AXI_Round_Robin_Arbiter 设计 - AW、W通道部分
2022-06-23 13:50:00 【Starry丶】
目录
1. 状态机设计
还是基于状态机，思路是收到了一包AW通道的数据，记录下它的len，然后根据len和awid收相应的AXI Master的W通道数据，保证AW通道和W通道顺序一致。
那权重怎么变化呢？此处想的是每AW和W通道完成一次收数，权重变化一次。注意要保证AW接受和W接收必须来自同一个AXI Master
1.1. WAIT_AW
等待某个AW通道与AXI Slave握手完成，即可转入下一状态
● 根据req输出grant
此处的req其实就是各AXI Master的awvalid组成的多bit数据，而grant就是仲裁的结果。注意在WAIT_AW时状态不发生变化
● 状态转移条件：AW通道握手完成
注意原算法的状态转移条件是req发生变化就转移，但在此处需要某个Master的awvalid为高且awready信号拉高才能握手，如下图
prio其实就是权重。虽然req中途发生了变化，但状态转移的条件是与Master0握手完成才转移条件。
注意AW通道只是一次性传递多个控制信息，不是burst，awready&awvalid有效一拍即可完成握手。
转入WAIT_W状态后awready不应再拉高，必须等待从WAIT_W回到WAIT_AW才能再拉高。
1.2. WAIT_W
然后进入WAIT_W状态，之前WAIT_AW状态下与哪个Master完成了握手，此处就必须等这个Master的W通道握手完成才能结束WAIT_W状态。
● grant保持，接受W通道数据
这里的grant必须要与WAIT_AW状态下握手完成时的grant一致，同时要一直接受W通道来的数据
● 状态转移条件：W通道握手完成
由于Master是固定的，所以只需看那个Master的wlast即可，这个信号表示最后一个数据。
握手完成之后，重新回到WAIT_AW状态。注意此时prio权重也要根据grant作修正，同时grant不能再继续保持了，转入WAIT_AW后要根据awvalid_mst作组合逻辑输出
综上所述，状态机变成
1.3. 代码
module axi_round_robin_arbiter_aw_w #(
parameter AWID_WIDTH = 8,
parameter AWADDR_WIDTH = 16,
parameter WDATA_WIDTH = 16,
parameter MAX_PRIO_INITIAL_INDEX = 0
)(
input aclk,
input arstn,
//AW CHANNEL
input [(AWID_WIDTH+2)*4-1:0] awid_mst,
input [AWADDR_WIDTH*4-1:0] awaddr_mst,
input [8*4-1:0] awlen_mst,
input [3*4-1:0] awsize_mst,
input [2*4-1:0] awburst_mst,
input [1*4-1:0] awvalid_mst,
output [1*4-1:0] awready_mst,
output [(AWID_WIDTH+2)-1:0] awid,
output [AWADDR_WIDTH-1:0] awaddr,
output [8-1:0] awlen,
output [3-1:0] awsize,
output [2-1:0] awburst,
output awvalid,
input awready,
//W CHANNEL
input [WDATA_WIDTH*4-1:0] wdata_mst,
input [1*4-1:0] wlast_mst,
input [1*4-1:0] wvalid_mst,
output [1*4-1:0] wready_mst,
output [WDATA_WIDTH-1:0] wdata,
output [1-1:0] wlast,
output [1-1:0] wvalid,
input [1-1:0] wready
);
localparam WAIT_AW = 1'b0;
localparam WAIT_W = 1'b1;
reg [4-1:0] cur_state;
reg [4-1:0] nxt_state;
reg [4-1:0] grant;
reg [4-1:0] grant_tmp;
reg [4-1:0] prio;
reg wvalid_mst_cs;
reg wlast_mst_cs;
wire [4-1:0] inital_state;
wire [4:0] res1;
wire [4:0] res2;
assign inital_state = {
{
(4-MAX_PRIO_INITIAL_INDEX-1){
1'b0}},1'b1,{
MAX_PRIO_INITIAL_INDEX{
1'b0}}};
[email protected](posedge aclk or negedge arstn) begin
if(!arstn)
cur_state <= WAIT_AW;
else
cur_state <= nxt_state;
end
[email protected](*) begin
case(cur_state)
WAIT_AW:
if((|awvalid_mst) && awready)
nxt_state = WAIT_W;
else
nxt_state = WAIT_AW;
WAIT_W:
if(wvalid_mst_cs && wlast_mst_cs && wready)
nxt_state = WAIT_AW;
else
nxt_state = WAIT_W;
default: nxt_state = WAIT_AW;
endcase
end
alwa[email protected](posedge aclk or negedge arstn) begin
if(!arstn)
prio <= inital_state;
else if(cur_state == WAIT_W && wvalid_mst_cs && wlast_mst_cs && wready)
prio <= (grant[3])? 4'b1:(grant << 1);
end
[email protected](*) begin
if(cur_state == WAIT_AW)
wlast_mst_cs = 1'b0;
else begin
case(grant)
4'b0001:
