User login 【 I 】

Login process analysis

Interface and logic simplification

template modify

• Modify the title <h3 class="title"> Xiao Mu reads </h3>
• Delete prompt area <div style="position:relative">...</div>
• modify input Of placeholder In Chinese , modify el-button The Chinese characters are Chinese
• Delete el-dialog Code

script modify

• Delete SocialSign Reference and registration of , Delete login Component's components Folder
• Delete showDialog Variable
• modify data The form verification text in is Chinese
• Delete created and destroyed Hook functions and annotated afterQRScan Code

Webstorm During the development process, you may encounter script Tag source code eslint About indent The error of , The solution is as follows ：ctrl + alt + L After formatting the code ,script There may be indent Warning of , There are two solutions ：

• close eslint Medium indent Check

• modify Webstorm in indent Set up

  Webstorm => Preferences => Editor => Code Style => HTML => Other

  stay do not indent of children add script that will do

VSCode Inside prettier The plug-in format does not exist. This problem can be ignored

Routing instance processing

Start modifying file ：

1. Create components src/views/book/create.vue , Write something casually

2. Configure the routing , modify src/router/index.js Of asyncRoutes：

   children Your route needs to have name attribute , Yes name Attribute will be in tags-view Show it in

   meta Properties in

   • roles Set the permission of this route , Multiple permissions are supported
   • title Set the route in the sidebar and breadcrumb display text
   • icon Corresponding src/icons/svg, Also support element-ui Of icon

   For other configuration items, please refer to ：vue-element-admin Routing and sidebar Configuration item

   export const asyncRoutes = [
     {

       path: '/book',
       component: Layout,
       redirect: '/book/create',
       meta: {
          title: ' Book management ', icon: 'documentation', roles: ['admin'] },
       children: [
         {

           path: '/book/create',
           component: () => import('@/views/book/create'),
           name: 'book',
           meta: {
          title: ' Upload books ', icon: 'edit', roles: ['admin'] }
         }
       ]
     },
     // 404 page must be placed at the end !!!
     {
          path: '*', redirect: '/404', hidden: true }
   ]


Preliminary knowledge

Routing and permission verification

The analysis of the middle and background routes is as follows ：

• Obtained Token：
  • visit /login ： Redirect to /
  • visit /login?redirect=/xxx ： Redirect to /xxx
  • visit /login Other routes ： Direct access /xxx
• Not obtained Token：
  • visit /login ： Direct access /login
  • visit /login Other routes ： Such as visit /dashboard, The actual access path is /login?redirect=%2Fdashboard , After logging in, you will be redirected directly /dashboard

Routing logic source code

1. main.js Global routing guard is loaded in

   import './permission'


2. permission Global routing guard is defined

   //  White list
   const whiteList = ['/login', '/auth-redirect']

   router.beforeEach(async(to, from, next) => {

     //  Start progress bar
     NProgress.start()

     //  Modify page title
     document.title = getPageTitle(to.meta.title)

     //  from  Cookie  obtain  Token
     const hasToken = getToken()

     //  Judge  Token  Whether there is
     if (hasToken) {

       //  If the current path is  login  Direct redirection to the home page
       if (to.path === '/login') {

         next({
          path: '/' })
         NProgress.done()
       } else {

         //  Determine whether the user's role exists
         const hasRoles = store.getters.roles && store.getters.roles.length > 0
         //  If the user role exists , Direct access to
         if (hasRoles) {

           next()
         } else {

           try {

             //  Get the user's role asynchronously
             const {
          roles } = await store.dispatch('user/getInfo')
             //  According to the user role , Dynamically generate routing
             const accessRoutes = await store.dispatch('permission/generateRoutes', roles)
             //  call  router.addRoutes  Dynamic add route
             router.addRoutes(accessRoutes)
             //  Use  replace  Access routing , Not in  history  Leave a record in the book
             next({
          ...to, replace: true })
           } catch (error) {

