Making wechat robot with go (I) sending messages

I'm studying these days Go, I also wrote several articles about reading Gin Back end project code blog . But programming this , Be sure to practice , Otherwise, it's all talk on paper . So I want to write some code to practice my hand . reasoning , I don't know what I can write to practice . And then it occurred to me , I've used it before Python Be a wechat chat robot （ Blog portal ）, At that time, the code was not put git On , Later, the server was reset, causing the code to disappear . Now I just don't know what project to do to practice , It can be used Go It also realizes a set of wechat chat robots .

Do as you say , Follow the blog you wrote before , Look at the time Python Code for . Switch to Go Optimized and realized .

0. Review the process

According to the previous Python The robot that writes automatically sends messages knows , To send a message, you need three parameters ：company_id、secret、angent_id. How to get these three parameters , Refer to the portal at the beginning of the article . The whole process of sending messages is First, through company_id and secret To call the interface to get token, Re pass token and angent_id To send to the corresponding interface post request , You can put the post The information in the request body is sent to wechat .

1. Project basic configuration

Due to the current demand for Go I'm not particularly proficient in learning the project layout , And for the basic part of the project, if you start from scratch , It takes a lot of time . So I use open source gin The method of secondary development of the project , To realize this robot .

I was studying the other day Gin when , I found an old brother who sealed a Gin The scaffold , It can be used out of the box . Project address : github Portal . Inside, read the configuration file , Write routing , Many operations such as connecting to the database have been realized . Therefore, we can carry out secondary development based on this project , Be a wechat robot .

Putting the project clone After the down , You can take a look at the layout of the whole project first , The main business core codes are placed in internal below . If we want to realize a function of actively sending messages to wechat , So much said is to write a method to send messages , Let the backend call this method .

To develop wechat robot based on this project , First, configure the three parameters . In the project , For various parameters, it is in config.yaml Middle configuration , Because the configuration of these three parameters can be added to this configuration file ：

Then in the code config/autoload Add a new weCaht.go file , Receive the configuration in the configuration file .

package autoload

type WeChatConfig struct {

	AgentId   string `ini:"wechat" yaml:"agent_id"`
	Secret    string `ini:"wechat" yaml:"secret"`
	CompanyId string `ini:"wechat" yaml:"company_id"`
}

var WeChat = WeChatConfig{
    }

also , Add this configuration to the configuration collection of the project . stay config/config.go Add the following code to ：

This operation , You can read the configuration file through code . In other packages , The corresponding values can be accessed in the following ways

config.Config.WeChat.CompanyId //yaml Medium company_id Field

2. Redis encapsulation

Because I want to send messages to wechat , First, get token, And the official introduction of this token The effective duration of is 2 Hours . Before Python In the project , Is directly to the token Written to the file , Read through file . In this project , I want to use it directly redis To store . Because use redis To store it , You can set key Value duration , After this time, it will be cleared automatically , This is much more convenient .

And we are based on this gin-layout In the project , Have been to redis Made a layer of encapsulation , Specific code can be viewed data/redis.go, Mainly by exposing a Rdb The structure of the body , To operate redis

At present, we use redis, Only the corresponding set and get Method . So I'm interested in redis Another layer of encapsulation . Exposure only set,get,del Method .
First of all, will Rdb Change the variable name to lowercase , This means no exposure , Then add the following code to this file

func SetRedis(key string, value string, t int64) bool {

	expire := time.Duration(t) * time.Second
	if err := rdb.Set(ctx, key, value, expire).Err(); err != nil {

		return false
	}
	return true
}

func GetRedis(key string) string {

	result, err := rdb.Get(ctx, key).Result()
	if err != nil {

		return ""
	}
	return result
}

func DelRedis(key string) bool {

	_, err := rdb.Del(ctx, key).Result()
	if err != nil {

		return false
	}
	return true
}

such , Use later redis When , Just call data.SetRedis(xxx) that will do .
Then modify the configuration file , Enable redis, According to the actual redis Configure to write .

3. Message body encapsulation

Finally, send it to wechat server post When asked , The corresponding request body format is as follows ：

{

        "touser": "@all",
        "msgtype": "text",
        "agentid": "xxxxx",
        "text": {
    "content": "xxxx"}
    }

therefore , Next, you can make a package for this structure . stay model It's a bag , Create a new one send_msg.go file

package model

type wcSendcontent struct {

	Content string `json:"content"`
}

type WcSendMsg struct {

	ToUser  string        `json:"touser"`
	MsgType string        `json:"msgtype"`
	AgentId string        `json:"agentid"`
	Text    wcSendcontent `json:"text"`
}

func (t *WcSendMsg) SetMessage(message string) {

	t.Text.Content = message
}

Targeted here message Information , Specifically exposed a method to set .

