【 Regular expression series 】 Greedy and non greedy patterns

Preface

This paper belongs to One of the regular expression series , For more, please go to Regular expression series

Greedy patterns and non greedy patterns are important characteristics of regular matching In understanding the difference between greed and non greed , According to the example , Step by step

The outline

• Introduction to matching rules
• A quick understanding of greedy and non greedy patterns
• Practice with examples
• Backtracking phenomenon and matching failure

Introduction to matching rules

var str='aabcab';
var reg=/ab/;
var res=str.match(reg);

// ab index  by  1
console.log(res);

To quickly understand regular matching rules , Try to understand the above example first

The matching step is like this :

• initial index=0, Match to character a
• Next, match the next character a, But because of aa and /ab/ Mismatch , So this match failed
• index Move to the next , from 1 Start , It's a rematch a
• Next, match the next character b, Just in time with /ab/ matching , Therefore, the match was successful , Back to ab,index=1
• If the regular match is followed by g This keyword , Will continue to start the next group of matching ( But in this case there is no g, So there is only one set of results )

The main points of

• The first match has the highest priority

A detailed explanation of this point is : For example, the first matching character is a, Assume that there is no matching failure in the subsequent matching . Then it will always match , Until the match is complete , in other words index=0 It won't change , Until the match is complete ( If a match fails and cannot be traced ,index Will continue to move down )

This applies to the following greedy and non greedy modes ( And the priority is higher than them ), So remember

A quick understanding of greedy and non greedy patterns

Greedy match pattern

Definition

Regular expressions to match , Will match as many qualified content as possible

identifier

+`,`?`,`*`,`{n}`,`{n,}`,`{n,m}

When the match , If the above identifier is encountered , Represents greedy matching , Will match as much content as possible

Example

var str='aacbacbc';
var reg=/a.*b/;
var res=str.match(reg);

// aacbacb index by 0
console.log(res);

In the above example , Match to first a after , Begin to match .*, Because it's the greedy model , It will always match back , Until the last one that meets the conditions b until , So the matching result is aacbacb

Example 2

var str='aacbacbc';
var reg=/ac.*b/;
var res=str.match(reg);

// acbacb index by 1
console.log(res);

The first match is a, Then match the next character a when , And regular do not match , So the match failed ,index Move to 1, Then the match was successful ac, Continue to match , Because it's the greedy model , Match as many results as possible , Until the last one that meets the requirements b until , So the matching result is acbacb

Non greedy matching pattern

Definition

Regular expressions to match , Will try to match as few qualified content as possible in other words , Once a match is found to meet the requirements , Match immediately , Instead of continuing to match ( Unless there is g, Open the next set of matching )

identifier

+?`,`??`,`*?`,`{n}?`,`{n,}?`,`{n,m}?

You can see , The identifiers of non greedy patterns are very regular , Is to add a after the identifier of greedy mode ?

Example

var str='aacbacbc';
var reg=/a.*?b/;
var res=str.match(reg);

// aacb index by 0
console.log(res);

In the above example , Match to first a after , Begin to match .*?, Because of the non greedy model , It matches the first one b after , It's a match , So the matching result is aacb

Why aacb instead of acb Well ？ Because I mentioned a priority rule that is being matched : The first match has the highest priority first a It's a match , As long as there is no matching failure , It will always match , Until the match is successful

Example 2

var str='aacbacbc';
var reg=/ac.*?b/;
var res=str.match(reg);

// acb index by 1
console.log(res);

Match first a, Next, match the second a when , The match failed index Turn into 1, Continue matching ac success , Continue matching b, Because of the non greedy model , here acb The minimum requirements for regularity have been met , So the match was successful , The result is acb

Example 3

var str='aacbacbc';
var reg=/a.*?/;
var res=str.match(reg);

// a index by 0
console.log(res);

var reg2=/a.*/;
var res2=str.match(reg2);

// aacbacbc index by 0
console.log(res2);

