Implementation of hotspot synchronized

One .synchronized Usage and byte compilation

 public synchronized  void testsynchronized(){
       System.out.println("ok");
   }
    public void testsynchronized1(){
        synchronized(Test.class){
            System.out.println("ok");
        }
    }
    public void testsynchronized2(){
        synchronized(this){
            System.out.println("ok");
        }
    }

utilize javap -v compile , The bytecode information is as follows

 public synchronized void testsynchronized();
    descriptor: ()V
    flags: ACC_PUBLIC, ACC_SYNCHRONIZED
    Code:
      stack=2, locals=1, args_size=1
         0: getstatic     #2                  // Field java/lang/System.out:Ljava/io/PrintStream;
         3: ldc           #3                  // String ok
         5: invokevirtual #4                  // Method java/io/PrintStream.println:(Ljava/lang/String;)V
         8: return
      LineNumberTable:
        line 8: 0
        line 9: 8
      LocalVariableTable:
        Start  Length  Slot  Name   Signature
            0       9     0  this   Lmy/test/Test;

  public void testsynchronized1();
    descriptor: ()V
    flags: ACC_PUBLIC
    Code:
      stack=2, locals=3, args_size=1
         0: ldc           #5                  // class my/test/Test
         2: dup
         3: astore_1
         4: monitorenter
         5: getstatic     #2                  // Field java/lang/System.out:Ljava/io/PrintStream;
         8: ldc           #3                  // String ok
        10: invokevirtual #4                  // Method java/io/PrintStream.println:(Ljava/lang/String;)V
        13: aload_1
        14: monitorexit
        15: goto          23
        18: astore_2
        19: aload_1
        20: monitorexit
        21: aload_2
        22: athrow
        23: return
      Exception table:
         from    to  target type
             5    15    18   any
            18    21    18   any
      LineNumberTable:
        line 11: 0
        line 12: 5
        line 13: 13
        line 14: 23
      LocalVariableTable:
        Start  Length  Slot  Name   Signature
            0      24     0  this   Lmy/test/Test;
      StackMapTable: number_of_entries = 2
        frame_type = 255 /* full_frame */
          offset_delta = 18
          locals = [ class my/test/Test, class java/lang/Object ]
          stack = [ class java/lang/Throwable ]
        frame_type = 250 /* chop */
          offset_delta = 4

  public void testsynchronized2();
    descriptor: ()V
    flags: ACC_PUBLIC
    Code:
      stack=2, locals=3, args_size=1
         0: aload_0
         1: dup
         2: astore_1
         3: monitorenter
         4: getstatic     #2                  // Field java/lang/System.out:Ljava/io/PrintStream;
         7: ldc           #3                  // String ok
         9: invokevirtual #4                  // Method java/io/PrintStream.println:(Ljava/lang/String;)V
        12: aload_1
        13: monitorexit
        14: goto          22
        17: astore_2
        18: aload_1
        19: monitorexit
        20: aload_2
        21: athrow
        22: return
      Exception table:
         from    to  target type
             4    14    17   any
            17    20    17   any
      LineNumberTable:
        line 16: 0
        line 17: 4
        line 18: 12
        line 19: 22
      LocalVariableTable:
        Start  Length  Slot  Name   Signature
            0      23     0  this   Lmy/test/Test;
      StackMapTable: number_of_entries = 2
        frame_type = 255 /* full_frame */
          offset_delta = 17
          locals = [ class my/test/Test, class java/lang/Object ]
          stack = [ class java/lang/Throwable ]
        frame_type = 250 /* chop */
          offset_delta = 4
}

synchronized When decorating a code block, it will be compiled into monitorenter and monitorexit The order is right ,monitorenter Used to acquire locks ,monitorexit Used to release locks .

Two .monitorenter Instructions implement

synchronized The lock used is the existence Java The one in the head ,HotSpot The object header of virtual machine mainly includes two parts of data ：Mark Word( Tag field ) and Klass Pointer( Class metadata pointer ), among Klass Point Is a pointer to its class metadata , The virtual machine uses this pointer to determine which class instance this object is ,Mark Word Used to store runtime data of the object itself , It's the key to implementing lightweight and biased locks .
Mark Word Used to store runtime data of the object itself , Such as hash code （HashCode）、GC Generational age 、 Lock status flag 、 A lock held by a thread 、 To the thread ID、 Time stamps and so on .

The interpreter performs monitorenter You will enter into InterpreterRuntime.cpp Of InterpreterRuntime::monitorenter Method .

