Unity shader depth of field effect

Realization effect

Depth of field effect

Realize the idea

It consists of two figures , They are the fuzzy state in the distance and the clear state near , Judge the distance between the object and the camera according to the depth of the object, and determine the state of the object . Two graphs are interpolated , The closer you get, the closer you get to the clear image .

Code

Script code ：

using System.Collections;
using System.Collections.Generic;
using UnityEngine;

public class DepthOfField : PostEffectsBase
{

    public Shader bloomShader;
    private Material bloomMaterial = null;
    public Material material
    {

        get
        {

            bloomMaterial = CheckShaderAndCreateMaterial(bloomShader, bloomMaterial);
            return bloomMaterial;
        }
    }

    // The number of iterations
    [Range(0, 4)]
    public int iterations = 3;
    // Fuzzy range
    [Range(0.2f, 3.0f)]
    public float blurSpread = 0.6f;
    // Scaling factor
    [Range(1, 8)]
    public int downSample = 2;
    [Range(0.0f, 50f)]
    // The distance between the dividing line near and far
    public float Threshold = 10f;
    [Range(0.0f, 1.0f)]
    // Fuzzy coefficient near
    public float NearBlurSize = 0.0f;
    // The blur coefficient in the distance
    [Range(0.0f, 1.0f)]
    public float FarBlurSize = 1.0f;
    private Camera myCamera;
    public Camera camera
    {

        get
        {

            if (myCamera == null)
            {

                myCamera = GetComponent<Camera>();
            }
            return myCamera;
        }
    }
    private Transform myCameraTransform;
    public Transform cameraTransform
    {

        get
        {

            if (myCameraTransform == null)
            {

                myCameraTransform = camera.transform;
            }
            return myCameraTransform;
        }
    }
    // Start is called before the first frame update
    private void OnEnable()
    {

        camera.depthTextureMode |= DepthTextureMode.Depth;
    }
    void Start()
    {


    }

    // Update is called once per frame
    void Update()
    {


    }
    public void OnRenderImage(RenderTexture source, RenderTexture destination)
    {

        if (material != null)
        {

            // The ginseng
            material.SetFloat("_Threshold", Threshold);
            material.SetFloat("_NearBlurSize", NearBlurSize);
            material.SetFloat("_FarBlurSize", FarBlurSize);
            int rtW = source.width / downSample;
            int rtH = source.height / downSample;

            RenderTexture buffer0 = RenderTexture.GetTemporary(rtW, rtH, 0);
            buffer0.filterMode = FilterMode.Bilinear;
            // Deliver clear images
            buffer0 = source;
            for (int i = 0; i < 3; i++)
            {

                material.SetFloat("_BlurSize", 1.0f + i * blurSpread);

                RenderTexture buffer1 = RenderTexture.GetTemporary(rtW, rtH, 0);
                Graphics.Blit(buffer0, buffer1, material, 0);
                RenderTexture.ReleaseTemporary(buffer0);
                buffer0 = buffer1;
                buffer1 = RenderTexture.GetTemporary(rtW, rtH, 1);
                Graphics.Blit(buffer0, buffer1, material, 1);
                RenderTexture.ReleaseTemporary(buffer0);
                buffer0 = buffer1;
            }

            // The extracted image is blurred and stored in the texture
            material.SetTexture("_Blur", buffer0);
            // Use the fourth pass Merge the blurred image with the original
            Graphics.Blit(source, destination, material,2);
            RenderTexture.ReleaseTemporary(buffer0);
        }
        else
        {

            Graphics.Blit(source, destination);
        }
    }
}

shader

// Upgrade NOTE: replaced 'mul(UNITY_MATRIX_MVP,*)' with 'UnityObjectToClipPos(*)'

Shader "Custom/depthoffield"
{

 Properties
    {

        _MainTex ("Base (RGB)", 2D) = "white" {
    }
    }
    SubShader
    {

    CGINCLUDE

    #include "unityCG.cginc"
    sampler2D _MainTex;
    half4 _MainTex_TexelSize;
    sampler2D _Blur;
    float _Threshold;
    sampler2D _CameraDepthTexture;
    float _NearBlurSize;
    float _FarBlurSize;

    // Structure diagram of fragment shader of mixed image
    struct v2fblur{

    float4 pos:SV_POSITION;
    // Clear and fuzzy texture coordinates are consistent
    half2 uv:TEXCOORD0;
    // Depth texture coordinates
    half2 uv_depth:TEXCOORD1;
    };

    // Vertex shader
    v2fblur vertBlur(appdata_img v){

    v2fblur o;
    o.pos =UnityObjectToClipPos(v.vertex);
    o.uv =v.texcoord;
    o.uv_depth =v.texcoord;
    // Platform differentiation
    #if UNITY_UV_STARTS_AT_TOP
    if(_MainTex_TexelSize.y<0.0){

    o.uv.y=1.0-o.uv.y;
    }
    #endif

    return o;
    }

    // Fragment Shader
    fixed4 fragBlur(v2fblur i):SV_Target{

    // Clear images
    fixed4 maincolor = tex2D(_MainTex,i.uv);
    // Blur the image
    fixed4 blurcolor =tex2D(_Blur,i.uv);
    // Depth value
    float linearDepth =LinearEyeDepth(SAMPLE_DEPTH_TEXTURE(_CameraDepthTexture,i.uv_depth));
    // Interpolation with critical value
    float dis = (linearDepth-_Threshold);
    if(dis<=0){

    dis*=_NearBlurSize;
    }else{

    dis*=_FarBlurSize;
    }
    // Limit to [0,1]
    dis = clamp(abs(dis),0,1);
    // Interpolation color , The fuzzy coefficient near is small , Far away
    return lerp(maincolor,blurcolor,dis);
    }
    ENDCG

    Tags{
    "RenderType"="Opaque"}
    ZTest Always Cull Off ZWrite Off

    // blurred
    UsePass "Custom/Chapter12-GaussianBlur/GAUSSIAN_BLUR_VERTICAL"
    UsePass "Custom/Chapter12-GaussianBlur/GAUSSIAN_BLUR_HORIZONTAL"

    // Blend images pass
    Pass{

    CGPROGRAM
    #pragma vertex vertBlur
    #pragma fragment fragBlur
    ENDCG
    }
    }
    FallBack "Diffuse"
}