             //  remove  Token  data
             await store.dispatch('user/resetToken')
             //  Display error message
             Message.error(error || 'Has Error')
             //  Redirect to login page
             next(`/login?redirect=${
           to.path}`)
             NProgress.done()
           }
         }
       }
     } else {

       //  If you visit  URL  On the white list , Direct access to
       if (whiteList.indexOf(to.path) !== -1) {

         next()
       } else {

         //  If you visit  URL  Not on the white list , Redirect directly to the login page , And will visit  URL  Add to  redirect  Parameters in
         next(`/login?redirect=${
           to.path}`)
         NProgress.done()
       }
     }
   })

   router.afterEach(() => {

     //  Stop progress bar
     NProgress.done()
   })


NProgress

//  Start progress bar
NProgress.start()
//  End progress bar
NProgress.done()
//  Controls whether the circular progress bar on the right displays
NProgress.configure({
     showSpinner: false })

Error in dynamically generating route or getting route

1. Distribution execution store.dispatch('user/resetToken'), eliminate Token 、 Reset roles
2. Display error message Message.error(error || 'Has Error')
3. Redirect to landing page next('/login?redirect=${to.path}'), Then end the progress bar

const actions = {

  resetToken({
      commit }) {

    return new Promise(resolve => {

      commit('SET_TOKEN', '')
      commit('SET_ROLES', [])
      removeToken()
      resolve()
    })
  },
}

const TokenKey = 'Admin-Token'
export function removeToken() {

  return Cookies.remove(TokenKey)
}

Dynamic routing analysis

There are two kinds of routes here ：

• constantRoutes： Represents routes that do not require dynamic judgment permission , Like landing page 、404、 And other common pages
• asyncRoutes： On behalf of those requirements, dynamically judge permissions and pass addRoutes Dynamically added pages

When a user logs in to the system , Routes will be generated dynamically , among constantRoutes Inevitable inclusion ,asyncRoutes It will be filtered

asyncRoutes The logic of filtering is to see whether the route contains meta and meta.roles attribute

• If this property is not available , Is a general routing , Permission verification is not required

• If you include roles attribute , It will determine whether the user's role has hit any permission in the route

  If hit , Save the route

  If you miss , Then directly discard the route

asyncRoutes After processing , Hui He constantRoutes Merge into a new routing object , And save to vuex Of permission/routes in

• After the user logs in to the system , The sidebar will start from vuex In order to get state.permission.routes , Dynamically render the user menu according to the route

Get user rights , Generate dynamic routing

const {
     roles } = await store.dispatch('user/getInfo')
const accessRoutes = await store.dispatch('permission/generateRoutes', roles)

The source code for generating dynamic routing is located in src/store/modules/permission.js Medium generateRoutes Method

import {
     asyncRoutes, constantRoutes } from '@/router'

const actions = {

  generateRoutes({
      commit }, roles) {

    //  return  Promise  object
    return new Promise(resolve => {

      let accessedRoutes
      if (roles.includes('admin')) {

        //  If the role contains  admin, Skip judgment directly , Direct will  asyncRoutes  All return
        accessedRoutes = asyncRoutes || []
      } else {

        //  If the role does not contain  admin, Call  filterAsyncRoutes  Filter routes
        accessedRoutes = filterAsyncRoutes(asyncRoutes, roles)
      }
      //  Save route to  vuex  in
      commit('SET_ROUTES', accessedRoutes)
      resolve(accessedRoutes)
    })
  }
}

commit('SET_ROUTES', accessedRoutes) Save the route in store in

const state = {

  routes: [],
  addRoutes: []
}
const mutations = {

  SET_ROUTES: (state, routes) => {

    state.addRoutes = routes
    state.routes = constantRoutes.concat(routes)
  }
}

If the role is not admin, It will call filterAsyncRoutes Method ：

export function filterAsyncRoutes(routes, roles) {

  const res = []

