图片保存：torchvision.utils.save_image(img, imgPath)

torchvision.utils.save_image(img, imgPath)

深度学习模型中，一般使用如下方式进行图像保存(torchvision.utils中的save_image()函数），这种方式只能保存RGB彩色图像，如果网络的输出是单通道灰度图像，则该函数依然会输出三个通道，每个通道的数值都是相同的，即“伪灰度图像”，虽然从视觉效果上看不出区别，但是图像所占内存比正常情况大了两倍。

save_image()函数：

def save_image(tensor, filename, nrow=8, padding=2,
               normalize=False, range=None, scale_each=False, pad_value=0):
    """Save a given Tensor into an image file. Args: tensor (Tensor or list): Image to be saved. If given a mini-batch tensor, saves the tensor as a grid of images by calling ``make_grid``. **kwargs: Other arguments are documented in ``make_grid``. """
    from PIL import Image
    grid = make_grid(tensor, nrow=nrow, padding=padding, pad_value=pad_value,
                     normalize=normalize, range=range, scale_each=scale_each)
    # Add 0.5 after unnormalizing to [0, 255] to round to nearest integer
    ndarr = grid.mul_(255).add_(0.5).clamp_(0, 255).permute(1, 2, 0).to('cpu', torch.uint8).numpy()
    im = Image.fromarray(ndarr)
    im.save(filename)

解决方式

 def saveImg(self, img, save_dir, type, name, Gray=False):
     fname, fext = name.split('.')
     imgPath = os.path.join(save_dir, "%s_%s.%s" % (fname, type, fext))
     # torchvision.utils.save_image(img, imgPath)
     # 改写：torchvision.utils.save_image
     grid = torchvision.utils.make_grid(img, nrow=8, padding=2, pad_value=0,
                                        normalize=False, range=None, scale_each=False)
     ndarr = grid.mul(255).add_(0.5).clamp_(0, 255).permute(1, 2, 0).to('cpu', torch.uint8).numpy()
     im = Image.fromarray(ndarr)
     # im.show()
     if Gray:
         im.convert('L').save(imgPath)  # Gray = 0.29900 * R + 0.58700 * G + 0.11400 * B
     else:
         im.save(imgPath)

保存图片的另一种方式（推荐）：

def saveImg(self, img, save_dir, type, name, Gray=False):
    fname, fext = name.split('.')
    imgPath = os.path.join(save_dir, "%s_%s.%s" % (fname, type, fext))
    img_array = self.tensor2array(img.data[0])
    image_pil = Image.fromarray(img_array)
    if Gray:
        image_pil.convert('L').save(imgPath)  # Gray = 0.29900 * R + 0.58700 * G + 0.11400 * B
    else:
        image_pil.save(imgPath)

# Converts a Tensor into a Numpy array
  # |imtype|: the desired type of the converted numpy array
  def tensor2array(self, image_tensor, imtype=np.uint8, normalize=True):
      if isinstance(image_tensor, list):
          image_numpy = []
          for i in range(len(image_tensor)):
              image_numpy.append(self.tensor2array(image_tensor[i], imtype, normalize))
          return image_numpy
      image_numpy = image_tensor.cpu().float().numpy()
      if normalize:
          image_numpy = (np.transpose(image_numpy, (1, 2, 0)) + 1) / 2.0 * 255.0
      else:
          image_numpy = np.transpose(image_numpy, (1, 2, 0)) * 255.0
      image_numpy = np.clip(image_numpy, 0, 255)
      if image_numpy.shape[2] == 1 or image_numpy.shape[2] > 3:
          image_numpy = image_numpy[:, :, 0]
      return image_numpy.astype(imtype)