wlast_mst_cs = wlast_mst[0];
4'b0010:
wlast_mst_cs = wlast_mst[1];
4'b0100:
wlast_mst_cs = wlast_mst[2];
4'b1000:
wlast_mst_cs = wlast_mst[3];
default:
wlast_mst_cs = 1'b0;
endcase
end
end
[email protected](*) begin
if(cur_state == WAIT_W)
wvalid_mst_cs = 1'b0;
else begin
case(grant)
4'b0001:
wvalid_mst_cs = wvalid_mst[0];
4'b0010:
wvalid_mst_cs = wvalid_mst[1];
4'b0100:
wvalid_mst_cs = wvalid_mst[2];
4'b1000:
wvalid_mst_cs = wvalid_mst[3];
default:
wvalid_mst_cs = 1'b0;
endcase
end
end
[email protected](posedge aclk or negedge arstn) begin
if(!arstn)
grant_tmp <= 'd0;
else if(cur_state == WAIT_AW && (|awvalid_mst) && awready)
grant_tmp <= grant;
end
assign res1 = {
1'b0,~awvalid_mst} + {
1'b0,prio};
assign res2 = res1[4] + res1;
[email protected](*) begin
if(cur_state == WAIT_AW)
grant = awvalid_mst & res2;
else
grant = grant_tmp;
end
//-----------------AW channel chip select--------------------------
reg [(AWID_WIDTH+2)-1:0] awid_r;
reg [AWADDR_WIDTH-1:0] awaddr_r;
reg [8-1:0] awlen_r;
reg [3-1:0] awsize_r;
reg [2-1:0] awburst_r;
reg awvalid_r;
reg [1*4-1:0] awready_mst_r;
[email protected](*) begin
if(cur_state == WAIT_AW) begin
case(grant)
4'b0001:
awid_r = awid_mst[(AWID_WIDTH+2)-1:0];
4'b0010:
awid_r = awid_mst[(AWID_WIDTH+2)*2-1:(AWID_WIDTH+2)];
4'b0100:
awid_r = awid_mst[(AWID_WIDTH+2)*3-1:(AWID_WIDTH+2)*2];
4'b1000:
awid_r = awid_mst[(AWID_WIDTH+2)*4-1:(AWID_WIDTH+2)*3];
default:
awid_r = 'd0;
endcase
end
else
awid_r = 'd0;
end
assign awid = awid_r;
[email protected](*) begin
if(cur_state == WAIT_AW) begin
case(grant)
4'b0001:
awaddr_r = awaddr_mst[AWADDR_WIDTH-1:0];
4'b0010:
awaddr_r = awaddr_mst[AWADDR_WIDTH*2-1:AWADDR_WIDTH];
4'b0100:
awaddr_r = awaddr_mst[AWADDR_WIDTH*3-1:AWADDR_WIDTH*2];
4'b1000:
awaddr_r = awaddr_mst[AWADDR_WIDTH*4-1:AWADDR_WIDTH*3];
default:
awaddr_r = 'd0;
endcase
end
else
awaddr_r = 'd0;
end
assign awaddr = awaddr_r;
[email protected](*) begin
if(cur_state == WAIT_AW) begin
case(grant)
4'b0001:
awlen_r = awlen_mst[8-1:0];
4'b0010:
awlen_r = awlen_mst[8*2-1:8];
4'b0100:
awlen_r = awlen_mst[8*3-1:8*2];
4'b1000:
awlen_r = awlen_mst[8*4-1:8*3];
default:
awlen_r = 'd0;
endcase
end
else
awlen_r = 'd0;
end
assign awlen = awlen_r;
[email protected](*) begin
if(cur_state == WAIT_AW) begin
case(grant)
4'b0001:
awsize_r = awsize_mst[3-1:0];
4'b0010:
awsize_r = awsize_mst[3*2-1:3];
4'b0100:
awsize_r = awsize_mst[3*3-1:3*2];
4'b1000:
awsize_r = awsize_mst[3*4-1:3*3];
default:
awsize_r = 'd0;
endcase
end
else
awsize_r = 'd0;
end
assign awsize = awsize_r;
[email protected](*) begin
if(cur_state == WAIT_AW) begin
case(grant)
4'b0001:
awburst_r = awburst_mst[2-1:0];
4'b0010:
awburst_r = awburst_mst[2*2-1:2];
4'b0100:
awburst_r = awburst_mst[2*3-1:2*2];
4'b1000:
awburst_r = awburst_mst[2*4-1:2*3];
default:
awburst_r = 'd0;
endcase
end
else
awburst_r = 'd0;
end
