Detectron2 draw confusion matrix, PR curve and confidence curve

Let me write it out front

As the title of the article says ：detectron2 Draw a confusion matrix 、PR curve 、 Confidence curve
detection2 There is no such function , Drawing code reference from yolov5 Source code ：ultralytics|yolov5

A digression , Now yolov5 can pip install yolov5 Used as a library function , It's really good ！

And what I want to say is , This part of the code is not easy to understand , But the idea is clear , I have successfully transplanted it many times , It must be able to run through , Don't run away with code , An error is reported and the code is said to be no good , The basic ability to look at the code is still necessary .

This code is only for learning and communication , If there is any bug You can solve it by yourself , I really can't solve it, so I asked me in the comment area .

Complete code

confusion_matrix.py（306 Line code ）

This code is added to detection2/evaluation/ Under the table of contents , Follow coco_evaluation.py In the peer Directory
function ： The function of calculating the confusion matrix 、 Calculation iou Function of 、 Drawing functions, etc （ Reference from yolov5 Of utils/metrics.py）

import math
import warnings
from pathlib import Path

import matplotlib.pyplot as plt
import numpy as np
import torch

class ConfusionMatrix:
    # Updated version of https://github.com/kaanakan/object_detection_confusion_matrix
    def __init__(self, nc, conf=0.25, iou_thres=0.45):
        self.matrix = np.zeros((nc + 1, nc + 1))
        self.nc = nc  # number of classes
        self.conf = conf
        self.iou_thres = iou_thres

    def process_batch(self, detections, labels):#
        """ Return intersection-over-union (Jaccard index) of boxes. Both sets of boxes are expected to be in (x1, y1, x2, y2) format. Arguments: detections (Array[N, 6]), x1, y1, x2, y2, conf, class labels (Array[M, 5]), class, x1, y1, x2, y2 Returns: None, updates confusion matrix accordingly """
        '''prediction[coco_dt.anns[i]["score"]'''

        detections = torch.tensor(xywh2xyxy(detections))
        labels = torch.tensor(np.hstack((labels[:,0][:,None],xywh2xyxy(labels[:,1:]))))

        '''mark from yolov5'''

        detections = detections[detections[:, 4] > self.conf]
        gt_classes = labels[:, 0].int()
        detection_classes = detections[:, 5].int()
        iou = box_iou(labels[:, 1:], detections[:, :4])

        x = torch.where(iou > self.iou_thres)
        if x[0].shape[0]:
            '''0:gt_bbox_id 1:dt_bbox_id 2:iou'''
            matches = torch.cat((torch.stack(x, 1), iou[x[0], x[1]][:, None]), 1).cpu().numpy()
            if x[0].shape[0] > 1:
                matches = matches[matches[:, 2].argsort()[::-1]]
                matches = matches[np.unique(matches[:, 1], return_index=True)[1]]#np.unique Remove duplicates
                matches = matches[matches[:, 2].argsort()[::-1]]
                matches = matches[np.unique(matches[:, 0], return_index=True)[1]]
        else:
            matches = np.zeros((0, 3))

        n = matches.shape[0] > 0
        m0, m1, _ = matches.transpose().astype(np.int16)
        for i, gc in enumerate(gt_classes):
            j = m0 == i
            if n and sum(j) == 1:
                self.matrix[detection_classes[m1[j]], gc] += 1  # correct
            else:
                self.matrix[self.nc, gc] += 1  # background FP

        if n:
            for i, dc in enumerate(detection_classes):
                if not any(m1 == i):
                    self.matrix[dc, self.nc] += 1  # background FN

    def matrix(self):
        return self.matrix

    def plot(self, normalize=True, save_dir='', names=(), rec_or_pred=0):#0=recall, 1=pred
        try:
            import seaborn as sn

            array = self.matrix / ((self.matrix.sum(rec_or_pred).reshape(1, -1) + 1E-6) if normalize else 1)  # normalize columns
            array[array < 0.0005] = 0.00 #np.nan # don't annotate (would appear as 0.00)
            array = self.matrix + array

            fig = plt.figure(figsize=(8, 6), tight_layout=True)
            sn.set(font_scale=1.0 if self.nc < 50 else 0.8)  # for label size
            labels = (0 < len(names) < 99) and len(names) == self.nc  # apply names to ticklabels
            with warnings.catch_warnings():
                warnings.simplefilter('ignore')  # suppress empty matrix RuntimeWarning: All-NaN slice encountered
                sn.heatmap(array, annot=self.nc < 30, annot_kws={
    "size": 8}, cmap='Blues', fmt='.2f', square=True,
                           xticklabels=names + ['background FP'] if labels else "auto",
                           yticklabels=names + ['background FN'] if labels else "auto").set_facecolor((1, 1, 1))
            fig.axes[0].set_xlabel('True')
            fig.axes[0].set_ylabel('Predicted')
            if rec_or_pred == 0:
                REC = sum([self.matrix[k, k] for k in range(self.nc)]) / sum(self.matrix.sum(rec_or_pred)[:-1])
                fig.suptitle("Recall (%.3f)"%REC)
            else:
                PRC = sum([self.matrix[k, k] for k in range(self.nc)]) / sum(self.matrix.sum(rec_or_pred)[:-1])
                fig.suptitle("Precision (%.3f)"%PRC)
            #plt.show()
            fig.savefig(save_dir, dpi=250)
            #plt.close()
            return REC, PRC, 2*REC*PRC/(REC+PRC)
        except Exception as e:
            print(f'WARNING: ConfusionMatrix plot failure: {
      e}')


