Static route configuration instance learning record

Static route configuration instance

Routes set manually are called static routes , Static routing is fixed , It will not change automatically with the change of network topology

---

---

1、 The goal of the experiment

Learn how to configure static routes , Understand the characteristics of router hop by hop forwarding .

---

2、 Network topology

---

3、 Configuration steps

（1） Configure ports by topology IP Address

R1 To configure ：

<R1>system-view  // Enter the system view
[R1]interface GigabitEthernet0/0/0
[R1-GigabitEthernet0/0/0]ip address 10.1.1.1 24  // configure port  IP  Address （IP  Address : 10.1.1.1  Subnet mask : 24）
[R1-GigabitEthernet0/0/0]quit
[R1]interface Ethernet0/0/1
[R1-Ethernet0/0/1]ip address 192.168.10.1 24  // configure port  IP  Address （IP  Address : 192.168.10.1  Subnet mask : 24）
[R1-Ethernet0/0/1]quit

R2 To configure ：

<R2>system-view  // Enter the system view
[R2]interface GigabitEthernet0/0/0
[R2-GigabitEthernet0/0/0]ip address 10.1.1.2 24  // configure port  IP  Address （IP  Address : 10.1.1.2  Subnet mask : 24）
[R2-GigabitEthernet0/0/0]quit
[R2]interface Ethernet0/0/1
[R2-Ethernet0/0/1]ip address 192.168.20.1 24  // configure port  IP  Address （IP  Address : 192.168.20.1  Subnet mask : 24）
[R2-Ethernet0/0/1]quit

（2） Configure static routing

R1 To configure ：

[R1]ip route-static 192.168.20.0 24 10.1.1.2  //ip route-static [ Destination address segment ] [ Destination address subnet mask ] [ Next jump  IP  Address ]

R2 To configure ：

[R2]ip route-static 192.168.10.0 24 10.1.1.1  //ip route-static [ Destination address segment ] [ Destination address subnet mask ] [ Next jump  IP  Address ]

---

4、 test

（1） View the established route entries , Static routing... Look

Tips ： Use display ip routing-table Command to view the routing table

see R1 Routing table ：

[R1]display ip routing-table  // View routing table
Route Flags: R - relay, D - download to fib
------------------------------------------------------------------------------
Routing Tables: Public
         Destinations : 7        Routes : 7

Destination/Mask    Proto   Pre  Cost      Flags NextHop         Interface

       10.1.1.0/24  Direct  0    0           D   10.1.1.1        GigabitEthernet
0/0/0
       10.1.1.1/32  Direct  0    0           D   127.0.0.1       GigabitEthernet
0/0/0
      127.0.0.0/8   Direct  0    0           D   127.0.0.1       InLoopBack0
      127.0.0.1/32  Direct  0    0           D   127.0.0.1       InLoopBack0
   192.168.10.0/24  Direct  0    0           D   192.168.10.1    Ethernet0/0/1
   192.168.10.1/32  Direct  0    0           D   127.0.0.1       Ethernet0/0/1
   192.168.20.0/24  Static  60   0          RD   10.1.1.2  GigabitEthernet  // R1  This is the static route
0/0/0

see R2 Routing table ：

[R2]display ip routing-table  // View routing table
Route Flags: R - relay, D - download to fib
------------------------------------------------------------------------------
Routing Tables: Public
         Destinations : 7        Routes : 7

Destination/Mask    Proto   Pre  Cost      Flags NextHop         Interface

       10.1.1.0/24  Direct  0    0           D   10.1.1.2        GigabitEthernet
0/0/0
       10.1.1.2/32  Direct  0    0           D   127.0.0.1       GigabitEthernet
0/0/0
      127.0.0.0/8   Direct  0    0           D   127.0.0.1       InLoopBack0
      127.0.0.1/32  Direct  0    0           D   127.0.0.1       InLoopBack0
   192.168.10.0/24  Static  60   0          RD   10.1.1.1          GigabitEthernet  // R2  This is the static route
0/0/0
   192.168.20.0/24  Direct  0    0           D   192.168.20.1    Ethernet0/0/1
   192.168.20.1/32  Direct  0    0           D   127.0.0.1       Ethernet0/0/1

（2）PC1 You can talk to PC2 Interworking

use PC1 Go to ping PC2 Of IP Address , The discovery has ping Through the
notes ： Access to the host IP The first few addresses may appear Request timeout! ( request timeout ) Tips , Normal phenomenon

use PC2 Go to ping PC1 Of IP Address , Discovery can also ping through
notes ： Access to the host IP The first few addresses may appear Request timeout! ( request timeout ) Tips , Normal phenomenon

---

5、 Summary

Configuring static routing is mainly to understand the concept of target address network segment and next hop .

In the routing table , Static routing Proto The field is displayed as Static, By default , Routing priority Pre by 60, The routing overhead is 0.

Advantages of static routing ： It does not occupy network bandwidth and system resources , Security .
Disadvantages of static routing ： When a failure occurs in the network , Static routing doesn't automatically fix , It must be manually configured one by one by the network administrator , It cannot automatically make corresponding adjustments according to the changes of network status .