assign awburst = awburst_r;
[email protected](*) begin
if(cur_state == WAIT_AW) begin
case(grant)
4'b0001:
awvalid_r = awvalid_mst[1-1:0];
4'b0010:
awvalid_r = awvalid_mst[1*2-1:1];
4'b0100:
awvalid_r = awvalid_mst[1*3-1:1*2];
4'b1000:
awvalid_r = awvalid_mst[1*4-1:1*3];
default:
awvalid_r = 'd0;
endcase
end
else
awvalid_r = 'd0;
end
assign awvalid = awvalid_r;
[email protected](*) begin
if(cur_state == WAIT_AW)
awready_mst_r = awready << grant;
else
awready_mst_r = 'd0;
end
assign awready_mst = awready_mst_r;
//-----------------W channel chip select--------------------------
reg [1*4-1:0] wready_mst_r;
reg [WDATA_WIDTH-1:0] wdata_r;
reg [1-1:0] wlast_r;
reg [1-1:0] wvalid_r;
[email protected](*) begin
if(cur_state == WAIT_AW)
wready_mst_r = 'd0;
else
wready_mst_r = wready << grant;
end
assign wready_mst = wready_mst_r;
[email protected](*) begin
if(cur_state == WAIT_AW)
wdata_r = 'd0;
else begin
case(grant)
4'b0001:
wdata_r = wdata_mst[WDATA_WIDTH-1:0];
4'b0010:
wdata_r = wdata_mst[WDATA_WIDTH*2-1:WDATA_WIDTH];
4'b0100:
wdata_r = wdata_mst[WDATA_WIDTH*3-1:WDATA_WIDTH*2];
4'b1000:
wdata_r = wdata_mst[WDATA_WIDTH*4-1:WDATA_WIDTH*3];
default:
wdata_r = 'd0;
endcase
end
end
assign wdata = wdata_r;
[email protected](*) begin
if(cur_state == WAIT_AW)
wlast_r = 'd0;
else begin
case(grant)
4'b0001:
wlast_r = wlast_mst[0];
4'b0010:
wlast_r = wlast_mst[1];
4'b0100:
wlast_r = wlast_mst[2];
4'b1000:
wlast_r = wlast_mst[3];
default:
wlast_r = 'd0;
endcase
end
end
assign wlast = wlast_r;
[email protected](*) begin
if(cur_state == WAIT_AW)
wvalid_r = 'd0;
else begin
case(grant)
4'b0001:
wvalid_r = wvalid_mst[0];
4'b0010:
wvalid_r = wvalid_mst[1];
4'b0100:
wvalid_r = wvalid_mst[2];
4'b1000:
wvalid_r = wvalid_mst[3];
default:
wvalid_r = 'd0;
endcase
end
end
assign wvalid = wvalid_r;
endmodule
2. 状态机改流水
可以发现，在上述状态机的设计中，WAIT_AW状态时AXI Master的AW通道和AXI Slave的AW通道信号能够相互通信，但此时W通道被阻断。在WAIT_W状态下，W通道的信号被打通，而AW通道的信号被阻隔。
此时想到，在WAIT_W状态下，AW通道直接被阻隔了，那能不能放开，让AW通道正常通信，即WAIT_AW和WAIT_W两种状态并行呢？
流水线设计可从状态机改造而来，例如乘法器就可分为先单bit相乘、再错位相加，那么在错位相加的时候可不可以对新的数据进行单bit相乘呢？可以，按照这个思路就将状态机优化成流水线了。
RTL乘法器IP设计
当然不是所有的状态机都可以完全优化成流水线，有的完全不能优化（例如USART），有的可以将部分状态进行流水优化。
那么 怎么将WAIT_AW和WAIT_W并行起来呢？
AW通道和W通道协同设计的根本原因是，W通道没有wid，所以AW通道的收数顺序必须与W通道的收数顺序一致。
所以，只需每次AW完成握手一次，记录下此时握手的Master是谁，即grant。每完成一次握手就将grant放入FIFO，而W通道呢则每完成一次握手就从FIFO读出grant知道下次要交互的Master，这样就实现了AW通道和W通道的流水啦。
既然两个通道使用同步FIFO隔离，那么就可以分成两个模块了
2.1. axi_round_robin_arbiter_aw
AW通道仲裁比较好说，但还是要使用状态机，此处的状态就要改成FIFO是否满了，FIFO满了通信就要阻断。
代码
module axi_round_robin_arbiter_aw #(
parameter AWID_WIDTH = 8,
parameter AWADDR_WIDTH = 16,
parameter MAX_PRIO_INITIAL_INDEX = 0
)(
input aclk,
input arstn,
//AW CHANNEL
input [(AWID_WIDTH+2)*4-1:0] awid_mst,
input [AWADDR_WIDTH*4-1:0] awaddr_mst,
input [8*4-1:0] awlen_mst,
input [3*4-1:0] awsize_mst,
input [2*4-1:0] awburst_mst,
input [1*4-1:0] awvalid_mst,
