Implementing IO multiplexing in UNIX using poll function to realize network socket server

One , Preface

UNIX There are five network models , Namely ： Synchronous blocking IO, Synchronous nonblocking IO, Signal driven IO, asynchronous IO And today's introduction IO Multiplexing .

that IO What is the problem of multiplexing ？

We know that UNIX Many functions under are blocked , Obstruction means IO The operation does not... Until the data is received or the result is obtained Returns the , It needs to be completely completed before returning to user space ; Suppose we now face such a problem ： We need to check whether the key should be pressed in a program , At the same time, he has to read data from the serial port for processing , We also need to deal with the data on the network , If it's just ordinary use of three read Call to solve , If the key is not pressed at this time ( That is, the data is not ready )read() The system call will not return there , Even now serial port or network Collateral socket There is no way to deal with the arrival of data , We can use multithreading to solve this problem , But it does not consume memory and cpu, So today we are going to learn a little IO Under the multiplexing model poll Function ！

Two , About poll

poll() System call in System V Introduction in ,poll() The mechanism of select() similar , And select() There is not much difference in nature , Managing multiple descriptors is also polling , Process according to the state of the descriptor , however poll() There is no limit on the maximum number of file descriptors （ But when the quantity is too large, the performance will also drop ）.poll() and select() There is also a drawback , The array containing a large number of file descriptors is copied between the user state and the address space of the kernel , Whether these file descriptors are ready or not , Its overhead increases linearly with the number of file descriptors .



3、 ... and ,poll Function usage

The function prototype ：

#include <poll.h>
struct pollfd
{
 int fd; /*  File descriptor  */
 short events; /*  Waiting Events  */
 short revents; /*  What actually happened  */
} ;
int poll(struct pollfd *fds, nfds_t nfds, int timeout);

When the function is called successfully ,poll() Return to structure revents Domain is not 0 Number of file descriptors ; If nothing happens before the timeout ,poll() return 0; When the failure ,poll() return -1, And set up errno Is one of the following values ：

　　EBADF　　 The file descriptor specified in one or more structures is invalid .

　　EFAULTfds　　 The address that the pointer points to exceeds the address space of the process .

　　EINTR　　　　 The requested event is preceded by a signal , Call can be re initiated .

　　EINVALnfds　　 Parameter out of PLIMIT_NOFILE value .

　　ENOMEM　　 Not enough memory available , Unable to complete request .

The first parameter Used to point to a struct pollfd An array of types , every last pollfd Structure specifies a monitored file descriptor , instructions poll() Monitor multiple documents Component descriptor . For each structure events Domain is the event mask that monitors the file descriptor , The domain is set up by the user .revents The domain is the result of the operation of the file descriptor Event mask , The kernel sets this field on the return of the call ,events Any event requested in the domain can be in revents Return in domain .

 POLLIN | POLLPRI Equivalent to select() Reading events ,POLLOUT |POLLWRBAND Equivalent to select() Write events for .POLLIN Equivalent to POLLRDNORM |POLLRDBAND, and POLLOUT Is equivalent to POLLWRNORM. for example , To monitor whether a file descriptor is readable and writable at the same time , We can set events by POLLIN |POLLOUT. stay poll return , We can check revents The logo in , Corresponding to the file descriptor request events Structure . If POLLIN Events are set , The file descriptor can be read without blocking . If POLLOUT Set up , Then the file descriptor can be written and Do not cause blockage . These flags are not mutually exclusive ： They can be set at the same time , Indicates that the read and write operations of this file descriptor will return normally without blocking .

The second parameter nfds Specifies the number of elements to listen for in the array ;

The third parameter timeout Specifies the number of milliseconds to wait , No matter what I/O Are you ready to ,poll Will return to .timeout A negative value is specified to indicate an infinite timeout , send poll() Hang until a specified event occurs ;timeout by 0 instructions poll The call immediately returns and lists the ready I/O File descriptor for , But don't wait for other events . In this case ,poll() Like its name , Once elected , Return immediately .