    def print(self):
        # for i in range(self.nc + 1):
        # print(' '.join(map(str, self.matrix[i])))
        REC = sum([self.matrix[k, k] for k in range(self.nc)]) / sum(self.matrix.sum(0)[:-1])
        PRC = sum([self.matrix[k, k] for k in range(self.nc)]) / sum(self.matrix.sum(1)[:-1])
        print("\nRecall: (%.4f)"%REC, "\nPrecision: (%.4f)"%PRC, "\nF1-score: (%.4f)" %(2 * REC * PRC / (REC + PRC)))



def box_iou(box1, box2):
    # https://github.com/pytorch/vision/blob/master/torchvision/ops/boxes.py
    """ Return intersection-over-union (Jaccard index) of boxes. Both sets of boxes are expected to be in (x1, y1, x2, y2) format. Arguments: box1 (Tensor[N, 4]) box2 (Tensor[M, 4]) Returns: iou (Tensor[N, M]): the NxM matrix containing the pairwise IoU values for every element in boxes1 and boxes2 """

    def box_area(box):
        # box = 4xn
        return (box[2] - box[0]) * (box[3] - box[1])

    area1 = box_area(box1.T)
    area2 = box_area(box2.T)

    # inter(N,M) = (rb(N,M,2) - lt(N,M,2)).clamp(0).prod(2)
    inter = (torch.min(box1[:, None, 2:], box2[:, 2:]) - torch.max(box1[:, None, :2], box2[:, :2])).clamp(0).prod(2)
    return inter / (area1[:, None] + area2 - inter)  # iou = inter / (area1 + area2 - inter)

def xywh2xyxy(x):
    # Convert nx4 boxes from [x, y, w, h] to [x1, y1, x2, y2] where xy1=top-left, xy2=bottom-right
    y = x.clone() if isinstance(x, torch.Tensor) else np.copy(x)
    y[:, 0] = x[:, 0] - x[:, 2] / 2  # top left x
    y[:, 1] = x[:, 1] - x[:, 3] / 2  # top left y
    y[:, 2] = x[:, 0] + x[:, 2] / 2  # bottom right x
    y[:, 3] = x[:, 1] + x[:, 3] / 2  # bottom right y
    return y

def process_batch(detections, labels, iouv):
    """ Return correct predictions matrix. Both sets of boxes are in (x1, y1, x2, y2) format. Arguments: detections (Array[N, 6]), x1, y1, x2, y2, conf, class labels (Array[M, 5]), class, x1, y1, x2, y2 Returns: correct (Array[N, 10]), for 10 IoU levels """
    correct = torch.zeros(detections.shape[0], iouv.shape[0], dtype=torch.bool, device=iouv.device)
    iou = box_iou(labels[:, 1:], detections[:, :4])
    x = torch.where((iou >= iouv[0]) & (labels[:, 0:1] == detections[:, 5]))  # IoU above threshold and classes match
    if x[0].shape[0]:
        matches = torch.cat((torch.stack(x, 1), iou[x[0], x[1]][:, None]), 1).cpu().numpy()  # [label, detection, iou]
        if x[0].shape[0] > 1:
            matches = matches[matches[:, 2].argsort()[::-1]]
            matches = matches[np.unique(matches[:, 1], return_index=True)[1]]
            # matches = matches[matches[:, 2].argsort()[::-1]]
            matches = matches[np.unique(matches[:, 0], return_index=True)[1]]
        matches = torch.Tensor(matches).to(iouv.device)
        correct[matches[:, 1].long()] = matches[:, 2:3] >= iouv
    return correct

def ap_per_class(tp, conf, pred_cls, target_cls, plot=False, save_dir='.', names=()):
    """ Compute the average precision, given the recall and precision curves. Source: https://github.com/rafaelpadilla/Object-Detection-Metrics. # Arguments tp: True positives (nparray, nx1 or nx10). conf: Objectness value from 0-1 (nparray). pred_cls: Predicted object classes (nparray). target_cls: True object classes (nparray). plot: Plot precision-recall curve at [email protected] save_dir: Plot save directory # Returns The average precision as computed in py-faster-rcnn. """

    # Sort by objectness
    i = np.argsort(-conf)
    tp, conf, pred_cls = tp[i], conf[i], pred_cls[i]

    # Find unique classes
    unique_classes = np.unique(target_cls)
    nc = unique_classes.shape[0]  # number of classes, number of detections

    # Create Precision-Recall curve and compute AP for each class
    px, py = np.linspace(0, 1, 1000), []  # for plotting
    ap, p, r = np.zeros((nc, tp.shape[1])), np.zeros((nc, 1000)), np.zeros((nc, 1000))
    for ci, c in enumerate(unique_classes):
        i = pred_cls == c
        n_l = (target_cls == c).sum()  # number of labels
        n_p = i.sum()  # number of predictions

        if n_p == 0 or n_l == 0:
            continue
        else:
            # Accumulate FPs and TPs
            fpc = (1 - tp[i]).cumsum(0)
            tpc = tp[i].cumsum(0)

            # Recall
            recall = tpc / (n_l + 1e-16)  # recall curve
            r[ci] = np.interp(-px, -conf[i], recall[:, 0], left=0)  # negative x, xp because xp decreases

            # Precision
            precision = tpc / (tpc + fpc)  # precision curve
            p[ci] = np.interp(-px, -conf[i], precision[:, 0], left=1)  # p at pr_score

