Adding sharding sphere5.0.0 sub tables to the ruoyi framework (adding custom sub table policies through SPI)

2022-06-29 11:27:00 【Procedural ape (siege lion)】

sharding shphere As a sub database and sub table component , When processing table splitting business , Compared with realizing the table splitting function by yourself , There are still many obvious advantages .

For one from 0 At the beginning springboot project , add to sharding sphere It is relatively simple to divide databases and tables , Sometimes it is necessary to add... To the existing program framework sharding sphere Database and table function of , This requires specific configuration according to the characteristics of the framework itself .

1. Add dependency

stay ruoyi-framework\pom.xml Module add sharding-jdbc Integration dependence :

<!-- sharding-jdbc Sub database and sub table  -->
<dependency>
    <groupId>org.apache.shardingsphere</groupId>
    <artifactId>shardingsphere-jdbc-core</artifactId>
    <version>5.0.0</version>
</dependency>

2. Create a test library

The same database as the main program is used here , So there is no need to create a separate database .

3. Create two test order tables

create table sys_order
(
  order_id      bigint(20)      not null                   comment ' Order ID',
  user_id       bigint(64)      not null                   comment ' The user id ',
  status        char(1)         not null                   comment ' state （0 Successful trade  1 The deal failed ）',
  order_no      varchar(64)     default null               comment ' Order flow ',
  primary key (order_id)
) engine=innodb comment = ' Order information sheet ';

create table sys_order_0
(
  order_id      bigint(20)      not null                   comment ' Order ID',
  user_id       bigint(64)      not null                   comment ' The user id ',
  status        char(1)         not null                   comment ' state （0 Successful trade  1 The deal failed ）',
  order_no      varchar(64)     default null               comment ' Order flow ',
  primary key (order_id)
) engine=innodb comment = ' Order information sheet ';


create table sys_order_1
(
  order_id      bigint(20)      not null                   comment ' Order ID',
  user_id       bigint(64)      not null                   comment ' The user id ',
  status        char(1)         not null                   comment ' state （0 Successful trade  1 The deal failed ）',
  order_no      varchar(64)     default null               comment ' Order flow ',
  primary key (order_id)
) engine=innodb comment = ' Order information sheet ';

4. Add data source to configuration file

stay application-druid.yml Add test data source , Location is at the same level as the master data source ：

#  Data source configuration
spring:
    datasource:
        type: com.alibaba.druid.pool.DruidDataSource
        driverClassName: com.mysql.cj.jdbc.Driver
        druid:
            #  Main database data source
            master:
                url: jdbc:mysql://localhost:3306/ry473?useUnicode=true&characterEncoding=utf8&zeroDateTimeBehavior=convertToNull&useSSL=true&serverTimezone=GMT%2B8
                username: root
                password: password
            #  Order Library 1
            shardsource:
                enabled: true
                url: jdbc:mysql://localhost:3306/ry473?useUnicode=true&characterEncoding=utf8&zeroDateTimeBehavior=convertToNull&useSSL=true&serverTimezone=GMT%2B8
                username: root
                password: password

5. Code generation tools generate code components

Generate through the code generation function sys_order Related components and added to the project , Include page 、 controller 、 Service layer 、mapper as well as mapper.xml Documents, etc. .

6. add to shardingsphere Configuration class

package com.ruoyi.framework.config;

import java.sql.SQLException;
import java.util.Collections;
import java.util.HashMap;
import java.util.Map;
import java.util.Properties;
import javax.sql.DataSource;
import org.apache.shardingsphere.driver.api.ShardingSphereDataSourceFactory;
import org.apache.shardingsphere.infra.config.algorithm.ShardingSphereAlgorithmConfiguration;
import org.apache.shardingsphere.sharding.api.config.ShardingRuleConfiguration;
import org.apache.shardingsphere.sharding.api.config.rule.ShardingTableRuleConfiguration;
import org.apache.shardingsphere.sharding.api.config.strategy.keygen.KeyGenerateStrategyConfiguration;
import org.apache.shardingsphere.sharding.api.config.strategy.sharding.StandardShardingStrategyConfiguration;

import org.springframework.beans.factory.annotation.Qualifier;
import org.springframework.boot.autoconfigure.condition.ConditionalOnProperty;
import org.springframework.boot.context.properties.ConfigurationProperties;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import com.alibaba.druid.pool.DruidDataSource;
import com.alibaba.druid.spring.boot.autoconfigure.DruidDataSourceBuilder;
import com.ruoyi.framework.config.properties.DruidProperties;

