SOC_ AHB_ SD_ IF

2022-06-30 06:43:00 【Eight four one one】

Catalog

1. Signal definition

  • AHB Classic signal ： The clock 、 Reset 、 Slave selection 、 Read write enable 、 Transmission status 、 Burst mode 、 Writing data 、 Address 、 Transmission width 、 Free busy signal 、 The corresponding 、 Reading data
  • Interrupt signal ：DMA interrupt 、 Clear the thrust
  • Register status signal ： See code comments for details
// AHB signals
input hclk;
input hrst_n;
input hsel;
input hwrite;
input   [1:0]   htrans;		//IDLE、BUSY、NONSEQ、SEQ
input   [2:0]   hburst;		//burst type , Support 4、8、16 burst,incrementing/wrapping
input   [31:0]  hwadata;
input   [31:0]  haddr;
input   [2:0]   hsize;		//8、16、32 bits this design
input 			hready_in;	//other slave is no busy

output			hready_out;
output  [1:0]   hresp;
output  [31:0]  hrdata;

//-- host_dma
output  		dma_en;		    //DMA Can make
output 			dma_direc;		// Transmission direction
output  [15:0]  transfer_size;	//dma transfer byte
output  [31:0]  dma_addr;		// There are different addresses of objects according to the direction

// interrupt signals generater enable
output  fifo_full_int_gen;
output	fifo_empty_int_gen;
output	dma_finish_int_gen;  //DMA The completion interrupt will be sent after the data is moved

//DMA_fifo
input	fifo_full_int;
input	fifo_empty_int;
input	dma_finish_int;

//clear interrupt signals
output	clr_fifo_full_int;
output	clr_fifo_empty_int;
output	clr_dma_finish_int;
input	clr_dma_en;


// Respond to
input [31:0]	response0;
input [31:0]	response1;
input [31:0]	response2;
input [31:0]	response3;

//sd_fifo
input			in_sd_clk;
input			sd_fifo_empty;
input			sd_fifo_full;
input			sd_fifo_re;

//state register signal
input			in_end_command;
input			in_end_command_and_response;
input			in_transfer_complete;
input			in_send_data_crc_error;
input			in_receive_data_crc_error;
input			in_response_timeout;
input [2:0]		in_cmd_current_state;
input			in_read_to_error;
input			one_bk_re_end;

output			sd_clk_enable;
output			hw_stop_clk;
output [7:0]	sd_clk_divider;
output			sd_soft_reset;
output			high_speed_clk;

output [31:0]	command_argument;
output [5:0]	command_index;
output [10:0]	block_size;
output [10:0]	block_len;
output			sd_op_finish;
output [31:0]	block_number;
output			data_direction;
output			data_width;
output [31:0]	read_to;		     	//read timeout
output			irq;				 	//interrupt to interrupt controler
output			out_response;	    	//respobnse 48bit
output			out_longresponse;		//longresponse 136bit
output			cmd_fsm_ready;	    	//fsm start signal
output			data_fsm_ready;	    	//fsm start signal

2. Internal signals

See the specific code and understand it naturally

reg			cmd_fsm_ready;
reg	[31:0]	hrdtata;
reg			sd_clk_enable;
reg	[7:0]	sd_clk_divider;
reg			sd_soft_reset;
reg			hw_stop_clk_en;
reg			high_speed_clk;
reg	[31:0]	command_argument;
reg	[5:0]	command_index;
reg 		command_enable;
reg 		data_present;		//indicate if the current command has data transfer
reg	[1:0]	response_type;
reg	[10:0]	block_size;
reg	[10:0]	block_len;
reg	[10:0]	block_len_r;
reg	[31:0]	block_number;
reg			data_direction;
reg			data_width;
reg	[31:0]	read_to;
reg			read_to_error;