output [1*4-1:0] awready_mst,
output [(AWID_WIDTH+2)-1:0] awid,
output [AWADDR_WIDTH-1:0] awaddr,
output [8-1:0] awlen,
output [3-1:0] awsize,
output [2-1:0] awburst,
output awvalid,
input awready,
input grant_fifo_full,
output [4-1:0] grant,
output grant_val
);
reg [4-1:0] cur_state;
reg [4-1:0] nxt_state;
wire [4-1:0] inital_state;
wire [4:0] res1;
wire [4:0] res2;
assign inital_state = {
{
(4-MAX_PRIO_INITIAL_INDEX-1){
1'b0}},1'b1,{
MAX_PRIO_INITIAL_INDEX{
1'b0}}};
[email protected](posedge aclk or negedge arstn) begin
if(!arstn)
cur_state <= inital_state;
else
cur_state <= nxt_state;
end
[email protected](*) begin
if(grant_val) begin
if(grant[3])
nxt_state = 4'b1;
else
nxt_state = grant << 1;
end
else
nxt_state = cur_state;
end
assign res1 = {
1'b0,~awvalid_mst} + {
1'b0,cur_state};
assign res2 = res1[4] + res1;
assign grant = awvalid_mst & res2;
assign grant_val = awvalid && awready;
//-----------------AW channel chip select--------------------------
reg [(AWID_WIDTH+2)-1:0] awid_r;
reg [AWADDR_WIDTH-1:0] awaddr_r;
reg [8-1:0] awlen_r;
reg [3-1:0] awsize_r;
reg [2-1:0] awburst_r;
reg awvalid_r;
reg [1*4-1:0] awready_mst_r;
[email protected](*) begin
if(!grant_fifo_full) begin
case(grant)
4'b0001:
awid_r = awid_mst[(AWID_WIDTH+2)-1:0];
4'b0010:
awid_r = awid_mst[(AWID_WIDTH+2)*2-1:(AWID_WIDTH+2)];
4'b0100:
awid_r = awid_mst[(AWID_WIDTH+2)*3-1:(AWID_WIDTH+2)*2];
4'b1000:
awid_r = awid_mst[(AWID_WIDTH+2)*4-1:(AWID_WIDTH+2)*3];
default:
awid_r = 'd0;
endcase
end
else
awid_r = 'd0;
end
assign awid = awid_r;
[email protected](*) begin
if(!grant_fifo_full) begin
case(grant)
4'b0001:
awaddr_r = awaddr_mst[AWADDR_WIDTH-1:0];
4'b0010:
awaddr_r = awaddr_mst[AWADDR_WIDTH*2-1:AWADDR_WIDTH];
4'b0100:
awaddr_r = awaddr_mst[AWADDR_WIDTH*3-1:AWADDR_WIDTH*2];
4'b1000:
awaddr_r = awaddr_mst[AWADDR_WIDTH*4-1:AWADDR_WIDTH*3];
default:
awaddr_r = 'd0;
endcase
end
else
awaddr_r = 'd0;
end
assign awaddr = awaddr_r;
[email protected](*) begin
if(!grant_fifo_full) begin
case(grant)
4'b0001:
awlen_r = awlen_mst[8-1:0];
4'b0010:
awlen_r = awlen_mst[8*2-1:8];
4'b0100:
awlen_r = awlen_mst[8*3-1:8*2];
4'b1000:
awlen_r = awlen_mst[8*4-1:8*3];
default:
awlen_r = 'd0;
endcase
end
else
awlen_r = 'd0;
end
assign awlen = awlen_r;
[email protected](*) begin
if(!grant_fifo_full) begin
case(grant)
4'b0001:
awsize_r = awsize_mst[3-1:0];
4'b0010:
awsize_r = awsize_mst[3*2-1:3];
4'b0100:
awsize_r = awsize_mst[3*3-1:3*2];
4'b1000:
awsize_r = awsize_mst[3*4-1:3*3];
default:
awsize_r = 'd0;
endcase
end
else
awsize_r = 'd0;
end
assign awsize = awsize_r;
[email protected](*) begin
if(!grant_fifo_full) begin
case(grant)
4'b0001:
awburst_r = awburst_mst[2-1:0];
4'b0010:
awburst_r = awburst_mst[2*2-1:2];
4'b0100:
awburst_r = awburst_mst[2*3-1:2*2];
4'b1000:
awburst_r = awburst_mst[2*4-1:2*3];
default:
awburst_r = 'd0;
