Pagoda workman WSS reverse proxy socket legal domain name applet chat remove port

advance workerman It's already configured



One 、 Configuration with ports （ Don't talk about configuration here , There are other tutorials ）

Chat in applet , Need to set up socket Legitimate domain name :wss://www.xxx.com:2000



Two 、 Settings without ports

Pagoda configuration domain name , Handle wss Communication services
1、 Go to the domain name service provider to add the domain name wss.xxx.com
2、 Server application SSL certificate , And download
3、 Pagoda add domain name , Choose pure static

4、 The setting of the domain name corresponding to the pagoda , To configure SSL certificate , Open the certificate package just downloaded , Fill in the corresponding content , preservation

5、 The setting of the domain name corresponding to the pagoda -> The configuration file , stay server{ } Add the following at the end of the inner

Log in and copy





           #  Reverse proxy   Transfer to local websocket Address ,wss://127.0.0.1:2000 , Corresponding  wss://card.xxxx.com:2000


    location / {


        proxy_redirect off;


        proxy_pass https://127.0.0.1:2000;


        proxy_set_header Host $host;


        proxy_set_header X-Real_IP $remote_addr;


        proxy_set_header X-Forwarded-For $remote_addr:$remote_port;


        proxy_http_version 1.1;


        #  add to wss Fields dedicated to the protocol header


        proxy_set_header Upgrade $http_upgrade;


        proxy_set_header Connection "upgrade";


    }







1.


2.


3.


4.


5.


6.


7.


8.


9.


10.


11.


12.



Mainly these two lines ：

proxy_set_header Upgrade $http_upgrade;
proxy_set_header Connection "upgrade";



​