            # AP from recall-precision curve
            for j in range(tp.shape[1]):
                ap[ci, j], mpre, mrec = compute_ap(recall[:, j], precision[:, j])
                if plot and j == 0:
                    py.append(np.interp(px, mrec, mpre))  # precision at [email protected]

    # Compute F1 (harmonic mean of precision and recall)
    f1 = 2 * p * r / (p + r + 1e-16)
    if plot:
        plot_pr_curve(px, py, ap, Path(save_dir) / 'PR_curve.png', names)
        plot_mc_curve(px, f1, Path(save_dir) / 'F1_curve.png', names, ylabel='F1')
        plot_mc_curve(px, p, Path(save_dir) / 'P_curve.png', names, ylabel='Precision')
        plot_mc_curve(px, r, Path(save_dir) / 'R_curve.png', names, ylabel='Recall')

    i = f1.mean(0).argmax()  # max F1 index
    return p[:, i], r[:, i], ap, f1[:, i], unique_classes.astype('int32')

def compute_ap(recall, precision):
    """ Compute the average precision, given the recall and precision curves # Arguments recall: The recall curve (list) precision: The precision curve (list) # Returns Average precision, precision curve, recall curve """

    # Append sentinel values to beginning and end
    mrec = np.concatenate(([0.0], recall, [1.0]))
    mpre = np.concatenate(([1.0], precision, [0.0]))

    # Compute the precision envelope
    mpre = np.flip(np.maximum.accumulate(np.flip(mpre)))

    # Integrate area under curve
    method = 'interp'  # methods: 'continuous', 'interp'
    if method == 'interp':
        x = np.linspace(0, 1, 101)  # 101-point interp (COCO)
        ap = np.trapz(np.interp(x, mrec, mpre), x)  # integrate
    else:  # 'continuous'
        i = np.where(mrec[1:] != mrec[:-1])[0]  # points where x axis (recall) changes
        ap = np.sum((mrec[i + 1] - mrec[i]) * mpre[i + 1])  # area under curve

    return ap, mpre, mrec

def plot_pr_curve(px, py, ap, save_dir='pr_curve.png', names=()):
    # Precision-recall curve
    fig, ax = plt.subplots(1, 1, figsize=(9, 6), tight_layout=True)
    py = np.stack(py, axis=1)

    if 0 < len(names) < 21:  # display per-class legend if < 21 classes
        for i, y in enumerate(py.T):
            ax.plot(px, y, linewidth=1, label=f'{
      names[i]} {
      ap[i, 0]:.3f}')  # plot(recall, precision)
    else:
        ax.plot(px, py, linewidth=1, color='grey')  # plot(recall, precision)

    ax.plot(px, py.mean(1), linewidth=3, color='blue', label='all classes %.3f [email protected]' % ap[:, 0].mean())
    ax.set_xlabel('Recall')
    ax.set_ylabel('Precision')
    ax.set_xlim(0, 1)
    ax.set_ylim(0, 1)
    plt.legend(bbox_to_anchor=(1.04, 1), loc="upper left")
    fig.savefig(Path(save_dir), dpi=250)
    plt.close()


def plot_mc_curve(px, py, save_dir='mc_curve.png', names=(), xlabel='Confidence', ylabel='Metric'):
    # Metric-confidence curve
    fig, ax = plt.subplots(1, 1, figsize=(9, 6), tight_layout=True)

    if 0 < len(names) < 21:  # display per-class legend if < 21 classes
        for i, y in enumerate(py):
            ax.plot(px, y, linewidth=1, label=f'{
      names[i]}')  # plot(confidence, metric)
    else:
        ax.plot(px, py.T, linewidth=1, color='grey')  # plot(confidence, metric)

    y = py.mean(0)
    ax.plot(px, y, linewidth=3, color='blue', label=f'all classes {
      y.max():.2f} at {
      px[y.argmax()]:.3f}')
    ax.set_xlabel(xlabel)
    ax.set_ylabel(ylabel)
    ax.set_xlim(0, 1)
    ax.set_ylim(0, 1)
    plt.legend(bbox_to_anchor=(1.04, 1), loc="upper left")
    fig.savefig(Path(save_dir), dpi=250)
    plt.close()

def plot_mc_pr_curve(detections, labels, save_dir, names):
    detections = torch.tensor(xywh2xyxy(detections))
    labels = torch.tensor(np.hstack((labels[:, 0][:, None], xywh2xyxy(labels[:, 1:]))))
    iouv = torch.linspace(0.5, 0.95, 10)  # iou vector for [email protected]:0.95
    correct = process_batch(detections, labels, iouv)
    stats = []
    tcls = labels[:, 0].tolist()  # target class
    stats.append((correct.cpu(), detections[:, 4].cpu(), detections[:, 5].cpu(), tcls))
    # (correct, conf, pcls, tcls)
    stats = [np.concatenate(x, 0) for x in zip(*stats)]  # to numpy
    if len(stats) and stats[0].any():
        p, r, ap, f1, ap_class = ap_per_class(*stats, plot=True, save_dir=save_dir, names=names)

After modification coco_evaluation.py（625 Line code ）

The original code is in detection2/evaluation/ Under the table of contents , Replace this code with the original coco_evaluation.py
function ： call confusion_matrix.py Inside the function to draw , You can annotate or uncomment the code according to your own needs （ altogether 36 That's ok ）

