardinalities )
  • Cost estimate
  • Learning optimizer ( IBM DB2 LEQ )
  • Indexes / View recommendation

4.2 DB4AI

• Embedded artificial intelligence algorithm ( MLSQL,SOLFlow )
• Embedded machine learning framework ( SparkML,Alink,dl-on-fink )

4.3 Summary

• Big data entrepreneurship is in full swing , SQL Query optimizer is still an essential and important component
• Evolution of engine architecture 、 Cloud native 、 Lake warehouse integration, etc SQL Query optimizer has new requirements and challenges
• AI The blessing , Learning query optimizers are evolving

5、 ... and 、 summary