This example is an example of 1 A supplement to , You can find , When there is no b when , Because of the non greedy model , Match to first a The direct matching is successful The latter greedy pattern will match all

Practice with examples

After a preliminary understanding of greedy mode and non greedy mode , You can deepen your understanding through practice

extract HTML Medium Div label

Give a HTML character string , as follows

 Other elements
<div><span> user :<span/><span> Zhang San <span/></div>
<div><span> password :<span/><span>123456<span/></div>
 Other elements

demand : Extract div The contents of the package ( Include div The label itself ), And store each result in an array

Code : This is accomplished by global matching of non greedy patterns , as follows

var reg=/<div>.*?<\/div>/g;
var res=str.match(reg);

// ["<div><span> user :<span/><span> Zhang San <span/></div>", "<div><span> password :<span/><span>123456<span/></div>"]
console.log(res);

Detailed explanation : Two knowledge points are used ,.*? Non greedy pattern matching and g The global matching

• .*?<\/div> Means only one match at a time div, This ensures that every div Will not cross the border
• final g Represents global matching , That is, after the first match is successful , Will put the matching results into the array , Then from the next index Start matching new results again

in addition : Suppose you use /<div>.*<\/div>/g Match greedy patterns , The result is

["<div><span> user :<span/><span> Zhang San <span/></div><div><span> password :<span/><span>123456<span/></div>"]

Because the greedy pattern matches the first one <div> Then it will match the following characters greedily , Until the last one who meets the conditions </div> until , This leads to the transfer of all div The labels are all matched together

Take two "" The substring in , It can no longer contain ""

The example is quoted from : Regular expressions Detailed explanation of greedy and non greedy patterns

"The phrase \"regular expression\" is called \"Regex\" for short"

demand : Extract substring between two quotation marks , You can no longer include quotation marks , For example, the above extraction result should be : "regular expression" And "Regex"( Every end of " Followed by a space )

Wrong solution : Through the following non greedy matching ( Please note the space )

var str='"The phrase \"regular expression\" is called \"Regex\" for short"';
var reg=/".*?" /g;
var res=str.match(reg);

// ['"The phrase "regular expression"  ', '"Regex"  ']
console.log(res);

You can see , The above match is exactly the wrong match , This regular matches to the first one that meets the condition "+ Space Then it stops automatically

The correct solution : Use greedy patterns for matching

var reg=/"[^"]*" /g;
var res=str.match(reg);

// ['"regular expression" ', '"Regex" ']
console.log(res);

In this match

• From the first " Begin to match , Next to the 12 When a ("r Of "), dissatisfaction [^"], Not satisfied with the future "+ Space , So the match failed ,index Move to the next , Start the next match
• The second match is from "r Of " Start , All the way to n" Space Of Space , This group just matched successfully ( Because it finally conforms to the regular " Space ), It's a good match "regular expression" Space
• The third match matches "Regex" Space ( The process will not be repeated )
• To the end , There's only one left " Direct matching failed ( Because first of all, it must conform to " Can begin to struggle to match )
• thus , Regular matching ends , The match is successful , And in line with expectations

Last : This example is relatively complicated , For better understanding , You can refer to the article in the quotation source , There is an introduction to the principle in addition , There is also a failure to match non greedy patterns in the reference article , Backtrack the characteristics that affect performance, etc. to analyze and explain the principle

Backtracking phenomenon and matching failure

Have you really understood the greedy model and the non greedy model ？

Backtracking phenomenon

I don't know about the last example mentioned above to flash back Does this word have a concept ？ The above example still refers to the example in the source for analysis

Original string

"Regex"

Greedy matching process analysis

".*"

• first " Take control , Match regular ", The match is successful , Control to .*
• .* After taking control , Match the next characters ,. Represents matching any character ,* Means matching or not , This is the identifier of greedy mode , Will try to match first , So next from 1 In position R Begin to match , Successfully matched in turn R,e,g,e,x, Then continue to match the last character ", The match is successful , At this point, the match has reached the end of the string , therefore .* Match over , Give the controller to the last in the regular expression "
• " After taking control , Because it has reached the end of the string , So the match failed , Look forward to the status available for backtracking , Control to .*,.* Give up a character ", And give control to ", At this point, the matching is successful
• thus , The entire regular expression is matched , The matching result is "Regex", The matching process is traced back to 1 Time

Non greedy matching expression

".*?"

