Preface

• Input/Output Box Control is also a common control , Used as a A single Input and output display , plastic , floating-point and character string Fine , Depends on binding symbol Data type of

• Demonstrate hardware and software environment Windows11 x64 ; CANoe 11 SP2 x64


---

Display type attribute settings

• Drag a few controls , Used to test the following four symbol Case of type


---

symbol It's plastic surgery

1️⃣ If symbol It's plastic surgery , be You can set Binary system , Hexadecimal or decimal display , The following figure is 16 Base display

---

symbol It's floating point

1️⃣ If symbol It's floating point , Then the optional attributes are ： Displayed decimal places （Decimal Place）:

• The decimal places set in the following figure are 4

---

symbol character string

1️⃣ If symbol Is string , Here's the picture

• Note that the string can only be displayed in a single line , Can't wrap .


  ---

symbol It is shaped and configured （value table）

1️⃣ If bound symbol Yes value table , It shows value table Corresponding description in

• The system variables in the following figure InputOutputBox_Symbol, Configured with Value Table

• Those who are not familiar with system variables can first understand the creation of system variables


  ---

  • Panel Choose from Symbol


    ---

  • CANoe Environment , See the result , It is shown that Value Table Description defined in .

  •

---

Alarm attribute settings

• 1️⃣ The so-called alarm attribute , You set a value range for this control , When it exceeds the defined value range , The background color of the control will be changed to the color of the response , As a warning ,

• Here we use symbol own property For example , Briefly explain , If bound symbol It's the signal , You can choose Database Values;

---

• 2️⃣ Let's take shaping system variables as an example , We can define the maximum and minimum values when defining variables

---

• 3️⃣ We set it to display yellow if it exceeds the minimum value , Exceeding the maximum value displays red
•

---

Font paragraph formatting

• 1️⃣ The front one is Text Property settings for , The latter is the attribute setting in the box

summary

• It needs to be used in the demonstration demo engineering , You can follow the official account online disk below to get it by yourself , Thank you for reading .
