Ruiji takeout - day01

Catalog

Overall introduction

Technology selection

Functional architecture

role

Development environment construction

Database environment construction

maven Project structures,

Import static resources

Static resource mapping configuration class

Background login function development

Demand analysis

Code development

establish Controller、 Service、 Mapper、 Entity class 、R object

Sort out the login method and processing logic

A functional test

Background system exit function

Demand analysis

Code implementation

---



Overall introduction

Technology selection

Functional architecture

role

Development environment construction

Database environment construction

maven Project structures,

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>

    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>2.5.4</version>
        <relativePath/> <!-- lookup parent from repository -->
    </parent>

    <groupId>com.zqf</groupId>
    <artifactId>reggie_take_out</artifactId>
    <version>1.0-SNAPSHOT</version>

    <properties>
        <java.version>1.8</java.version>
    </properties>
    <dependencies>

        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter</artifactId>
        </dependency>

        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-test</artifactId>
            <scope>test</scope>
        </dependency>

        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
            <scope>compile</scope>
        </dependency>

        <dependency>
            <groupId>com.baomidou</groupId>
            <artifactId>mybatis-plus-boot-starter</artifactId>
            <version>3.4.2</version>
        </dependency>

        <dependency>
            <groupId>org.projectlombok</groupId>
            <artifactId>lombok</artifactId>
            <version>1.18.20</version>
        </dependency>

        <dependency>
            <groupId>com.alibaba</groupId>
            <artifactId>fastjson</artifactId>
            <version>1.2.76</version>
        </dependency>

        <dependency>
            <groupId>commons-lang</groupId>
            <artifactId>commons-lang</artifactId>
            <version>2.6</version>
        </dependency>

        <dependency>
            <groupId>mysql</groupId>
            <artifactId>mysql-connector-java</artifactId>
            <scope>runtime</scope>
        </dependency>

        <dependency>
            <groupId>com.alibaba</groupId>
            <artifactId>druid-spring-boot-starter</artifactId>
            <version>1.1.23</version>
        </dependency>

    </dependencies>

    <build>
        <plugins>
            <plugin>
                <groupId>org.springframework.boot</groupId>
                <artifactId>spring-boot-maven-plugin</artifactId>
                <version>2.3.7.RELEASE</version>
            </plugin>
        </plugins>
    </build>


</project>

Import static resources

Static resource mapping configuration class

package com.zqf.reggie.config;

import lombok.extern.slf4j.Slf4j;
import org.springframework.context.annotation.Configuration;
import org.springframework.web.servlet.config.annotation.ResourceHandlerRegistry;
import org.springframework.web.servlet.config.annotation.WebMvcConfigurationSupport;

@Slf4j
@Configuration
public class WebMvcConfig extends WebMvcConfigurationSupport {

    /**
     *  Static resource mapping
     * @param registry
     */
    @Override
    protected void addResourceHandlers(ResourceHandlerRegistry registry) {
        log.info(" Start static resource mapping ");
        // Resource processor , route
        registry.addResourceHandler("/backed/**").addResourceLocations("classpath:/backend/");
        registry.addResourceHandler("/front/**").addResourceLocations("classpath:/front/");
    }
}

Background login function development

Demand analysis

  The background staff login corresponds to the following table ：

  Be careful ：

         The front end obtains these values from the returned results , This requires that the data processed by the server contain code,data,msg. It clarifies what kind of data the server should respond to after processing data .

Code development

establish Controller、 Service、 Mapper、 Entity class 、R object

• 1） Create entity class Employee, and employee Table to map

package com.zqf.reggie.entity;

import com.baomidou.mybatisplus.annotation.FieldFill;
import com.baomidou.mybatisplus.annotation.TableField;
import lombok.Data;
import java.io.Serializable;
import java.time.LocalDateTime;

/**
 *  Employee entity
 */
@Data
public class Employee implements Serializable {

    private static final long serialVersionUID = 1L;

    private Long id;

    private String username;

    private String name;

    private String password;

    private String phone;

    private String sex;

    private String idNumber;// Id card number

    private Integer status;

    private LocalDateTime createTime;

    private LocalDateTime updateTime;