reg			dma_finish_interrupt_mask;
reg			end_command_and_response_interrupt_mask;
reg			sd_fifo_empty_interrupt_mask;	//tx fifo empty interrupt mask
reg			fifo_full_interrupt_mask;		//tx fifo full interrupt mask
reg			fifo_empty_interrupt_mask;
reg			sd_fifo_full_interrupt_mask;	//rx fifo full interrupt mask
reg			command_complete_interrupt_mask;
reg			transfer_complete_interrupt_mask;
reg			read_to_error_interrupt_mask;
reg			rx_fifo_write_error_interrupt_mask;
reg			tx_fifo_read_error_interrupt_mask;
reg			read_data_crc_error_interrupt_mask;
reg			write_data_crc_error_interrupt_mask;
reg			response_timeout_error_interrupt_mask;

reg			sd_fifo_empty_r;
reg			sd_fifo_full_r;
reg			end_command;
reg			transfer_complete;
reg			send_data_crc_error;
reg			receive_data_crc_error;
reg			response_timeout;
reg			out_response;
reg			out_longresponse;
reg			end_command_and_response;

//--host_dma
reg			dma_en;
reg			dma_direc;transfer_size;
reg	[15:0]	dma_addr;
reg	[31:0]	fifo_full_int_gen;
reg			fifo_empty_int_gen;
reg			dma_finish_int_gen;
reg			clr_fifo_full_int;
reg			clr_fifo_empty_int;
reg			clr_dma_finish_int;
//-------------internal register-------------
reg 		hwrite_r;
reg [2:0]	hsize_r;
reg [2:0]	hburst_r;
reg [1:0]	htrans_r;
reg [31:0]	haddr_r;

reg 		dma_end_tp;
reg 		dma_end;
reg 		dma_end_r;
reg 		cmd_ready_pre;
reg 		hw_stop_clk;

reg [31:0]	block_number_ahb;
reg [31:0]	block_num_tp;
reg 		one_bk_re_end_tp_1;
reg 		one_bk_re_end_tp_2;
reg 		one_bk_re_end_tp_3;
reg 		cmd_state_send_tp1;
reg 		cmd_state_send_tp2;
reg 		cmd_state_send_tp3;
reg 		in_end_cmd_and_resp_tp_1;
reg 		in_end_cmd_and_resp_tp_2;
reg 		in_end_cmd_and_resp_tp_3;
reg 		sd_fifo_empty_tp1;
reg 		sd_fifo_full_tp1;
reg 		in_end_cmd_tp_1;
reg 		in_end_cmd_tp_2;
reg 		in_end_cmd_tp_3;
reg 		in_transfer_end_tp_1;
reg 		in_transfer_end_tp_2;
reg 		in_transfer_end_tp_3;
reg 		in_rd_to_err_tp_1;
reg 		in_rd_to_err_tp_2;
reg 		in_rd_to_err_tp_3;
reg 		in_send_data_crc_err_tp_1;
reg 		in_send_data_crc_err_tp_2;
reg 		in_send_data_crc_err_tp_3;
reg 		in_receive_data_crc_err_tp_1;
reg 		in_receive_data_crc_err_tp_2;
reg 		in_receive_data_crc_err_tp_3;
reg 		in_resp_timeout_tp_1;
reg 		in_resp_timeout_tp_2;
reg 		in_resp_timeout_tp_3;
reg [31:0]	response0_ahb;
reg [31:0]	response1_ahb;
reg [31:0]	response2_ahb;
reg [31:0]	response3_ahb;
reg 		cmd_state_send;
reg 		ahb_wr_reg_en;
reg 		ahb_rd_reg_en;

3. Function code

3.1 Free busy and response

  • Single cycle configuration register , There is no need to lower
  • The response has been to 0, That is to say okay
assign hready_out = 1'b1;
assign hresp =2'b0;