# Copyright (c) Facebook, Inc. and its affiliates.
import contextlib
import copy
import io
import itertools
import json
import logging
import numpy as np
import os
import pickle
from collections import OrderedDict
import pycocotools.mask as mask_util
import torch
from pycocotools.coco import COCO
from pycocotools.cocoeval import COCOeval
from tabulate import tabulate

import detectron2.utils.comm as comm
from detectron2.config import CfgNode
from detectron2.data import MetadataCatalog
from detectron2.data.datasets.coco import convert_to_coco_json
from detectron2.evaluation.fast_eval_api import COCOeval_opt
from detectron2.structures import Boxes, BoxMode, pairwise_iou
from detectron2.utils.file_io import PathManager
from detectron2.utils.logger import create_small_table

from .evaluator import DatasetEvaluator


class COCOEvaluator(DatasetEvaluator):
    """ Evaluate AR for object proposals, AP for instance detection/segmentation, AP for keypoint detection outputs using COCO's metrics. See http://cocodataset.org/#detection-eval and http://cocodataset.org/#keypoints-eval to understand its metrics. The metrics range from 0 to 100 (instead of 0 to 1), where a -1 or NaN means the metric cannot be computed (e.g. due to no predictions made). In addition to COCO, this evaluator is able to support any bounding box detection, instance segmentation, or keypoint detection dataset. """

    def __init__(
        self,
        dataset_name,
        tasks=None,
        distributed=True,
        output_dir=None,
        *,
        use_fast_impl=True,
        kpt_oks_sigmas=(),
        cfg_file=None ###additional
    ):
        """ Args: dataset_name (str): name of the dataset to be evaluated. It must have either the following corresponding metadata: "json_file": the path to the COCO format annotation Or it must be in detectron2's standard dataset format so it can be converted to COCO format automatically. tasks (tuple[str]): tasks that can be evaluated under the given configuration. A task is one of "bbox", "segm", "keypoints". By default, will infer this automatically from predictions. distributed (True): if True, will collect results from all ranks and run evaluation in the main process. Otherwise, will only evaluate the results in the current process. output_dir (str): optional, an output directory to dump all results predicted on the dataset. The dump contains two files: 1. "instances_predictions.pth" a file that can be loaded with `torch.load` and contains all the results in the format they are produced by the model. 2. "coco_instances_results.json" a json file in COCO's result format. use_fast_impl (bool): use a fast but **unofficial** implementation to compute AP. Although the results should be very close to the official implementation in COCO API, it is still recommended to compute results with the official API for use in papers. The faster implementation also uses more RAM. kpt_oks_sigmas (list[float]): The sigmas used to calculate keypoint OKS. See http://cocodataset.org/#keypoints-eval When empty, it will use the defaults in COCO. Otherwise it should be the same length as ROI_KEYPOINT_HEAD.NUM_KEYPOINTS. """
        self._logger = logging.getLogger(__name__)
        self._distributed = distributed
        self._output_dir = output_dir
        self._use_fast_impl = use_fast_impl
        self._cfg_file = cfg_file##

        if tasks is not None and isinstance(tasks, CfgNode):
            kpt_oks_sigmas = (
                tasks.TEST.KEYPOINT_OKS_SIGMAS if not kpt_oks_sigmas else kpt_oks_sigmas
            )
            self._logger.warn(
                "COCO Evaluator instantiated using config, this is deprecated behavior."
                " Please pass in explicit arguments instead."
            )
            self._tasks = None  # Infering it from predictions should be better
        else:
            self._tasks = tasks

        self._cpu_device = torch.device("cpu")

        self._metadata = MetadataCatalog.get(dataset_name)
        if not hasattr(self._metadata, "json_file"):
            self._logger.info(
                f"'{
      dataset_name}' is not registered by `register_coco_instances`."
                " Therefore trying to convert it to COCO format ..."
            )

            cache_path = os.path.join(output_dir, f"{
      dataset_name}_coco_format.json")
            self._metadata.json_file = cache_path
            convert_to_coco_json(dataset_name, cache_path)

        json_file = PathManager.get_local_path(self._metadata.json_file)
        with contextlib.redirect_stdout(io.StringIO()):
            self._coco_api = COCO(json_file)

        # Test set json files do not contain annotations (evaluation must be
        # performed using the COCO evaluation server).
        self._do_evaluation = "annotations" in self._coco_api.dataset
        if self._do_evaluation:
            self._kpt_oks_sigmas = kpt_oks_sigmas

    def reset(self):
        self._predictions = []

    def process(self, inputs, outputs):
        """ Args: inputs: the inputs to a COCO model (e.g., GeneralizedRCNN). It is a list of dict. Each dict corresponds to an image and contains keys like "height", "width", "file_name", "image_id". outputs: the outputs of a COCO model. It is a list of dicts with key "instances" that contains :class:`Instances`. """
        for input, output in zip(inputs, outputs):
            prediction = {
    "image_id": input["image_id"]}

            if "instances" in output:
                instances = output["instances"].to(self._cpu_device)
                prediction["instances"] = instances_to_coco_json(instances, input["image_id"])
            if "proposals" in output:
                prediction["proposals"] = output["proposals"].to(self._cpu_device)
            if len(prediction) > 1:
                self._predictions.append(prediction)

    def evaluate(self, img_ids=None):
        """ Args: img_ids: a list of image IDs to evaluate on. Default to None for the whole dataset """
        if self._distributed:
            comm.synchronize()
            predictions = comm.gather(self._predictions, dst=0)
            predictions = list(itertools.chain(*predictions))

            if not comm.is_main_process():
                return {
    }
        else:
            predictions = self._predictions

        if len(predictions) == 0:
            self._logger.warning("[COCOEvaluator] Did not receive valid predictions.")
            return {
    }