RT_ENTRY_NO_ASYNC(void, InterpreterRuntime::monitorenter(JavaThread* thread, BasicObjectLock* elem))
#ifdef ASSERT
  thread->last_frame().interpreter_frame_verify_monitor(elem);
#endif
  if (PrintBiasedLockingStatistics) {
    Atomic::inc(BiasedLocking::slow_path_entry_count_addr());
  }
  Handle h_obj(thread, elem->obj());
  assert(Universe::heap()->is_in_reserved_or_null(h_obj()),
         "must be NULL or an object");
  if (UseBiasedLocking) {
    // Retry fast entry if bias is revoked to avoid unnecessary inflation
    ObjectSynchronizer::fast_enter(h_obj, elem->lock(), true, CHECK);
  } else {
    ObjectSynchronizer::slow_enter(h_obj, elem->lock(), CHECK);
  }
  assert(Universe::heap()->is_in_reserved_or_null(elem->obj()),
         "must be NULL or an object");
#ifdef ASSERT
  thread->last_frame().interpreter_frame_verify_monitor(elem);
#endif
IRT_END

It mainly describes whether the parameter is enabled UseBiasedLocking, If on , Then execute the deflection lock fast_enter Method , Otherwise, execute the lightweight lock slow_enter Method .

1. Biased locking
Purpose ： In order to reduce unnecessary lightweight lock execution paths without multi thread contention .
Mark Word The lock identification bit is 01.

void ObjectSynchronizer::fast_enter(Handle obj, BasicLock* lock, bool attempt_rebias, TRAPS) {
 if (UseBiasedLocking) {
    if (!SafepointSynchronize::is_at_safepoint()) {
      BiasedLocking::Condition cond = BiasedLocking::revoke_and_rebias(obj, attempt_rebias, THREAD);
      if (cond == BiasedLocking::BIAS_REVOKED_AND_REBIASED) {
        return;
      }
    } else {
      assert(!attempt_rebias, "can not rebias toward VM thread");
      BiasedLocking::revoke_at_safepoint(obj);
    }
    assert(!obj->mark()->has_bias_pattern(), "biases should be revoked by now");
 }

The main methods are revoke_and_rebias, Too long , Stick it or not , Look not to understand , Just give a general idea .
1. First, judge whether it is at the safe point
2. Determine whether there is lock contention , If there is no lock competition, it will Mark Word The lock identification bit is 01
3. If the lock object is biased and if it is allowed to attempt to acquire a biased lock , Then try to acquire the bias lock again , Otherwise, cancel the bias lock operation
4. Go to this step , Upgrade to lightweight lock

2. Lightweight lock
Purpose ： In the competition of multithreading , Reduces the performance cost of traditional heavyweight locks using operating system mutexes .Mark Word The lock identification bit is 00.

void ObjectSynchronizer::slow_enter(Handle obj, BasicLock* lock, TRAPS) {
  markOop mark = obj->mark();
  assert(!mark->has_bias_pattern(), "should not see bias pattern here");

  if (mark->is_neutral()) {
    // Anticipate successful CAS -- the ST of the displaced mark must
    // be visible <= the ST performed by the CAS.
    lock->set_displaced_header(mark);
    if (mark == (markOop) Atomic::cmpxchg_ptr(lock, obj()->mark_addr(), mark)) {
      TEVENT (slow_enter: release stacklock) ;
      return ;
    }
    // Fall through to inflate() ...
  } else
  if (mark->has_locker() && THREAD->is_lock_owned((address)mark->locker())) {
    assert(lock != mark->locker(), "must not re-lock the same lock");
    assert(lock != (BasicLock*)obj->mark(), "don't relock with same BasicLock");
    lock->set_displaced_header(NULL);
    return;
  }

#if 0
  // The following optimization isn't particularly useful.
  if (mark->has_monitor() && mark->monitor()->is_entered(THREAD)) {
    lock->set_displaced_header (NULL) ;
    return ;
  }
#endif

  // The object header will never be displaced to this lock,
  // so it does not matter what the value is, except that it
  // must be non-zero to avoid looking like a re-entrant lock,
  // and must not look locked either.
  lock->set_displaced_header(markOopDesc::unused_mark());
  ObjectSynchronizer::inflate(THREAD, obj())->enter(THREAD);
}

1.is_neutral Said if biased_lock:0 And lock:01 No lock state .
2. adopt CAS Try to markword Update to point BasicLock Object pointer , If the update is successful , Competition to lock , Then execute the synchronization code .
3. If at present mark In a locked state , And mark Medium ptr Pointer to the stack frame of the current thread , Then execute the synchronization code , Otherwise, multiple threads compete for lightweight locks , Lightweight locks need to be upgraded to heavyweight locks .

To be continued ...