3.2 keep for the future AHB Incoming control signals

  • When selected as a slave , And there are hready_in == 1 when , Store the control signal in the register _r in
always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
	begin
		hwrite_r 	<= 1'b0;
        hsize_r 	<= 3'b0;
        hburst_r	<= 3'b0;
        htrans_r	<= 2'b0;
        haddr_r		<= 32'b0;
	end

	else if (hsel && hready_in)
	begin
		hwrite_r 	<= hwrite;
        hsize_r 	<= hsize;
        hburst_r	<= hburst;
        htrans_r	<= htrans;
        haddr_r		<= haddr;
	end
	else begin
		hwrite_r 	<= 1'b0;
        hsize_r 	<= 3'b0;
        hburst_r	<= 3'b0;
        htrans_r	<= 2'b0;
        haddr_r		<= 32'b0;
	end
end

3.3 AHB Read / write register enable

  • htrans ：10 NOSNSEQ 11 SEQ Both are data valid signals
  • When writing, you should take a beat to make sure that the data address is aligned , Single cycle read / write requirements
  • There is no need to take a picture when reading , Because reading data will be delayed
assign ahb_wr_reg_en = hready_in && hwrite_r && (htrans_r == 2'b10 | htrans_r == 2'b11);
assign ahb_rd_reg_en = hsel && hready_in && !hwrite & (htrans_r == 2'b10 | htrans_r == 2'b11);

3.4 The length of the transmission block

  • amount to block_size Two shots turned into block_len
always @(posedge in_sd_clk or negedge hrst_n) begin
	if (!hrst_n)
	begin
		block_len   <= 11'd200;
		block_len_r <= 11'd200;
	end
	else
	begin
		block_len_r <= block_size;
		block_len <= block_len_r;
	end
end

3.5 Register configuration

3.5.1 DMA_CTRL_ADDR

  • dma_en It's a traig The signal , Only by clr_dma_en Just cleared
//--------------------------------------------------------------
//DMA control operation
//DMA_CTRL_ADDR : [0] dma_en
// [4] dma_direc
// [31:16] transfer_size
// [15:5]/[3:1] reserved
//-------------------------------------------------------------
always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
		dma_en <= 1'b0;
	else if (clr_dma_en)
		dma_en <= 1'b0;
	else if (ahb_wr_reg_en & (haddr_r[7:0]) == `DMA_CTRL_ADDR)
		dma_en <= hwdata[0];
end

always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
	begin
		dma_direc <= 1'b0;
		transfer_size <= 16'b0;
		dma_addr <= 32'b0;
	end
	else if (ahb_wr_reg_en)
	begin
		case (haddr_r[7:0])
			`DMA_CTRL_ADDR : begin
				dma_direc <= hwdata[4];
				transfer_size <= hwdata[31:16];
			end
			`DMA_ADDR_ADDR:
				dma_addr <= hwdata[31:0];
		endcase
	end
end

3.5.2 INT_GEN_REG_ADDR

  • to fifo_full_int_gen、fifo_empty_int_gen 、dma_finish_int_gen assignment , The initial value is 1
  • from AHB The signal of a bit that writes data determines
always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
	begin
		fifo_full_int_gen <= 1'b1;
		fifo_empty_int_gen <= 1'b1;
		dma_finish_int_gen <= 1'b1;
	end
	else if (ahb_wr_reg_en && (haddr_r[7:0]== `INT_GEN_REG_ADDR))
	begin
		fifo_full_int_gen <= hwdata[0];
		fifo_empty_int_gen <= hwdata[4];
		dma_finish_int_gen <= hwdata[8];
	end
end

3.5.3 CLR_INT_REG_ADDR

  • from AHB The signal of a bit that writes data determines
//-------------------------------------------------------------
//CLR_INT_REG_ADDR spec
// [0] clr_fifo_full_int
// [4] clr_fifo_empty_int
// [8] clr_dma_finish_int
// [....] reserved
//-------------------------------------------------------------
always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
	begin
		clr_fifo_full_int <= 1'b0;
		clr_fifo_empty_int <= 1'b0;
		clr_dma_finish_int <= 1'b0;
	end
	else if (ahb_wr_reg_en && (haddr_r[7:0]== `CLR_INT_REG_ADDR))
	begin
		clr_fifo_full_int <= hwdata[0];
		clr_fifo_empty_int <= hwdata[4];
		clr_dma_finish_int <= hwdata[8];
	end
	else
	begin
		clr_fifo_full_int <= 1'b0;
		clr_fifo_empty_int <= 1'b0;
		clr_dma_finish_int <= 1'b0;
	end
end