        if self._output_dir:
            PathManager.mkdirs(self._output_dir)
            file_path = os.path.join(self._output_dir, "instances_predictions.pth")
            with PathManager.open(file_path, "wb") as f:
                torch.save(predictions, f)

        self._results = OrderedDict()
        if "proposals" in predictions[0]:
            self._eval_box_proposals(predictions)
        if "instances" in predictions[0]:#\\\\
            self._eval_predictions(predictions, img_ids=img_ids)
        # Copy so the caller can do whatever with results
        return copy.deepcopy(self._results)

    def _tasks_from_predictions(self, predictions):
        """ Get COCO API "tasks" (i.e. iou_type) from COCO-format predictions. """
        tasks = {
    "bbox"}
        for pred in predictions:
            if "segmentation" in pred:
                tasks.add("segm")
            if "keypoints" in pred:
                tasks.add("keypoints")
        return sorted(tasks)

    def _eval_predictions(self, predictions, img_ids=None):
        """ Evaluate predictions. Fill self._results with the metrics of the tasks. """
        self._logger.info("Preparing results for COCO format ...")
        coco_results = list(itertools.chain(*[x["instances"] for x in predictions]))
        tasks = self._tasks or self._tasks_from_predictions(coco_results)

        # unmap the category ids for COCO
        if hasattr(self._metadata, "thing_dataset_id_to_contiguous_id"):
            dataset_id_to_contiguous_id = self._metadata.thing_dataset_id_to_contiguous_id
            all_contiguous_ids = list(dataset_id_to_contiguous_id.values())
            num_classes = len(all_contiguous_ids)
            assert min(all_contiguous_ids) == 0 and max(all_contiguous_ids) == num_classes - 1

            reverse_id_mapping = {
    v: k for k, v in dataset_id_to_contiguous_id.items()}
            for result in coco_results:
                category_id = result["category_id"]
                assert category_id < num_classes, (
                    f"A prediction has class={
      category_id}, "
                    f"but the dataset only has {
      num_classes} classes and "
                    f"predicted class id should be in [0, {
      num_classes - 1}]."
                )
                result["category_id"] = reverse_id_mapping[category_id]

        if self._output_dir:
            file_path = os.path.join(self._output_dir, "coco_instances_results.json")
            self._logger.info("Saving results to {}".format(file_path))
            with PathManager.open(file_path, "w") as f:
                f.write(json.dumps(coco_results))
                f.flush()

        if not self._do_evaluation:
            self._logger.info("Annotations are not available for evaluation.")
            return

        self._logger.info(
            "Evaluating predictions with {} COCO API...".format(
                "unofficial" if self._use_fast_impl else "official"
            )
        )
        for task in sorted(tasks):
            assert task in {
    "bbox", "segm", "keypoints"}, f"Got unknown task: {
      task}!"
            coco_eval = (
                _evaluate_predictions_on_coco(
                    self._coco_api,
                    coco_results,
                    task,
                    kpt_oks_sigmas=self._kpt_oks_sigmas,
                    use_fast_impl=self._use_fast_impl,
                    img_ids=img_ids,
                    cfg_file=self._cfg_file,
                )
                if len(coco_results) > 0
                else None  # cocoapi does not handle empty results very well
            )

            print("============Per-category AP===========")
            '''per-category AP'''
            res = self._derive_coco_results(
                coco_eval, task, class_names=self._metadata.get("thing_classes")
            )
            self._results[task] = res

    def _eval_box_proposals(self, predictions):
        """ Evaluate the box proposals in predictions. Fill self._results with the metrics for "box_proposals" task. """
        if self._output_dir:
            # Saving generated box proposals to file.
            # Predicted box_proposals are in XYXY_ABS mode.
            bbox_mode = BoxMode.XYXY_ABS.value
            ids, boxes, objectness_logits = [], [], []
            for prediction in predictions:
                ids.append(prediction["image_id"])
                boxes.append(prediction["proposals"].proposal_boxes.tensor.numpy())
                objectness_logits.append(prediction["proposals"].objectness_logits.numpy())

            proposal_data = {

                "boxes": boxes,
                "objectness_logits": objectness_logits,
                "ids": ids,
                "bbox_mode": bbox_mode,
            }
            with PathManager.open(os.path.join(self._output_dir, "box_proposals.pkl"), "wb") as f:
                pickle.dump(proposal_data, f)

        if not self._do_evaluation:
            self._logger.info("Annotations are not available for evaluation.")
            return

        self._logger.info("Evaluating bbox proposals ...")
        res = {
    }
        areas = {
    "all": "", "small": "s", "medium": "m", "large": "l"}
        for limit in [100, 1000]:
            for area, suffix in areas.items():
                stats = _evaluate_box_proposals(predictions, self._coco_api, area=area, limit=limit)
                key = "AR{}@{:d}".format(suffix, limit)
                res[key] = float(stats["ar"].item() * 100)
        self._logger.info("Proposal metrics: \n" + create_small_table(res))
        self._results["box_proposals"] = res

    def _derive_coco_results(self, coco_eval, iou_type, class_names=None):
        """ Derive the desired score numbers from summarized COCOeval. Args: coco_eval (None or COCOEval): None represents no predictions from model. iou_type (str): class_names (None or list[str]): if provided, will use it to predict per-category AP. Returns: a dict of {metric name: score} """

        metrics = {

            "bbox": ["AP", "AP50", "AP75", "APs", "APm", "APl"],
            "segm": ["AP", "AP50", "AP75", "APs", "APm", "APl"],
            "keypoints": ["AP", "AP50", "AP75", "APm", "APl"],
        }[iou_type]

        if coco_eval is None:
            self._logger.warn("No predictions from the model!")
            return {
    metric: float("nan") for metric in metrics}

