Hefei University of technology information theory and coding course design, including code, visual interface, course design report

Course design of information theory and coding in Hefei University of Technology , With code , Visual interface , Course design report

Students who want the source code click here

It must be done

Binary Huffman coding is applied to any input string sequence 、fano code 、 Run length coding and Arithmetic coding , Give the coding result 、 Coding efficiency ; And realize the corresponding decoding operation .

Choose a question

Yes, one BMP First, binary Huffman coding and run length coding are carried out for the gray-scale image of format , According to the result of Huffman coding, the run length coding is transformed into binary sequence .（ Pixels are encoded by Hoffman , Run with equal length code ）. And design the corresponding decoding .

Development tools and environments

Editing tools ：Visual Studio Code
Compiler tools ：python 3.9.7
Interface tools ：PyQt5 designer
The library used ：math; Pillow 8.4.0; PyQt5 5.15.4;

Module partition

As shown in the figure below , There are five buttons , Realize the corresponding functions of five topics , Call five python File for corresponding coding . Enter the encoded string in the text box , Click on different buttons , You can get the character and its corresponding code , Coding results , Decoding result and coding efficiency .Huffman Encoded as Huffman.py,Fano Encoded as fano.py, The run length code is run_length2.py, The arithmetic code is signal.py, The gray image is encoded as bmp_huffman.py, The source file of the main interface is main.ui and UI_main.py, The main function is main.py Be responsible for unified management of coding program and interface program . The following figure shows the main window of the software ：

The following is the module division of each sub file ：

Huffman.py The division of modules

The name of the function	Function input	Output function
Class node	Huffman Node parameters	A node
get_text_count()	Encoded string	Characters and corresponding probabilities
create_nodes()	Character string	Node list
create_huffman_tree()	Node list	Huffman Trees and root nodes
huffman_encoding()	Character frequency and Huffman Trees	The string and average code length of each node
encode_str()	Text and node list	Encoded string
decode_str()	Encoded string and node list	Decoded string
get_H()	Characters and corresponding probabilities	The entropy of the source

fano.py The division of modules

The name of the function	Function input	Output function
Class node	fano Node parameters	A node
get_text_count()	Encoded string	Characters and corresponding probabilities
create_nodes()	Character string	Node list
fano_encode()	Node list and character corresponding probability	Each node is compiled into a string
encode_str()	Text and node list	Encoded string
decode_str()	List of encoded string nodes	Decoded string
get_H()	Characters and corresponding probabilities	The entropy of the source
get_average_code_length()	Node list	Average code length

run_lenggth2.py Module partition

The name of the function	Function input	Output function
get_text_count()	Encoded string	Characters and corresponding probabilities
get_max_bin_length()	Encoded string	Maximum binary length of run length code
encode_str()	Encoded string and run list	Encoded string
decode_str()	Encoded string and run list	Decoded string
get_H()	Characters and corresponding probabilities	The entropy of the source

signal.py The division of modules

The name of the function	Function input	Output function
get_text_count()	Encoded string	The entropy and average code length of characters and their corresponding probabilities and sources
encode_str()	The corresponding probability of encoded string and character	Decimal decimals compiled
ten2bin()	Decimal number	Binary decimals
decode_str()	The corresponding probability of decimal decimals and characters	Decoded string

bmp_huffman.py The division of modules

The name of the function	Function input	Output function
Class node	Huffman Node parameters	A node
get_image_list()	Image path （ Images ）	List of pixel values , Itinerary list , Maximum binary length
get_image_list_count()	List of pixel values	A character , Frequency dictionary and corresponding character probability
create_nodes()	Character string	Node list
create_huffman_tree()	Node list	Huffman Trees and root nodes
huffman_encoding()	Character frequency and Huffman Trees	The string and average code length of each node
encode_str()	List of pixel values , Node list , Run table	Encoded string
decode_str()	Encoded string and node list	Decoded string
get_H()	Characters and corresponding probabilities	The entropy of the source
get_average_length()	Run list and node list	Average code length
compare()	Image path , Decode string and pixel value list	Whether the decoding is consistent

Interface function

As shown in the figure Click the corresponding button to realize the corresponding function
