[stm32f103rct6] can communication

【 software design 】

CAN Pin initialization

/*
 *  Function name ：CAN_GPIO_Config
 *  describe   ：CAN Of GPIO  To configure
 *  Input   ： nothing
 *  Output   :  nothing
 *  call   ： Internal calls
 */
static void CAN_GPIO_Config(void)
{
	GPIO_InitTypeDef GPIO_InitStructure;

	/* Enable GPIO clock */
	RCC_APB2PeriphClockCmd(CAN_TX_GPIO_CLK | CAN_RX_GPIO_CLK, ENABLE);
	// Remap pin
	GPIO_PinRemapConfig(GPIO_Remap1_CAN1, ENABLE);

	/* Configure CAN TX pins */
	GPIO_InitStructure.GPIO_Pin = CAN_TX_PIN;
	GPIO_InitStructure.GPIO_Mode = GPIO_Mode_AF_PP; //  Multiplexing push pull output
	GPIO_InitStructure.GPIO_Speed = GPIO_Speed_50MHz;

	GPIO_Init(CAN_TX_GPIO_PORT, &GPIO_InitStructure);

	/* Configure CAN RX  pins */
	GPIO_InitStructure.GPIO_Pin = CAN_RX_PIN;
	GPIO_InitStructure.GPIO_Mode = GPIO_Mode_IPU; //  Pull up input
	GPIO_InitStructure.GPIO_Speed = GPIO_Speed_50MHz;

	GPIO_Init(CAN_RX_GPIO_PORT, &GPIO_InitStructure);
}

CAN Interrupt priority configuration

/*
 *  Function name ：CAN_NVIC_Config
 *  describe   ：CAN Of NVIC  To configure , The first 1 Priority groups ,0,0 priority
 *  Input   ： nothing
 *  Output   :  nothing
 *  call   ： Internal calls
 */
static void CAN_NVIC_Config(void)
{
	NVIC_InitTypeDef NVIC_InitStructure;
	/* Configure one bit for preemption priority */
	NVIC_PriorityGroupConfig(NVIC_PriorityGroup_1);
	/* Interrupt settings */
	NVIC_InitStructure.NVIC_IRQChannel = CAN_RX_IRQ;		  //CAN1 RX0 interrupt
	NVIC_InitStructure.NVIC_IRQChannelPreemptionPriority = 0; // preemption 0
	NVIC_InitStructure.NVIC_IRQChannelSubPriority = 0;		  // The sub priority is 0
	NVIC_InitStructure.NVIC_IRQChannelCmd = ENABLE;
	NVIC_Init(&NVIC_InitStructure);
}

CAN Mode configuration

/*
 *  Function name ：CAN_Mode_Config
 *  describe   ：CAN The pattern of   To configure
 *  Input   ： nothing
 *  Output   :  nothing
 *  call   ： Internal calls
 */
static void CAN_Mode_Config(void)
{
	CAN_InitTypeDef CAN_InitStructure;
	/************************CAN Communication parameter settings **********************************/
	/* Enable CAN clock */
	RCC_APB1PeriphClockCmd(CAN_CLK, ENABLE);

	/*CAN Register initialization */
	CAN_DeInit(CANx);
	CAN_StructInit(&CAN_InitStructure);

	/*CAN Unit initialization */
	CAN_InitStructure.CAN_TTCM = DISABLE;		  //MCR-TTCM   Turn off time trigger communication mode enable
	CAN_InitStructure.CAN_ABOM = ENABLE;		  //MCR-ABOM   Automatic offline Management
	CAN_InitStructure.CAN_AWUM = ENABLE;		  //MCR-AWUM   Use auto wake mode
	CAN_InitStructure.CAN_NART = DISABLE;		  //MCR-NART   Automatic retransmission of messages is prohibited 	  DISABLE- Automatic retransmission
	CAN_InitStructure.CAN_RFLM = DISABLE;		  //MCR-RFLM   receive FIFO  Lock mode   DISABLE- In case of overflow, the new message will cover the original message
	CAN_InitStructure.CAN_TXFP = DISABLE;		  //MCR-TXFP   send out FIFO priority  DISABLE- The priority depends on the message identifier
	CAN_InitStructure.CAN_Mode = CAN_Mode_Normal; // Normal operation mode
	CAN_InitStructure.CAN_SJW = CAN_SJW_1tq;	  //BTR-SJW  Resynchronize jump width  2 Time units

	/* ss=1 bs1=9 bs2=8  Bit time width is (1+8+9)  The baud rate is the clock period tq*(1+8+9)  */
	CAN_InitStructure.CAN_BS1 = CAN_BS1_3tq; //BTR-TS1  Period of time 1  Occupied 9 Time units
	CAN_InitStructure.CAN_BS2 = CAN_BS2_2tq; //BTR-TS1  Period of time 9  Occupied 8 Time units

	/* CAN Baudrate = 1 MBps (1MBps Already been stm32 Of CAN Maximum speed ) (CAN  The clock frequency is  APB1 = 36 MHz) */
	CAN_InitStructure.CAN_Prescaler = 48; BTR-BRP  Baud rate divider    Defines the time length of the time unit  36/(1+8+9)/4= 0.5 Mbps
	CAN_Init(CANx, &CAN_InitStructure);
}

