Raw socket usage

One 、 What can a raw socket do ？

Usually, programmers connect to the socket they touch (Socket) There are two types ：

1. Streaming socket (SOCK_STREAM)： A connection oriented Socket, For connection oriented TCP Service application ;
2. Datagram socket (SOCK_DGRAM)： A connectionless Socket, Corresponds to unconnected UDP Service application .

From the user's point of view ,SOCK_STREAM、SOCK_DGRAM These two types of sockets do seem to cover TCP/IP All of the applications , Because it is based on TCP/IP Application , At the protocol stack level , In the transport layer, it can only be built on TCP or UDP The agreement above , and SOCK_STREAM、SOCK_DGRAM And corresponding to TCP and UDP, Therefore, almost all applications can be implemented with these two types of sockets .

however , When we face the following problems ,SOCK_STREAM、SOCK_DGRAM Will appear so helpless ：
1. How to send a custom IP package ?
2. How to send a ICMP Agreement package ?
3. How to analyze all packets passing through the network , And whether or not the bag was sent to you ?
4. How to disguise local IP Address ?

This makes us have to face another profound theme —— Raw socket (SOCK_RAW).

Raw sockets are widely used in advanced network programming , It is also a broad means of hacking . The famous Internet sniffer( A network analysis method based on the principle of passive interception )、 Denial of service attacks (DOS)、IP Spoofing and so on can be realized through the original socket . Raw socket (SOCK_RAW) It can be used to self assemble packets , It can receive all the data frames on the local network card ( Data packets ), It is very useful for monitoring network traffic and analyzing network data . The original socket is based on IP Packet programming (SOCK_PACKET It's based on data link layer programming ). in addition , You must have administrator privileges to use raw sockets . Raw socket (SOCK_RAW) With standard sockets (SOCK_STREAM、SOCK_DGRAM) The difference is that the original socket is set directly “ root ” At the core of the operating system network (Network Core), and SOCK_STREAM、SOCK_DGRAM be “ suspension ” On TCP and UDP The periphery of the agreement .

Streaming sockets can only send and receive TCP Protocol data , Datagram socket can only send and receive UDP Protocol data , The original socket can send and receive packets that are not processed by the kernel .

Two 、 Raw socket programming

Raw socket programming and before UDP Programming is almost , After creating a socket , Receive data or send data through this socket . The difference lies in , The raw socket can self assemble packets ( Camouflage local IP, Local MAC), It can receive all the data frames on the local network card ( Data packets ). in addition , You must have administrator privileges to use raw sockets .

The creation of the original socket ：

int socket ( int family, int type, int protocol );

Parameters ：

family： Protocol family Write here PF_PACKET

type： Socket class , Write here SOCK_RAW

protocol： Type of agreement , Specifies the type of packet that can be received or sent , Can't write “0”, The values are as follows , Be careful , You need to use

htons() Do byte order conversion .

ETH_P_IP：IPV4 Data packets

ETH_P_ARP：ARP Data packets

ETH_P_ALL： Packets of any protocol type

Return value ：

success ( >0 )： Socket , Here is the socket of the link layer

Failure ( <0 )： error

Examples are as follows ：

//  Required header file
#include <sys/socket.h>
#include <netinet/ether.h>
#include <stdio.h>  // perror

int main(int argc,charchar *argv[])
{
    int sock_raw_fd = socket(PF_PACKET, SOCK_RAW, htons(ETH_P_ALL) );

    if(sock_raw_fd < 0){
        perror("socket");
        return -1;
    }

    return 0;
}

【 Article Welfare 】 need C/C++ Linux Background server architect and audio and video learning materials plus group 812855908（ The information includes C/C++,Linux,golang technology , kernel ,Nginx,ZeroMQ,MySQL,Redis,fastdfs,MongoDB,ZK, Streaming media , Audio and video ,CDN,P2P,K8S,Docker,TCP/IP, coroutines ,DPDK,ffmpeg, Interview questions of Dachang etc. ）

Get the packet function of the link layer ：

ssize_t recvfrom( int sockfd, void *buf,  size_t nbytes,
            int flags,  struct sockaddr *from,
              socklen_t *addrlen );

Parameters ：

sockfd: Raw socket

buf： Receive data buffer

nbytes: The size of the receive data buffer

flags： Socket flag ( Often 0)

from： It's not useful here , Write NULL

addrlen： It's not useful here , Write NULL

Return value ：

success ： Number of characters received

Failure ：-1

Examples are as follows ：

#include <stdio.h>
#include <netinet/in.h>
#include <sys/socket.h>
#include <netinet/ether.h>

int main(int argc,charchar *argv[])
{
    unsigned char buf[1024] = {0};
    int sock_raw_fd = socket(PF_PACKET, SOCK_RAW, htons(ETH_P_ALL));

    // Get the data packet of link layer
    int len = recvfrom(sock_raw_fd, buf, sizeof(buf), 0, NULL, NULL);
    printf("len = %d\n", len);

    return 0;
}

Hybrid mode

By default , We receive data , The destination address is a local address , Will receive . Sometimes we want to receive all the data streams that pass through the network card , Whether or not the destination address is it , At this time, we need to set the network card to hybrid mode .

The hybrid mode of network card is usually used by network administrator when analyzing network data as a means of network fault diagnosis , At the same time, this mode is also used by network hackers as the entrance of network data eavesdropping . stay Linux When setting network card hybrid mode in the operating system, administrator's permission is required . stay Windows Operating system and Linux The operating system has the use of hybrid mode packet capture tools , Like the famous open source software Wireshark.