3、 ... and ,poll Implement the example of the server （ The code contains detailed comments ）

#include <stdio.h>
#include <stdlib.h>
#include <unistd.h>
#include <string.h>
#include <errno.h>
#include <ctype.h>
#include <time.h>
#include <pthread.h>
#include <getopt.h>
#include <libgen.h>
#include <sys/types.h>
#include <sys/socket.h>
#include <arpa/inet.h>
#include <netinet/in.h>
#include <poll.h>

#define ARRAY_SIZE(x) (sizeof(x)/sizeof(x[0]))// The macro defines the size of each array ;

static inline void print_usage(char *progname);// Definition print_usage function ;
int socket_server_init(char *listen_ip, int listen_port);// Definition socket_server_init function ;

int main(int argc, char **argv)
{
    int              listenfd, connfd;
    int              serv_port = 0;
    int              daemon_run = 0;
    char            *progname = NULL;
    int              opt;
    int              rv;
    int              i, j;
    int              found;
    int              max;
    char             buf[1024];
    struct pollfd    fds_array[1024];
    struct option    long_options[] ={
                                         {"daemon", no_argument, NULL, 'b'},
                                         {"port", required_argument, NULL, 'p'},
                                         {"help", no_argument, NULL, 'h'},
                                         {NULL, 0, NULL, 0}
                                     }; progname = basename(argv[0]);

                  /* Set the parameters to be taken by the program during compilation */
    while ((opt = getopt_long(argc, argv, "bp:h", long_options, NULL)) != -1)
    {
        switch (opt)
        {
            case 'b':
                daemon_run=1;
                break;
            case 'p':
                serv_port = atoi(optarg);
                break;
            case 'h': /* Get help information */
                print_usage(progname);
                return EXIT_SUCCESS;
                default:
                break;
        }
    }
    if( !serv_port )// When the program is compiled without ports ;
    {
        print_usage(progname);
        return -1;
    }
    if( (listenfd=socket_server_init(NULL, serv_port)) < 0 )// Call function socket_server_init When the failure ;
    {
        printf("ERROR: %s server listen on port %d failure\n", argv[0],serv_port);
        return -2;
    }
    printf("%s server start to listen on port %d\n", argv[0],serv_port);

    if( daemon_run )// Whether to throw it into the background ;
    {
        daemon(0, 0);
    }
    for(i=0; i<ARRAY_SIZE(fds_array) ; i++)// Traverse each array ;
    {
        fds_array[i].fd=-1;// Set the file descriptor in each array to 1;
    }
    fds_array[0].fd = listenfd;// take listenfd Set to... In the first array fd;
    fds_array[0].events = POLLIN;// Set... In the first array events Domain events are readable with data
    max = 0;
    for ( ; ; )// Dead cycle ;
    {
        rv = poll(fds_array, max+1, -1);// call poll function , Infinite timeout ;
        if(rv < 0)
        {
            printf("poll failure: %s\n", strerror(errno));// Error handling ;
            break;
        }
        else if(rv == 0)
        {
            printf("poll get timeout\n");// timeout handler ;
            continue;
        }

        /*rv Greater than 0 The time server has two events to handle ： The first is listening for connections , The second is to operate the connected client ;*/
        if (fds_array[0].revents & POLLIN)// Listening to the connection
        {
            if( (connfd=accept(listenfd, (struct sockaddr *)NULL, NULL)) < 0)// call accept Function accepts requests from clients ;            {
                printf("accept new client failure: %s\n", strerror(errno));// Error handling ;
                continue;// Jump out of this cycle ;
            }
            found = 0;
            for(i=1; i<ARRAY_SIZE(fds_array) ; i++)// Traversal array ;
            {
                if( fds_array[i].fd < 0 )// If this array is not occupied ;
                {
                    printf("accept new client[%d] and add it into array\n", connfd );/
                    fds_array[i].fd = connfd;// take connfd Write this array ;
                    fds_array[i].events = POLLIN;// Set the events Domain events are readable with data ;
                    found = 1;
                    break;
                }
            }
            if( !found )
            {
                printf("accept new client[%d] but full, so refuse it\n", connfd);
                close(connfd);
                continue;
            }

