四、入库管理功能的完善

一、数据库的创建

在fiber_yy数据库下创建yy_textile表

先随便添加几条数据

二、页面的完善

登录注册页面我就不演示了，前几篇博文也都有介绍

warehousing入库页面

main_page页面进行功能完善

三、代码实现

warehousing页面

using System;
using System.IO;
using System.Collections.Generic;
using System.ComponentModel;
using System.Data;
using System.Data.OleDb;
using System.Drawing;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
using System.Windows.Forms;
using System.Data.Sql;
using System.Data.SqlClient;
namespace fiber_yy
{

    public partial class warehousing : Form
    {

        public string constr = "server=CY-20190824RMES;Initial Catalog=fiber_yy;User ID=sa;pwd=beyond";

        public warehousing()
        {

            InitializeComponent();
        }

        private void button2_Click(object sender, EventArgs e)
        {


            OpenFileDialog ofdlgTest = new OpenFileDialog();
            //ofdlgTest.Filter = "*.jpg|*.png"; //文件过滤 筛选可以打开的文件
            ofdlgTest.Filter = "";
            ofdlgTest.Multiselect = false;    //设置不可以选择多个文件

            //显示文件打开对话框
            DialogResult result = ofdlgTest.ShowDialog();

            //选择打开按钮的时候，将文件名显示到文本框中
            if (result == DialogResult.OK)                   //判断是否打开文件
            {

                this.textBox11.Text = ofdlgTest.FileName;

                pictureBox1.Image = Image.FromFile(ofdlgTest.FileName);
            }

        }

        private void button1_Click(object sender, EventArgs e)
        {

            try
            {

                string path = textBox11.Text;

                FileStream fs = new FileStream(path, FileMode.Open, FileAccess.Read); //将指定路径的图片添加到FileStream类中
                BinaryReader br = new BinaryReader(fs);//通过FileStream对象实例化BinaryReader对象

                byte[] imgBytesIn = br.ReadBytes(Convert.ToInt32(fs.Length));//将图片转为二进制数据
                                                                             //Save(imgBytesIn);//调用（自己写的一个方法）
                SqlConnection conn = new SqlConnection(constr);
                conn.Open();

                string name = textBox1.Text;
                int number = int.Parse(textBox2.Text);
                float warp_density = float.Parse(textBox3.Text);
                float weft_density = float.Parse(textBox4.Text);
                float warp_linear_density = float.Parse(textBox5.Text);
                float weft_linear_density = float.Parse(textBox6.Text);
                string material = textBox7.Text;
                float square_meter_weight = float.Parse(textBox8.Text);
                float width_of_cloth = float.Parse(textBox9.Text);
                float horse_length = float.Parse(textBox10.Text);

                string organization = textBox12.Text;
                int stock = int.Parse(textBox13.Text);



                SqlCommand cmd = new SqlCommand("insert into yy_textile (name,number,warp_density,weft_density,warp_linear_density,weft_linear_density,material,square_meter_weight,width_of_cloth,horse_length,picture,organization,stock) " +
                    "values(@name,@number,@warp_density,@weft_density,@warp_linear_density,@weft_linear_density,@material,@square_meter_weight,@width_of_cloth,@horse_length,@picture,@organization,@stock);", conn); //SQL语句


                cmd.Parameters.Add("@name", SqlDbType.VarChar);
                cmd.Parameters["@name"].Value = name;

                cmd.Parameters.Add("@number", SqlDbType.Int);
                cmd.Parameters["@number"].Value = number;

                cmd.Parameters.Add("@warp_density", SqlDbType.Float);
                cmd.Parameters["@warp_density"].Value = warp_density;

                cmd.Parameters.Add("@weft_density", SqlDbType.Float);
                cmd.Parameters["@weft_density"].Value = weft_density;

                cmd.Parameters.Add("@warp_linear_density", SqlDbType.Float);
                cmd.Parameters["@warp_linear_density"].Value = warp_linear_density;

                cmd.Parameters.Add("@weft_linear_density", SqlDbType.Float);
                cmd.Parameters["@weft_linear_density"].Value = weft_linear_density;

                cmd.Parameters.Add("@material", SqlDbType.VarChar);
                cmd.Parameters["@material"].Value = material;

                cmd.Parameters.Add("@square_meter_weight", SqlDbType.Float);
                cmd.Parameters["@square_meter_weight"].Value = square_meter_weight;

                cmd.Parameters.Add("@width_of_cloth", SqlDbType.Float);
                cmd.Parameters["@width_of_cloth"].Value = width_of_cloth;

                cmd.Parameters.Add("@horse_length", SqlDbType.Float);
                cmd.Parameters["@horse_length"].Value = horse_length;

                cmd.Parameters.Add("@picture", SqlDbType.Image);
                cmd.Parameters["@picture"].Value = imgBytesIn;

                cmd.Parameters.Add("@organization", SqlDbType.VarChar);
                cmd.Parameters["@organization"].Value = organization;

                cmd.Parameters.Add("@stock", SqlDbType.Int);
                cmd.Parameters["@stock"].Value = stock;



                cmd.ExecuteNonQuery();

                conn.Close();
                MessageBox.Show("图片上传成功");
            }
            catch
            {

                MessageBox.Show("请核对输入信息");
            }

        }

        private void button3_Click(object sender, EventArgs e)
        {

            new main_page().Show();
            this.Hide();
        }
    }
}

main_page页面

using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Data;
using System.Drawing;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
using System.Windows.Forms;

namespace fiber_yy
{

    public partial class main_page : Form
    {

        public main_page()
        {

            InitializeComponent();
        }

        private void button1_Click(object sender, EventArgs e)
        {

            MessageBox.Show("退出成功");
            this.Close();
            new Form1().Show();
        }

        private void button2_Click(object sender, EventArgs e)
        {

            this.Close();
            new warehousing().Show();
        }

        private void button3_Click(object sender, EventArgs e)
        {

            this.Close();
            new shipment().Show();
        }

        private void button4_Click(object sender, EventArgs e)
        {

            this.Close();
            new query().Show();
        }
    }
}

四、效果演示

程序运行

注册我就不演示了，请参考前几篇博文
从yy_user表中找个账号密码，直接用户登录


登录成功

进入系统

首先演示下入库管理功能

入库