By order to Linux Network card set hybrid mode ( Administrator privileges required )

Set hybrid mode ：ifconfig eth0 promisc

Cancel hybrid mode ：ifconfig eth0 -promisc

Give to by code Linux Network card set hybrid mode

The core code is as follows ：

struct ifreq ethreq;    // Network interface address

strncpy(ethreq.ifr_name, "eth0", IFNAMSIZ);         // Specify the network card name
if(-1 == ioctl(sock_raw_fd, SIOCGIFINDEX, &ethreq)) // Get the network interface
{
    perror("ioctl");
    close(sock_raw_fd);
    exit(-1);
}

ethreq.ifr_flags |= IFF_PROMISC;
if(-1 == ioctl(sock_raw_fd, SIOCSIFINDEX, &ethreq)) // Network card set hybrid mode
{
    perror("ioctl");
    close(sock_raw_fd);
    exit(-1);
}

Send custom packets ：

ssize_t sendto( int sockfd,const void *buf,
            size_t nbytes,int flags,
            const struct sockaddr *to,socklen_t addrlen );

Parameters ：

sockfd： Raw socket

buf： Send data buffer

nbytes: The size of the send data buffer

flags： It's usually 0

to： Local network interface , It refers to the network card from which the data should be sent out , Instead of the previous destination address

addrlen：to The length of the pointed content

Return value ：

success ： Number of characters to send data
Failure ： -1

 Send the complete code as follows ：
struct sockaddr_ll sll;                 // Original socket address structure
struct ifreq ethreq;                    // Network interface address

strncpy(ethreq.ifr_name, "eth0", IFNAMSIZ);         // Specify the network card name
if(-1 == ioctl(sock_raw_fd, SIOCGIFINDEX, ðreq))    // Get the network interface
{
    perror("ioctl");
    close(sock_raw_fd);
    exit(-1);
}

/* Assign the network interface to the original socket address structure */
bzero(&sll, sizeof(sll));
sll.sll_ifindex = ethreq.ifr_ifindex;

//  send data
// send_msg, msg_len  There is no definition here , Simulate
int len = sendto(sock_raw_fd, send_msg, msg_len, 0 , (struct sockaddr *)&sll, sizeof(sll));
if(len == -1)
{
    perror("sendto");
}

Here the header file is as follows ：

#include <net/if.h>// struct ifreq
#include <sys/ioctl.h> // ioctl、SIOCGIFADDR
#include <sys/socket.h> // socket
#include <netinet/ether.h> // ETH_P_ALL
#include <netpacket/packet.h> // struct sockaddr_ll

3、 ... and 、 Original socket instance ：MAC Header message analysis

I know from the above , We can use the original socket and recvfrom( ) You can get the data packets of the link layer , What kind of link layer packets do we receive ?

Link layer packet format

MAC Head ( Wired LAN )

Be careful ：CRC、PAD It can be ignored when packaging
One of the cases of link layer packets ：

unsigned char msg[1024] = {
    //-------------- Group MAC--------14------
    0xb8, 0x88, 0xe3, 0xe1, 0x10, 0xe6, // dst_mac: b8:88:e3:e1:10:e6
    0xc8, 0x9c, 0xdc, 0xb7, 0x0f, 0x19, // src_mac: c8:9c:dc:b7:0f:19
    0x08, 0x00,                         //  type ：0x0800 IP agreement
    // …… ……
    // …… ……
};

Received link layer packets , And make a simple analysis of it ：

#include <stdio.h>
#include <string.h>
#include <stdlib.h>
#include <sys/socket.h>
#include <netinet/in.h>
#include <arpa/inet.h>
#include <netinet/ether.h>

int main(int argc,charchar *argv[])
{
    int i = 0;
    unsigned char buf[1024] = "";
    int sock_raw_fd = socket(PF_PACKET, SOCK_RAW, htons(ETH_P_ALL));
    while(1)
    {
        unsigned char src_mac[18] = "";
        unsigned char dst_mac[18] = "";
        // Get the data frame of link layer
        recvfrom(sock_raw_fd, buf, sizeof(buf),0,NULL,NULL);
        // from buf To extract the purpose of mac、 Source mac
        sprintf(dst_mac,"%02x:%02x:%02x:%02x:%02x:%02x", buf[0], buf[1], buf[2], buf[3], buf[4], buf[5]);
        sprintf(src_mac,"%02x:%02x:%02x:%02x:%02x:%02x", buf[6], buf[7], buf[8], buf[9], buf[10], buf[11]);
        // Judge whether it is IP Data packets
        if(buf[12]==0x08 && buf[13]==0x00)
        {
            printf("______________IP The datagram _______________\n");
            printf("MAC:%s >> %s\n",src_mac,dst_mac);
        }// Judge whether it is ARP Data packets
        else if(buf[12]==0x08 && buf[13]==0x06)
        {
            printf("______________ARP The datagram _______________\n");
            printf("MAC:%s >> %s\n",src_mac,dst_mac);
        }// Judge whether it is RARP Data packets
        else if(buf[12]==0x80 && buf[13]==0x35)
        {
            printf("______________RARP The datagram _______________\n");
            printf("MAC:%s>>%s\n",src_mac,dst_mac);
        }
    }
    return 0;
}

Remember to run the program with administrator privileges ：
