HCI 接口

HCI Interface

The communication between a Host (a computer or an MCU) and a Host Controller (the actual Bluetooth chipset) follows the Host Controller Interface (HCI), see {@fig:HostChipsetConnection}. HCI defines how commands, events, asynchronous and synchronous data packets are exchanged. Asynchronous packets (ACL) are used for data transfer, while synchronous packets (SCO) are used for Voice with the Headset and the Hands-Free Profiles.

HCI H2

On desktop-class computers incl. laptops, USB is mainly used as HCI transport layer. For USB Bluetooth chipsets, there is little variation: most USB dongles on the market currently contain a Broadcom BCM20702 or a CSR 851x chipset. It is also called H2.

On embedded systems, UART connections are used instead, although USB could be used as well.

For UART connections, different transport layer variants exist.

HCI H4

The most common one is the official "UART Transport", also called H4. It requires hardware flow control via the CTS/RTS lines and assumes no errors on the UART lines.

HCI H5

The "Three-Wire UART Transport", also called H5, makes use of the SLIP protocol to transmit a packet and can deal with packet loss and bit-errors by retransmission. While it is possible to use H5 really with "three wires" without hardware handshake, we recommend to use a full UART with hardware handshake. If your design lacks the hardware handshake, H5 is your only option.

BCSP

The predecessor of H5. The main difference to H5 is that Even Parity is used for BCSP. To use BCSP with BTstack, you use the H5 transport and can call hci_transport_h5_enable_bcsp_mode

eHCILL

Finally, Texas Instruments extended H4 to create the "eHCILL transport" layer that allows both sides to enter sleep mode without loosing synchronisation. While it is easier to implement than H5, it it is only supported by TI chipsets and cannot handle packet loss or bit-errors.

H4 over SPI

Chipsets from Dialog Semiconductor and EM Marin allow to send H4 formatted HCI packets via SPI. SPI has the benefit of a simpler implementation for both Host Controller and Host as it does not require an exact clock. The SPI Master, here the Host, provides the SPI Clock and the SPI Slave (Host Controller) only has to read and update it's data lines when the clock line changes. The EM9304 supports an SPI clock of up to 8 Mhz. However, an additional protocol is needed to let the Host know when the Host Controller has HCI packet for it. Often, an additional GPIO is used to signal this.