        # the standard metrics
        results = {

            metric: float(coco_eval.stats[idx] * 100 if coco_eval.stats[idx] >= 0 else "nan")
            for idx, metric in enumerate(metrics)
        }
        self._logger.info(
            "Evaluation results for {}: \n".format(iou_type) + create_small_table(results)
        )
        if not np.isfinite(sum(results.values())):
            self._logger.info("Some metrics cannot be computed and is shown as NaN.")

        if class_names is None or len(class_names) <= 1:
            return results
        # Compute per-category AP
        # from https://github.com/facebookresearch/Detectron/blob/a6a835f5b8208c45d0dce217ce9bbda915f44df7/detectron/datasets/json_dataset_evaluator.py#L222-L252 # noqa
        precisions = coco_eval.eval["precision"]
        # precision has dims (iou, recall, cls, area range, max dets)
        assert len(class_names) == precisions.shape[2]

        results_per_category = []
        for idx, name in enumerate(class_names):
            # area range index 0: all area ranges
            # max dets index -1: typically 100 per image
            #print("\n\niou:",precisions.shape[0])=10
            precision = precisions[0, :, idx, 0, -1]
            precision = precision[precision > -1]
            ap = np.mean(precision) if precision.size else float("nan")
            results_per_category.append(("{}".format(name), float(ap * 100)))

        # tabulate it
        N_COLS = min(6, len(results_per_category) * 2)
        results_flatten = list(itertools.chain(*results_per_category))
        results_2d = itertools.zip_longest(*[results_flatten[i::N_COLS] for i in range(N_COLS)])
        table = tabulate(
            results_2d,
            tablefmt="pipe",
            floatfmt=".3f",
            headers=["category", "AP50"] * (N_COLS // 2),#AP
            numalign="left",
        )
        self._logger.info("Per-category {} AP: \n".format(iou_type) + table)

        results.update({
    "AP50-" + name: ap for name, ap in results_per_category})#AP
        return results


def instances_to_coco_json(instances, img_id):
    """ Dump an "Instances" object to a COCO-format json that's used for evaluation. Args: instances (Instances): img_id (int): the image id Returns: list[dict]: list of json annotations in COCO format. """
    num_instance = len(instances)
    if num_instance == 0:
        return []

    boxes = instances.pred_boxes.tensor.numpy()
    boxes = BoxMode.convert(boxes, BoxMode.XYXY_ABS, BoxMode.XYWH_ABS)
    boxes = boxes.tolist()
    scores = instances.scores.tolist()
    classes = instances.pred_classes.tolist()

    has_mask = instances.has("pred_masks")
    if has_mask:
        # use RLE to encode the masks, because they are too large and takes memory
        # since this evaluator stores outputs of the entire dataset
        rles = [
            mask_util.encode(np.array(mask[:, :, None], order="F", dtype="uint8"))[0]
            for mask in instances.pred_masks
        ]
        for rle in rles:
            # "counts" is an array encoded by mask_util as a byte-stream. Python3's
            # json writer which always produces strings cannot serialize a bytestream
            # unless you decode it. Thankfully, utf-8 works out (which is also what
            # the pycocotools/_mask.pyx does).
            rle["counts"] = rle["counts"].decode("utf-8")

    has_keypoints = instances.has("pred_keypoints")
    if has_keypoints:
        keypoints = instances.pred_keypoints

    results = []
    for k in range(num_instance):
        result = {

            "image_id": img_id,
            "category_id": classes[k],
            "bbox": boxes[k],
            "score": scores[k],
        }
        if has_mask:
            result["segmentation"] = rles[k]
        if has_keypoints:
            # In COCO annotations,
            # keypoints coordinates are pixel indices.
            # However our predictions are floating point coordinates.
            # Therefore we subtract 0.5 to be consistent with the annotation format.
            # This is the inverse of data loading logic in `datasets/coco.py`.
            keypoints[k][:, :2] -= 0.5
            result["keypoints"] = keypoints[k].flatten().tolist()
        results.append(result)
    return results


# inspired from Detectron:
# https://github.com/facebookresearch/Detectron/blob/a6a835f5b8208c45d0dce217ce9bbda915f44df7/detectron/datasets/json_dataset_evaluator.py#L255 # noqa
def _evaluate_box_proposals(dataset_predictions, coco_api, thresholds=None, area="all", limit=None):
    """ Evaluate detection proposal recall metrics. This function is a much faster alternative to the official COCO API recall evaluation code. However, it produces slightly different results. """
    # Record max overlap value for each gt box
    # Return vector of overlap values
    areas = {

        "all": 0,
        "small": 1,
        "medium": 2,
        "large": 3,
        "96-128": 4,
        "128-256": 5,
        "256-512": 6,
        "512-inf": 7,
    }
    area_ranges = [
        [0 ** 2, 1e5 ** 2],  # all
        [0 ** 2, 32 ** 2],  # small
        [32 ** 2, 96 ** 2],  # medium
        [96 ** 2, 1e5 ** 2],  # large
        [96 ** 2, 128 ** 2],  # 96-128
        [128 ** 2, 256 ** 2],  # 128-256
        [256 ** 2, 512 ** 2],  # 256-512
        [512 ** 2, 1e5 ** 2],
    ]  # 512-inf
    assert area in areas, "Unknown area range: {}".format(area)
    area_range = area_ranges[areas[area]]
    gt_overlaps = []
    num_pos = 0

    for prediction_dict in dataset_predictions:
        predictions = prediction_dict["proposals"]

