XML modeling

2022-07-23 11:26:00 【_ Leaf1217】

Catalog

Two 、23 Factory mode of three modeling methods

One 、 Learn to XML modeling

Today we'll see how XML modeling , First of all, we should model it first XML file 【config.xml】 Put it here ：

<?xml version="1.0" encoding="UTF-8"?>

<config>
	<action path="/regAction" type="test.RegAction">
		<forward name="failed" path="/reg.jsp" redirect="false" />
		<forward name="success" path="/login.jsp" redirect="true" />
	</action>

	<action path="/loginAction" type="test.LoginAction">
		<forward name="failed" path="/login.jsp" redirect="false" />
		<forward name="success" path="/main.jsp" redirect="true" />
	</action>
</config>

Let's first analyze this xml file ：

1) Analyze tags
A root tag ：config
A sub tag ：action
action There are sub tags inside ：forward
2) Analysis properties
action：path、type
forward：name、path、redirect

According to the above analysis, we can know that there are three different tags in this configuration file ：

config： There are sub tags 、 There is no attribute

action： There are sub tags

forward： No sub tags

So we started our The first step of modeling ,

utilize Object oriented programming idea For different labels Construction entity ：

ForwardModel：

package com.leaf.mode;
/**
 * forward label
 * @author Leaf
 *
 * 2022 year 6 month 15 Japan   In the morning 8:40:48
 */
public class ForwardModel {
	//<forward name="success" path="/main.jsp" redirect="true" />
	private String name;
	private String path;
	private boolean redirect;

	public String getName() {
		return name;
	}
	public void setName(String name) {
		this.name = name;
	}
	public String getPath() {
		return path;
	}
	public void setPath(String path) {
		this.path = path;
	}
	public boolean isRedirect() {
		return redirect;
	}
	public void setRedirect(boolean redirect) {
		this.redirect = redirect;
	}

	public ForwardModel() {

	}
	public ForwardModel(String name, String path, boolean redirect) {
		this.name = name;
		this.path = path;
		this.redirect = redirect;
	}

	@Override
	public String toString() {
		return "ForwardMode [name=" + name + ", path=" + path + ", redirect=" + redirect + "]";
	}

}

ActionModel： There are sub tags , need Two behavior methods ：

1） add to forward label

2） Inquire about forward label

package com.leaf.mode;

import java.util.HashMap;
import java.util.Map;

/**
 * action label
 * @author Leaf
 *
 * 2022 year 6 month 15 Japan   In the morning 8:41:08
 */
public class ActionModel {
	//<action path="/loginAction" type="test.LoginAction">
	private String path;
	private String type;
	private Map<String, ForwardModel> fMap = new HashMap<String, ForwardModel>();

	public String getPath() {
		return path;
	}
	public void setPath(String path) {
		this.path = path;
	}
	public String getType() {
		return type;
	}
	public void setType(String type) {
		this.type = type;
	}

	public ActionModel() {
		// TODO Auto-generated constructor stub
	}
	public ActionModel(String path, String type) {
		super();
		this.path = path;
		this.type = type;
	}

	/**
	 *  Two behaviors : increase forward object | lookup forward object
	 * @param forward object
	 */
	// Will a new forward Label objects are added to the container
	public void push(ForwardModel f) {
		fMap.put(f.getName(), f);
	}
    // Inquire about forward label
	public ForwardModel pop(String name) {
		return fMap.get(name);
	}

	@Override
	public String toString() {
		return "ActionMode [path=" + path + ", type=" + type + "]";
	}

}

ConfigModel： There is no attribute 、 There are sub tags 、 need Two behavior methods ：

1） add to action label

2） Inquire about action label

package com.leaf.mode;
/**
 * config label
 * @author Leaf
 *
 * 2022 year 6 month 15 Japan   In the morning 8:41:23
 */

import java.util.HashMap;
import java.util.Map;

public class ConfigModel {

	private Map<String, ActionModel> aMap = new HashMap<String, ActionModel>();

	public void push(ActionModel am) {
		aMap.put(am.getPath(), am);
	}

	public ActionModel pop(String path) {
		return aMap.get(path);
	}

}

Two 、23 Factory mode of three modeling methods

But after we build entity classes for each tag and write the corresponding behavior methods ,

Need Create a factory pattern class ：ConfigModelFactory

First take a look at the comments about this factory schema class ：

/**
* 23 Factory mode of design mode
* ConfigModelFactory It's for production ConfigModel Object's
* manufactured ConfigModel Object contains Config.xml Configuration content in
*
* Produced here ConfigModel There is configuration information
* 1、 analysis Config.xml Configuration information in
* 2、 Load the corresponding configuration information into different model objects
* @author Leaf
*
* 2022 year 6 month 15 Japan In the morning 9:00:42
*/

