Compile Caffe's project using cmake

Use CMake compile Caffe Project

Recently I was compiling a Caffe Project , This dependency is always missing at compile time , That dependency , Here are a few lessons learned .

1. Caffe You have to use CMake To compile

I started with what the author provided Makefile To compile Caffe, As a result, when compiling my project , There will always be no Caffe Dependence , So I've been reporting mistakes .

2. Boost The library cannot be used apt Tool to install

apt-get The installation of tools is simple , Save a lot of trouble , The same is true of me , compile Caffe Time is no problem , But compile later Caffe Project time , There will be many strange problems , Later, I used the source code to install Boost success , The time spent in the middle is simply touching .

3. CMake Precompiled output

I use CLion To compile , Here, I will directly attach build The output of the console , You can see my dependent version below .

/root/clion-2021.3.2/bin/cmake/linux/bin/cmake -DCMAKE_BUILD_TYPE=Debug -DCMAKE_MAKE_PROGRAM=/root/clion-2021.3.2/bin/ninja/linux/ninja -G Ninja /root/CLionProjects/caffe_classification_demo
-- The C compiler identification is GNU 9.4.0
-- The CXX compiler identification is GNU 9.4.0
-- Detecting C compiler ABI info
-- Detecting C compiler ABI info - done
-- Check for working C compiler: /usr/bin/cc - skipped
-- Detecting C compile features
-- Detecting C compile features - done
-- Detecting CXX compiler ABI info
-- Detecting CXX compiler ABI info - done
-- Check for working CXX compiler: /usr/bin/c++ - skipped
-- Detecting CXX compile features
-- Detecting CXX compile features - done
-- Found OpenCV: /usr/local (found version "3.4.5")
-- Found Boost: /usr/local/include (found version "1.63.0") found components: filesystem system
-- Found Protobuf: /usr/local/lib/libprotobuf.so;-lpthread (found version "3.3.0")
Caffe_INCLUDE_DIRS /usr/local/dxai_caffe/src;/usr/local/include;/usr/include;/usr/local/dxai_caffe/build/include;/usr/include/hdf5/serial;/usr/local/include/opencv;/usr/include/x86_64-linux-gnu;/usr/local/dxai_caffe/include
Caffe_LIBRARIES caffe
-- Configuring done
-- Generating done
-- Build files have been written to: /root/CLionProjects/caffe_classification_demo/cmake-build-debug

[Finished]

4. CMakeLists.txt

Here also directly to my CMakeLists.txt Of ,CMakeList.txt Of find_package It's always windy , Not intelligent at all ( Make complaints about , But it may also be that my younger brother is incompetent ). The following is the correct way of writing which I have tried for many days and nights .

cmake_minimum_required(VERSION 3.21)
project(caffe_demo)

set(CMAKE_CXX_STANDARD 14)

# cpu only
option(USE_OPENCV "whether use opencv" ON)
if (USE_OPENCV)
    add_definitions(-DUSE_OPENCV)
endif()

option(CPU_ONLY "whether use cpu only" ON)
if(CPU_ONLY)
    add_definitions(-DCPU_ONLY)
endif()


#  Set the Library Directory
# OpenCV
find_package(OpenCV REQUIRED)
include_directories(${OpenCV_INCLUDE_DIRS})

# Boost
add_definitions(-DBOOST_ERROR_CODE_HEADER_ONLY)
find_package(Boost REQUIRED COMPONENTS filesystem system) #  Said the use of boost Of filesystem Components
include_directories(${Boost_INCLUDE_DIRS})


# protobuf
find_package(Protobuf REQUIRED)
include_directories(${Protobuf_INCLUDE_DIRS})

# glog
SET(GLOG_INC_DIR /usr/local/include)
SET(GLOG_LINK_DIR /usr/local/lib)

include_directories(${GLOG_INC_DIR})
link_directories(${GLOG_LINK_DIR})
link_libraries(glog)


# Caffe
find_package(Caffe REQUIRED)
if (Caffe_FOUND)
    message("Caffe_INCLUDE_DIRS ${Caffe_INCLUDE_DIRS}")
    message("Caffe_LIBRARIES ${Caffe_LIBRARIES}")
endif ()
include_directories(${Caffe_INCLUDE_DIRS})



add_executable(testDetection testDetection.cpp)
add_executable(detection detection.cpp)
##  For the specified bin File add third party link library
TARGET_LINK_LIBRARIES(testDetection ${OpenCV_LIBRARIES})
TARGET_LINK_LIBRARIES(testDetection glog)
TARGET_LINK_LIBRARIES(testDetection ${Caffe_LIBRARIES})

TARGET_LINK_LIBRARIES(detection ${OpenCV_LIBRARIES})
TARGET_LINK_LIBRARIES(detection glog)
TARGET_LINK_LIBRARIES(detection ${Caffe_LIBRARIES})