  //  Traverse all routes
  routes.forEach(route => {

    //  Make a shallow copy of the route , Be careful  children  No copying , Because there's no need to be right about  children  Judge , So you can use a shallow copy
    const tmp = {
     ...route }
    //  Check whether the user has access to the route
    if (hasPermission(roles, tmp)) {

      //  When the route has access , Determine whether the route has  children  attribute
      if (tmp.children) {

        //  When the route contains  children  when , Yes  children  Iterative call  filterAsyncRoutes  Method
        tmp.children = filterAsyncRoutes(tmp.children, roles)
      }
      //  When the route has access , take  temp  Save to  res  in
      res.push(tmp)
    }
  })

  return res
}

Check permission method hasPermission Source code is as follows ：

function hasPermission(roles, route) {

  //  Check whether the route contains  meta  and  meta.roles  attribute
  if (route.meta && route.meta.roles) {

    //  Judge  route.meta.roles  Whether user roles are included in the  roles  Any one of the permissions in
    return roles.some(role => route.meta.roles.includes(role))
  } else {

    //  If the route does not  meta  or  meta.roles  attribute , It is deemed that the route does not need permission control （ All users have access to this route ）
    return true
  }
}

Sidebar

• sidebar Quote from layout Components , Component is located src/layout/index.vue
• sidebar The component source code is located in src/layout/components/Sidebar/index.vue

el-menu Usage analysis

<template>
  <el-row class="tac">
    <el-col :span="12">
      <el-menu default-active="1-1" background-color="#545c64" text-color="#fff" active-text-color="#ffd04b" mode="vertical" unique-opened :collapse="isCollapse" :collapse-transition="false" class="el-menu-vertical-demo" @open="handleOpen" @close="handleClose" @select="handleSelect" >
        <el-submenu index="1">
          <template slot="title">
            <i class="el-icon-location"></i>
            <span> Navigation one </span>
          </template>
          <el-menu-item-group>
            <template slot="title"> Group one </template>
            <el-menu-item index="1-1"> Options 1</el-menu-item>
            <el-menu-item index="1-2"> Options 2</el-menu-item>
          </el-menu-item-group>
          <el-menu-item-group title=" grouping 2">
            <el-menu-item index="1-3"> Options 3</el-menu-item>
          </el-menu-item-group>
          <el-submenu index="1-4">
            <template slot="title"> Options 4</template>
            <el-menu-item index="1-4-1"> Options 1</el-menu-item>
          </el-submenu>
        </el-submenu>
        <el-submenu index="2">
          <template slot="title">
            <i class="el-icon-menu"></i>
            <span slot="title"> Navigation two </span>
          </template>
          <el-menu-item index="2-1"> Options 2-1</el-menu-item>
        </el-submenu>
        <el-menu-item index="3" disabled>
          <i class="el-icon-document"></i>
          <span slot="title"> Navigation three </span>
        </el-menu-item>
        <el-menu-item index="4">
          <i class="el-icon-setting"></i>
          <span slot="title"> Navigation four </span>
        </el-menu-item>
      </el-menu>
    </el-col>
    <el-col>
      <el-button @click="isCollapse = !isCollapse"> Fold </el-button>
    </el-col>
  </el-row>
</template>

<script> export default {
       data() {
       return {
       isCollapse: false } }, methods: {
       handleSelect(index, indexPath) {
       console.log('handleSelect', index, indexPath) }, handleOpen(index, indexPath) {
       console.log('handleOpen', index, indexPath) }, handleClose(index, indexPath) {
       console.log('handleClose', index, indexPath) } } } </script>

el-menu Represents the menu container component ：

• default-active： Current active menu index, Be careful ： If there is a submenu , You need to fill in the submenu ID

• unique-opened： Whether to keep only one submenu expanded

• collapse： Is the menu folded up horizontally （ Only in mode by vertical You can use ）

