Qcodeeditor - QT based code editor

One Basic introduction

It’s not a project from a Qt example.

This is not qt Example project of ！！！ This is an introduction to the open source project

QCodeEditor Is a support for automatic completion 、 Code editor for syntax highlighting and line numbering .
It's for anyone who wants to support multiple languages , From programming languages to markup languages , Even custom scripting languages . In the present state , It can perfectly handle all the functions mentioned above , But there are still many things to be achieved .QCodeEditor Is based on Qt Of QPlainTextEdit, It already includes an interface for adding syntax highlighting and autocompletion .

Source code and sample code download links ：https://download.csdn.net/download/weixin_42887343/76428055

Two Code using

Using the editor itself is simple . Can pass QPlainTextEdit Add... To the form a And elevate it to kgl::QCodeEditor（ Please note that , Must be “ include/KGL/Widgets ” Add to INCLUDEPATH Variable and global include Must select “ ” Check box ） Or programmatically add it to the form ：

using namespace kgl;

// ## MainWindow::MainWindow
QCodeEditor *editor = new QCodeEditor;
setCentralWidget(editor); // or: ui->someLayout->addWidget(editor);

By using QCodeEditorDesign This class can change the visual appearance of the editor . In the following example , Let's assume that the code editor is surrounded by multiple widgets , So a border is added to it . We also modified the appearance to have “ Dark ” style ：

using namespace kgl;

// ## MainWindow::MainWindow
QCodeEditorDesign design;
design.setLineColumnVisible(false);
design.setEditorBackColor(0xff333333);
design.setEditorTextColor(0xffdddddd);
design.setEditorBorderColor(0xff999999);
design.setEditorBorder(QMargins(1,1,1,1)); // l t r b
editor->setDesign(design);

But how to actually add some syntax highlighting rules , As shown in the figure above ？ There are two ways to do this ： Add them programmatically or from XML Extract them from the file .

Programmatically ：

using namespace kgl;

// ## MainWindow::MainWindow
QList<QSyntaxRule> rules;
QSyntaxRule rule;
rule.setForeColor(QColor(Qt::blue));
rule.setRegex("\\bFoo\\b");
rule.setId("Foo");
rules.push_back(rule);
editor->setRules(rules);

XML file ：

using namespace kgl;
// ## MainWindow::MainWindow
QCodeEditorDesign design;
// modify design ...
QList<QSyntaxRule> rules =
QSyntaxRules::loadFromFile(":/rule_cpp.xml", design);
editor->setRules(rules);
// Note: ':/rule_cpp.xml' refers to the path of a QRC resource

The next chapter provides how to create these XML A guide to the rules . But first of all , Our editor needs some autocomplete keywords ：

// ## MainWindow::MainWindow
QStringList keywords = {
     "printf", "scanf" };
editor->setKeywords(keywords);

If you want to add an icon to indicate that the keyword is a function / member / macro /… QStandardItemModel, You need to create a custom and pass it to “ QCodeEditor::setKeywordModel(model)”.

3、 ... and establish XML Rules file

XML The rules file contains the topmost element composed of multiple child elements . Each child element must contain a regular expression or a list of keywords , All other properties are optional ：

<rules>
    <rule>
        <regex>\bFoo\b</regex>
        <keywords>foo bar key</keywords>
    </rule>
</rules>

References to all available attributes , Please go to rules_template.xml Of github page .QCodeEditor Even rules with more than one row are supported . Although they are useful for implementing multiline annotations , But they can also be used for other purposes .

Four ID Usefulness

from rules_template.xml It can be seen that , Rules can even define custom ID. In this section , I'll show you how to use ID And why they are so useful . People may have noticed , Adding keywords statically is not a good practice , Especially if your language allows you to include other files or define variables .