3.5.4 INTERRUPT_STATUS_REGISTER_ADDR

Insert picture description here

  • end_command_and_response position
always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
    begin
		in_end_cmd_and_resp_tp_1 	<= 1'b0;
		in_end_cmd_and_resp_tp_2 	<= 1'b0;
		in_end_cmd_and_resp_tp_3 	<= 1'b0;
	end
	else
	begin
		in_end_cmd_and_resp_tp_1 <= in_end_command_and_response;
		in_end_cmd_and_resp_tp_2 <= in_end_cmd_and_resp_tp_1;
		in_end_cmd_and_resp_tp_3 <= in_end_cmd_and_resp_tp_2;
	end
end

always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
		end_command_and_response <= 1'b0;
	else if (cmd_ready_pre)
		end_command_and_response <= 1'b0;
	else if (!in_end_cmd_and_resp_tp_3 && in_end_cmd_and_resp_tp_2)
		end_command_and_response <= 1'b1;
end
  • sd_fifo_empty_r position
always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
	begin
		sd_fifo_empty_tp1 <= 1'b0;
		sd_fifo_empty_r <= 1'b0;
	end
	else begin
		sd_fifo_empty_tp1 <= sd_fifo_empty;
		sd_fifo_empty_r <= sd_fifo_empty_tp1;
	end
end
  • sd_fifo_full_r position
always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
	begin
		sd_fifo_full_tp1 <= 1'b0;
		sd_fifo_full_r <= 1'b0;
	end
	else begin
		sd_fifo_full_tp1 <= sd_fifo_full;
		sd_fifo_full_r <= sd_fifo_full_tp1;
	end
end
  • end_command position
always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
	begin
		in_end_cmd_tp_1 	<= 1'b0;
		in_end_cmd_tp_2 	<= 1'b0;
		in_end_cmd_tp_3 	<= 1'b0;
	end
	else
	begin
		in_end_cmd_tp_1 <= in_end_command;
		in_end_cmd_tp_2 <= in_end_cmd_tp_1;
		in_end_cmd_tp_3 <= in_end_cmd_tp_2;
	end
end

always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
		end_command <= 1'b0;
	else if (cmd_ready_pre)
		end_command <= 1'b0;
	else if (!in_end_cmd_tp_3 && in_end_cmd_tp_2)
		end_command<= 1'b1;
end
  • transfer_complete position
always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
	begin
		in_transfer_end_tp_1 	<= 1'b0;
		in_transfer_end_tp_2 	<= 1'b0;
		in_transfer_end_tp_3 	<= 1'b0;
	end
	else
	begin
		in_transfer_end_tp_1 <= in_transfer_complete;
		in_transfer_end_tp_2 <= in_transfer_end_tp_1;
		in_transfer_end_tp_3 <= in_transfer_end_tp_2;
	end
end

always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
		transfer_complete <= 1'b0;
	else if (cmd_ready_pre)
		transfer_complete <= 1'b0;
	else if (!in_transfer_end_tp_3 && in_transfer_end_tp_2)
		transfer_complete<= 1'b1;
end
  • read_to_error position
always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
	begin
		in_rd_to_err_tp_1 	<= 1'b0;
		in_rd_to_err_tp_2 	<= 1'b0;
		in_rd_to_err_tp_3 	<= 1'b0;
	end
	else
	begin
		in_rd_to_err_tp_1 <= in_read_to_error;
		in_rd_to_err_tp_2 <= in_rd_to_err_tp_1;
		in_rd_to_err_tp_3 <= in_rd_to_err_tp_2;
	end
end

