Pytorch builds transformer to realize multivariable and multi step time series forecasting (load forecasting)

I. Preface

I have written many articles about time series prediction ：

1. In depth understanding of PyTorch in LSTM Input and output of （ from input Input to Linear Output ）
2. PyTorch build LSTM Time series prediction is realized （ Load forecasting ）
3. PyTorch build LSTM Realize multivariable time series prediction （ Load forecasting ）
4. PyTorch Build a two-way network LSTM Time series prediction is realized （ Load forecasting ）
5. PyTorch build LSTM Realize multivariable and multi step time series prediction （ One ）： Direct multiple output
6. PyTorch build LSTM Realize multivariable and multi step time series prediction （ Two ）： Single step rolling prediction
7. PyTorch build LSTM Realize multivariable and multi step time series prediction （ 3、 ... and ）： Multi model single step prediction
8. PyTorch build LSTM Realize multivariable and multi step time series prediction （ Four ）： Multi model rolling prediction
9. PyTorch build LSTM Realize multivariable and multi step time series prediction （ 5、 ... and ）：seq2seq
10. PyTorch To realize LSTM Several methods of multi step time series prediction are summarized （ Load forecasting ）
11. PyTorch-LSTM How to predict the real future value in time series prediction
12. PyTorch build LSTM Realize multivariable input and multivariable output time series prediction （ Multi task learning ）
13. PyTorch build ANN Time series prediction is realized （ Wind speed prediction ）
14. PyTorch build CNN Time series prediction is realized （ Wind speed prediction ）
15. PyTorch build CNN-LSTM The hybrid model realizes the prediction of multivariable and multi step time series （ Load forecasting ）
16. PyTorch build Transformer Realize multivariable and multi step time series prediction （ Load forecasting ）
17. Summary of time series prediction series （ How to use the code ）

None of the above articles has touched on the popular in recent years Attention Mechanism , along with Attention The mechanism proposed together is transformer Model , About transformer The principle of the model is explained on the Internet , I won't describe it here , Write again if you have a chance .

II. Transformer

PyTorch Encapsulates the Transformer The concrete realization of , If the import fails, you can refer to ：torch.nn.Transformer Import failed .

Transformer The model is built as follows ：

class TransformerModel(nn.Module):
    def __init__(self, args):
        super(TransformerModel, self).__init__()
        self.args = args
        # embed_dim = head_dim * num_heads?
        self.input_fc = nn.Linear(args.input_size, args.d_model)
        self.output_fc = nn.Linear(args.input_size, args.d_model)
        self.pos_emb = PositionalEncoding(args.d_model)
        encoder_layer = nn.TransformerEncoderLayer(
            d_model=args.d_model,
            nhead=8,
            dim_feedforward=4 * args.input_size,
            batch_first=True,
            dropout=0.1,
            device=device
        )
        decoder_layer = nn.TransformerDecoderLayer(
            d_model=args.d_model,
            nhead=8,
            dropout=0.1,
            dim_feedforward=4 * args.input_size,
            batch_first=True,
            device=device
        )
        self.encoder = torch.nn.TransformerEncoder(encoder_layer, num_layers=8)
        self.decoder = torch.nn.TransformerDecoder(decoder_layer, num_layers=8)
        self.fc = nn.Linear(args.output_size * args.d_model, args.output_size)

    def forward(self, x, y):
        # print(x.size()) # (256, 24, 7)
        x = self.input_fc(x)  # (256, 24, 128)
        x = self.pos_emb(x)   # (256, 24, 128)
        x = self.encoder(x)
        # print(y.size()) # (256, 4, 7)
        y = self.output_fc(y)   # (256, 4, 128)
        out = self.decoder(y, x)  # (256, 4, 128)
        out = out.view(out.shape[0], -1)   # (256, 4 * 128)
        out = self.fc(out)  # (256, 4)

        return out

The initial data input dimension is 7, That is, the load value at each time and 6 Environment variables . stay Transformer In the original paper , The embedded dimension of the text is 512, and PyTorch Regulations nhead Sum of numbers d_model That is, the embedded dimension must satisfy the integer division relationship , So first, the original data from 7 Dimension maps to d_model dimension ：

x = self.input_fc(x)

among input_fc：

self.input_fc = nn.Linear(args.input_size, args.d_model)

Then encode the position of the original input ：

x = self.pos_emb(x)

Then it goes through the coding layer ：

x = self.encoder(x)

The resulting output is consistent with the input dimension .

Then output the encoder x And labels y At the same time, input the decoder to decode ：

y = self.output_fc(y)   # (256, 4, 128)
out = self.decoder(y, x)

label y Before entering the decoder, you also need to change its dimension from 7 Mapping to d_model.

It is worth noting that , In the previous article ,y The dimensions of are all (batch_size, output_size), And in the Transformer in ,y The dimensions are (batch_size, output_size, d_model).

III. Code implementation

3.1 Data processing

Before utilization 24 Hourly load value + After prediction of environmental variables 4 Load value at a time , Data processing is the same as before , Just pay attention to ,y It no longer contains only the load value 1 A variable , But and x equally , Both contain 7 A variable .

3.2 model training / test

Same as above .

3.3 experimental result

The relevant parameters are as follows ：

def args_parser():
    parser = argparse.ArgumentParser()

    parser.add_argument('--epochs', type=int, default=50, help='input dimension')
    parser.add_argument('--seq_len', type=int, default=24, help='seq len')
    parser.add_argument('--input_size', type=int, default=7, help='input dimension')
    parser.add_argument('--d_model', type=int, default=128, help='input dimension')
    parser.add_argument('--output_size', type=int, default=4, help='output dimension')
    parser.add_argument('--lr', type=float, default=2e-4, help='learning rate')
    parser.add_argument('--batch_size', type=int, default=256, help='batch size')
    parser.add_argument('--optimizer', type=str, default='adam', help='type of optimizer')
    parser.add_argument('--device', default=torch.device("cuda" if torch.cuda.is_available() else "cpu"))
    parser.add_argument('--weight_decay', type=float, default=1e-9, help='weight decay')
    parser.add_argument('--bidirectional', type=bool, default=False, help='LSTM direction')
    parser.add_argument('--step_size', type=int, default=10, help='step size')
    parser.add_argument('--gamma', type=float, default=0.5, help='gamma')

    args = parser.parse_args()

    return args

Training 50 round ,MAPE by 5.04%：

IV. Source code and data

be based on PyTorch Of Transformer Time series prediction code