            max = i>max ? i : max;
            if (--rv <= 0)
            continue;
        }
        else // Operate on the connected client
        {
            for(i=1; i<ARRAY_SIZE(fds_array); i++)// Traversal array
            {
                if( fds_array[i].fd < 0 )
                continue;
                if( (rv=read(fds_array[i].fd, buf, sizeof(buf))) <= 0)// Read this array fd Of buf The content of ;
                {
                    printf("socket[%d] read failure or get disconncet.\n", fds_array[i].fd);// Write failure ;
                    close(fds_array[i].fd);
                    fds_array[i].fd = -1;// And release this array ;
                }
                else
                {
                    printf("socket[%d] read get %d bytes data\n", fds_array[i].fd, rv);// Print the content read from the client to standard output ;
                    for(j=0; j<rv; j++)// Traverse every byte read ;
                    buf[j]=toupper(buf[j]);// Convert lowercase to uppercase ;
                    if( write(fds_array[i].fd, buf, rv) < 0 )// Write this array fd Medium 1buf;
                    {
                        printf("socket[%d] write failure: %s\n", fds_array[i].fd, strerror(errno));
                        close(fds_array[i].fd);
                        fds_array[i].fd = -1;
                    }
                }
            }
        }
    }
    CleanUp:
    close(listenfd);
    return 0;
}

static inline void print_usage(char *progname)
{
    printf("Usage: %s [OPTION]...\n", progname);
    printf(" %s is a socket server program, which used to verify client and echo back string from it\n",progname);
    printf("\nMandatory arguments to long options are mandatory for short options too:\n");
    printf(" -b[daemon ] set program running on background\n");
    printf(" -p[port ] Socket server port address\n");
    printf(" -h[help ] Display this help information\n");
    printf("\nExample: %s -b -p 8900\n", progname);
    return ;
}

int socket_server_init(char *listen_ip, int listen_port)
{
    struct sockaddr_in servaddr;
    int rv = 0;
    int on = 1;
    int listenfd;
    if ( (listenfd = socket(AF_INET, SOCK_STREAM, 0)) < 0)
    {
        printf("Use socket() to create a TCP socket failure: %s\n", strerror(errno));
        return -1;
    }

    setsockopt(listenfd, SOL_SOCKET, SO_REUSEADDR, &on, sizeof(on));
    memset(&servaddr, 0, sizeof(servaddr));
    servaddr.sin_family = AF_INET;
    servaddr.sin_port = htons(listen_port);
    if( !listen_ip ) /* Listen all the local IP address */
    {
        servaddr.sin_addr.s_addr = htonl(INADDR_ANY);
    }
    else /* listen the specified IP address */
    {
        if (inet_pton(AF_INET, listen_ip, &servaddr.sin_addr) <= 0)
        {
            printf("inet_pton() set listen IP address failure.\n");
            rv = -2;
            goto CleanUp;
        }
    }
    if(bind(listenfd, (struct sockaddr *) &servaddr, sizeof(servaddr)) < 0)
    {
        printf("Use bind() to bind the TCP socket failure: %s\n", strerror(errno));
        rv = -3;
        goto CleanUp;
    }
    if(listen(listenfd, 13) < 0)
    {
        printf("Use bind() to bind the TCP socket failure: %s\n", strerror(errno));
        rv = -4;
        goto CleanUp;
    }
    CleanUp:
    if(rv<0)
    close(listenfd);
    else
    rv = listenfd;
    return rv;
}

5、 ... and , Results screenshots

client ：

  Server side ：

  6、 ... and , summary

poll The most important thing in the function is to pollfd This structure Only by understanding can we adopt specific operations for your needs , Make clear C The concept of structure array in language can be found in poll It's like a fish in water .