    @TableField(fill = FieldFill.INSERT)
    private Long createUser;

    @TableField(fill = FieldFill.INSERT_UPDATE)
    private Long updateUser;

}

• 2） establish EmployeeMapper Interface

package com.zqf.reggie.mapper;

import com.baomidou.mybatisplus.core.mapper.BaseMapper;
import com.zqf.reggie.entity.Employee;
import org.apache.ibatis.annotations.Mapper;

@Mapper
public interface EmployeeMapper extends BaseMapper<Employee>{
}

• 3） establish Service And implementation class

package com.zqf.reggie.service;

import com.baomidou.mybatisplus.extension.service.IService;
import com.zqf.reggie.entity.Employee;

public interface EmployeeService extends IService<Employee> {
}

package com.zqf.reggie.service.impl;

import com.baomidou.mybatisplus.extension.service.impl.ServiceImpl;
import com.zqf.reggie.entity.Employee;
import com.zqf.reggie.mapper.EmployeeMapper;
import com.zqf.reggie.service.EmployeeService;
import org.springframework.stereotype.Service;

@Service
public class EmployeeServiceImpl extends ServiceImpl<EmployeeMapper,Employee> implements EmployeeService{
}

• Create presentation layer Controller

@Slf4j
@RestController
@RequestMapping("/employee")
public class EmployeeController {

    @Autowired
    private EmployeeService employeeService;

}

• Import the general return result class R

This class is a general result class , All the results of the server response will eventually be packaged into this type and returned to the front-end page

package com.zqf.reggie.common;

import lombok.Data;
import java.util.HashMap;
import java.util.Map;

/**
 *  General return result , The data responded by the server will eventually be encapsulated into this object
 * @param <T>
 */
@Data
public class R<T> {

    private Integer code; // code ：1 success ,0 And other numbers are failures

    private String msg; // error message

    private T data; // data

    private Map map = new HashMap(); // Dynamic data

    // When the response is successful , Return to one R object
    public static <T> R<T> success(T object) {
        R<T> r = new R<T>();
        r.data = object;
        r.code = 1;
        return r;
    }

    // When the response fails , Return to one R object
    public static <T> R<T> error(String msg) {
        R r = new R();
        r.msg = msg;
        r.code = 0;
        return r;
    }

    // Used for operation Map Dynamic data
    public R<T> add(String key, Object value) {
        this.map.put(key, value);
        return this;
    }

}

Sort out the login method and processing logic

•   Login logic implementation

/**
     *  Employee login
     * @param request
     * @param employee
     * @return
     */
    @PostMapping("/login")
    public R<Employee> login(HttpServletRequest request,@RequestBody Employee employee){

        //1、 Submit the password of the page password Conduct md5 Encryption processing
        String password = employee.getPassword();
        password = DigestUtils.md5DigestAsHex(password.getBytes());

        //2、 According to the user name submitted on the page username Query the database
        LambdaQueryWrapper<Employee> queryWrapper = new LambdaQueryWrapper<>();
        queryWrapper.eq(Employee::getUsername,employee.getUsername());
        Employee emp = employeeService.getOne(queryWrapper);

        //3、 If there is no query, the login failure result will be returned
        if(emp == null){
            return R.error(" Login failed ");
        }

        //4、 Password comparison , If not, the login failure result will be returned
        if(!emp.getPassword().equals(password)){
            return R.error(" Login failed ");
        }

        //5、 View employee status , If it is disabled , The disabled employee result is returned
        if(emp.getStatus() == 0){
            return R.error(" Account has been disabled ");
        }

        //6、 Login successful , Staff id Deposit in Session And return the login success result
        request.getSession().setAttribute("employee",emp.getId());
        return R.success(emp);
    }

A functional test

（ Landing successful , Jump to another page ） A little

Background system exit function

Demand analysis

Code implementation

/**
     *  Employee exit
     * @param request
     * @return
     */
    @PostMapping("/logout")
    public R<String> logout(HttpServletRequest request){
        // clear Session Of the currently logged in employee saved in id
        request.getSession().removeAttribute("employee");
        return R.success(" Quit successfully ");
    }