endcase
end
else
awburst_r = 'd0;
end
assign awburst = awburst_r;
[email protected](*) begin
if(!grant_fifo_full) begin
case(grant)
4'b0001:
awvalid_r = awvalid_mst[1-1:0];
4'b0010:
awvalid_r = awvalid_mst[1*2-1:1];
4'b0100:
awvalid_r = awvalid_mst[1*3-1:1*2];
4'b1000:
awvalid_r = awvalid_mst[1*4-1:1*3];
default:
awvalid_r = 'd0;
endcase
end
else
awvalid_r = 'd0;
end
assign awvalid = awvalid_r;
[email protected](*) begin
if(!grant_fifo_full)
awready_mst_r = awready << grant;
else
awready_mst_r = 'd0;
end
assign awready_mst = awready_mst_r;
endmodule
2.2. axi_round_robin_arbiter_w
对于W通道而言，必须从FIFO读出grant才能与grant规定的Master握手，所以还是按照状态机的设计过程，分为两个状态
RD_GRANT
该状态下就一直读FIFO，同时W通道被阻塞，直到grant被读出
HANDSHAKE
此时grant会一直保持，按照grant选择Master等待握手完成就可以。
代码
module axi_round_robin_arbiter_w #(
parameter WDATA_WIDTH = 16,
parameter MAX_PRIO_INITIAL_INDEX = 0
)(
input aclk,
input arstn,
//W CHANNEL
input [WDATA_WIDTH*4-1:0] wdata_mst,
input [1*4-1:0] wlast_mst,
input [1*4-1:0] wvalid_mst,
output [1*4-1:0] wready_mst,
output [WDATA_WIDTH-1:0] wdata,
output [1-1:0] wlast,
output [1-1:0] wvalid,
input [1-1:0] wready,
output fifo_rd_en,
input fifo_empty,
input [4-1:0] grant,
input grant_val
);
localparam IDLE = 2'b00;
localparam RD_GRANT = 2'b01;
localparam HANDSHAKE = 2'b11;
reg [1:0] cur_state;
reg [1:0] nxt_state;
reg fifo_rd_en_r;
[email protected](posedge aclk or negedge arstn) begin
if(!arstn)
cur_state <= IDLE;
else
cur_state <= nxt_state;
end
[email protected](*) begin
case(cur_state)
IDLE:
nxt_state = RD_GRANT;
RD_GRANT:
if(grant_val)
nxt_state = HANDSHAKE;
else
nxt_state = RD_GRANT;
HANDSHAKE:
if(wlast && wready)
nxt_state = HANDSHAKE;
else
nxt_state = RD_GRANT;
default: nxt_state = IDLE;
endcase
end
[email protected](posedge aclk or negedge arstn) begin
if(!arstn)
fifo_rd_en_r <= 1'b0;
else if(cur_state == IDLE)
fifo_rd_en_r <= 1'b1;
else if(cur_state == RD_GRANT) begin
if(!fifo_empty)
fifo_rd_en_r <= 1'b0;
end
else if(cur_state == HANDSHAKE) begin
if(wlast && wready)
fifo_rd_en_r <= 1'b1;
end
end
assign fifo_rd_en = fifo_rd_en_r;
//-----------------W channel chip select--------------------------
reg [1*4-1:0] wready_mst_r;
reg [WDATA_WIDTH-1:0] wdata_r;
reg [1-1:0] wlast_r;
reg [1-1:0] wvalid_r;
[email protected](*) begin
if(!cur_state[0]) //(cur_state == IDLE) && (cur_state == RD_GRANT)
wready_mst_r = 'd0;
else
wready_mst_r = wready << grant;
end
assign wready_mst = wready_mst_r;
[email protected](*) begin
if(!cur_state[0])
wdata_r = 'd0;
else begin
case(grant)
4'b0001:
wdata_r = wdata_mst[WDATA_WIDTH-1:0];
4'b0010:
wdata_r = wdata_mst[WDATA_WIDTH*2-1:WDATA_WIDTH];
4'b0100:
wdata_r = wdata_mst[WDATA_WIDTH*3-1:WDATA_WIDTH*2];
4'b1000:
wdata_r = wdata_mst[WDATA_WIDTH*4-1:WDATA_WIDTH*3];
default:
wdata_r = 'd0;
endcase
end
end
assign wdata = wdata_r;
[email protected](*) begin
if(!cur_state[0])