• first " Take control , Match regular ", The match is successful , Control to .*?
• .*? After taking control , Because this is an identifier in non greedy mode , Therefore, in the case of matching and mismatching, the priority will be mismatching , So try not to match anything , Hand over control ", here index stay 1 It's about (R At the end of the character )
• " After taking control , Begin to match 1 Situated R, Matching failure , Look forward to the status available for backtracking , Control to .*?,.*? Eat one character ,index here we are 2 It's about , And give control to "
• " After taking control , Begin to match 2 Situated e, Matching failure , Repeat the above backtracking process , until .*? Eat into x character , And then give control to ”
• " After taking control , Begin to match 6 Situated ", The match is successful
• thus , The entire regular expression is matched , The matching result is ”Regex”, The matching process is traced back to 5 Time

Optimize the removal of backtracking

In the above greedy matching , There is a backtracking phenomenon , In fact, you can also prevent backtracking by optimizing expressions , such as

"[^"]*"

In this expression, a sub expression is constructed -[] Medium ^", Its function is to exclude " matching , such * The greedy match will not take the initiative to eat ", In the end, it will be " matching ", The match is successful , No backtracking

summary

From the above analysis, it can be seen that , In the case of a successful match , The greedy model has less backtracking ( It can be verified by more experiments ), Therefore, in application , In the case of not being very proficient in regularity , The matching of greedy patterns can be given priority , This can avoid many performance problems

Match the failure case

The above retrospective analysis is based on the success of matching , What if the match fails ？

var str = '"Regex'
var reg = /"[^"]*"/g;

In this original character , No best ", So matching will fail , Its process is roughly as follows

• " matching ", next [] Of ^" And * matching R,e,g,e,x
• Then at the end ," Take control , Because in the end , Start backtracking
• The result of successive backtracking is * Give up x,e,g,e,R, until * Can no longer yield characters , The first round of matching failed
• next index Start moving down , In turn " matching R,e,g,e,x They all failed , There was no match until the end , Therefore, the regular expression matching failed this time , There is no match for the result ( Or return null)

What about the non greedy model ？

/"[^"]*?"/g

• " matching ", next * Try not to match ," matching R, Failure , Then go back ,* buy in R
• The next step is similar to the previous step ,* Go back and eat in turn e,g,e,x, All the way to the end ,* Look back again when you want to eat , We have reached the end of the string , Unable to continue , So the first round of matching failed
• next index Start moving down , In turn " matching R,e,g,e,x They all failed , return null

summary

Through the example of matching failure, we can see the difference between greedy and non greedy patterns . Greed is Eat first , Go back and give up , Non greed is Ignore first , Go back and eat

and , In case of a match failure , Greedy mode also has a lot of backtracking ( Of course, non greed has always been a lot of backtracking )

however , In practice, it can be optimized by sub expression , For example, build ^xxx, The matching can fail in advance when the matching fails to meet the conditions , So there will be less backtracking

var str = '"cccccc'
var reg = /"[^"c]*"/g;

This directly excludes c, therefore * I won't eat it , The match failed directly , A lot of backtracking is reduced ( Of course , The above is just the simplest example , The actual situation is more complicated )

Write it at the end

Regular matching , Greedy mode and non greedy mode can be seen at first glance , It's easy to understand , But a real in-depth understanding requires mastering the principles of regularity , also , When you really understand them , It's not just about writing regular expressions , It's a high-performance regular expression , For example, it is easier to write high-performance expressions after understanding the backtracking feature in non greedy patterns
