wallys//IPQ5018/IPQ6010/PD-60 802.3AT Input Output 10/100/1000M

PD-60 802.3AT Input Output

802.3AT/AT 85% Efficiency 10/100/1000M GE Surge Protection

Wallys Communications (Suzhou) Co LTD  has been specializing in product design & manufacturing and delivering superior OEM/ODM services in wireless communications. Dedicated to innovative designs for wireless modules. Customization is also supported, We have 90% of the world market, We're a supplier to Facebook.

EMAIL:[email protected]

WEB:https://www.wallystech.com/.

Support 802.3BT/AT/AF

The output voltage is 48V

The efficiency is 90%

Support surge protection

Support RoHS compliance ensure a high level protection of human health and the environment from risks that can be posed by chemicals

Applications

Parameter	Rating	Unit
Input voltage	42~56	V
Output Voltage	48	V
The maximum output voltage	56	V
10/100/1000Mbps Gigabit Ethernet	2xRJ45（one is for input，one is for output）
Surge protection	Yes
Operating Temperature	-40 to +70	ºC
Operating Humidity Range	5 to +95 (non-condensing)	%
Storage Humidity Range	0 to +90 (non-condensing)	%
ROHS Compliance	YES

Applications

Parameter	Rating	Unit
Length	100.7	Mm
Width	27.4	Mm