always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
		read_to_error <= 1'b0;
	else if (cmd_ready_pre)
		read_to_error <= 1'b0;
	else if (!in_rd_to_err_tp_3 && in_rd_to_err_tp_2)
		read_to_error<= 1'b1;
end
  • send_data_crc_error position
always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
	begin
		in_send_data_crc_err_tp_1 	<= 1'b0;
		in_send_data_crc_err_tp_2 	<= 1'b0;
		in_send_data_crc_err_tp_3 	<= 1'b0;
	end
	else
	begin
		in_send_data_crc_err_tp_1 <= in_send_data_crc_error;
		in_send_data_crc_err_tp_2 <= in_send_data_crc_err_tp_1;
		in_send_data_crc_err_tp_3 <= in_send_data_crc_err_tp_2;
	end
end

always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
		send_data_crc_error <= 1'b0;
	else if (cmd_ready_pre)
		send_data_crc_error <= 1'b0;
	else if (!in_send_data_crc_err_tp_3 && in_send_data_crc_err_tp_2)
		send_data_crc_error<= 1'b1;
end
  • receive_data_crc_error position
always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
	begin
		in_receive_data_crc_err_tp_1 	<= 1'b0;
		in_receive_data_crc_err_tp_2 	<= 1'b0;
		in_receive_data_crc_err_tp_3 	<= 1'b0;
	end
	else
	begin
		in_receive_data_crc_err_tp_1 <= in_receive_data_crc_error;
		in_receive_data_crc_err_tp_2 <= in_receive_data_crc_err_tp_1;
		in_receive_data_crc_err_tp_3 <= in_receive_data_crc_err_tp_2;
	end
end

always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
		receive_data_crc_error <= 1'b0;
	else if (cmd_ready_pre)
		receive_data_crc_error <= 1'b0;
	else if (!in_receive_data_crc_err_tp_3 && in_receive_data_crc_err_tp_2)
		receive_data_crc_error<= 1'b1;
end
  • response_timeout position
always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
	begin
		in_resp_timeout_tp_1 	<= 1'b0;
		in_resp_timeout_tp_2 	<= 1'b0;
		in_resp_timeout_tp_3 	<= 1'b0;
	end
	else
	begin
		in_resp_timeout_tp_1 <= in_resp_timeout;
		in_resp_timeout_tp_2 <= in_resp_timeout_tp_1;
		in_resp_timeout_tp_3 <= in_resp_timeout_tp_2;
	end
end

always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
		response_timeout <= 1'b0;
	else if (cmd_ready_pre)
		response_timeout <= 1'b0;
	else if (!in_resp_timeout_tp_3 && in_resp_timeout_tp_2)
		response_timeout<= 1'b1;
end

3.5.5 Write control register

always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
	begin
		sd_clk_enable		<= 1'b0;
		sd_clk_divider		<= 8'b0;
		sd_soft_reset		<= 1'b1;
		command_argument	<= 32'b0;
		command_index		<= 6'b0;
		command_enable		<= 1'b0;
		data_present		<= 1'b0;
		response_type		<= 2'b0;
		block_size			<= 11'd200;
		block_number_ahb	<= 32'b0;
		data_direction		<= 1'b0;
		data_width			<= 1'b0;
		read_to				<= 32'hffff_ffff;
		dma_finish_interrupt_mask				<= 1'b0;
		end_command_and_response_interrupt_mask	<= 1'b0;
		fifo_full_interrupt_mask                <= 1'b0;
		command_complete_interrupt_mask		    <= 1'b0;
		transfer_complete_interrupt_mask	    <= 1'b0;
		read_to_error_interrupt_mask			<= 1'b0;
		rx_fifo_write_error_interrupt_mask      <= 1'b0;
		tx_fifo_read_error_interrupt_mask       <= 1'b0;
		read_data_crc_error_interrupt_mask      <= 1'b0;
		write_data_crc_error_interrupt_mask     <= 1'b0;
		response_timeout_error_interrupt_mask   <= 1'b0;
		fifo_empty_interrupt_mask               <= 1'b0;
		sd_fifo_full_interrupt_mask             <= 1'b0;
		sd_fifo_empty_interrupt_mask            <= 1'b0;
		hw_stop_clk_en                          <= 1'b0;
		high_speed_clk                          <= 1'b0;

	end
	else if (ahb_wr_reg_en)
	begin
		case (haddr_r[7:0])

