Data storage in memory (C language)

hello, I am a bug. Today, let's learn about How data is stored in memory ：

One 、 data type

One 、 Introduce

Data types can be roughly divided into built-in types and user-defined types , Built in types are divided into three major types ： integer 、 Floating point numbers 、 Pointer types . ️️

Two 、 The meaning of type

1、 Determine the size of the space created with this type of data .
2、 How to look at the perspective of memory space .

Be careful ️ ️

Character types are also a member of the integer family , Because the essence of storing character types is to store their ASCII Code value . ️️

---

Two 、 The storage of integers in memory

Original code 、 Inverse code 、 Complement code

Encoding mode ： Convert data into binary by certain means , And this method is called coding method .

1、 Original code

Because the computer can only recognize 0 and 1, So the stored data can only be stored in binary . Then we have to convert the data into binary form . For positive numbers , Its binary number can be directly converted . So how to realize the binary of negative numbers ？ To represent a negative number , People added a sign bit before binary numbers . This encoding method is called the original code , The appearance of the original code can solve the problem of computer storage , But the question that follows is , How to calculate it ？ The arithmetic logic unit in a computer cannot directly calculate subtraction , To calculate subtraction, we have to convert it into addition . ️️
When we add with the original code , Pictured ️ ️：

There is no problem with the result of the addition calculation , Then let's do the subtraction , Pictured ️ ️：

For subtraction , We must first convert it into an addition operation . When we think about sign bits , The calculation result is obviously wrong ！ Therefore, the original code cannot be used for the data stored by the computer .

---

2、 Inverse code

Because the original code of subtraction is not applicable , People invented the inverse code to solve this problem .

The inverse code is calculated as ： The inverse of a positive number is itself , The inverse of a negative number is that the sign bit remains unchanged , Other bits are reversed .

When subtracting an inverse code , Pay attention to the following points ：
1、 The sign bit and the data participate in the calculation .
2、 If carry occurs after the sign bits are added , Then we should send it to the lowest to carry .
3、 The result of inverse code operation is still inverse code . To get the original code , The key is to look at the sign bit , Symbol bit 0, So the inverse code is the same as the original code ; Symbol bit 1, Then we should negate the inverse code by bit .

The addition operation of the inverse code is no different from the original code , Here we look directly at subtraction , Pictured ️ ️：

There is no problem with the calculation results , So the inverse code can solve the subtraction operation very well . But in certain situations , There are still some small problems , Pictured ️ ️：

After the calculation result is reversed , There is -0 This situation .0 Why is there a difference between positive and negative ？ For us , Plus or minus 0 There may be no difference . But for computers . Complement is all 0 And all 1 When they are, they mean +0 and -0, For such meaningless things , It still needs to be solved . So the complement appears .

---

3、 Complement code

The complement is calculated by ： The complement of a positive number is the same as the original code , Negative numbers are complemented by adding one to the inverse code .

When subtracting a complement , Pay attention to the following points ：
1、 The sign bit and the data participate in the calculation .
2、 If carry occurs after the sign bits are added , Then we should abandon it directly .
3、 The result of the inverse operation is also a complement . To get the original code , The key is to look at the sign bit , Symbol bit 0, Then the complement code is the same as the original code ; Symbol bit 1, Then the complement of the complement is the original code .

There is no difference between the addition of complement and the original code , Here we look directly at subtraction , Pictured ️ ️：

There is no problem with the result of calculation , Look again at 0 Sign problem , Pictured ️ ️：

In the calculation result 0 The sign problem of is also solved .

The advantages of complement ：
1、 Use complement , Can solve the inverse code representation 0 The positive and negative representations of .
2、 The number range represented by complement code is larger than that of original code and inverse code .

summary ：
In memory , Storing integer data is a stored complement . Storing integer data using complements can handle both symbolic and numeric fields ; At the same time, addition and subtraction can also be handled in a unified way , because cpu Only adders , So avoid subtraction directly . And the conversion process between the original code and the complement code is also consistent , So no additional hardware circuits are required .

---

3、 ... and 、 Byte order at the large and small end

Byte order at the large and small end ：（ stay C++ Mentioned in , Here, let's briefly sort out ）
In a computer, we use bytes , Each address unit corresponds to a byte . about char This one byte type , There is no need to consider the order of bytes in memory when storing data . But for short、int And other types that occupy multiple bytes , How to arrange the order of data bytes is an inevitable problem .

Big end storage ： That is, the high order of data is stored in the low order of memory , The lower bits of data are stored in the upper bits of memory .
Small end storage ： That is, the high order of data is stored in the high order of memory , The low order of data is stored in the low order of memory .

Pictured ️ ️：

Through the memory window, we can see , The address increases gradually from left to right , On low position 44 The low bit stored in the address , So it is currently a small end storage .

Be careful ️ ️

That we use a lot X86 The structure is small end mode , and KEIL C51 It's the big end mode . A great deal of ARM,DSP It's all small end mode . There are some ARM The processor can also choose the big end mode or the small end mode by the hardware .