4. Core code

In setting up redis, After the message body is encapsulated , You can write the core code . Mainly through sending http request , obtain token, Re pass token send out post Request to send a message . We can do it in service Create a new one under the package weChat.go The file of , Build a new one inside SendWeChat Method to send messages .

package service

import (
	"bytes"
	"encoding/json"
	"errors"
	"fmt"

	c "github.com/wannanbigpig/gin-layout/config"
	"github.com/wannanbigpig/gin-layout/data"
	"github.com/wannanbigpig/gin-layout/internal/model"
	log "github.com/wannanbigpig/gin-layout/internal/pkg/logger"
	"github.com/wannanbigpig/gin-layout/pkg/utils"
	"go.uber.org/zap"
)

/** * @description:  Send messages to enterprises and micro enterprises  * @param {string} message  The message content  * @param {string} msgType  Message type  * @return {*} */
func SendWeChat(message string, msgType string) error {

	redis_key := "access_token"
	//  Try from redis Read from token
	accessToken := data.GetRedis(redis_key)
	http := &utils.HttpRequest{
    }
	//  if redis Medium token Has expired , Then re request api obtain token
	if accessToken == "" {

		log.Logger.Info("access token is null, will recall")
		getTokenUrl := fmt.Sprintf("https://qyapi.weixin.qq.com/cgi-bin/gettoken?corpid=%s&corpsecret=%s",
			c.Config.WeChat.CompanyId, c.Config.WeChat.Secret)
		log.Logger.Info("token_url", zap.String("url", getTokenUrl))
		http.Request("GET", getTokenUrl, nil)
		ret := make(map[string]interface{
    })
		if err := http.ParseJson(&ret); err != nil {

			return err
		}
		marshal, _ := json.Marshal(ret)
		log.Logger.Info(string(marshal))
		accessToken = fmt.Sprintf("%v", ret["access_token"])
		//  write in redis  The period of validity 2 Hours
		data.SetRedis(redis_key, accessToken, 7200)
	}
	msg := &model.WcSendMsg{

		ToUser:  "@all",
		MsgType: msgType,
		AgentId: c.Config.WeChat.AgentId,
	}
	msg.SetMessage(message)
	sendMsgUrl := fmt.Sprintf("https://qyapi.weixin.qq.com/cgi-bin/message/send?access_token=%v", accessToken)
	log.Logger.Info("sendMsgUrl = " + string(sendMsgUrl))
	header := map[string]string{
    "Content-Type": "application/json"}
	bytesData, _ := json.Marshal(msg)
	http.Request("POST", sendMsgUrl, bytes.NewReader(bytesData), header)
	log.Logger.Info("bytes data = " + string(bytesData))
	ret := make(map[string]interface{
    })
	err := http.ParseJson(&ret)
	if err != nil {

		return err
	}
	if ret["errcode"].(float64) != 0 {

		errmsg := fmt.Sprintf("%v", ret["errmsg"])
		return errors.New(errmsg)
	}
	return nil
}

As you can see from the code above , The first is through redis To get token, If not, request api obtain token, And write it to redis in , Valid for 2 Hours . Then generate a previously encapsulated message structure , take AgentId and message After filling , By sending post request , The purpose of sending messages has been achieved .

5. Local testing

If you want to verify this method , You can provide an external interface , Call the method of sending messages after accessing this interface .
Can be in controller Create a new one in the directory weChat.go, Implement a get Requested method , Get... In the request msg Parameters , Then call the method of sending enterprise and micro enterprise just implemented .

package wechat

import (
	"github.com/gin-gonic/gin"
	"github.com/wannanbigpig/gin-layout/internal/pkg/error_code"
	log "github.com/wannanbigpig/gin-layout/internal/pkg/logger"
	r "github.com/wannanbigpig/gin-layout/internal/pkg/response"
	"github.com/wannanbigpig/gin-layout/internal/service"
)

func SendMsg(c *gin.Context) {

	msg, ok := c.GetQuery("msg")
	if !ok {

		msg = "please input message"
	}
	log.Logger.Info("send wechat message: " + msg)
	err := service.SendWeChat(msg, "text")
	if err != nil {

		r.Resp().FailCode(c, error_code.FAILURE, err.Error())
		return
	}
	r.Success(c, "success")
}

After writing , Bind this method to the route . stay routers Create a new one under the package weChatRouter.go file

package routers

import (
	"github.com/gin-gonic/gin"
	w "github.com/wannanbigpig/gin-layout/internal/controller/wechat"
)

func setWeChatRouter(r *gin.Engine) {

	// version 1
	v1 := r.Group("wechat")
	{

		v1.GET("/send", w.SendMsg)
	}
}

such , You can use wechat/send Of url To request this interface . Finally, call the method of this binding route , stay routers/router.go Add a line of code to

Then start the project , For example, send a msg=Hello,Golang Request

curl --location --request GET "http://${IP}:${PORT}/wechat/send?msg=Hello,Golang"

Execute this command , You can get the screenshot at the beginning of this article .

Of course , This api The interface is mainly for us to verify , When the actual project runs , It is suggested not to do this . Because this interface has no authentication measures , If it is exposed , Then others can also arbitrarily call this interface to send messages to your enterprise .