		`CLOCK_CONTROL_REGISTER_ADDR: begin
			sd_clk_enable <= hwdata[2];
			sd_clk_divider <= hwdata[15:8];
		end

		`SOFTWARE_RESET_REGISTER_ADDR: begin
			sd_soft_reset <= hwdata[0];
		end

		`CLK_EN_SPEED_UP_ADDR: begin
			hw_stop_clk_en <= hwdata[0];
			high_speed_clk <= hwdata[4];
		end

		`ARGUMENT_REGISTER_ADDR : begin
			command_argument <= hwdata;
		end

		`COMMAND_REGISTER_ADDR : begin
			command_index <= hwdata[10:5];
			command_enable<= hwdata[3];
			data_present  <= hwdata[2];
			response_type <= hwdata[1:0];
		end

		`BLOCK_SIZE_REGISTER_ADDR: begin
			block_size <= hwdata[10:0];
		end

		`BLOCK_COUNT_REGISTER_ADDR: begin
			block_number_ahb <= hwdata [31:0];
		end

		`TRANSFER_MODE_REGISTER_ADDR : begin
			data_direction <= hwdata[1];
			data_width <= hwdata[0];
		end

		`READ_TIMEOUT_CONTROL_REGISTER_ADDR: begin
			read_to <= hwdata[31:0];
		end

		`INTERRUPT_STATUS_MASK_REGISTER_ADDR: begin
			dma_finish_interrupt_mask				<= hwdata[13];
			end_command_and_response_interrupt_mask	<= hwdata[12];
			sd_fifo_full_interrupt_mask             <= hwdata[11];
			fifo_full_interrupt_mask                <= hwdata[10];
			fifo_empty_interrupt_mask               <= hwdata[9];
			sd_fifo_empty_interrupt_mask            <= hwdata[8;
			command_complete_interrupt_mask		    <= hwdata[7];
			transfer_complete_interrupt_mask	    <= hwdata[6];
		    read_to_error_interrupt_mask			<= hwdata[5];
		    rx_fifo_write_error_interrupt_mask      <= hwdata[4];
            tx_fifo_read_error_interrupt_mask       <= hwdata[3];
            read_data_crc_error_interrupt_mask      <= hwdata[2];
            write_data_crc_error_interrupt_mask     <= hwdata[1];
            response_timeout_error_interrupt_mask   <= hwdata[0];
        end
		endcase
	end
end

3.5.6 Read register

always @(posedge hclk or negedge hrst_n)
begin
	if (!hrst_n)
		hrdata <= 32'b0;
	else if (ahb_rd_reg_en)
	begin
		case (haddr[7:0])
		`CLOCK_CONTROL_REGISTER_ADDR:
			hrdata <= {
    16'b0,sd_clk_divider,5'b0,sd_clk_enable,2'b0};
		`SOFTWARE_RESET_REGISTER_ADDR:
			hrdata <= {
    31'b0,sd_soft_reset};
		`CLK_EN_SPEED_UP_ADDR:
			hrdata <= {
    27'b0,high_speed_clk,3'b0,hw_stop_clk_en};
		`ARGUMENT_REGISTER_ADDR:
			hrdata <= command_argument;
		`COMMAND_REGISTER_ADDR:
			hrdata <= {
    21'b0,command_index,1'b0,command_enable,data_present,response_type};
		`BLOCK_SIZE_REGISTER_ADDR:
			hrdata <= {
    21'b0,block_size};
		`BLOCK_COUNT_REGISTER_ADDR:
			hrdata <= block_number_ahb;
		`TRANSFER_MODE_REGISTER_ADDR:
			hrdata <= {
    30'b0,data_direction,data_width};
		`READ_TIMEOUT_CONTROL_REGISTER_ADDR:
			hrdata <= read_to;
		`DMA_ADDR_ADDR :
			hrdata <= dma_addr;
		`DMA_CTRL_ADDR:
			hrdata <= {
    transfer_size,11'b0,dma_direc,3'b0,dma_en};
		`INT_GEN_REG_ADDR:
			hrdata <= {
    23'b0,dma_finish_int_gen,3'b0,fifo_empty_int_gen,3'b0,fifo_full_int_gen};
		`CLR_INT_REG_ADDR:
			hrdata <= {
    23'b0,clr_fifo_empty_int,3'b0,clr_fifo_full_int,3'b0,clr_dma_finish_int};
		`RESPONSE0_REGISTER_ADDR:
			hrdata <= response0_ahb;
		`RESPONSE1_REGISTER_ADDR:
			hrdata <= response1_ahb;
		`RESPONSE2_REGISTER_ADDR:
			hrdata <= response2_ahb;
		`RESPONSE3_REGISTER_ADDR:
			hrdata <= response3_ahb;
		`INTERRUPT_STATUS_REGISTER_ADDR:
		begin
			hrdata <= {

