New can also create objects. Why do you need factory mode?

In the design pattern , Factory pattern is a kind of creative design pattern . In order to follow the opening and closing principles of software design and development , A simple factory model has been derived , Factory method pattern and abstract factory pattern . As a creative design pattern , Factory pattern is used to create new objects . So here's the problem , With C++ For example ,C++ The class constructor of can also create new objects , Why do we have to introduce the factory model ？

Encapsulate the initialization work when creating objects

If you use C Language , The tasks assigned and initialized include ：

• malloc Application memory （ But the application object is not initialized , Just have a piece of memory space ）, And force type conversion
• Initialize this memory
• Do other works

There seems to be some trouble , Allocate memory 、 Type conversion 、 initialization . If it is C++,new The action of includes two steps: allocating memory and calling constructor , Relatively simplified . This is a simple object for the general initialization process . What if the initialization process is complicated ？ What is a complicated initialization process ？ That is to say Creating objects is not just about allocating memory space , There are other initialization tasks to be done , Even work related to external variables or resources .

The following code is NVDLA Of compiler Part of the source code of ：

SDPScaleOpNode* NodeFactory::newSDPScaleOpNode
(
    ScaleNode* origCanNode,
    Graph* engGraph
)
{
    B b;
    DD dd;
    NvU16 numBatches = engGraph->profile()->multiBatchSize();

    b = dd = new SDPScaleOpNode(origCanNode, numBatches);
    dd->setName(std::string("sdp-scale-") + toString(s_sdp_scale_priv.size()));
    dd->setId(engGraph->nextNodeId());
    dd->setGraph(engGraph);
    engGraph->insertNode(b);

    s_sdp_scale_priv.insert(std::pair<B, DD>(b, dd));
    return dd;
}

Copy

I deleted part of the code for observation . This interface is to create a SDPScaleOpNode, But encapsulated in NodeFactory Of newSDPScaleOpNode() In the interface . In this interface, except

new SDPScaleOpNode(origCanNode, numBatches);

Copy

outside , There's more setter and insert Work . If factory mode packaging is not used , Then every time you create one node, Must be created node Write other setter and insert Code for , Not easy to read , And cause code redundancy .

The following code is tensorflow A fragment in the source code . You can see , establish device The initialization process of is more complex , You can even handle some exceptions .

std::unique_ptr<Device> DeviceFactory::NewDevice(const string& type,
                                                 const SessionOptions& options,
                                                 const string& name_prefix) {
  auto device_factory = GetFactory(type);
  if (!device_factory) {
    return nullptr;
  }
  SessionOptions opt = options;
  (*opt.config.mutable_device_count())[type] = 1;
  std::vector<std::unique_ptr<Device>> devices;
  TF_CHECK_OK(device_factory->CreateDevices(opt, name_prefix, &devices));
  int expected_num_devices = 1;
  auto iter = options.config.device_count().find(type);
  if (iter != options.config.device_count().end()) {
    expected_num_devices = iter->second;
  }
  DCHECK_EQ(devices.size(), static_cast<size_t>(expected_num_devices));
  return std::move(devices[0]);
}

Copy

Unify the naming of the interface for creating objects

With the above example , It's easier to understand “ Unified interface naming ” 了 .

• If it is class Football, Then the creation is to new Football;
• If you create Basketball, Must new Basketball;
• If it is Volleyball, be new VolleyBall;
• If it is AbcdEfgHijkOpq1234567, be new AbcdEfgHijkOpq1234567（ The name of the class is very long ）.

If there is factory mode for packaging , Then it becomes

createFootball();
createBasketball();
createVolleyball();
createAbcdEfgHijkOpq1234567();

Copy

The interface name is very clear , And you can probably know its function by function name .

Whether the object really needs “ establish ”？

Every time new, Will allocate memory （ Not to mention placement new）. But in some cases , Do we really need to allocate memory every time ？ To get a thread from the thread pool , To get a piece of memory from the memory pool , To get a resource from a resource pool , These resources have their own , There is no need to reassign , Unless the resources in the pool are used up . So another function of the factory model is , Control the timing of some resource allocation , When you really need to allocate memory , To allocate .

Binding polymorphism , To facilitate extension

Factory mode combined with polymorphism , Defines an interface for creating objects , But let subclasses decide which class to instantiate , Increase the flexibility of the code . For example, the following code , Through a unified interface getSportProduct(), Different products can be created at runtime .

int test()
{
  AbstractFactory *fac = NULL;
  AbstractSportProduct *product = NULL;

  fac = new BasketballFactory();
  product = fac->getSportProduct();

  fac = new FootballFactory();
  product = fac->getSportProduct();

  fac = new VolleyballFactory();
  product = fac->getSportProduct();

  // other work

    return 0;
}

Copy
