Quickly build a real-time face mask detection system in five minutes (opencv+paddlehub with source code)

Reading guide

This article mainly introduces how to use OpenCV and PaddleHub Realize a real-time face mask detection system .（ official account ：OpenCV And AI Deep learning ）

Background introduction

     from 19 The epidemic broke out in and now , It is normal for everyone to wear masks . There are many related applications , Such as virus development prediction 、 Mask wearing detection and face recognition with mask .

     The face mask wearing detection system introduced today mainly uses OpenCV And Baidu feijiang (PaddlePaddle) Of PaddleHub Detection model provided .PaddleHub It provides many practical models , Including image processing 、 word processing 、 Audio processing 、 Video processing and industrial applications .github Address ：https://github.com/PaddlePaddle/PaddleHub

Face mask detection

    The model of face detection part is as follows ：

     The two models in the red box support face mask detection , Choose here pyramidbox_lite_server_mask, Detailed implementation steps ：

【1】 install PaddlePaddle、PaddleHub and OpenCV(opencv-python)

pip install paddlepaddle -i https://pypi.tuna.tsinghua.edu.cn/simple  --trusted-host https://pypi.tuna.tsinghua.edu.cn

pip install paddlehub -i https://pypi.tuna.tsinghua.edu.cn/simple  --trusted-host https://pypi.tuna.tsinghua.edu.cn

pip install opencv-python -i https://pypi.tuna.tsinghua.edu.cn/simple  --trusted-host https://pypi.tuna.tsinghua.edu.cn

     Version used in this article ：

    PaddlePaddle---2.3.0

    PaddleHun---2.2.0

    opencv-python---4.6.0.66

     Be careful ： install PaddlePaddle There may be some problems , Lead to import paddle Failure , You can search for solutions according to the error information .

【2】 Picture face mask detection

     Prepare the map to be measured , Run the following code , Modify the image path ：

import paddlehub as hub
import cv2

mask_detector = hub.Module(name="pyramidbox_lite_server_mask")
img_path = './imgs/A0.png'
img = cv2.imread(img_path)

input_dict = {"data": [img]}
result = mask_detector.face_detection(data=input_dict)

count = len(result[0]['data'])
if count < 1:
  print('There is no face detected!')
else:
  for i in range(0,count):

    #print(result[0]['data'][i])
    label = result[0]['data'][i].get('label')
    score = float(result[0]['data'][i].get('confidence'))
    x1 = int(result[0]['data'][i].get('left'))
    y1 = int(result[0]['data'][i].get('top'))
    x2 = int(result[0]['data'][i].get('right'))
    y2 = int(result[0]['data'][i].get('bottom'))
    cv2.rectangle(img,(x1,y1),(x2,y2),(255,200,0),2)
    if label == 'NO MASK':
      cv2.putText(img,label,(x1,y1),0,0.8,(0,0,255),2)
    else:
      cv2.putText(img,label,(x1,y1),0,0.8,(0,255,0),2)

cv2.imwrite('result.jpg',img)
cv2.imshow('mask-detection', img)
cv2.waitKey()
cv2.destroyAllWindows()
print('Done!')



  The first time the code starts, the corresponding model will be downloaded to the following location ：

    C:\Users\xxx\.paddlehub\modules, No more downloads in the future

Test chart 1：

Running results ：

Test chart 2：

Running results ：

Test chart 3：

Running results ：

Test chart 4：

Running results ：

     From the above test results , It's not bad ！

【3】 Video or camera real-time face mask detection

     Prepare to test the video or directly open the camera to detect , Select the corresponding code ：

cap = cv2.VideoCapture('2.mp4') # Video file detection # cap = cv2.VideoCapture(0) # Camera detection

  Complete code ：

import paddlehub as hub
import cv2

mask_detector = hub.Module(name="pyramidbox_lite_server_mask")

def mask_detecion(img):
  input_dict = {"data": [img]}
  result = mask_detector.face_detection(data=input_dict)
  count = len(result[0]['data'])
  if count < 1:
    #print('There is no face detected!')
    pass
  else:
    for i in range(0,count):
      #print(result[0]['data'][i])
      label = result[0]['data'][i].get('label')
      score = float(result[0]['data'][i].get('confidence'))
      x1 = int(result[0]['data'][i].get('left'))
      y1 = int(result[0]['data'][i].get('top'))
      x2 = int(result[0]['data'][i].get('right'))
      y2 = int(result[0]['data'][i].get('bottom'))
      cv2.rectangle(img,(x1,y1),(x2,y2),(255,200,0),2)
      if label == 'NO MASK':
        cv2.putText(img,label,(x1,y1),0,0.8,(0,0,255),2)
      else:
        cv2.putText(img,label,(x1,y1),0,0.8,(0,255,0),2)
  return img


if __name__ == '__main__':
  cap = cv2.VideoCapture('2.mp4') # Video file detection
  #cap = cv2.VideoCapture(0) # Camera detection
  if(cap.isOpened()): # Video opened successfully
    while(True):
      ret,frame = cap.read()# Read a frame
      result = mask_detecion(frame)
      cv2.imshow('mask_detection',result)
      if cv2.waitKey(1)&0xFF ==27: # Press down Esc Key to exit
        break
  else:
    print ('open video/camera failed!')
  cap.release()
  cv2.destroyAllWindows()

    test result ：