CAN Filter configuration

/*
 *  Function name ：CAN_Filter_Config
 *  describe   ：CAN Filter   To configure
 *  Input   ： nothing
 *  Output   :  nothing
 *  call   ： Internal calls
 */
static void CAN_Filter_Config(void)
{
	CAN_FilterInitTypeDef CAN_FilterInitStructure;

	/*CAN Filter initialization */
	CAN_FilterInitStructure.CAN_FilterNumber = 0;					 // Filter group 0
	CAN_FilterInitStructure.CAN_FilterMode = CAN_FilterMode_IdMask;	 // Working in mask mode
	CAN_FilterInitStructure.CAN_FilterScale = CAN_FilterScale_32bit; // The filter bit width is single 32 position .
	/*  Enable filter , Compare and screen according to the content of the mark , Expand ID Don't just throw away the following , If yes , Will be deposited in the FIFO0. */

	// Configuration of standard data frame
		CAN_FilterInitStructure.CAN_FilterIdHigh   = (((u32)0x45<<21)&0xffff0000)>>16;
		CAN_FilterInitStructure.CAN_FilterIdLow   = (((u32)0x45<<21)|CAN_ID_STD|CAN_RTR_DATA)&0xffff;
		CAN_FilterInitStructure.CAN_FilterMaskIdHigh  = 0xFFFF;
		CAN_FilterInitStructure.CAN_FilterMaskIdLow   = 0xFFFF;

// Configuration of extended data frame
//	CAN_FilterInitStructure.CAN_FilterIdHigh = ((((u32)0x45 << 3) | CAN_ID_STD | CAN_RTR_DATA) & 0xFFFF0000) >> 16; // To be screened ID High position
//	CAN_FilterInitStructure.CAN_FilterIdLow = (((u32)0x45 << 3) | CAN_ID_STD | CAN_RTR_DATA) & 0xFFFF;			  // To be screened ID Low position
//	CAN_FilterInitStructure.CAN_FilterMaskIdHigh = 0xFFFF;															  // Filter high 16 Each bit must match
//	CAN_FilterInitStructure.CAN_FilterMaskIdLow = 0xFFFF;															  // Filter low 16 Each bit must match
	CAN_FilterInitStructure.CAN_FilterFIFOAssignment = CAN_Filter_FIFO0;											  // The filter is associated with FIFO0
	CAN_FilterInitStructure.CAN_FilterActivation = ENABLE;															  // Enable filter
	CAN_FilterInit(&CAN_FilterInitStructure);
	/*CAN Communication interrupt enable */
	CAN_ITConfig(CANx, CAN_IT_FMP0, ENABLE);
}

CAN Consolidation configuration

/*
 *  Function name ：CAN_Config
 *  describe   ： Full configuration CAN The function of
 *  Input   ： nothing
 *  Output   :  nothing
 *  call   ： External call
 */
void CAN_Config(void)
{
	CAN_GPIO_Config();
	CAN_NVIC_Config();
	CAN_Mode_Config();
	CAN_Filter_Config();
}

initialization RxMessage Data structures

/**
  * @brief   initialization  RxMessage Data structures
  * @param  RxMessage:  Point to the data structure to initialize
  * @retval None
  */
void Init_RxMes(CanRxMsg *RxMessage)
{
	uint8_t ubCounter = 0;

	/* Clear the receiving structure */
	RxMessage->StdId = 0x00;
	RxMessage->ExtId = 0x00;
	RxMessage->IDE = CAN_ID_STD;
	RxMessage->DLC = 0;
	RxMessage->FMI = 0;
	for (ubCounter = 0; ubCounter < 8; ubCounter++)
	{
		RxMessage->Data[ubCounter] = 0x00;
	}
}

Set up CAN_SetMsg

/*
 *  Function name ：CAN_SetMsg
 *  describe   ：CAN Content setting of communication message , Set a data content to 0-7 Data packets of
 *  Input   ： Send message structure
 *  Output   :  nothing
 *  call   ： External call
 */
void CAN_SetMsg(CanTxMsg *TxMessage)
{
//	uint8_t ubCounter = 0;

	TxMessage->StdId=0x45;		// Standards used ID
	//TxMessage->ExtId = 0x45;
	TxMessage->IDE = CAN_ID_STD;   // The standard model
	TxMessage->RTR = CAN_RTR_DATA; // It's sending data
	TxMessage->DLC = 8;			   // The data length is 8 byte

	/* Set the data to send 0-7*/
//	for (ubCounter = 0; ubCounter < 8; ubCounter++)
//	{
//		TxMessage->Data[ubCounter] = ubCounter;
//	}

	TxMessage->Data[0] = 0;
	TxMessage->Data[1] = speedct*1000;
	TxMessage->Data[2] = poct*1000;
	TxMessage->Data[3] = 0;
	TxMessage->Data[4] = 0;
	TxMessage->Data[5] = 0;
	TxMessage->Data[6] = 0;
	TxMessage->Data[7] = 0;
}