						18'b0,
						dma_finish_int,
						end_command_and_response,
						sd_fifo_empty_r,
						fifo_full_int,
						fifo_empty_int,
						sd_fifo_full_r,
						end_command,
						transfer_complete,
						read_to_error,
						1'b0,
						1'b0,
						receive_data_crc_error,
						send_data_crc_error,
						response_timeout};
		end
		default : hrdata <= 32'h0;
		endcase
	end
end

3.6 Data state machine ready signal data_fsm_ready

  • data_fsm_ready yes fsm Start signal
  • It works data_present It means you are ready to write
  • sd_fifo_full Express fifo Write full , Need from fifo Go to sd Card writing
  • in_end_command,CMD17 After reading the command, proceed to DMA Move
  • data_direction ： 1-> Write sd card 0-> read sd card
assign data_fsm_ready = data_present &&
						(data_direction ? (sd_fifo_full):(in_end_command));

3.7 SD Operation end signal sd_op_finish

  • To clear away FIFO ptr
  • dirction 1: Write sd 0： read sd
  • (!dma_end_r && dma_end) Generate a pulse for the end of data transfer , It's equivalent to monitoring edge , So three beats
always @(posedge in_sd_clk or negedge hrst_n) begin
	if (!hrst_n)
	begin
		dma_end_tp 	<= 1'b0;
		dma_end 	<= 1'b0;
		dma_end_r 	<= 1'b0;
	end
	else
	begin
		dma_end_tp 	<= dma_finish_int;
		dma_end 	<= dma_end_tp;
		dma_end_r 	<= dma_end;
	end
end

assign sd_op_finish = data_direction ? in_transfer_complete : (!dma_end_r && dma_end);

3.8 For low power consumption stop sd_clk The signal hw_stop_clk

  • One block End pulse , stop sd_clk
  • dma You can stop the clock when moving data , Don't stop the clock after moving
always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
	begin
		one_bk_re_end_tp_1 	<= 1'b0;
		one_bk_re_end_tp_2 	<= 1'b0;
		one_bk_re_end_tp_3 	<= 1'b0;
	end
	else
	begin
		one_bk_re_end_tp_1 <= one_bk_re_end;
		one_bk_re_end_tp_2 <= one_bk_re_end_tp_1;
		one_bk_re_end_tp_3 <= one_bk_re_end_tp_2;
	end
end

always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
		hw_stop_clk <= 1'b0;
	else if (!data_direction && hw_stop_clk_en)
	begin
		if (!one_bk_re_end_tp_3 && one_bk_re_end_tp_2)
			hw_stop_clk <= 1'b1;
		else if (dma_finish_int)
			hw_stop_clk <= 1'b0;
	end
	else
		hw_stop_clk <= 1'b0;
end