  It can be used in combination with buttons , Click to collapse and click to expand

• collapse-transition： Whether to display the collapse animation

• @select： Click menu event . Callback function ：index： Select... Of the menu item index;indexPath： Select... Of the menu item index path, You can get 1-4-1 Of all the parent menus of the menu ID

  handleSelect 1-4-1 ['1', '1-4', '1-4-1']


• @open： The event is triggered when the parent menu is opened

• @close： The event is triggered when the parent menu is closed

el-submenu Represents the submenu container ：el-submenu And el-menu Different ,el-menu Represents the entire menu , and el-submenu Represents a specific menu ,el-submenu It can be customized slot Of title Customize menu styles ：

<el-submenu index="1">
  <template slot="title">
    <i class="el-icon-location"></i>
    <span> Navigation one </span>
  </template>
</el-submenu>

el-submenu In container default Of slot Used to store submenus , It can contain three submenu components ：

• el-menu-item-group： Menu grouping , Add a title to a group of menus ,el-menu-item-group The contents of the container need to be stored el-menu-item Components , Support title Of slot To customize the title style
• el-submenu：el-submenu Support circular nesting el-submenu, This enables more than two levels of subcomponents to be implemented
• el-menu-item： Submenu component

sidebar Source code analysis

• src/layout/components/Sidebar/index.vue

<template>
  <div :class="{
     'has-logo':showLogo}">
    <logo v-if="showLogo" :collapse="isCollapse" />
    <el-scrollbar wrap-class="scrollbar-wrapper">
      <el-menu :default-active="activeMenu" :collapse="isCollapse" :background-color="variables.menuBg" :text-color="variables.menuText" :unique-opened="false" :active-text-color="variables.menuActiveText" :collapse-transition="false" mode="vertical" >
        <sidebar-item v-for="route in permission_routes" :key="route.path" :item="route" :base-path="route.path" />
      </el-menu>
    </el-scrollbar>
  </div>
</template>

<script> import {
       mapGetters } from 'vuex' import Logo from './Logo' import SidebarItem from './SidebarItem' import variables from '@/styles/variables.scss' export default {
       components: {
       SidebarItem, Logo }, computed: {
       ...mapGetters([ 'permission_routes', 'sidebar' ]), activeMenu() {
       const route = this.$route const {
       meta, path } = route if (meta.activeMenu) {
       return meta.activeMenu } return path }, showLogo() {
       return this.$store.state.settings.sidebarLogo }, variables() {
       return variables }, isCollapse() {
       return !this.sidebar.opened } } } const state = {
       sidebar: {
       opened: Cookies.get('sidebarStatus') ? !!+Cookies.get('sidebarStatus') : true } } </script>

• :default-active="activeMenu"： adopt meta.activeMenu attribute , Specify the highlighted menu corresponding to the route

  meta.activeMenu You need to provide a legal route , Otherwise, it will not take effect

• :collapse="isCollapse"：NavBar Click the button in , Will modify Cookie Medium sidebarStatus, from vuex When the value is taken, the sidebarStatus To Boolean, And determine whether the left menu bar needs to be shrunk by default

• v-if="showLogo"： Judge settings.js Whether the configuration items in need to be displayed Logo

• text-color="variables.menuText"： from @/styles/variables.scss In order to get scss object , To get the style

sidebar Pass through v-for Loop traversal sidebar-item Implement submenu ：

<sidebar-item v-for="route in permission_routes" :key="route.path" :item="route" :base-path="route.path" />

sidebar-item Source code analysis

• src/layout/components/Sidebar/SidebarItem.vue

Be careful ： Components can call their own... In their own templates , But you need to give this component name attribute , Will report a mistake For recursive components, make sure to provide the "name" option.