        # sort predictions in descending order
        # TODO maybe remove this and make it explicit in the documentation
        inds = predictions.objectness_logits.sort(descending=True)[1]
        predictions = predictions[inds]

        ann_ids = coco_api.getAnnIds(imgIds=prediction_dict["image_id"])
        anno = coco_api.loadAnns(ann_ids)
        gt_boxes = [
            BoxMode.convert(obj["bbox"], BoxMode.XYWH_ABS, BoxMode.XYXY_ABS)
            for obj in anno
            if obj["iscrowd"] == 0
        ]
        gt_boxes = torch.as_tensor(gt_boxes).reshape(-1, 4)  # guard against no boxes
        gt_boxes = Boxes(gt_boxes)
        gt_areas = torch.as_tensor([obj["area"] for obj in anno if obj["iscrowd"] == 0])

        if len(gt_boxes) == 0 or len(predictions) == 0:
            continue

        valid_gt_inds = (gt_areas >= area_range[0]) & (gt_areas <= area_range[1])
        gt_boxes = gt_boxes[valid_gt_inds]

        num_pos += len(gt_boxes)

        if len(gt_boxes) == 0:
            continue

        if limit is not None and len(predictions) > limit:
            predictions = predictions[:limit]

        overlaps = pairwise_iou(predictions.proposal_boxes, gt_boxes)

        _gt_overlaps = torch.zeros(len(gt_boxes))
        for j in range(min(len(predictions), len(gt_boxes))):
            # find which proposal box maximally covers each gt box
            # and get the iou amount of coverage for each gt box
            max_overlaps, argmax_overlaps = overlaps.max(dim=0)

            # find which gt box is 'best' covered (i.e. 'best' = most iou)
            gt_ovr, gt_ind = max_overlaps.max(dim=0)
            assert gt_ovr >= 0
            # find the proposal box that covers the best covered gt box
            box_ind = argmax_overlaps[gt_ind]
            # record the iou coverage of this gt box
            _gt_overlaps[j] = overlaps[box_ind, gt_ind]
            assert _gt_overlaps[j] == gt_ovr
            # mark the proposal box and the gt box as used
            overlaps[box_ind, :] = -1
            overlaps[:, gt_ind] = -1

        # append recorded iou coverage level
        gt_overlaps.append(_gt_overlaps)
    gt_overlaps = (
        torch.cat(gt_overlaps, dim=0) if len(gt_overlaps) else torch.zeros(0, dtype=torch.float32)
    )
    gt_overlaps, _ = torch.sort(gt_overlaps)

    if thresholds is None:
        step = 0.05
        thresholds = torch.arange(0.5, 0.95 + 1e-5, step, dtype=torch.float32)
    recalls = torch.zeros_like(thresholds)
    # compute recall for each iou threshold
    for i, t in enumerate(thresholds):
        recalls[i] = (gt_overlaps >= t).float().sum() / float(num_pos)#t
    # ar = 2 * np.trapz(recalls, thresholds)
    ar = recalls.mean()
    return {

        "ar": ar,
        "recalls": recalls,
        "thresholds": thresholds,
        "gt_overlaps": gt_overlaps,
        "num_pos": num_pos,
    }


def _evaluate_predictions_on_coco(
    coco_gt, coco_results, iou_type, kpt_oks_sigmas=None, use_fast_impl=True,
        img_ids=None, cfg_file=None
):
    """ Evaluate the coco results using COCOEval API. """
    assert len(coco_results) > 0

    if iou_type == "segm":
        coco_results = copy.deepcopy(coco_results)
        # When evaluating mask AP, if the results contain bbox, cocoapi will
        # use the box area as the area of the instance, instead of the mask area.
        # This leads to a different definition of small/medium/large.
        # We remove the bbox field to let mask AP use mask area.
        for c in coco_results:
            c.pop("bbox", None)

    coco_dt = coco_gt.loadRes(coco_results)

    ''' '''
     This code 36 That's ok （ Reference resources yolov5 Source code ） For me to add the drawing code , The main functions are as follows ：
    1.coco_dt Turn it into predictions
    2.coco_gt Turn into labels
    3. draw confusion matrix
    4. draw PR Curves, etc
    ''' plot = True #(cfg_file != None) and (isinstance(cfg_file,CfgNode)) print("plot: ",plot) if plot: from ..utils.confusion_matrix import ConfusionMatrix,xywh2xyxy,process_batch,ap_per_class C_M = ConfusionMatrix(nc=3, conf=0.65,iou_thres=0.5) stats = [] for i in range(len(coco_gt.imgs)):#460 Pictures  bbox_gt = np.array([y['bbox'] for y in coco_gt.imgToAnns[20210700001+i]]) class_gt = np.array([[y['category_id']-1] for y in coco_gt.imgToAnns[20210700001+i]]) labels = np.hstack((class_gt,bbox_gt)) bbox_dt = np.array([y['bbox'] for y in coco_dt.imgToAnns[20210700001+i]]) conf_dt = np.array([[y['score']] for y in coco_dt.imgToAnns[20210700001+i]]) class_dt = np.array([[y['category_id']-1] for y in coco_dt.imgToAnns[20210700001+i]]) predictions = np.hstack((np.hstack((bbox_dt,conf_dt)),class_dt)) C_M.process_batch(predictions, labels) #'''PR Isocurve ''' # detects = torch.tensor(xywh2xyxy(predictions)) # labs = torch.tensor(np.hstack((labels[:, 0][:, None], xywh2xyxy(labels[:, 1:])))) # iouv = torch.linspace(0.5, 0.95, 10) # iou vector for [email protected]:0.95 # correct = process_batch(detects, labs, iouv) # tcls = labs[:, 0].tolist() # target class # stats.append((correct.cpu(), detects[:, 4].cpu(), detects[:, 5].cpu(), tcls)) C_M.print() # plot_dir = "/home/server/xcg/SwinT_detectron2/" + cfg_file.OUTPUT_DIR # # names = {k: v for k, v in enumerate(["fuwo", "cewo", "zhanli"])} # stats = [np.concatenate(x, 0) for x in zip(*stats)] # to numpy # if len(stats) and stats[0].any(): # p, r, ap, f1, ap_class = ap_per_class(*stats, plot=True, save_dir=plot_dir, names=names) # C_M.plot(save_dir=plot_dir+ 'confusion_matrix_rec.png',names=["fuwo","cewo","zhanli"], rec_or_pred=0) # C_M.plot(save_dir=plot_dir+ 'confusion_matrix_pred.png',names=["fuwo", "cewo", "zhanli"], rec_or_pred=1) '''