CAN Accept service interruption

/*
 *  Function name ：USB_LP_CAN1_RX0_IRQHandler
 *  describe   ：USB Break and CAN Receive interrupt service program ,USB Follow CAN public I/O, Only... Is used here CAN The interrupt .
 *  Input   ： nothing
 *  Output   :  nothing
 *  call   ： nothing
 */
void CAN_RX_IRQHandler(void)
{
	/* Read messages from the mailbox */
	CAN_Receive(CANx, CAN_FIFO0, &RxMessage);

	/*  Compare ID Is it 0x1314 */
	if((RxMessage.StdId==0x45) && (RxMessage.IDE==CAN_ID_STD) && (RxMessage.DLC==8) )
	{
	flag = 1; 					       // Successful reception
	}
	else
	{
	flag = 0; 					   // Reception failed
	}
}

The main function

int main(void)
{

	MY_NVIC_PriorityGroupConfig(2);	//===== Set interrupt grouping
	delay_init();  					//===== Delay function initialization
	KEY_Init();                     //===== Key initialization
	usart1_init(115200);			//===== A serial port 1 initialization
	CAN_Config();					/* initialization can, In interrupt reception CAN Data packets */
	MiniBalance_PWM_Init(7199, 0); //===== initialization PWM 10KHZ, For driving motor   To initialize the electric regulating interface
	TIM5_Cap_Init(0XFFFF,72-1);	  //===== Ultrasonic wave begins to melt   Default comment   Ultrasonic wiring   Reference resources timer.h file
	TIM3_Cap_Init(0XFFFF,72-1);	  //===== Ultrasonic wave begins to melt   Default comment   Ultrasonic wiring   Reference resources timer.h file

    while(1)
	{
		/* Set the message to send */
		CAN_SetMsg(&TxMessage);

		/* Store the message in the sending mailbox , send out */
		CAN_Transmit(CANx, &TxMessage);

		can_delay(10000);// Wait for the transmission to finish , You can use CAN_TransmitStatus Check the status

		if(flag==1)
		{
			printf("\r\nCAN Data received ：\r\n");
			CAN_DEBUG_ARRAY(RxMessage.Data,8);
			x = RxMessage.Data[0];
			ang = RxMessage.Data[1];
			flag=0;
		}

	}
}

CAN The header file

#ifndef __CAN_H
#define __CAN_H

#include "stm32f10x.h"
#include "usart.h"

#define CANx CAN1
#define CAN_CLK RCC_APB1Periph_CAN1
#define CAN_RX_IRQ USB_LP_CAN1_RX0_IRQn
#define CAN_RX_IRQHandler USB_LP_CAN1_RX0_IRQHandler

#define CAN_RX_PIN GPIO_Pin_8
#define CAN_TX_PIN GPIO_Pin_9
#define CAN_TX_GPIO_PORT GPIOB
#define CAN_RX_GPIO_PORT GPIOB
#define CAN_TX_GPIO_CLK (RCC_APB2Periph_AFIO | RCC_APB2Periph_GPIOB)
#define CAN_RX_GPIO_CLK RCC_APB2Periph_GPIOB

/*debug*/

#define CAN_DEBUG_ON 1
#define CAN_DEBUG_ARRAY_ON 1
#define CAN_DEBUG_FUNC_ON 1

// Log define
#define CAN_INFO(fmt, arg...) printf("<<-CAN-INFO->> " fmt "\n", ##arg)
#define CAN_ERROR(fmt, arg...) printf("<<-CAN-ERROR->> " fmt "\n", ##arg)
#define CAN_DEBUG(fmt, arg...)                                        \
    do                                                                \
    {                                                                 \
        if (CAN_DEBUG_ON)                                             \
            printf("<<-CAN-DEBUG->> [%d]" fmt "\n", __LINE__, ##arg); \
    } while (0)

#define CAN_DEBUG_ARRAY(array, num)            \
    do                                         \
    {                                          \
        int32_t i;                             \
        float *a = array;                    \
        if (CAN_DEBUG_ARRAY_ON)                \
        {                                      \
            printf("<<-CAN-DEBUG-ARRAY->>\n"); \
            for (i = 0; i < (num); i++)        \
            {                                  \
                printf("%f   ", (a)[i]);     \
                if ((i + 1) % 10 == 0)         \
                {                              \
                    printf("\n");              \
                }                              \
            }                                  \
            printf("\n");                      \
        }                                      \
    } while (0)

#define CAN_DEBUG_FUNC()                                                    \
    do                                                                      \
    {                                                                       \
        if (CAN_DEBUG_FUNC_ON)                                              \
            printf("<<-CAN-FUNC->> Func:%[email protected]:%d\n", __func__, __LINE__); \
    } while (0)

static void CAN_GPIO_Config(void);
static void CAN_NVIC_Config(void);
static void CAN_Mode_Config(void);
static void CAN_Filter_Config(void);
void CAN_Config(void);
void CAN_SetMsg(CanTxMsg *TxMessage);
void Init_RxMes(CanRxMsg *RxMessage);

#endif