<template>
  <div v-if="!item.hidden">
    <template v-if="hasOneShowingChild(item.children,item) && (!onlyOneChild.children||onlyOneChild.noShowingChildren)&&!item.alwaysShow">
      <app-link v-if="onlyOneChild.meta" :to="resolvePath(onlyOneChild.path)">
        <el-menu-item :index="resolvePath(onlyOneChild.path)" :class="{
     'submenu-title-noDropdown':!isNest}">
          <item :icon="onlyOneChild.meta.icon||(item.meta&&item.meta.icon)" :title="onlyOneChild.meta.title" />
        </el-menu-item>
      </app-link>
    </template>

    <el-submenu v-else ref="subMenu" :index="resolvePath(item.path)" popper-append-to-body>
      <template slot="title">
        <item v-if="item.meta" :icon="item.meta && item.meta.icon" :title="item.meta.title" />
      </template>
      <sidebar-item v-for="child in item.children" :key="child.path" :is-nest="true" :item="child" :base-path="resolvePath(child.path)" class="nest-menu" />
    </el-submenu>
  </div>
</template>

<script> import path from 'path' import {
       isExternal } from '@/utils/validate' import Item from './Item' import AppLink from './Link' import FixiOSBug from './FixiOSBug' export default {
       name: 'SidebarItem', components: {
       Item, AppLink }, mixins: [FixiOSBug], props: {
       // route object item: {
       type: Object, required: true }, isNest: {
       type: Boolean, default: false }, basePath: {
       type: String, default: '' } }, data() {
       // To fix https://github.com/PanJiaChen/vue-admin-template/issues/237 // TODO: refactor with render function this.onlyOneChild = null return {
      } }, methods: {
       hasOneShowingChild(children = [], parent) {
       const showingChildren = children.filter(item => {
       if (item.hidden) {
       return false } else {
       // Temp set(will be used if only has one showing child) this.onlyOneChild = item return true } }) // When there is only one child router, the child router is displayed by default if (showingChildren.length === 1) {
       return true } // Show parent if there are no child router to display if (showingChildren.length === 0) {
       this.onlyOneChild = {
       ... parent, path: '', noShowingChildren: true } return true } return false }, resolvePath(routePath) {
       if (isExternal(routePath)) {
       return routePath } if (isExternal(this.basePath)) {
       return this.basePath } return path.resolve(this.basePath, routePath) } } } </script>

sidebar-item Of props as follows ：

• item： Routing objects
• basePath： Routing path

sidebar-item Show logical analysis ：

• adopt item.hidden Control whether the menu is displayed



• adopt hasOneShowingChild(item.children,item) && (!onlyOneChild.children||onlyOneChild.noShowingChildren)&&!item.always Show logic template Whether the menu is displayed ,template Represents a single menu

  • hasOneShowingChild： Determine whether there is only one sub route to be displayed
  • !onlyOneChild.children||onlyOneChild.noShowingChildren ： Determine the submenu to be displayed , Does it include children attribute , If you include , It means that there may be sub menus in the sub menu , At this point, we need to judge again noShowingChildren attribute
  • !item.alwaysShow ： Determine whether there is... In the route alwaysShow attribute , If there is , Then return to false, Don't show template menu , That is to say, as long as you configure alwaysShow Attributes will go directly to el-submenu Components

hasOneShowingChild Method source code details ：

• children ：router Object's children attribute
• item ：router object

hasOneShowingChild(children = [], parent) {

  const showingChildren = children.filter(item => {

    //  If  children  The route in contains  hidden  attribute , Then return to  false
    if (item.hidden) {

      return false
    } else {

      //  Assign a sub route to  onlyOneChild, Used to display when only one route is included
      this.onlyOneChild = item
      return true
    }
  })

  //  If after filtering , Show only one route , Then return to  true
  if (showingChildren.length === 1) {

    return true
  }

  //  If there are no sub routes to show , Will  onlyOneChild  Of  path  Set an empty route , And add  noShowingChildren  attribute , Indicates that although there are sub routes , But there is no need to show the sub route
  if (showingChildren.length === 0) {

    this.onlyOneChild = {
     ...parent, path: '', noShowingChildren: true }
    return true
  }

