Machine learning perceptron and k-nearest neighbor

One 、 perceptron

import numpy as np
from matplotlib import pyplot as plt
np.random.seed(3)

# In fact, we should use x1=np.linspace(0,5,50)
#X Axis dataset
x1=[i for i in np.arange(0,5,0.1)]
# Positive sample data set
x2=np.abs(np.random.randn(50))
# Negative sample data set
x3=np.abs(np.random.randn(50)+8)
plt.scatter(x1,x2)
plt.scatter(x1,x3)

# Use the above data to build a data matrix

# features 1
x_1=x1+x1
# features 2
x_2=list(x2)+list(x3)
# Label column
y=[1]*50+[-1]*50
data=np.zeros((100,3))
data=np.c_[x_1,x_2,y]
data.shape
#(100, 3)

class Perceptron():
	 """ :param data: ndarray Format data : N x P N individual P D data  :param lr:  Learning rate  :param maxiter:  Maximum number of iterations  :param w_vect:  Initial weight vector  """

    def __init__(self,data,lr,maxiter,w_vect):
        self.data=data
        self.w=w_vect
        self.lr=lr
        self.maxiter=maxiter


    def get_wrong(self):
      """ :return:  Misclassification data set matrix and corresponding index of original matrix  """
      	# Filter data
        x=np.c_[self.data[:,:-1],np.ones(self.data.shape[0])]
        wrong_index=np.where((x.dot(self.w)*((self.data[:,-1]).reshape(-1,1))<=0))[0]
        return data[wrong_index,:],wrong_index


    def fit(self):
        for j in range(self.maxiter):
            error=0
            wrong_data,wrong_index=self.get_wrong()
            #print(wrong_data)
            x=np.c_[wrong_data[:,:-1],np.ones(wrong_data.shape[0])]

            # Scrambling data sets to obtain different hyperplane solutions
            np.random.shuffle(x)
            for i in range(0,wrong_data.shape[0]):
                gradient=((-wrong_data[i,-1:])*x[i,:]).reshape(-1,1)
                self.w=self.w-self.lr*gradient
                error+=1
            #print(gradient.shape)
            if error==0:
                break

#w_vect=np.zeros((data.shape[1],1))
w_vect=np.array([[0],[0],[0]])
a=Perceptron(data,0.01,200,w_vect)
a.fit()
weights=a.w
w1 = weights[0][0]
w2 = weights[1][0]
bias = weights[-1][0]
print(a.w)
x6 = -w1 / w2 * np.array(x1) - bias / w2
plt.scatter(x1,x2)
plt.scatter(x1,x3)
plt.plot(x1,x6)

Two 、KNN

# establish kd Trees
import numpy as np
import matplotlib.pyplot as plt

class kdTree():
    def __init__(self, parent_node):
        # Node initialization

        self.nodedata = None   # The data value of the current node , Two dimensional data
        self.split = None # Sequence number of the direction axis of the split plane ,0 Represents along x Axis segmentation ,1 Represents along y Axis segmentation
        self.range = None  # Split threshold
        self.left = None    # Left subtree node
        self.right = None   # Right subtree node
        self.parent = parent_node  # Parent node
        self.leftdata = None  # Keep all the data of the left node
        self.rightdata = None # Keep all the data of the right node
        self.isinvted = False # Record whether the current node has been accessed

    def print(self):

        # Print the current node information

        print(self.nodedata, self.split, self.range)

    def getSplitAxis(self, all_data):

        # Determine the segmentation axis according to the variance

        var_all_data = np.var(all_data, axis=0)
        if var_all_data[0] > var_all_data[1]:
            return 0
        else:
            return 1


    def getRange(self, split_axis, all_data):

        # Get the size of the median data value on the corresponding split axis

        split_all_data = all_data[:, split_axis]
        data_count = split_all_data.shape[0]
        med_index = int(data_count/2)
        sort_split_all_data = np.sort(split_all_data)
        range_data = sort_split_all_data[med_index]
        return range_data


    def getNodeLeftRigthData(self, all_data):

        # Divide the data into the left subtree , Right subtree and get the current node

        data_count = all_data.shape[0]
        ls_leftdata = []
        ls_rightdata = []
        for i in range(data_count):
            now_data = all_data[i]
            if now_data[self.split] < self.range:
                ls_leftdata.append(now_data)
            elif now_data[self.split] == self.range and self.nodedata == None:
                self.nodedata = now_data
            else:
                ls_rightdata.append(now_data)
        self.leftdata = np.array(ls_leftdata)
        self.rightdata = np.array(ls_rightdata)


    def createNextNode(self,all_data):

        # Iteratively create nodes , Generate kd Trees

        if all_data.shape[0] == 0:
            print("create kd tree finished!")
            return None
        self.split = self.getSplitAxis(all_data)
        self.range = self.getRange(self.split, all_data)
        self.getNodeLeftRigthData(all_data)
        if self.leftdata.shape[0] != 0:
            self.left = kdTree(self)
            self.left.createNextNode(self.leftdata)
        if self.rightdata.shape[0] != 0:
            self.right = kdTree(self)
            self.right.createNextNode(self.rightdata)

    def plotKdTree(self):

        # Draw the recursive iteration process of tree structure on the graph

        if self.parent == None:
            plt.figure(dpi=300)
            plt.xlim([0.0, 10.0])
            plt.ylim([0.0, 10.0])
        color = np.random.random(3)
        if self.left != None:
            plt.plot([self.nodedata[0], self.left.nodedata[0]],[self.nodedata[1], self.left.nodedata[1]], '-o', color=color)
            plt.arrow(x=self.nodedata[0], y=self.nodedata[1], dx=(self.left.nodedata[0]-self.nodedata[0])/2.0, dy=(self.left.nodedata[1]-self.nodedata[1])/2.0, color=color, head_width=0.2)
            self.left.plotKdTree()
        if self.right != None:
            plt.plot([self.nodedata[0], self.right.nodedata[0]],[self.nodedata[1], self.right.nodedata[1]], '-o', color=color)
            plt.arrow(x=self.nodedata[0], y=self.nodedata[1], dx=(self.right.nodedata[0]-self.nodedata[0])/2.0, dy=(self.right.nodedata[1]-self.nodedata[1])/2.0, color=color, head_width=0.2)
            self.right.plotKdTree()
        # if self.split == 0:
        # x = self.range
        # plt.vlines(x, 0, 10, color=color, linestyles='--')
        # else:
        # y = self.range
        # plt.hlines(y, 0, 10, color=color, linestyles='--')


test_array = 10.0*np.random.random([30,2])
my_kd_tree = kdTree(None)
my_kd_tree.createNextNode(test_array)
my_kd_tree.plotKdTree()