/**
 * sharding  Configuration information
 *
 * @author ruoyi
 */
@Configuration
public class ShardingDataSourceConfig
{
    @Bean
    @ConfigurationProperties("spring.datasource.druid.shardsource")
    @ConditionalOnProperty(prefix = "spring.datasource.druid.shardsource", name = "enabled", havingValue = "true")
    public DataSource shardDataSource(DruidProperties druidProperties)
    {
        DruidDataSource dataSource = DruidDataSourceBuilder.create().build();
        return druidProperties.dataSource(dataSource);
    }

//    @Bean
//    @ConfigurationProperties("spring.datasource.druid.order2")
//    @ConditionalOnProperty(prefix = "spring.datasource.druid.order2", name = "enabled", havingValue = "true")
//    public DataSource order2DataSource(DruidProperties druidProperties)
//    {
//        DruidDataSource dataSource = DruidDataSourceBuilder.create().build();
//        return druidProperties.dataSource(dataSource);
//    }

    @Bean(name = "shardingDataSource")
    public DataSource shardingDataSource(@Qualifier("shardDataSource") DataSource shardDataSource) throws SQLException
    {
        Map<String, DataSource> dataSourceMap = new HashMap<>();
        dataSourceMap.put("order", shardDataSource);
        // dataSourceMap.put("order2", order2DataSource);

        // sys_order  Table rule configuration
        // TableRuleConfiguration orderTableRuleConfig = new TableRuleConfiguration("sys_order", "order$->{1..2}.sys_order_$->{0..1}");

        ShardingTableRuleConfiguration orderTableRuleConfig = new ShardingTableRuleConfiguration("sys_order", "order.sys_order_$->{0..1}");

        orderTableRuleConfig.setTableShardingStrategy(
                new StandardShardingStrategyConfiguration("order_id", "tableShardingAlgorithm"));

        //  Configure the sub database strategy
        // orderTableRuleConfig.setDatabaseShardingStrategyConfig(new InlineShardingStrategyConfiguration("user_id", "order$->{user_id % 2 + 1}"));
        //  Configure sub table strategy
        // orderTableRuleConfig.setTableShardingStrategyConfig(new InlineShardingStrategyConfiguration("order_id", "sys_order_$->{order_id % 2}"));

        //  Distributed primary key
        orderTableRuleConfig.setKeyGenerateStrategy(new KeyGenerateStrategyConfiguration("order_id", "snowflake"));

        //  Configure sharding rules
        ShardingRuleConfiguration shardingRuleConfig = new ShardingRuleConfiguration();
        shardingRuleConfig.getTables().add(orderTableRuleConfig);

        Properties pDatabase = new Properties();
        pDatabase.setProperty("shardCount", "2");

        //  Set up the sub table policy
        ShardingSphereAlgorithmConfiguration ssactable = new ShardingSphereAlgorithmConfiguration(
                "ORDER_ID_SHARD", pDatabase);
        shardingRuleConfig.getShardingAlgorithms().put("tableShardingAlgorithm", ssactable);

        //  built-in Snowflake Distributed sequence algorithm configuration
        Properties snowflakeProp = new Properties();
        snowflakeProp.setProperty("worker-id", "1");
        shardingRuleConfig.getKeyGenerators().put("snowflake",
                new ShardingSphereAlgorithmConfiguration("SNOWFLAKE", snowflakeProp));

        //  Get data source object
        DataSource dataSource = ShardingSphereDataSourceFactory.createDataSource(dataSourceMap,
                Collections.singleton(shardingRuleConfig),
                getProperties());
        return dataSource;
    }

    /**
     *  System parameter configuration
     */
    private Properties getProperties()
    {
        Properties shardingProperties = new Properties();
        shardingProperties.put("sql.show", true);
        return shardingProperties;
    }
}

7. druid Configuration class configuration

@Bean(name = "dynamicDataSource")
    @Primary
    public DynamicDataSource dataSource(DataSource masterDataSource)
    {
        Map<Object, Object> targetDataSources = new HashMap<>();
        targetDataSources.put(DataSourceType.MASTER.name(), masterDataSource);
        setDataSource(targetDataSources, DataSourceType.SLAVE.name(), "slaveDataSource");
        setDataSource(targetDataSources, DataSourceType.SHARDING.name(), "shardingDataSource");
        return new DynamicDataSource(masterDataSource, targetDataSources);
    }

8. Add a table splitting policy

package com.ruoyi.framework.config;

import java.util.Collection;
import java.util.Properties;
import java.util.regex.Matcher;
import java.util.regex.Pattern;

import org.apache.shardingsphere.sharding.api.sharding.standard.PreciseShardingValue;
import org.apache.shardingsphere.sharding.api.sharding.standard.RangeShardingValue;
import org.apache.shardingsphere.sharding.api.sharding.standard.StandardShardingAlgorithm;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.stereotype.Component;