    coco_eval = (COCOeval_opt if use_fast_impl else COCOeval)(coco_gt, coco_dt, iou_type)
    if img_ids is not None:
        coco_eval.params.imgIds = img_ids

    if iou_type == "keypoints":
        # Use the COCO default keypoint OKS sigmas unless overrides are specified
        if kpt_oks_sigmas:
            assert hasattr(coco_eval.params, "kpt_oks_sigmas"), "pycocotools is too old!"
            coco_eval.params.kpt_oks_sigmas = np.array(kpt_oks_sigmas)
        # COCOAPI requires every detection and every gt to have keypoints, so
        # we just take the first entry from both
        num_keypoints_dt = len(coco_results[0]["keypoints"]) // 3
        num_keypoints_gt = len(next(iter(coco_gt.anns.values()))["keypoints"]) // 3
        num_keypoints_oks = len(coco_eval.params.kpt_oks_sigmas)
        assert num_keypoints_oks == num_keypoints_dt == num_keypoints_gt, (
            f"[COCOEvaluator] Prediction contain {
      num_keypoints_dt} keypoints. "
            f"Ground truth contains {
      num_keypoints_gt} keypoints. "
            f"The length of cfg.TEST.KEYPOINT_OKS_SIGMAS is {
      num_keypoints_oks}. "
            "They have to agree with each other. For meaning of OKS, please refer to "
            "http://cocodataset.org/#keypoints-eval."
        )

    coco_eval.evaluate()
    coco_eval.accumulate()
    coco_eval.summarize()#Average Recall (AR) @[ IoU=0.50:0.95 | area= large | maxDets=100 ] = 0.799

    return coco_eval

 This code 36 That's ok （ Reference resources yolov5 Source code ） For me to add the drawing code , The main functions are as follows ：
1.coco_dt Turn it into predictions
2.coco_gt Turn into labels
3. draw confusion matrix
4. draw PR Curves, etc

plot = True #(cfg_file != None) and (isinstance(cfg_file,CfgNode))
    print("plot: ",plot)
    if plot:
        from ..utils.confusion_matrix import ConfusionMatrix,xywh2xyxy,process_batch,ap_per_class
        C_M = ConfusionMatrix(nc=3, conf=0.65,iou_thres=0.5)
        stats = []
        for i in range(len(coco_gt.imgs)):#460 Pictures
            bbox_gt = np.array([y['bbox'] for y in coco_gt.imgToAnns[20210700001+i]])
            class_gt = np.array([[y['category_id']-1] for y in coco_gt.imgToAnns[20210700001+i]])
            labels = np.hstack((class_gt,bbox_gt))

            bbox_dt = np.array([y['bbox'] for y in coco_dt.imgToAnns[20210700001+i]])
            conf_dt = np.array([[y['score']] for y in coco_dt.imgToAnns[20210700001+i]])
            class_dt = np.array([[y['category_id']-1] for y in coco_dt.imgToAnns[20210700001+i]])
            predictions = np.hstack((np.hstack((bbox_dt,conf_dt)),class_dt))

            C_M.process_batch(predictions, labels)

            #'''PR Isocurve '''
            # detects = torch.tensor(xywh2xyxy(predictions))
            # labs = torch.tensor(np.hstack((labels[:, 0][:, None], xywh2xyxy(labels[:, 1:]))))
            # iouv = torch.linspace(0.5, 0.95, 10) # iou vector for [email protected]:0.95
            # correct = process_batch(detects, labs, iouv)
            # tcls = labs[:, 0].tolist() # target class
            # stats.append((correct.cpu(), detects[:, 4].cpu(), detects[:, 5].cpu(), tcls))

        C_M.print()

        # plot_dir = "/home/server/xcg/SwinT_detectron2/" + cfg_file.OUTPUT_DIR
        #
        # names = {k: v for k, v in enumerate(["fuwo", "cewo", "zhanli"])}
        # stats = [np.concatenate(x, 0) for x in zip(*stats)] # to numpy
        # if len(stats) and stats[0].any():
        # p, r, ap, f1, ap_class = ap_per_class(*stats, plot=True, save_dir=plot_dir, names=names)
        # C_M.plot(save_dir=plot_dir+ 'confusion_matrix_rec.png',names=["fuwo","cewo","zhanli"], rec_or_pred=0)
        # C_M.plot(save_dir=plot_dir+ 'confusion_matrix_pred.png',names=["fuwo", "cewo", "zhanli"], rec_or_pred=1)
