Storage of floating point in memory

I wrote the storage of integer in memory , Today, let's talk about the storage of floating-point numbers in memory , See if it is the same as integer ~

Let's start with a piece of code ：

#include<stdio.h>
int main()
{
	int n = 9;
	float* pFloat = (float*)&n;
	printf("n The value of is ：%d\n", n);
	printf("*pFloat The value of is ：%f\n", *pFloat);
	*pFloat = 9.0;
	printf("num The value of is ：%d\n", n);
	printf("*pFloat The value of is ：%f\n", *pFloat);
	return 0;
}

Output results ：

From this result, we can see that , When an integer is read as a floating-point type , You will find that the final result is very different from the integer , When a floating-point number is read as an integer , The result is also different from the original floating-point type . From this, we can roughly guess that the memory storage of floating-point type should be different from that of integer type . Is this the case , Please see below

  According to international standards IEEE（ Institute of electrical and Electronic Engineering ） 754, Any binary floating point number V It can be expressed in the following form ：

V=(-1)^S*M*2^E

(-1)^S The sign bit , When S=0 when ,V Is a positive number ,S=1 when ,V It's a negative number ;

M It's a significant number ,0<=M<=1;

2^E Is the number of digits .

for instance ：

Decimal 5.5, Written as binary is 101.1 , amount to 1.01×2^2 .

Because about binary “ Scientific enumeration ” Your meaning is as follows （ Analogous to the decimal system ）：

  Well, according to the above format ,S=0,M=101,E=2. Take this as an example , All binaries can be written in this form . So floating point numbers are stored in memory only S,M and E The value of the ~

IEEE 754 Regulations ：

about 32 Floating point number of bits , The highest bit is the sign bit S, Next 8 Bits are exponents E, The rest 23 Bits are significant numbers M.

about 64 Floating point number of bits , The highest bit is the sign bit S, Next 11 Bits are exponents E, The rest 52 Bits are significant numbers M.

 IEEE 754 For significant figures M and E, There are some special rules .

  As I said before ,1<=M<2, in other words ,M It can be written. 1.###### In the form of , among ###### Represents the fractional part .

IEEE 754 Regulations , Save on the computer M when , By default, the first digit of this number is always 1, Therefore, it can be omitted , Save only the back #####（ decimal ） part . For example, the significant number is 1.001 when , Just save the decimal part 001, Wait until you read , And then 1 Read it . In this way, the storage is saved as significant numbers . With 32 For example, the number of significant digits , Leave to M Only 23 position , But the first 1 Leave it out , I can save it 24 Significant digits .

And for the index E, The situation is more complicated .

First E It's an unsigned integer .

That means , If E by 8 position , that E The value range of is 0~255. If E Position as 11 position , be E The value range of is 0~2047. But for scientific counting ,E Can be negative . So in Deposit in E When it is really worth it, you should first add a middle number in the deposit . about 8 Bit E, To add 127. about 11 Bit E To add 2047.

Last , Index E Fetching from memory can be further divided into three cases ：

（1） Stored E Not all for 0 Or not all of them 1 when , Floating point numbers are represented by the following rules , The index E Calculated value subtract 127（ or 1023）, Get the real value , then Significant figures M Add the first 1.

such as ：

0.5（ Decimal system ） Converting to binary is 0.1, Because the integer part must be 1, That is, to move the decimal part back by one digit , That is to say 1.0*2^-1（-1^0*1.0*2^-1）. among E=-1. When storing, add... To its real value 127, Then the stored value is 126, Binary is 01111110; Remove the integer part 1, The decimal part is 0, Then make up 0 To 23 position 00000000000000000000000, The stored binary representation is :

0 01111110 00000000000000000000000

（2） Stored E All for 0 when , The exponent of a floating point number E（ True value ） be equal to 1-127（ perhaps 1-1023） That's the true value , Significant figures M No more first 1, It's reduced to 0.xxxxxx Decimals of . This is to show that ±0, And close to 0 A very small number of .

（3） Stored E All for 1 when , If the significant number M All for 0, Express ± infinity （ It depends on the sign bit s）

That's all for the storage rules of floating-point numbers . Now let's analyze the original code .

When the whole number 9 When stored as a floating-point number ,  First , To put 0x00000009 Split into

0000 0000 0000 0000 0000 0000 0000 1001

Get the first sign bit s=0, Back 8 Bit index E=00000000 , Last 23 The significant number of bits is 000000000000000 00001001,E The real value of is 1-127=-126.

Because the index E All for 0, So the second case in the previous section . therefore , Floating point numbers V The just ：

V=(-1)^0 × 0.00000000000000000001001×2^(-126)=1.001×2^(-146 ）

obviously ,V It's a very small one, close to 0 Positive number of , So the decimal number is 0.000000.

Let's look at the second part of the example , Floating point numbers 9.0, What happens when it is read out as an integer ？

9.0 It can be written. -1^0*1.001*2^3, Because it is a positive number , therefore S=0,E The real value of is 3, Significant figures M=001. I.e. storage time index E be equal to 3+127=130, namely 10000010; Significant figures M001 Add... To the back 20 individual 0, Cramming 23 position . The storage form is as follows ：

01000001000100000000000000000000

This 32 The binary number of bits , Restore to decimal , Read as an integer , Namely 1091567616. That is the final result .
