A code takes you to draw multi format sangjimei pictures such as interactive +pdf+png

Write it at the front

Sangjitu is very nice , It is used to observe the subordinate relationship between different categories , And draw a beautiful structure diagram , Of course, it can be used in many places . Here we use microbiome data phyloseq object , Quickly and easily build a sanggi map for you . So if you have phyloseq Try it directly . The test data in this paper comes from ggClusterNet, Everyone from github Download and use .

actual combat

Import requires R package

library(ggClusterNet)
library(tidyverse)
library(phyloseq)
library(tidyverse)
library(viridis)
library(patchwork)
library(networkD3)
data(ps)

We combined microbiological data at genus level , Then take the top 50 genera with the highest abundance , Then remove Unassigned”) %>%  vegan_tax() %>% Of microbes . Note that these functions exist in ggClusterNet in , Pay attention to download and installation .

tax = ps %>%
  ggClusterNet::tax_glom_wt(ranks = 6) %>%
  filter_OTU_ps(50) %>%
  subset_taxa(Genus  != "Unassigned") %>%
  vegan_tax() %>%
  as.data.frame()
head(tax)

Build connections , A source —- One goal . Mark the labels of different classification levels .

id2 = c("k","p","c","o","f","g")
dat = NULL
for (i in 1:5) {
  dat <- tax[,c(i,i+1)] %>% distinct(.keep_all = TRUE)
  colnames(dat) = c("source","target")
  dat$source = paste(id2[i],dat$source,sep = "_")
  dat$target = paste(id2[i+1],dat$target,sep = "_")
  if (i == 1) {
    dat2 = dat
  }

  dat2 = rbind(dat2,dat)

}

dim(dat2)
# dat2 = dat2 %>% distinct(.keep_all = TRUE)

head(dat2)

Structure abundance table , Here we are only right KO1 This single sample is enriched ：

otu = ps %>%
  ggClusterNet::tax_glom_wt(ranks = 6) %>%
  scale_micro() %>%
  filter_OTU_ps(50) %>%
  subset_taxa(Genus  != "Unassigned") %>%
  vegan_otu() %>%
  t() %>%
  as.data.frame()

head(otu)
otutax = cbind(otu,tax)

id = rank.names(ps)[1:6]
dat = NULL
for (i in 1:6) {
  dat <- otutax %>%
    group_by(!!sym(id[i])) %>%
    summarise(sum(KO1))
  colnames(dat) = c("target","value")
  dat$target = paste(id2[i],dat$target,sep = "_")
  if (i == 1) {
    dat3 = dat
  }

  dat3 = rbind(dat3,dat)
}

dat4 <- dat2 %>% left_join(dat3)
sankey = dat4

Construct nodes and connection tables , preservation html file ,pdf and png file .

nodes <- data.frame(name = unique(c(as.character(sankey$source),as.character(sankey$target))),stringsAsFactors = FALSE)
nodes$ID <- 0:(nrow(nodes)-1)
sankey <- merge(sankey,nodes,by.x = "source",by.y = "name")
sankey <- merge(sankey,nodes,by.x = "target",by.y = "name")
colnames(sankey) <- c("X","Y","value","source","target")
sankey <- subset(sankey,select = c("source","target","value"))
nodes <- subset(nodes,select = c("name"))

ColourScal='d3.scaleOrdinal() .range(["#E41A1C", "#377EB8", "#4DAF4A", "#984EA3", "#FF7F00", "#FFFF33", "#A65628", "#F781BF", "#999999"])'

sankey$energy_type <- sub(' .*', '', nodes[sankey$source + 1, 'name'])

p <- sankeyNetwork(Links = sankey, Nodes = nodes,
                   Source = "source",Target = "target",Value = "value",
                   NodeID = "name",
                   sinksRight=FALSE,
                   LinkGroup = 'energy_type',
                   colourScale= ColourScal,
                   # nodeWidth=40,
                   # fontSize=13
                   # nodePadding=20
                   )
p

saveNetwork(p,"sankey1.html")
library(webshot)

webshot("sankey.html" , "sankey.png")
webshot("sankey.html" , "sankey.pdf")