  //  return  false, It means that there is no need to show sub routes , Or more than one sub route to be shown
  return false
}

If displayed template Components , First, we will show app-link Components , And then there was el-menu-item, The innermost nest is item Components

item Components need to be routed meta Contained in the title and icon attribute , Otherwise, the content will be rendered as empty vnode object

<app-link v-if="onlyOneChild.meta" :to="resolvePath(onlyOneChild.path)">
  <el-menu-item :index="resolvePath(onlyOneChild.path)" :class="{
     'submenu-title-noDropdown':!isNest}">
    <item :icon="onlyOneChild.meta.icon||(item.meta&&item.meta.icon)" :title="onlyOneChild.meta.title" />
  </el-menu-item>
</app-link>

If template The menu does not show , Show el-submenu menu ,el-submenu Nested components are used in logic , take sidebar-item Nested in el-submenu in ：

<el-submenu v-else ref="subMenu" :index="resolvePath(item.path)" popper-append-to-body>
  <template slot="title">
    <item v-if="item.meta" :icon="item.meta && item.meta.icon" :title="item.meta.title" />
  </template>
  <sidebar-item v-for="child in item.children" :key="child.path" :is-nest="true" :item="child" :base-path="resolvePath(child.path)" class="nest-menu" />
</el-submenu>

app-link Source code analysis

app-link Is a dynamic component , Through analysis to Parameters , If you include http The prefix becomes a a label , Otherwise it will become a router-link Components

• component Is a built-in component

  props：is、inline-template

  effect ： according to is, To decide which component is rendered

<template>
  <component :is="type" v-bind="linkProps(to)">
    <slot />
  </component>
</template>

<script> import {
       isExternal } from '@/utils/validate' export default {
       props: {
       to: {
       type: String, required: true } }, computed: {
       isExternal() {
       return isExternal(this.to) }, type() {
       if (this.isExternal) {
       return 'a' } return 'router-link' } }, methods: {
       linkProps(to) {
       if (this.isExternal) {
       return {
       href: to, target: '_blank', rel: 'noopener' } } return {
       to: to } } } } </script>

isExternal Function is matched by a regular expression http link ：

export function isExternal(path) {

  return /^(https?:|mailto:|tel:)/.test(path)
}

item Source code analysis

item Components are defined by render Function to complete component rendering

• If item Can't get meta Medium icon The parent route will be taken icon

render Function parameter ：

• createElement function ： The return value is a dummy DOM, namely VNode, That is, the rendered node

  createElement There are three parameters ：

  1. To render html label 、 Components ： { String | Object | Function }
  2. html Properties of ：{ Object }
  3. Virtual child nodes VNodes, At present html The child elements of the tag ：{ String | Array }

• context ： It contains props Equal parameter

<script> export default {
       name: 'MenuItem', functional: true, props: {
       icon: {
       type: String, default: '' }, title: {
       type: String, default: '' } }, render(h, context) {
       const {
       icon, title } = context.props const vnodes = [] if (icon) {
       if (icon.includes('el-icon')) {
       vnodes.push(<i class={
      [icon, 'sub-el-icon']} />) } else {
       vnodes.push(<svg-icon icon-class={
      icon}/>) } } if (title) {
       vnodes.push(<span slot='title'>{
      (title)}</span>) } return vnodes } } </script>

summary

sidebar：sidebar It mainly includes el-menu Container assembly ,el-menu Middle traversal vuex Medium routes, Generate sidebar-item Components .sidebar The main configuration items are as follows ：