Then I put it directly Factory class code La ：

package com.leaf.mode;

import java.io.InputStream;
import java.util.List;

import org.dom4j.Document;
import org.dom4j.DocumentException;
import org.dom4j.Element;
import org.dom4j.io.SAXReader;

/**
 * 23 Factory mode of design mode
 * ConfigModelFactory It's for production ConfigModel Object's
 *  manufactured ConfigModel Object contains Config.xml Configuration content in
 *
 *  Produced here ConfigModel There is configuration information
 * 1、 analysis Config.xml Configuration information in
 * 2、 Load the corresponding configuration information into different model objects
 * @author Leaf
 *
 * 2022 year 6 month 15 Japan   In the morning 9:00:42
 */
public class ConfigModelFactory {
	public static ConfigModel bulid(String path) throws Exception {
		InputStream in = ConfigModelFactory.class.getResourceAsStream(path);
		SAXReader sr = new SAXReader();
		Document doc = sr.read(in);
		List<Element> actionEles = doc.selectNodes("/config/action");
		ConfigModel cm = new ConfigModel();
		for (Element actionEle : actionEles) {
			ActionModel am = new ActionModel();
			am.setPath(actionEle.attributeValue("path"));
			am.setType(actionEle.attributeValue("type"));
			// take forwardmodel Assign and add to Actionmodel in
			List<Element> forwardEle = actionEle.selectNodes("forward");
			for (Element element : forwardEle) {
				ForwardModel forwardModel = new ForwardModel();
				forwardModel.setName(element.attributeValue("name"));
				forwardModel.setPath(element.attributeValue("path"));
				//redirect: Can only be false|true, Allow space , The default value is false
				forwardModel.setRedirect("true".equals(element.attributeValue("redirect")));
				am.push(forwardModel);
			}
			cm.push(am);
		}
		return cm;
	}
	// Only test here , It can be called directly where it is used bulid(" File path ") Of ;
	public static ConfigModel bulid() throws Exception {
		String defaultPath = "config.xml";
		return bulid(defaultPath);
	}
}

When all these are built, we can create another class Call tests Use it ：

   public static void main(String[] args) throws Exception {
       // Call the method of the factory class to get the tag config
       ConfigModel cm = ConfigModelFactory.bulid();

       // call config How to query
       ActionModel am = cm.pop("/loginAction");
       // Print test
       System.out.println("Type:\t"+am.getType()+"\n");

       // Inquire about
       ForwardModel fm = am.pop("success");
       // Print test
       System.out.println("Path:\t"+fm.getPath());
   }

Running results ：

3、 ... and 、 Practice cases

Case study ： Yes web.xml Modeling , Write a servlet adopt url-pattern Read servlet-class Value ;

First of all, put XML file ：web.xml

<?xml version="1.0" encoding="UTF-8"?>
<web-app>
  <servlet>
  	<servlet-name>jrebelServlet</servlet-name>
  	<servlet-class>com.leaf.xml.JrebelServlet</servlet-class>
  </servlet>

  <servlet-mapping>
  	<servlet-name>jrebelServlet</servlet-name>
  	<url-pattern>/jrebelServlet</url-pattern>
  </servlet-mapping>

  <servlet>
  	<servlet-name>jrebelServlet2</servlet-name>
  	<servlet-class>com.leaf.xml.JrebelServlet2</servlet-class>
  </servlet>

  <servlet-mapping>
  	<servlet-name>jrebelServlet2</servlet-name>
  	<url-pattern>/jrebelServlet2</url-pattern>
  	<url-pattern>/jrebelServlet3</url-pattern>
  </servlet-mapping>
</web-app>

Then let's go analysis Look at the whole XML file Of structure ：

1) Analyze tags
A root tag ：web-app
Two sub tags ：servlet、servlet-mapping
servlet There are sub tags inside ：servlet-name、servlet-class
servlet-mapping There are sub tags inside ：servlet-name、url-pattern

According to the above analysis, we can know that there are six different tags in this configuration file ：

servlet-name、servlet-class、url-pattern、servlet、servlet-mapping、web-app

except servlet、servlet-mapping、web-app outside , Other tags have values ;

therefore , Old rules , Let's give them six different labels first Object oriented idea Build entity classes ：

ServletNameModel、ServletClassModel、UrlPatternModel、ServletModel、ServletMappingModel、WebAppModel;

There have been examples above , There is no more code for putting entity classes here ;