So how do we design a program to judge whether the current machine is a big end or a small end ？ ️ ️

char Check()
{

	int a = 1;
	return *(char*)&a;
}

int main()
{


	if (Check())// For real, it is a small terminal
	{

		printf(" The small end \n");
	}
	else// Big terminal
		printf(" Big end \n");

	return 0;
}

When we int Form storage of 1 when , So we used 4 Bytes to store . We then force the address to *char, After strong rotation, we can dereference the data on the lowest bit , So if it's a big terminal , So what is stored in the lower order is 00, If it is a small terminal , So what is stored in the lower order is 01, In this way, it can be distinguished .

---

Four 、 Floating point storage in memory

Floating point storage rules ：
According to international standards IEEE（ Institute of electrical and Electronic Engineering ） 754, Any binary floating point number V It can be expressed in the following form ️ ️：

With 6.0 For example , It's written in binary as 110.0, namely 1.1X2^2 . that S = 0,M = 1.1,E = 2 .
With -6.0 For example , It's written in binary as -110.0, namely -1.1X2^2 . that S = 1,M = -1.1,E = 2 .

So how do we store floating point numbers in memory ？
IEEE 754 Regulations ：️ ️
about 32 Floating point number of bits , The highest 1 Bits are sign bits S, And then 8 Bits are exponents E, The rest 23 Bits are significant numbers M.

about 64 Floating point number of bits , The highest 1 Bits are sign bits S, And then 11 Bits are exponents E, The rest 52 Bits are significant numbers M.

In addition to the above ,IEEE 754 For significant figures M And the index E, There are some special rules .

1、M：1≤M<2 , in other words ,M It can be written. 1.xxxxxx In the form of , among xxxxxx Represents the fractional part .
IEEE 754 Regulations , Keep it in the computer M when , By default, the first digit of this number is always 1, So it can be discarded , Save only the back xxxxxx part . For example preservation 1.01 When , Save only 01, Wait until you read , Put the first 1 Add . The purpose of this , It's saving 1 Significant digits . With 32 For example, a floating-point number , Leave to M Only 23 position , Will come first 1 After giving up , It's equivalent to being able to save 24 Significant digits .

2、E： First ,E For an unsigned integer （unsigned int）, It means , If E by 8 position , Its value range is 0—255; If E by 11 position , Its value range is 0—2047. But in scientific counting E You can have negative numbers . therefore IEEE 754 Regulations , In memory E The true value of must be added with an intermediate number , about 8 Bit E, The middle number is 127; about 11 Bit E, The middle number is 1023. such as ,2^10 Of E yes 10, So save it as 32 When floating-point numbers are in place , Must be saved as 10+127=137, namely 10001001.

With 6.5f For example , After it is converted into binary, it is expressed as 1.101X2^2, that S = 0,M = 1.101,E = 2 + 127 = 129. After saving it , Pictured ️ ️：

Let's look at the memory in the compiler , Pictured ️ ️：

Because the current machine is a small terminal machine ,6.5f The hexadecimal representation of is 0x40d00000, To store in the memory, it is necessary to store according to the small end .

then , take E There are also the following rules for taking out ：

（1）E Not all for 0 Or not all of them 1
At this time , Floating point numbers are represented by the following rules , The index E The calculated value of minus 127（ or 1023）, Get the real value , And then the significant number M Add the first 1.
（2）E For all 1
At this time , If the significant number M All for 0, Express ± infinity （ It depends on the sign bit s）.
（3）E For all 0
At this time , The exponent of a floating point number E be equal to 1-127（ perhaps 1-1023） That's the true value , Significant figures M No more first 1, It's reduced to 0.xxxxxx Decimals of . This is to show that ±0, And close to 0 A very small number of .

---

When we understand the storage of integer and floating-point numbers in memory , Try the following question .
Please write the output value of the following program ： ️ ️

int main()
{

 int n = 9;
 float *pFloat = (float *)&n;
 printf("n The value of is ：%d\n",n);
 printf("*pFloat The value of is ：%f\n",*pFloat);
 *pFloat = 9.0f;// Let's just add f, It is said to be float
 // *pFloat = 9.0; Because the default floating-point number type in the current compiler is double, So implicit type conversion occurs here , the double Turn it into float
 printf("num The value of is ：%d\n",n);
 printf("*pFloat The value of is ：%f\n",*pFloat);
 return 0; }

 The output result is ：9 、0.000000 、1,091,567,616、9.000000

analysis ：
n Is a positive number , that n The original code of 、 Complement code 、 The reverse code is consistent .n The complement of is ：1001 （ Ahead 0 Omit ）. At this time , We will n Forced address conversion of float The pointer to , So we're going to n Put the value of into *pfloat in , here E For all 0, So when you take it out in the form of a floating-point number , The number is infinitely close to 0, So the result is 0.000000 .
When we give *pfloat Deposit in 9.0f when , Its binary is ：0 10000010 00100000000000000000000, Hex is ：0x41100000, Take out according to the integer , So that is 1,091,567,616 .

verification ：️ ️

---

Today's content is over here , I hope you can gain something .