wlast_r = 'd0;
else begin
case(grant)
4'b0001:
wlast_r = wlast_mst[0];
4'b0010:
wlast_r = wlast_mst[1];
4'b0100:
wlast_r = wlast_mst[2];
4'b1000:
wlast_r = wlast_mst[3];
default:
wlast_r = 'd0;
endcase
end
end
assign wlast = wlast_r;
[email protected](*) begin
if(!cur_state[0])
wvalid_r = 'd0;
else begin
case(grant)
4'b0001:
wvalid_r = wvalid_mst[0];
4'b0010:
wvalid_r = wvalid_mst[1];
4'b0100:
wvalid_r = wvalid_mst[2];
4'b1000:
wvalid_r = wvalid_mst[3];
default:
wvalid_r = 'd0;
endcase
end
end
assign wvalid = wvalid_r;
endmodule
边栏推荐
- 【深入理解TcaplusDB技术】TcaplusDB构造数据
- [deeply understand tcapulusdb technology] tmonitor system upgrade
- Instructions for laravel8 Beanstalk
- Google Earth engine (GEE) -- Comparative Case Analysis of calculating slope with different methods
- Is flush a stock? Is it safe to open an account online now?
- 微信小程序之input调整
- 微信小程序之在wx:for中绑定事件
- Assembly language interrupt and external device operation --06
- leetcode:42.接雨水
- [Level 2 warranty] which brand of Fortress machine is good for Level 2 warranty?
猜你喜欢
【深入理解TcaplusDB技术】如何实现Tmonitor单机安装
Flutter Clip剪裁组件
Instructions for laravel8 Beanstalk
Tencent cloud tdsql-c heavy upgrade, leading the cloud native database market in terms of performance
The company has only one test, but the leader asked me to operate 1000 mobile numbers at the same time
MIT 6.031 reading5: version control learning experience
![[deeply understand tcapulusdb technology] table management of document acceptance](/img/59/e435623ab9cc7d2aa164c2f08e135f.png)
[deeply understand tcapulusdb technology] table management of document acceptance
今年英语高考，CMU用重构预训练交出134高分，大幅超越GPT3
Intelligent digital signage solution
微信小程序之获取php后台数据库转化的json
随机推荐
How do I turn on / off the timestamp when debugging the chrome console?
Actual combat | how to make a slam track truth acquisition device?
Kali use
[deeply understand tcapulusdb technology] table management of document acceptance
Interrupt and polling
【深入理解TcaplusDB技术】TcaplusDB业务数据备份
When did the redo log under InnoDB in mysql start to perform check point disk dropping?
JSP_ SSM Wanfu cinema ticket sales management system, including paper [demonstration video]
Assembly language interrupt and external device operation --06
[compréhension approfondie de la technologie tcaplusdb] données de construction tcaplusdb
Building Intel devcloud
【深入理解TcaplusDB技术】TcaplusDB构造数据
ICML 2022 | 上下文集成的基于transformer的拍卖设计神经网络
Detailed explanation of kubernetes log monitoring system architecture
Cause analysis and intelligent solution of information system row lock waiting
大厂架构师：如何画一张大气的业务大图？
图解OneFlow的学习率调整策略
WPF (c) new open source control library: newbeecoder UI waiting animation
Short talk about community: how to build a game community?
Use xtradiagram Diagramcontrol for drawing and controlling process graphics