• activeMenu： According to the current route meta.activeMenu Properties control the highlighted menu in the sidebar
• isCollapse： according to Cookie Of sidebarStatus Controls whether the sidebar is collapsed
• variables： adopt @/styles/variables.scss fill el-menu Basic style of

sidebar-item ： It is mainly divided into two parts ：

• The first part is when only one children Or not children Show when , The components shown include ：
  • app-link： Dynamic components ,path When is a link , Is shown as a label ,path When routing , Is shown as router-link Components
  • el-menu-item： A menu item , When sidebar-item For the wrong nest When the component ,el-menu-item Will increase submenu-title-noDropdown Of class
  • item：el-menu-item Contents of Li , Mainly icon and title, When title Empty is , The entire menu item will not show
• The second part is when children Show when there are more than two items , The components shown include ：
  • el-submenu： Submenu component container , For nested submenu components
  • sidebar-item：el-submenu Iterations nested sidebar-item Components , stay sidebar-item There are two changes in the component ：
    • Set up is-nest The attribute is true
    • according to child.path Generated base-path Property passed in sidebar-item Components

vue elementui navmenu Multi level navigation menu ( level 、 vertical )

Front end development and high-end operation

Type conversion

Fast turn Number

var a = '1'

console.log(typeof a)
console.log(typeof Number(a)) //  Common writing
console.log(typeof +a)        //  High end writing

Fast turn Boolean

var a = 0

console.log(typeof a)
console.log(typeof Boolean(a)) //  Common writing
console.log(typeof !!a)        //  High end writing

Mixed writing

• First to Number, And then to Boolean

var a = '0'

console.log(!!a)  //  Direct transfer will get  true, Fall short of expectations
console.log(!!+a) //  First to  Number  And then to  Boolean, In line with expectations

JS and CSS Dual purpose style

template You need to dynamically define styles in , General practice ：

<template>
  <div :style="{ color: textColor }">Text</div>
</template>

<script> export default {
       data() {
       return {
       textColor: '#ff5000' } } } </script>

Definition SCSS file

$menuActiveText:#409EFF;

:export {
  menuActiveText: $menuActiveText;
}

stay JS I quote ：

• Use import quote SCSS file
• Definition computed take styles Object becomes a responsive object
• stay template Use in syles object

<template>
  <div :style="{ color: styles.menuActiveText }">Text</div>
</template>

<script> import styles from '@/styles/variables.scss' export default {
       computed: {
       styles() {
       return styles } } } </script>

Continuous deconstruction

Extract an attribute from the first object element of the array , such as ：err Object contains a errors Array ,errors Each object of the array contains a msg attribute

err = {

  errors: [
    {

      msg: 'this is a message'
    }
  ]
}

//  The fast extraction method is
const [{
     msg }] = err.errors
//  If you don't use deconstruction, it is written as
const msg = err.errors[0].msg

Redirect

Login redirection

• src/views/login/index.vue Chinese vs $route monitor ：

watch: {

  $route: {

    handler: function(route) {

      const query = route.query
      if (query) {

        this.redirect = query.redirect
        this.otherQuery = this.getOtherQuery(query)
      }
    },
    immediate: true
  }
}

this.getOtherQuery(query) The purpose of is to get the division redirect Query criteria other than , After successful login ：

this.$store
  .dispatch('user/login', this.loginForm)
  .then(() => {

    this.$router.push({

      path: this.redirect || '/',
      query: this.otherQuery
    })
    this.loading = false
  })
  .catch(() => {

    this.loading = false
  })

Complete the redirected code ：

this.$router.push({

  path: this.redirect || '/',
  query: this.otherQuery
})

vue-element-admin Special redirection components are provided , Source code is as follows ：

<script> export default {
       created() {
       const {
       params, query } = this.$route const {
       path } = params this.$router.replace({
       path: '/' + path, query }) }, render: function(h) {
       return h() // avoid warning message } } </script>

Redirection component

The redirection component is configured with dynamic routing ：

• * Indicates that zero or more routes are matched , For example, the route is /redirect when , Can still match redirect Components . If you will * Get rid of