3.9 Command state machine start signal cmd_state_send

  • Play three times to monitor the edge
  • After the command is sent, it is right cmd_ready_pre （cmd_fsm_ready ） Zero clearing
  • Pay attention to 1 Conditions ： Command enable 、 Write register enable 、 The address is the register address
assign cmd_state_send = (in_cmd_current_state == `CMD_STATE_SEND);

always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
	begin
		cmd_state_send_tp1 	<= 1'b0;
		cmd_state_send_tp2 	<= 1'b0;
		cmd_state_send_tp3 	<= 1'b0;
	end
	else
	begin
		cmd_state_send_tp1 <= cmd_state_send;
		cmd_state_send_tp2 <= cmd_state_send_tp1;
		cmd_state_send_tp3 <= cmd_state_send_tp2;
	end
end

always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
		cmd_ready_pre <= 1'b0;
	else if (!cmd_state_send_tp3 && cmd_state_send_tp2)
	// Has started to send  cmd_ready_pre Zero clearing , Send it again next time when you match it
		cmd_ready_pre <= 1'b0;
	else if (command_enable && (ahb_wr_reg_en &&(haddr_r[7：0] == `ARGUMENT_REGISTER_ADDR)))
		cmd_ready_pre <= 1'b1;
end

always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
		cmd_fsm_ready <= 1'b0;
	else
		cmd_fsm_ready <= cmd_ready_pre;
end

3.10 Generation of interrupt signal

  • Including whether there is mask Mask interrupt
assign irq =((dma_finish_int && !dma_finish_interrupt_mask) ||
			(end_command_and_response && !end_command_and_response_interrupt_mask) ||
			(sd_fifo_empty_r && !sd_fifo_empty_interrupt_mask) ||
			(fifo_full_int && !fifo_full_interrupt_mask) ||
			(fifo_empty_int && !fifo_empty_interrupt_mask) ||
			(sd_fifo_full_r && ! sd_fifo_full_interrupt_mask)||
			(end_command && !command_complete_interrupt_mask) ||
			(transfer_complete && !transfer_complete_interrupt_mask) ||
			(1'b0 && !rx_fifo_write_error_interrupt_mask) ||
			(1'b0 && !tx_fifo_read_error_interrupt_mask) ||
			(receive_data_crc_error && read_data_crc_error_interrupt_mask) ||
			(send_data_crc_error && !write_data_crc_error_interrupt_mask) ||
			(response_timeout && !response_timeout_error_interrupt_mask) ||
			(read_to_error && !read_to_error_interrupt_mask) );

3.11 Respond to

  • The response signal is given after the command with response is completed
  • according to response_type Select the response type
always @(posedge hclk or negedge hrst_n) begin
	if (!hrst_n)
	begin
		response0_ahb <= 32'h0;
		response1_ahb <= 32'h0;
		response2_ahb <= 32'h0;
		response3_ahb <= 32'h0;
	end
	else if (!in_end_cmd_and_resp_tp_3 && in_end_cmd_and_resp_tp_2)
	begin
		response0_ahb <= response0;
		response1_ahb <= response1;
		response2_ahb <= response2;
		response3_ahb <= response3;
	end
end

always @( response_type)begin
    out_response     = 1'b0;
    out_longresponse = 1'b0;
    case (response_type)
        2'b00:
        begin
        out_response     = 1 'b0;
        out_longresponse = 1 'b0;
        end
        2'b01:
        begin
        out_response     = 1'b1;
        out_longresponse = 1'b1;
        end
        2 'b10:
        begin
        out_response     = 1'b1;
        out_longresponse = 1'b0;
        end
        2 'bll:
        begin
        out_response     = 1'b1;
        out_longresponse = 1'b0;
        end
    endcase
end

3.12 Number of pieces block_number

  • Two shots
always @(posedge in_sd_clk or neged  hrst_n) begin
	if (!hrst_n)
	begin
		block_num_tp <= 32'h0;
		block_number <= 32'h0;
	end
	else begin
		block_num_tp <= block_number_ahb;
		block_number <= block_num_tp;
	end
end
原网站

版权声明
本文为[Eight four one one]所创，转载请带上原文链接，感谢
https://yzsam.com/2022/181/202206300638230564.html

边栏推荐

猜你喜欢

随机推荐
