一般运维架构图
2022-06-11 12:05:00 【乌托邦为什么被占用了】
架构图：
整体架构如架构图所示，client端请求通过域名解析访问到服务端负载均衡器slb或者nginx（静态内容存储在阿里云oss并通过cnd加速访问），然后经过安全组过滤，请求最终到达server端，经过业务处理并在阿里云数据库RDS读写数据后返回客户端