@Component
public class TableShardingAlgorithm implements StandardShardingAlgorithm<Long>{

    private static Logger log = LoggerFactory.getLogger(TableShardingAlgorithm.class);

    private Properties props;

    // @Value("${sharding.shardcount}")
    private Long shardCount = 2l;


    public Properties getProps() {
        return props;
    }

    public void setProps(Properties props) {
        this.props = props;
    }

    @Override
    public String doSharding(Collection<String> tableNames, PreciseShardingValue<Long> shardingValue) {

        Long lShard = 0l;
        lShard = (Long)shardingValue.getValue();

        //  Read the set parameters
        if(props != null)
        {
            String shardCountStr = props.getProperty("shardCount", "2");
            shardCount = Long.parseLong(shardCountStr);
        }

        Long lowMod = lShard % 2;


        Long shardTableMod = lowMod;

        //  Convert to a formatted string
        String shardModStr = "_" + shardTableMod;

        for (String table : tableNames) {
            if (table.endsWith(shardModStr)) {
                return table;
            }
        }

        return "";
    }

    @Override
    public String getType() {
        // TODO Auto-generated method stub
        return "ORDER_ID_SHARD";

    }

    @Override
    public void init() {
        // TODO Auto-generated method stub

    }

    @Override
    public Collection<String> doSharding(Collection<String> tableNames,
                                         RangeShardingValue<Long> shardingValue) {

        return null;

    }

}

9. adopt spi Set up the sub table policy

stay resource Create under directory META-INF\services Catalog , create a file org.apache.shardingsphere.sharding.spi.ShardingAlgorithm, And add the following to the file ：

com.ruoyi.framework.config.TableShardingAlgorithm

Custom policy , Need to pass through spi Mechanism to configure .

10. Add annotations to the implementation file of the service

Through annotation @DataSource(DataSourceType.SHARDING), The framework can determine that the corresponding operations need to use the database connection of the split table .

package com.ruoyi.system.service.impl;

import java.util.List;

import com.ruoyi.common.annotation.DataSource;
import com.ruoyi.common.enums.DataSourceType;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Service;
import com.ruoyi.system.mapper.SysOrderMapper;
import com.ruoyi.system.domain.SysOrder;
import com.ruoyi.system.service.ISysOrderService;
import com.ruoyi.common.core.text.Convert;

/**
 *  Order information Service The business layer deals with
 *
 * @author ruoyi
 * @date 2022-06-27
 */
@Service
public class SysOrderServiceImpl implements ISysOrderService
{
    @Autowired
    private SysOrderMapper sysOrderMapper;

    /**
     *  Query order information
     *
     * @param orderId  Order info PK
     * @return  Order information
     */
    @Override
    @DataSource(DataSourceType.SHARDING)
    public SysOrder selectSysOrderByOrderId(Long orderId)
    {
        return sysOrderMapper.selectSysOrderByOrderId(orderId);
    }

    /**
     *  Query the order information list
     *
     * @param sysOrder  Order information
     * @return  Order information
     */
    @Override
    @DataSource(DataSourceType.SHARDING)
    public List<SysOrder> selectSysOrderList(SysOrder sysOrder)
    {
        return sysOrderMapper.selectSysOrderList(sysOrder);
    }

    /**
     *  Add order information
     *
     * @param sysOrder  Order information
     * @return  result
     */
    @Override
    @DataSource(DataSourceType.SHARDING)
    public int insertSysOrder(SysOrder sysOrder)
    {
        return sysOrderMapper.insertSysOrder(sysOrder);
    }

    /**
     *  Modify order information
     *
     * @param sysOrder  Order information
     * @return  result
     */
    @Override
    @DataSource(DataSourceType.SHARDING)
    public int updateSysOrder(SysOrder sysOrder)
    {
        return sysOrderMapper.updateSysOrder(sysOrder);
    }

    /**
     *  Batch delete order information
     *
     * @param orderIds  Order information PK to be deleted
     * @return  result
     */
    @Override
    @DataSource(DataSourceType.SHARDING)
    public int deleteSysOrderByOrderIds(String orderIds)
    {
        return sysOrderMapper.deleteSysOrderByOrderIds(Convert.toStrArray(orderIds));
    }

    /**
     *  Delete order information
     *
     * @param orderId  Order info PK
     * @return  result
     */
    @Override
    @DataSource(DataSourceType.SHARDING)
    public int deleteSysOrderByOrderId(Long orderId)
    {
        return sysOrderMapper.deleteSysOrderByOrderId(orderId);
    }
}