After we build the entity class, we need to create a factory class , Put it here Factory class code ：WebAppFactory

package com.leaf.modezuoye;

import java.io.InputStream;
import java.util.List;

import org.dom4j.Document;
import org.dom4j.Element;
import org.dom4j.io.SAXReader;

/**
 * WebApp Factory
 * @author Leaf
 *
 * 2022 year 6 month 15 Japan   In the morning 11:34:52
 */
public class WebAppFactory {

	/**
	 *  modeling
	 * @param path xml name
	 * @return
	 */
	public static WebAppModel build(String path) {
		InputStream in = WebAppFactory.class.getResourceAsStream(path);
		SAXReader sr = new SAXReader();
		WebAppModel wam = new WebAppModel();
		try {
			Document doc = sr.read(in);
			// take servlet The contents of the label are filled in web-app
			List<Element> servletEles = doc.selectNodes("/web-app/servlet");
			for (Element servletEle : servletEles) {
				ServletModel servletModel = new ServletModel();

				// to servlet  fill xml The content of
				Element servletNameEle = (Element) servletEle.selectSingleNode("servlet-name");
				Element servletClassEle = (Element) servletEle.selectSingleNode("servlet-class");
				ServletNameModel servletNameModel = new ServletNameModel();
				ServletClassModel servletClassModel = new ServletClassModel();
				servletNameModel.setNr(servletNameEle.getText());
				servletClassModel.setNr(servletClassEle.getText());

				servletModel.setSnm(servletNameModel);
				servletModel.setScm(servletClassModel);

				wam.push(servletModel);
			}

			/*
			 *  take servlet-mapping The contents of the label are filled in web_app
			 */
			List<Element> servletMappingEles = doc.selectNodes("/web-app/servlet-mapping");
			for (Element servletMappingEle : servletMappingEles) {
				ServletMappingModel servletMappingModel = new ServletMappingModel();

				/*
				 *  to servletmapingmodel fill xml The content of
				 */
				Element servletNameEle = (Element) servletMappingEle.selectSingleNode("servlet-name");
				ServletNameModel servletNameModel = new ServletNameModel();
				servletNameModel.setNr(servletNameEle.getText());
				servletMappingModel.setSnm(servletNameModel);

				List<Element> urlPatternEles = servletMappingEle.selectNodes("url-pattern");
				for (Element urlPatternEle : urlPatternEles) {
					UrlPatternModel urlPatternModel = new UrlPatternModel();
					urlPatternModel.setNr(urlPatternEle.getText());
					servletMappingModel.push(urlPatternModel);
				}

				wam.push(servletMappingModel);
			}

		} catch (Exception e) {
			e.printStackTrace();
		}
		return wam;
	}

	/**
	 *  Automatically find the corresponding background processing class through the web address entered by the browser
	 * @param webAppModel	 The modeled entity class
	 * @param url	 The web address visited by the browser
	 * @return
	 */
	public static String getServletClassByUrl(WebAppModel webAppModel, String url) {
		String servletClass = "";
		/*
		 *  Find the corresponding URL of the browser servlet-name
		 */
		String servletName = "";
		List<ServletMappingModel> servletMappingModels = webAppModel.pop();
		for (ServletMappingModel servletMappingModel : servletMappingModels) {
			List<UrlPatternModel> urlPatternModels = servletMappingModel.getUrlPatternModels();
			for (UrlPatternModel urlPatternModel : urlPatternModels) {
				if(url.equals(urlPatternModel.getNr())) {
					ServletNameModel servletNameModel = servletMappingModel.getSnm();
					servletName = servletNameModel.getNr();
				}
			}
		}

		/*
		 *  find servlet-name Corresponding background processing class
		 */
		List<ServletModel> servletModels = webAppModel.getServletModels();
		for (ServletModel servletModel : servletModels) {
			ServletNameModel servletNameModel = servletModel.getSnm();
			if(servletName.equals(servletNameModel.getNr())) {
				ServletClassModel servletClassModel = servletModel.getScm();
				servletClass = servletClassModel.getNr();
			}
		}
		return servletClass;
	}

	// test
	public static void main(String[] args) {

		WebAppModel webAppModel = WebAppFactory.build("web.xml");
		String res = getServletClassByUrl(webAppModel, "/jrebelServlet");
		String res2 = getServletClassByUrl(webAppModel, "/jrebelServlet2");
		String res3 = getServletClassByUrl(webAppModel, "/jrebelServlet3");
		System.out.println(res);
		System.out.println(res2);
		System.out.println(res3);

	}

}

Running results ：