  At this point the route /redirect Will only match to Layout Components , And cannot match redirect Components

{

  path: '/redirect',
  component: Layout,
  hidden: true,
  children: [
    {

      path: '/redirect/:path(.*)',
      component: () => import('@/views/redirect/index')
    }
  ]
},

Breadcrumb navigation

el-breadcrumb-item

• el-breadcrumb： Breadcrumb navigation container ,separator Controls the breadcrumb navigation text divider
• el-breadcrumb-item： Bread crumbs sub project , have access to to Property to switch routes ,slot Can contain a Label to jump to the outer chain

Use to Properties and a The difference between label switching and routing is ：to Attribute switching routing is a dynamic replacement App.vue Routing content in , and a Label switching routes will refresh the page

<el-breadcrumb separator="/">
  <el-breadcrumb-item :to="{ path: '/' }"> home page </el-breadcrumb-item>
  <el-breadcrumb-item><a href="/"> Activity management </a></el-breadcrumb-item>
  <el-breadcrumb-item> Activity list </el-breadcrumb-item>
  <el-breadcrumb-item> Activity details </el-breadcrumb-item>
</el-breadcrumb>

Routing and breadcrumb navigation mapping

Breadcrumb navigation template source code ：

• el-breadcrumb-item I made a judgment , If it is the last element or route redirect Property specified as noRedirect Then no link is generated , Otherwise... Will be used a Tag event triggers , But here we use @click.prevent The default... Is blocked a Tag event triggers , Instead of using custom handleLink Method to handle route jumps

<el-breadcrumb class="app-breadcrumb" separator="/">
  <transition-group name="breadcrumb">
    <el-breadcrumb-item v-for="(item,index) in levelList" :key="item.path">
      <span v-if="item.redirect==='noRedirect'||index==levelList.length-1" class="no-redirect">{
   { item.meta.title }}</span>
      <a v-else @click.prevent="handleLink(item)">{
   { item.meta.title }}</a>
    </el-breadcrumb-item>
  </transition-group>
</el-breadcrumb>

The more important thing is levelList , It's through getBreadcrumb Method generated

The breadcrumb navigation implementation logic is as follows ：

• obtain this.$route.matched, And filter that it does not contain item.meta.title The item , Generate a new breadcrumb navigation array matched
• Judge matched Whether the first item is dashboard, If not , Then add dashboard Navigate the first item for breadcrumbs
• Filter again matched in item.meta.title Empty items and item.meta.breadcrumb by false The item

getBreadcrumb() {

  // only show routes with meta.title
  let matched = this.$route.matched.filter(item => item.meta && item.meta.title)
  const first = matched[0]

  if (!this.isDashboard(first)) {

    matched = [{
     path: '/dashboard', meta: {
     title: 'Dashboard' }}].concat(matched)
  }

  this.levelList = matched.filter(item => item.meta && item.meta.title && item.meta.breadcrumb !== false)
},

isDashboard(route) {

  const name = route && route.name
  if (!name) {

    return false
  }
  return name.trim().toLocaleLowerCase() === 'Dashboard'.toLocaleLowerCase()
},

When the route is switched , Will also call again getBreadcrumb Method generation

watch: {

  $route(route) {

    // if you go to the redirect page, do not update the breadcrumbs
    if (route.path.startsWith('/redirect/')) {

      return
    }
    this.getBreadcrumb()
  }
},

handleLink The source code of the method is as follows ：

• there pathCompile Used to solve the matching problem of dynamic routing

handleLink(item) {

  const {
     redirect, path } = item
  if (redirect) {

    this.$router.push(redirect)
    return
  }
  this.$router.push(this.pathCompile(path))
}

pathCompile(path) {

  // To solve this problem https://github.com/PanJiaChen/vue-element-admin/issues/561
  const {
     params } = this.$route
  var toPath = pathToRegexp.compile(path)
  return toPath(params)
},