“onMatch” The signal
QCodeEditorHighlighteronMatch as long as a string- Find... Through regular expressions - Be highlighted , Will send out a message called ’ ’ The signal of . This enables us to retrieve information with string The problem of ：

// ## MainWindow.h
using namespace kgl;
class MainWindow : public QMainWindow {

Q_OBJECT
public:
...

private slots:

    void addMacro(const QSyntaxRule &rule, QString seq, QTextBlock block);

private:

    QMap<QTextBlock, QSyntaxRule> m_RuleMap;
    QMap<QTextBlock, QString> m_MacroMap;
    QCodeEditor *m_Editor;
};

// ## MainWindow::MainWindow
QSyntaxRule defineRule;
defineRule.setRegex("(#define\\s+)\\K(\\D\\w*)(?=\s+\S+)");
defineRule.setId("define");
editor->setRules({
     defineRule });
connect(m_Editor->highlighter(), SIGNAL(onMatch(QSyntaxRule,QString,QTextBlock)),
                            this, SLOT(addMacro(QSyntaxRule,QString,QTextBlock)));

// ## MainWindow::addMacro
if (rule.id() == "define") {

    foreach (const QTextBlock &b, m_RuleMap.keys()) {

        if (b.userData() != NULL && block.userData() != NULL) {

            auto *d1 = static_cast<QCodeEditorBlockData *>(block.userData());
            auto *d2 = static_cast<QCodeEditorBlockData *>(b.userData());
            if (d1->id == d2->id) {

                return;
            }
        }
    }

    // Not existing yet; add it
    QString def = seq.split(' ').at(0);
    m_RuleMap.insert(block, rule);
    m_MacroMap.insert(block, def);
    m_Editor->addKeyword(def);
}

such , Can be a custom class 、 Variables and definitions provide automatic completion , Or include other files and import symbols from them .

“onRemove” The signal
Deleting macros that have been added can be a bit tricky , because QTextBlock Its design makes it almost impossible for us to track it .QCodeEditorHighlighter Provide ’ onRemove’ The signal , Once the highlighter detects that the previously matched rule no longer matches , Will send the signal ：

// ## MainWindow.h
private slots:

    void addMacro(const QSyntaxRule &rule, QString seq, QTextBlock block);
    void removeMacro(QCodeEditorBlockData *data); // Add this to the slots

// ## MainWindow::MainWindow
// Add another connection
connect(m_Editor->highlighter(), SIGNAL(onRemove(QCodeEditorBlockData*)),
                        this, SLOT(removeMacro(QCodeEditorBlockData*)));

// ## MainWindow::removeMacro
foreach (const QTextBlock &b, m_RuleMap.keys()) {

    if (b.userData()) {

        auto *d = static_cast<QCodeEditorBlockData *>(b.userData());
        if (d->id == data->id) {

            // Data is the same; block must be the one from before!
            m_Editor->removeKeyword(m_MacroMap.value(b));
            m_RuleMap.remove(b);
            m_MacroMap.remove(b);
        }
    }
}

It is a difficult task to implement such a signal which is relatively simple to use . see “ Point of interest ” Chapter for more information .

5、 ... and Compilation instructions

To compile QCodeEditor, You need to define ’ KGL_BUILD’ To export symbols to the dynamic library . If you want to build a static library , Just define ’ KGL_STATIC’. Also make sure you use Qt5 Or later .

6、 ... and Points of concern

One of the biggest obstacles is to render line numbers correctly . Although it is very easy to add rows and columns as child widgets , However, this is not the case for determining all the line numbers visible when scrolling . In the reading Qt After a long period of time , I think I can skip to the next line in the iteration , And stop the iteration immediately when the current row is no longer visible .

Another big obstacle is indenting multiple selected rows when the tab key is pressed . I use really amazing ’ QTextCursor::movePosition’ Method solved the problem , This makes it possible to implement this function （ And back indent ） It's easy .

QTextBlock
Even though QTextBlock It has amazing functions and possibilities , But it still has a weakness ： For us , Track... In a text widget QTextBlock It's almost impossible . To implement a signal that allows the deletion of keywords , I first try to copy the problem QTextBlock, Then use overloaded ‘==’ Operator to check for equality . It doesn't work , Because the line number may change and cause the equation to fail . track QTextBlock The only possibility is to use ’ setUserData’ Function to assign QTextBlockUserData. To achieve this , I inherited QTextBlockUserData And will auuid and the Storage regex string In which the .uuid（+ some do-while loop ） Ensure that the block is truly unique throughout the application . Through these measurements ,‘onRemove’ The signal is finally reliable and error free .

---

Article reference link ：https://www.codeproject.com/Articles/1139741/QCodeEditor-Widget-for-Qt
