Flame framework - Flame WTF form: file upload, verification code

2022-07-25 10:53:00 【White chocolate Lin】

Catalog

In the last article , We learned Flask frame ——Flask-WTF Forms ： data validation 、CSRF Protect , This article is for us to learn Flask frame ——Flask-WTF Forms ： Upload files 、 Verification Code .

Upload files

Flask-WTF The form provides FileField Field to handle file upload , After the form is submitted , Automatically from flask.request.files Extract data from .

The sample code is as follows ：

import os
from flask import Flask, render_template
from flask_wtf import FlaskForm, CSRFProtect
from flask_wtf.file import FileField, FileRequired, FileAllowed

app = Flask(__name__)
app.config['SECRET_KEY']='hakhfaskh'      # To configure CSRF The key needed , Its value is arbitrary
csrf = CSRFProtect(app)          # take CSRF Protection is added to app in

class Myform(FlaskForm):
    file = FileField(label=' Upload the user's Avatar ',validators=[FileRequired(), FileAllowed(['jpg','png'])])   # establish FileField Field

@app.route('/',methods=['GET','POST'])
def hello_world():
    myform = Myform()         # Create a form object
    if myform.validate_on_submit():          # Check whether it is a POST Request and whether the request is valid
        filename=myform.file.data.filename    # Get the passed in file name
        filepath=os.path.dirname(os.path.abspath(__file__))       # Get the file path of the current project
        savepath=os.path.join(filepath,'static')      # Set save file path
        myform.file.data.save(os.path.join(savepath,filename))    # Save the file
        return ' Submit successfully '
    return render_template('file.html', myform=myform) # Use render_template() Method rendering file.html Document and will myform Pass on to file.html in

if __name__ == '__main__':
    app.run(debug=True)

To configure CSRF The required key and will CSRF Protection is added to app in , Then create a name called Myform Form class for , In the class, we define FileField File field and use FileRequired File validation functions and FileAllowed File type verification function .

Create a form class object in the view function , Used validate_on_submit() Method to check whether it is a POST Request and whether the request is valid , Get the passed in file name and define the path to save the file , Finally using render_template() Method rendering file.html Document and will myform Pass on to file.html in .

Create a file.html file , Its contents are as follows ：

<!DOCTYPE html>
<html lang="en">
<head>
    <meta charset="UTF-8">
    <title>Title</title>
</head>
<body>
    <form action="{
   { url_for('hello_world') }}" method="post" enctype="multipart/form-data">
        {
   { myform.csrf_token }}  {# Rendering csrf#}
        <p>{
   { myform.file.label }}{
   { myform.file }}</p>
        <input type="submit" value=" Submit ">
    </form>
</body>
</html>

Be careful ： Related to documents , Need to be in HTML Form enctype Set to multipart/form-data.

start-up flask project , visit http://127.0.0.1:5000/ And select the file , As shown in the figure below ：

Verification Code

Flask-WTF adopt RecaptchaField It also provides support for verification code , The sample code is as follows ：

from flask import Flask, render_template
from flask_wtf import FlaskForm, RecaptchaField, CSRFProtect

app = Flask(__name__)
app.config['SECRET_KEY']='hakhfaskh' # To configure CSRF The key needed , Its value is arbitrary
csrf = CSRFProtect(app)     # take CSRF Protection is added to app in

class Myform(FlaskForm):
    recaptcha = RecaptchaField() # Verification code field

@app.route('/')
def yanzm():
    myform=Myform()   # Create a form object
    return render_template('yanzm.html', myform=myform)  # Use render_template() Method rendering yanzm.html Document and will myform Pass on to file.html in

if __name__ == '__main__':
    app.run()

To configure CSRF The required key and will CSRF Protection is added to app in , Create a Myform Form class for , In the class, we define RecaptchaField Verification code field , In the view function, we create the form object , Use render_template() Method rendering yanzm.html Document and will myform Pass on to file.html in .

The following parameters need to be configured to use the verification code ：

RECAPTCHA_PUBLIC_KEY： Mandatory , Public key ;
RECAPTCHA_PRIVATE_KEY： Mandatory , Private key ;
RECAPTCHA_API_SERVER： Optional , Verification Code API The server ;
RECAPTCHA_PARAMETERS： Optional , One JavaScript（api.js） Dictionary of parameters ;
RECAPTCHA_DATA_ATTRS： Optional , A list of data attribute items https://developers.google.com/recaptcha/docs/display.

Create a yanzm.html, Its contents are as follows ：

<!DOCTYPE html>
<html lang="en">
<head>
    <meta charset="UTF-8">
    <title>Title</title>
</head>
<body>
   <form action="/" method="post">
        {
   { myform.csrf_token }}
       {
   { myform.recaptcha }}
   </form>
</body>
</html>

start-up flask project , visit http://127.0.0.1:5000/, Found nothing to show , This is because RecaptchaField() Field needs to call Google's verification code API, And call Google's verification code API Need to climb over the wall , We didn't climb over the wall , So nothing shows , As shown in the figure below ：

Use RecaptchaField() The verification code field needs to cross the wall , Then we won't use it , We draw the verification code ourselves .

Here we draw the verification code using pillow Graphics library , It executes the following code installation ：

pip install pillow

Install well pillow after , Let's create a name uitl.py file , Its function is to draw our graphic verification code , The code is as follows ：

import random
from PIL import Image, ImageFont, ImageDraw

# Customize get_color Method , Get three random numbers and save them in tuples
def get_color():
    return (random.randint(0,255),random.randint(0,255),random.randint(0,255))

# Customize generate_image Method to draw a picture verification code
def generate_image(4):
    size=(130,50)       # Set the size of the verification code
    im=Image.new('RGB',size,color=get_random_color()) # Create a verification code background
    font=ImageFont.truetype('C:\Windows\Fonts/simsun.ttc',size=40) # Set verification code font
    draw=ImageDraw.Draw(im)    # establish ImageDraw object
    code=''    # Set the verification code value
    s='abcdefghijklmnopqrstuvwxyz123456'  # Set the value range of the verification code
    for i in range(4):      # draw 4 Digit verification code value
        c=random.choice(s)   # Random in s The value of
        code+=c      # Put the obtained value in the verification code
        draw.text((9+random.randint(4,7)+20*i,random.randint(4,7)),text=c,fill=get_random_color(),font=font) # Write the verification code value in the verification code background
    im.show()
    return im ,code    # Return the image and verification code value

We customize get_color Method gets a three bit random number stored in a tuple and returns , Customize it again generate_image() Method to draw a picture verification code , Set the value range of the verification code 、 Background image size font, etc , And randomly obtain the verification code value and write it into the verification code background .

You can do it according to pillow Library documentation to add some interference lines to the verification code , In this way, the simple version of the graphic verification code is made , As shown in the figure below ：

Here we draw 4 Character image verification code , The code generation of image verification code has been written , Next we write flask Project to use the verification code , The sample code is as follows ：

from flask import Flask, render_template, session
from flask_wtf import FlaskForm, CSRFProtect
from wtforms import StringField, ValidationError

app = Flask(__name__)
app.config['SECRET_KEY']='hakhfaskh'      # To configure CSRF The key needed , Its value is arbitrary
csrf = CSRFProtect(app)          # take CSRF Protection is added to app in

class Myform(FlaskForm):   # Create a form class
    recaptcha = StringField()   # Create a text field
    def validate_recaptcha(self, data):   # Custom validation
        input_code=data.data       # The value of the entered verification code
        code=session.get('valid')    # obtain session Of valid value
        if input_code.lower()!=code.lower():  # Convert the verification code value to lowercase and judge whether the input verification code and the image verification code value are consistent
            raise ValidationError(' Verification code error ')  # Throw an error

@app.route('/',methods=['GET','POST'])
def yanzm():
    myform=Myform()        # Create form class objects
    if myform.validate_on_submit():    # Check whether it is a POST Request and whether the request is valid
        return ' Verify success '
    return render_template('yanzm.html', myform=myform)  # Use render_template() Method rendering yanzm.html Document and will myform Pass on to file.html in

if __name__ == '__main__':
    app.run()

Set up CSRF Protect , Create a form class to use StringField() Text fields and custom validation functions , Then create a form class object in the view function , Use validate_on_submit() Method to check whether it is a POST Request and whether the request is valid , Use render_template() Method rendering yanzm.html Document and will myform Pass on to file.html in .

Is this ok ？ Here we also need to create a view function to get the image verification code , The code is as follows ：

from util import generate_image   # Import generate_image
@app.route('/image')
def get_image():
    im,code=generate_image() # Get the verification code image and value
    buffer=BytesIO()   # take image Object to binary
    im.save(buffer,"JPEG")  # Save in binary form as JPEG Format
    buf_bytes=buffer.getvalue()  # Read binary verification code
    session['valid']=code     # Save to session in , Control the expiration time of the verification code
    response=make_response(buf_bytes)  # structure response object
    response.headers['Content-Type']='image/jpg' # Custom request header
    return response

In the view function , We call generate_image() Method to obtain the verification code image and value and save the image in binary form as JPEG Format , Generally, the verification code has an expiration time , So we use session Control the implementation time of the verification code , Use make_response() structure response Object to customize the request header for the verification code image .

Next we write yanzm.html file , The code is as follows ：

<!DOCTYPE html>
<html lang="en">
<head>
    <meta charset="UTF-8">
    <title>Title</title>
</head>
<body>
   <form action="/" method="post">
        {
   { myform.csrf_token }}  {# Rendering csrf#}
       {
   { myform.recaptcha }}<img src="{
   { url_for('get_image') }}" alt="" id="img">
        <p>{
   { myform.recaptcha.errors.0 }}</p>
        <input type="submit" value=" Submit ">
   </form>
</body>
</html>

In general , As long as we click the image verification code, it will refresh , So we can add the following code to control the refresh of the image verification code ：

<script src="http://libs.baidu.com/jquery/2.0.0/jquery.min.js"></script>
<script>
    $('#img').click(function (){
        $(this).attr('src',"{
   { url_for('get_image') }}?ran="+Math.random());
    })
</script>

Here we call Baidu jquery And add a click event for the verification code .

Okay , In this way, we have successfully drawn our image verification code , start-up flask project , visit http://127.0.0.1:5000/, As shown in the figure below ：

When we input correctly and click Submit , It will show that the verification is successful , When we input incorrectly and click Submit , The verification code error will be displayed .

Okay ,Flask frame ——Flask-WTF Forms ： Upload files 、 That's all for the verification code , Thank you for watching. , Next article study Flask frame ——Flask-Mail mail .

official account ： White chocolate LIN

The official account is released Python、 database 、Linux、Flask、 automated testing 、Git Etc ！

- END -
